JNZCU00042.4GHz Transceiver

English Advanced features. Software is optional for this mouse! Download the free mouse software (Logitech ® SetPoint ® for Windows ® or Logitech Control Center for Macintosh ® ) at www.logitech.com/downloads to enable side-to-side scrolling and middle button features. Español Funciones avanzadas. El software es opcional para este mouse. Descarga el software de mouse gratuito (Logitech ® SetPoint ® para Windows ® o Logitech Control Center para Macintosh ® ) en www.logitech.com/downloads para activar las funciones de desplazamiento horizontal y de botón central. Français Fonctions avancées. Le logiciel de cette souris est disponible en option. Téléchargez-le gratuitement (Logitech ® SetPoint ® pour Windows ® ou Logitech Control Center pour Macintosh ® ) sur www.logitech.com/downloads pour activer l'utilisation du défilement horizontal et du bouton central. Português Recursos avançados. O software é opcional para este mouse! Faça o download gratuito do software do mouse (Logitech® SetPoint ® para Windows ® ou Logitech Control Center para Macintosh ® ) em www.logitech.com/downloads para ativar a rolagem horizontal e os recursos do botão do meio. English Mac ® OS X Users: When plugging in the Unifying receiver, the Keyboard Assistant dialog box may appear. You can just close this window. Español Usuarios de Mac ® OS X: Al conectar el receptor Unifying, puede aparecer la ventana del cuadro de diálogo Asistente Configuración Teclado. Puedes cerrar esta ventana. Français Utilisateurs Mac ® OS X: lorsque vous branchez le récepteur Unifying, la boîte de dialogue de l'assistant de configuration du clavier peut s'afficher. Vous pouvez simplement fermer cette boîte de dialogue. Português Usuários do Mac ® OS X: Ao conectar o receptor Unifying, poderá ser exibida a janela da caixa de diálogo Assistente de instalação do teclado. Simplesmente feche a janela. ON 1 3 Quick start guide Logitech ® Wireless Mouse M505 1 Quick start guide Logitech ® Wireless Mouse M505 2 AA 5 USB 6 M505 7 4 M505 2 English Congratulations! You are now ready to use your mouse. Español ¡Enhorabuena! Ya puedes empezar a usar el mouse. Français Félicitations ! Vous pouvez à présent utiliser la souris. Português Parabéns! Agora você está preparado para usar seu mouse. Thank you! Merci! ¡Gracias! Obrigado! 3 English Advanced features. Software is optional for this mouse! Download the free mouse software (Logitech ® SetPoint ® for Windows ® or Logitech Control Center for Macintosh ® ) at www.logitech.com/downloads to enable side-to-side scrolling and middle button features. Español Funciones avanzadas. El software es opcional para este mouse. Descarga el software de mouse gratuito (Logitech ® SetPoint ® para Windows ® o Logitech Control Center para Macintosh ® ) en www.logitech.com/downloads para activar las funciones de desplazamiento horizontal y de botón central. Français Fonctions avancées. Le logiciel de cette souris est disponible en option. Téléchargez-le gratuitement (Logitech ® SetPoint ® pour Windows ® ou Logitech Control Center pour Macintosh ® ) sur www.logitech.com/downloads pour activer l'utilisation du défilement horizontal et du bouton central. Português Recursos avançados. O software é opcional para este mouse! Faça o download gratuito do software do mouse (Logitech® SetPoint ® para Windows ® ou Logitech Control Center para Macintosh ® ) em www.logitech.com/downloads para ativar a rolagem horizontal e os recursos do botão do meio. English Mac ® OS X Users: When plugging in the Unifying receiver, the Keyboard Assistant dialog box may appear. You can just close this window. Español Usuarios de Mac ® OS X: Al conectar el receptor Unifying, puede aparecer la ventana del cuadro de diálogo Asistente Configuración Teclado. Puedes cerrar esta ventana. Français Utilisateurs Mac ® OS X: lorsque vous branchez le récepteur Unifying, la boîte de dialogue de l'assistant de configuration du clavier peut s'afficher. Vous pouvez simplement fermer cette boîte de dialogue. Português Usuários do Mac ® OS X: Ao conectar o receptor Unifying, poderá ser exibida a janela da caixa de diálogo Assistente de instalação do teclado. Simplesmente feche a janela. ON 1 3 Quick start guide Logitech ® Wireless Mouse M505 1 Quick start guide Logitech ® Wireless Mouse M505 2 AA 5 USB 6 M505 7 4 M505 2 English Congratulations! You are now ready to use your mouse. Español ¡Enhorabuena! Ya puedes empezar a usar el mouse. Français Félicitations ! Vous pouvez à présent utiliser la souris. Português Parabéns! Agora você está preparado para usar seu mouse. Thank you! Merci! ¡Gracias! Obrigado! 3 English Advanced features. Software is optional for this mouse! Download the free mouse software (Logitech ® SetPoint ® for Windows ® or Logitech Control Center for Macintosh ® ) at www.logitech.com/downloads to enable side-to-side scrolling and middle button features. Español Funciones avanzadas. El software es opcional para este mouse. Descarga el software de mouse gratuito (Logitech ® SetPoint ® para Windows ® o Logitech Control Center para Macintosh ® ) en www.logitech.com/downloads para activar las funciones de desplazamiento horizontal y de botón central. Français Fonctions avancées. Le logiciel de cette souris est disponible en option. Téléchargez-le gratuitement (Logitech ® SetPoint ® pour Windows ® ou Logitech Control Center pour Macintosh ® ) sur www.logitech.com/downloads pour activer l'utilisation du défilement horizontal et du bouton central. Português Recursos avançados. O software é opcional para este mouse! Faça o download gratuito do software do mouse (Logitech® SetPoint ® para Windows ® ou Logitech Control Center para Macintosh ® ) em www.logitech.com/downloads para ativar a rolagem horizontal e os recursos do botão do meio. English Mac ® OS X Users: When plugging in the Unifying receiver, the Keyboard Assistant dialog box may appear. You can just close this window. Español Usuarios de Mac ® OS X: Al conectar el receptor Unifying, puede aparecer la v…

