JNZCU00132.4GHz USB Transceiver

Saf ety , R egulator y, and Warranty English Important ergonomic information. Long periods of repetitive motion using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulders, neck, or back, see a qualified health professional. For more information, please read the Comfort Guidelines located on the Logitech® web site at http://www.logitech.com/comfort, or on the Logitech® Software CD. Do not immerse product in any liquid or expose it to heat or moisture. There are no serviceable parts. Class 1 LED products. The product contains Class 1 LED. Operating temperature between 5°C (41°F) to 40°C (104° F). Class 1 laser products. International standards and safety. Logitech Class 1 laser products comply with International Standard IEC/EN 60825-1: 2007, Class 1 Laser Product, and also comply with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007: 1) Emission of one parallel beam or two parallel beams (for devices that can track on glass) of infrared user- invisible light; 2) Maximum power of 716 microwatts CW, wavelength range 832 — 865 nanometers; 3) Operating temperature between 5°C (41°F) and 40°C (104° F). CAUTION! There is a risk of radiation exposure if product is misused or disassembled. Class 1M laser products. International standards and safety. Logitech Class 1M laser products comply with International Standard IEC/EN 60825-1: 2007, Class 1M Laser Product. Logitech Class 1M laser products also comply with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007, as follows: 1) Emission of diverging beam of minimum +/-2° of infrared user-invisible light; 2) Maximum power of 1.4 milliwatts CW, wavelength range 832 — 865 nanometers; 3) Operating temperature between 5°C (41°F) and 40°C (104° F). CAUTION! Invisible Laser Radiation. There is a risk of radiation exposure if product is misused or disassembled. Viewing the laser output with certain optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of 100mm may pose an eye hazard. Additional compliance information. To obtain additional information about Class 1 LED, Class 1 lasers, Class 1M lasers, or other compliance-related matters, go to http://www.logitech.com/compliance, or call Logitech customer support. (Customer support telephone numbers are listed in the product documentation.) Battery warning! Risk of explosion or personal injury if batteries are replaced by incorrect type, mutilated, or exposed to conducting materials, liquid, fire, or heat (above 54° C or 130° F). Do not use or recharge damaged rechargeable batteries. Do not mix battery types. Dispose of spent or damaged batteries according to manufacturer instructions and local laws. Power supply warning! Caution electric shock/fire hazard! For indoor use only. Do not expose to moisture, liquid, or heat. Do not use any other power supply with your Logitech product. Device pairing limitations. Some Unifying devices may be limited in the number of times they can be paired (connected) to a Unifying receiver. Although the number of pairings possible may vary, the minimum number of available pairings is 45. UL statement. Your product is UL approved. Use only with UL listed ITE computers. FCC – United States and Canada This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Compliance Information Statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the receiving antenna. 2) Increase the separation between the equipment and receiver. 3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4) Consult the dealer or an experienced radio/TV technician for help. Modifications to this product not authorized by Logitech could void your right to use or operate this product by the FCC Where shielded interface cables or accessories have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canada (IC) Statements: Corded products: This Class B digital apparatus complies with Canadian ICES-003. Cordless (Radio Transmitter) products: Section A. RSS-310 (27 MHz transmitters and receivers): This Category II radio communication device complies with Industry Canada Standard RSS-310. Section B. RSS-210 (2.4 GHz transmitters or transceivers): This Category I radio communication device complies with RSS-210 of Industry Canada. Logitech hardware product limited warranty Logitech warrants to the original purchaser that your Logitech hardware product shall be free from defects in material and workmanship for the period of time, identified on your product packag…

Text truncated - open the document above for the full version.

