JNZCU00072.4GHz Transceiver

Mode name:M-R0009 & C-U0007

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: JNZCU0007 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to DA 04-1705 of the Commission’s Rules, we request short-term confidential treatment for the following information until Mar.31, 2010 of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External Photos Internal Photos Test Setup Photos User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards

POWER OF ATTORNEY To whom it may concern: We, the undersigned LOGITECH FAR EAST LTD. hereby authorize Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15B&C approval and any communication needed with the national authority. Any and all acts carried out by Bureau Veritas Consumer Product Service (Hong Kong) Limited, Taoyuan Branch on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Product name: 2.4GHz Transceiver Brand name: Logitech Model name: C-U0007 Sincerely yours, Signature:

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

Mª Gema Briseño Pascual De: [email protected] Enviado el: martes, 11 de marzo de 2008 12:59 Para: Mª Gema Briseño Pascual Asunto: Fw: FCC ID on manual Page 1 of 2 10/04/2008 Hello Gema, Here you are. Thank you Kind regards Pascal Bornel ----- Forwarded by Pascal Bornel/CH/EU/LOGITECH on 03/11/2008 12:30 PM ----- Hi Pascal, Below info from FCC telling us "device is small and warrants placing the ID in the user manual." Thank you, Best Regards, Bharat Shah E: [email protected] Tel : (510)-713-4777 Fax : (510)-713-5294 efax :(419)-828-4405 ----- Forwarded by Bharat Shah/CA/US/LOGITECH on 03/10/2008 08:08 AM ----- I agree this device is small and warrants placing the ID in the user manual. Raymond LaForge Chief, (FCC-OET) Auditing and Compliance Branch (301) 362-3041 03/10/2008 04:10 PM Bharat Shah/CA/US/LOGITECH To Pascal Bornel/CH/EU/LOGITECH@LOGITECH cc Philippe Vulliens/CH/EU/LOGITECH@LOGITECH Subject Fw: FCC ID on manual 03/10/2008 04:47 AM "Raymond Laforge" <[email protected]> To <[email protected]> cc Subject RE: FCC ID on manual -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Friday, March 07, 2008 2:26 PM To: Rich Fabina; Raymond Laforge Cc: [email protected] Subject: Fw: FCC ID on manual Hi Rich & Raymond, How are you ? We are in process of designing Receiver. The receiver is too small in size, larger place is 2mm, as you see from below attached drawing. (See attached file: C-UBD58 outline drawing .JPG)(See attached file: P1010012.JPG)(See attached file: P1010014.JPG)(See attached file: P1010015.JPG) Laser etching on the metallic part could be subject to rubbing and could be hardly legible as well due to the bad contrast. Unless we remove the Logitech brand there is no other space on the plastic part. Due to described problem above, it has been decided to put FCC ID in the manual. I hope that it is acceptable to FCC, correct ? Please advise otherwise. Thank you very much for your help. Best Regards, Bharat Shah E: [email protected] Tel : (510)-713-4777 Fax : (510)-713-5294 efax :(419)-828-4405 Page 2 of 2 10/04/2008

Page 4 Page 5

Report No.: RF981222H02 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF981222H02 MODEL NO.: C-U0007 RECEIVED: Dec. 22, 2009 TESTED: Dec. 24 to 28, 2009 ISSUED: Dec. 30, 2009 APPLICANT: LOGITECH FAR EAST LTD. ADDRESS: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch TEST LOCATION: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 29 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF981222H02 2 Report Format Version 3.0.1 Table of Contents 1 CERTIFICATION.............................................................................................3 2 SUMMARY OF TEST RESULTS.....................................................................4 2.1 MEASUREMENT UNCERTAINTY......................................................................4 3 GENERAL INFORMATION.............................................................................5 3.1 GENERAL DESCRIPTION OF EUT................................................................5 3.2 DESCRIPTION OF TEST MODES..................................................................6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.................................6 3.4 DESCRIPTION OF SUPPORT UNITS............................................................7 3.5 CONFIGURATION OF SYSTEM UNDER TEST.............................................8 4 TEST PROCEDURES AND RESULTS...........................................................9 4.1 CONDUCTED EMISSION MEASUREMENT..................................................9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................9 4.1.2 TEST INSTRUMENTS....................................................................................9 4.1.3 TEST PROCEDURES...................................................................................10 4.1.4 TEST SETUP................................................................................................10 4.1.5 EUT OPERATING CONDITIONS...................................................................11 4.1.6 TEST RESULTS............................................................................................12 4.2 RADIATED EMISSION MEASUREMENT.....................................................14 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...................................14 4.2.2 TEST INSTRUMENTS..................................................................................15 4.2.3 TEST PROCEDURES...................................................................................16 4.2.4 DEVIATION FROM TEST STANDARD.........................................................16 4.2.5 TEST SETUP................................................................................................17 4.2.6 EUT OPERATING CONDITIONS..................................................................17 4.2.7 TEST RESULTS............................................................................................18 4.3 CONDUCTED - OUT BAND MEASUREMENT.............................................25 4.3.1 LIMITS OF CONDUCTED - OUT BAND MEASUREMENT..........................25 4.3.2 TEST INSTRUMENTS..................................................................................25 4.3.3 TEST PROCEDURE.....................................................................................25 4.3.4 DEVIATION FROM TEST STANDARD.........................................................25 4.3.5 EUT OPERATING CONDITION....................................................................25 4.3.6 TEST RESULTS............................................................................................26 5 INFORMATION ON THE TESTING LABORATORIES..................................28 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB........................................................29 Report No.: RF981222H02 3 Report Format Version 3.0.1 1 CERTIFICATION PRODUCT : 2.4GHz Transceiver BRAND NAME : Logitech MODEL NO. : C-U0007 TESTED : Dec. 24 to 28, 2009 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : LOGITECH FAR EAST LTD. STANDARDS : 47 CFR Part 15, Subpart C (Section 15.249), ANSI C63.4-2003 The above equipment (Model: C-U0007) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Dec. 30, 2009 ( Sunny Wen, Specialist ) TECHNICAL ACCEPTANCE : , DATE: Dec. 30, 2009 ( Hank Chung, Deputy Manager ) APPROVED BY : , DATE: Dec. 30, 2009 ( May Chen, Deputy Manager ) Report No.: RF981222H02 4 Report Format Version 3.0.1 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type Result Remark 15.207 Conducted Emission Test PASS Minimum passing margin is -10.71dB at 16.535MHz 15.249 Radiated Emission Test PASS Minimum passing margin is -4.6dB at 2400.00MHz 15.249 Conducted - Out Band Measurement PASS Meet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a cov…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