Text truncated - open the document above for the full version.

English Plug it. Forget it. Add to it. You’ve got a Logitech ® Unifying receiver. Now add a compatible wireless keyboard that uses the same receiver as your mouse. It’s easy. Just start the Logitech ® Unifying software* and follow the onscreen instructions. For more information and to download the software, visit www.logitech.com/unifying * PC: Go to Start / All Programs / Logitech / Unifying / Logitech Unifying Software * Mac: Go to Applications / Utilities / Logitech Unifying Software Español Conéctalo. Olvídate de él. Agrega más. Tienes un receptor Logitech ® Unifying. Agrega ahora un teclado inalámbrico compatible que use el mismo receptor que el mouse. Es fácil. Basta iniciar el software Logitech ® Unifying* y seguir las instrucciones en pantalla. Para obtener más información y para descargar el software, visita www.logitech.com/unifying * PC: selecciona Inicio / Todos los programas / Logitech / Unifying / Software Logitech Unifying * MAC: selecciona Aplicaciones / Utilidades / Software Logitech Unifying Français Branchez. Oubliez. Ajoutez. Vous disposez d'un récepteur Logitech ® Unifying. Ajoutez maintenant un clavier sans fil compatible qui utilise le même récepteur que votre souris. C'est facile! Démarrez tout simplement le logiciel Logitech ® Unifying* et suivez les instructions à l’écran. Pour en savoir plus et pour télécharger le logiciel, rendez-vous sur www.logitech.com/unifying. * PC: Cliquez sur Démarrer / Tous les programmes / Logitech / Unifying / Logitech Unifying Software * MAC: Cliquez sur Applications / Utilitaires / Logitech Unifying Software Português Conecte-o. Esqueça-o. Adicione-o. Você possui um receptor Logitech ® Unifying. Agora adicione um teclado sem fio compatível que usa o mesmo receptor usado pelo mouse. É fácil. Basta iniciar o software* Logitech ® Unifying e seguir as instruções na tela. Para obter mais informações e para fazer o download do software, visite www.logitech.com/unifying * PC: vá para Iniciar / Todos os programas / Logitech / Unifying / Logitech Unifying Software * MAC: vá para Aplicativos / Utilitários / Logitech Unifying Software English No pointer movement or erratic movement 1. Power on? 2. Check Unifying receiver; change ports. 3. Check battery. 4. Try a different surface. 5. Remove metallic objects between mouse and Unifying receiver 6. If the Unifying receiver is plugged into a USB hub, try plugging it directly into your computer. 7. Move the Unifying receiver to a USB port closer to the mouse, or go to www.logitech.com/usbextender for a USB extension stand that will allow the Unifying receiver to be placed closer to the mouse. Español El puntero no se mueve o realiza movimientos erráticos 1. ¿Está encendido? 2. Comprueba el receptor Unifying; cambia de puerto. 3. Comprueba la pila. 4. Prueba el mouse en otra superficie. 5. Retira los objetos metálicos situados entre el mouse y el receptor Unifying. 6. Si el receptor Unifying está conectado a un concentrador USB, conéctelo directamente al ordenador. 7. Lleva el receptor Unifying a un puerto USB más cercano al mouse, o visita www.logitech.com/usbextender para obtener una base de extensión USB que te permitirá colocar el receptor Unifying más cerca del mouse. Français Pointeur immobile ou incontrôlable 1. Souris activée? 2. Vérifiez le récepteur Unifying; changez de port. 3. Vérifiez les piles. 4. Essayez une autre surface. 5. Déplacez tout objet métallique se trouvant entre la souris et le récepteur Unifying. 6. Si le récepteur Unifying est branché dans un hub USB, branchez-le plutôt directement sur l'ordinateur. 7. Branchez le récepteur Unifying dans un port USB plus proche de la souris ou consultez le site www.logitech.com/usbextender pour obtenir un support d'extension USB qui permettra de rapprocher le récepteur Unifying de la souris. Português Nenhum movimento ou movimento aleatório do ponteiro 1. Está ligado? 2. Verifique o receptor Unifying, troque de portas. 3. Verifique a bateria. 4. Experimente uma superfície diferente. 5. Remova objetos metálicos entre o mouse e o receptor Unifying. 6. Remova quaisquer objectos metálicos colocados entre o rato e o receptor Unifying. 7. Mova o receptor Unifying para uma porta USB mais próxima do mouse, ou visite www.logitech.com/usbextender para obter um suporte de extensão USB que permitirá que o receptor Unifying seja colocado mais perto do mouse. USB 2 3 4 M505 1 3 4 1 2 5 M505 6 7 8 English 1. Left and right mouse buttons. 2. Battery LED flashes red when battery power is low. 3. Scroll wheel. 4. Press the wheel down for middle button (function can vary by software application). 5. Side-to-side scrolling (function can vary by software application). This function doesn’t work in Linux. 6. On/Off slider switch. 7. Battery door release slider. 8. Unifying receiver storage. Español 1. Botones izquierdo y derecho. 2. El diodo de estado de pila emite destellos rojos cuando la pila se está agotando. 3. Botón rueda. 4. Pulsa el botón rueda para usarlo como botón central (la función puede variar según la aplicación de software). 5. Desplazamiento horizontal (la función puede variar según la aplicación de software). Esta función no está disponible en Linux. 6. Conmutador de encendido/apagado. 7. Botón de compartimento de pila. 8. Almacenamiento de receptor Unifying. Français 1. Boutons droit et gauche de la souris. 2. Le témoin lumineux clignote en rouge lorsque le niveau de charge des piles est faible. 3. Roulette de défilement. 4. Appuyez sur la roulette pour l'utiliser comme bouton central (la fonction varie suivant l'application logicielle). 5. Défilement horizontal (la fonction varie suivant l'application logicielle). Cette fonction n'est pas disponible sur les systèmes Linux. 6. Commutateur Marche/Arrêt. 7. Bouton d'ouverture du compartiment des piles. 8. Compartiment de stockage du récepteur Unifying. Português 1. Botões esquerdo e direito do mouse. 2. A luz vermelha do LED de bateria pisca quando a energia está baixa. 3. Roda de rolagem. 4…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