Logitech® Wireless Mouse M545 Setup Guide On AA 1 3 2 English Advanced features: Software is optional for this mouse! Download the free mouse software at www.logitech.com/support/m545 to customize button functions, adjust speed of tracking and scrolling. Note: If other USB 3.0 devices are in use, please try to plug Pico receiver into other USB port at a distance. © 2013 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. © 620-003584.002 www.logitech.com Logitech® Wireless Mouse M545 Setup Guide USB English Help with setup: Mouse not working đƫIs the mouse powered on? đƫIs the Pico receiver securely plugged into a computer USB port? Try changing USB ports. đƫIf the Pico receiver is plugged into a USB hub, try plugging it directly into a USB port on your computer. đƫTry moving the Pico receiver to a USB port closer to the mouse. đƫRemove metallic objects between the mouse and the Pico receiver. đƫCheck the orientation of the battery inside the mouse. Replace the battery if necessary. The mouse uses one AA alkaline battery. đƫTry reconnecting the mouse and Pico receiver using the Logitech Unifying software. (Refer to the Unifying section in this guide.) đƫIf other USB 3.0 devices are in use, try plugging Pico receiver into other USB port at a distance. English The Logitech® Unifying receiver Plug it. Forget it. Add to it. Your new Logitech product ships with a Logitech® Unifying receiver. Did you know you can add a compatible Logitech wireless device that uses the same receiver as your current Logitech Unifying product? Are you Unifying-ready? If you have a Logitech wireless device that’s Unifying-ready, you can pair it with additional Unifying devices. Just look for the orange Unifying logo on the new device or its packaging. Build your ideal combo. Add something. Replace something. It’s easy, and you’ll use only one USB port for up to six devices. Getting started is easy If you’re ready to pair your device(s) via Unifying, here’s what you need to do: 1. Make sure your Unifying receiver is plugged in. 2. If you haven’t already, download the Logitech® Unifying software from www.logitech.com/unifying. 3. Start the Unifying software* and follow the onscreen instructions to pair the new wireless device with your existing Unifying receiver. *Go to Start / All Programs / Logitech / Unifying / Logitech Unifying Software 1. 2. ® 3. www.logitech.com/support/m545 English Features 1. Left and right mouse buttons 2. Scroll wheel 3. Battery LED—Flashes green when mouse is powered on, and it flashes red when the battery power is low 4. Middle button—The function of this button depends on your operating system and the application being used. For example, if you are browsing the Internet in Windows and click on a link using the Middle button, typically the link opens in a new tab. 5. Tilt button đƫWindow 7 and Windows 8 without software: Tilt left/right for backward/forward. đƫWindows 8 with software installed: Tilt left to show the Application Switcher; Tilt right to show the Charm Bar. 6. Side button đƫWindows 7: Press to toggle between minimizing all applications (Show Desktop) and restoring all applications. đƫWindows 8: Press to switch to Desktop mode in Start Screen or applications. 7. Side button đƫWindows 8: Press to switch between the Start Screen and the last open application. đƫWindows 7: Press to open the Start Menu. 8. On/Off slider switch 9. Pico receiver storage—When the mouse is not in use, you can store the Pico receiver inside the mouse. 10. Battery door 1. 2. 3. 4. 5. 6. 7. “ “ 8. 9. 10. AA 3 1 4 5 8 9 10 2 6 7

Report No.: 130709E02 1 of 3 CONSTRUCTION PHOTOS OF EUT

(Fig.1) FCC ID: JNZCU0013 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 130709E02 2 of 3 Report No.: 130709E02 3 of 3

Report No.: RF130709E02 1 of 27 Report Format Version 5.0.1 FCC TEST REPORT REPORT NO.: RF130709E02 MODEL NO.: C-U0013 FCC ID: JNZCU0013 RECEIVED: July 09, 2013 TESTED: July 09 to 11, 2013 ISSUED: July 18, 2013 APPLICANT: LOGITECH FAR EAST LTD. ADDRESS: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF130709E02 2 of 27 Report Format Version 5.0.1 Table of Contents RELEASE CONTROL RECORD................................................................................. 3 1 CERTIFICATION .............................................................................................. 4 2 SUMMARY OF TEST RESULTS ...................................................................... 5 2.1 MEASUREMENT UNCERTAINTY ........................................................................ 5 3 GENERAL INFORMATION ............................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT ................................................................. 6 3.2 DESCRIPTION OF TEST MODES ................................................................... 7 3.3 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ................... 7 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................. 9 3.5 DESCRIPTION OF SUPPORT UNITS ........................................................... 10 3.6 CONFIGURATION OF SYSTEM UNDER TEST ............................................ 10 4 TEST PROCEDURES AND RESULTS............................................................11 4.1 CONDUCTED EMISSION MEASUREMENT ..................................................11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................11 4.1.2 TEST INSTRUMENTS ....................................................................................11 4.1.3 TEST PROCEDURES .................................................................................... 12 4.1.4 DEVIATION FROM TEST STANDARD .......................................................... 12 4.1.5 TEST SETUP ................................................................................................. 13 4.1.6 EUT OPERATING CONDITIONS ................................................................... 13 4.1.7 TEST RESULTS ............................................................................................. 14 4.2 RADIATED EMISSION AND BAND EDGE MEASUREMENT ........................ 16 4.2.1 LIMITS OF RADIATED EMISSION AND BAND EDGE MEASUREMENT...... 16 4.2.2 TEST INSTRUMENTS ................................................................................... 17 4.2.3 TEST PROCEDURES .................................................................................... 18 4.2.4 DEVIATION FROM TEST STANDARD .......................................................... 18 4.2.5 TEST SETUP ................................................................................................. 19 4.2.6 EUT OPERATING CONDITIONS ................................................................... 19 4.2.7 TEST RESULTS ............................................................................................. 20 5 PHOTOGRAPHS OF THE TEST CONFIGURATION ..................................... 25 6 INFORMATION ON THE TESTING LABORATORIES ................................... 26 7 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB .......................................................... 27 Report No.: RF130709E02 3 of 27 Report Format Version 5.0.1 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF130709E02 Original release July 18, 2013 Report No.: RF130709E02 4 of 27 Report Format Version 5.0.1 1 CERTIFICATION PRODUCT : 2.4GHz USB Transceiver BRAND NAME : Logitech MODEL NO. : C-U0013 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : LOGITECH FAR EAST LTD. TESTED : July 09 to 11, 2013 STANDARDS : FCC Part 15, Subpart C (Section 15.249) ANSI C63.10-2009 The above equipment (Model: C-U0013) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. …

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST 3