FCC Label on manual

Mª Gema Briseño Pascual De: [email protected] Enviado el: martes, 11 de marzo de 2008 12:59 Para: Mª Gema Briseño Pascual Asunto: Fw: FCC ID on manual Page 1 of 2 10/04/2008 Hello Gema, Here you are. Thank you Kind regards Pascal Bornel ----- Forwarded by Pascal Bornel/CH/EU/LOGITECH on 03/11/2008 12:30 PM ----- Hi Pascal, Below info from FCC telling us "device is small and warrants placing the ID in the user manual." Thank you, Best Regards, Bharat Shah E: [email protected] Tel : (510)-713-4777 Fax : (510)-713-5294 efax :(419)-828-4405 ----- Forwarded by Bharat Shah/CA/US/LOGITECH on 03/10/2008 08:08 AM ----- I agree this device is small and warrants placing the ID in the user manual. Raymond LaForge Chief, (FCC-OET) Auditing and Compliance Branch (301) 362-3041 03/10/2008 04:10 PM Bharat Shah/CA/US/LOGITECH To Pascal Bornel/CH/EU/LOGITECH@LOGITECH cc Philippe Vulliens/CH/EU/LOGITECH@LOGITECH Subject Fw: FCC ID on manual 03/10/2008 04:47 AM "Raymond Laforge" <[email protected]> To <[email protected]> cc Subject RE: FCC ID on manual -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Friday, March 07, 2008 2:26 PM To: Rich Fabina; Raymond Laforge Cc: [email protected] Subject: Fw: FCC ID on manual Hi Rich & Raymond, How are you ? We are in process of designing Receiver. The receiver is too small in size, larger place is 2mm, as you see from below attached drawing. (See attached file: C-UBD58 outline drawing .JPG)(See attached file: P1010012.JPG)(See attached file: P1010014.JPG)(See attached file: P1010015.JPG) Laser etching on the metallic part could be subject to rubbing and could be hardly legible as well due to the bad contrast. Unless we remove the Logitech brand there is no other space on the plastic part. Due to described problem above, it has been decided to put FCC ID in the manual. I hope that it is acceptable to FCC, correct ? Please advise otherwise. Thank you very much for your help. Best Regards, Bharat Shah E: [email protected] Tel : (510)-713-4777 Fax : (510)-713-5294 efax :(419)-828-4405 Page 2 of 2 10/04/2008

Page 1 CONSTRUCTION PHOTOS OF EUT EUT with JEM recharge USB cable EUT with HANK recharge USB cable Page 2 EUT with CAN4311881042453K antenna Page 3 Page 4 Page 5 EUT with EBMGH8A245FM antenna Page 6 Page 7 Page 8 EUT with AT8010-E2R9HAA_ antenna Page 9 Page 10 JEM recharge USB cable Page 11 Hank recharge USB cable

Report No.: RF981207H04 1 Report Format Version 3.0.0 FCC TEST REPORT REPORT NO.: RF981207H04 MODEL NO.: C-U0004 RECEIVED: Dec. 07, 2009 TESTED: Dec. 08 to 10, 2009 ISSUED: Dec. 15, 2009 APPLICANT: LOGITECH FAR EAST LTD. ADDRESS: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch TEST LOCATION: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 29 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF981207H04 2 Report Format Version 3.0.0 Table of Contents 1 CERTIFICATION.............................................................................................3 2 SUMMARY OF TEST RESULTS.....................................................................4 2.1 MEASUREMENT UNCERTAINTY..................................................................4 3 GENERAL INFORMATION.............................................................................5 3.1 GENERAL DESCRIPTION OF EUT................................................................5 3.2 DESCRIPTION OF TEST MODES..................................................................6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.................................6 3.4 DESCRIPTION OF SUPPORT UNITS............................................................7 3.5 CONFIGURATION OF SYSTEM UNDER TEST.............................................8 4 TEST PROCEDURES AND RESULTS...........................................................9 4.1 CONDUCTED EMISSION MEASUREMENT..................................................9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................9 4.1.2 TEST INSTRUMENTS....................................................................................9 4.1.3 TEST PROCEDURES...................................................................................10 4.1.4 TEST SETUP................................................................................................10 4.1.5 EUT OPERATING CONDITIONS...................................................................11 4.1.6 TEST RESULTS............................................................................................12 4.2 RADIATED EMISSION MEASUREMENT.....................................................14 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................14 4.2.2 TEST INSTRUMENTS..................................................................................16 4.2.3 TEST PROCEDURES...................................................................................17 4.2.4 DEVIATION FROM TEST STANDARD.........................................................17 4.2.5 TEST SETUP................................................................................................18 4.2.6 EUT OPERATING CONDITIONS..................................................................18 4.2.7 TEST RESULTS............................................................................................19 4.3 CONDUCTED - OUT BAND MEASUREMENT.............................................26 4.3.1 LIMITS OF CONDUCTED - OUT BAND MEASUREMENT..........................26 4.3.2 TEST INSTRUMENTS..................................................................................26 4.3.3 TEST PROCEDURE.....................................................................................26 4.3.4 DEVIATION FROM TEST STANDARD.........................................................26 4.3.5 EUT OPERATING CONDITION....................................................................26 4.3.6 TEST RESULTS............................................................................................27 5 INFORMATION ON THE TESTING LABORATORIES..................................28 6 APPENDIX-A- MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB..........................................................29 Report No.: RF981207H04 3 Report Format Version 3.0.0 1 CERTIFICATION PRODUCT : 2.4GHz Transceiver BRAND NAME : Logitech MODEL NO. : C-U0004 TESTED : Dec. 08 to 10, 2009 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : LOGITECH FAR EAST LTD. STANDARDS : 47 CFR Part 15, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment (Model: C-U0004) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Dec. 15, 2009 ( Claire Kuan, Specialist ) TECHNICAL ACCEPTANCE : , DATE: Dec. 15, 2009 ( Hank Chung, Deputy Manager ) APPROVED BY : , DATE: Dec. 15, 2009 (May Chen, Deputy Manager ) Report No.: RF981207H04 4 Report Format Version 3.0.0 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type Result Remark 15.207 Conducted Emission Test PASS Minimum passing margin is -12.69dB at 0.216MHz 15.249 Radiated Emission Test PASS Minimum passing margin is -4.8dB at 625.00MHz 15.249 Band Edge Measurement PASS Meet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
