Getting started with Première utilisation Logitech® Touch Lapdesk N600 1 2 3 English Open the touchpad tray fully to turn on the lapdesk. You are now ready to browse! Español Abre completamente la bandeja del touchpad para encender el soporte para las rodillas. Ya puedes empezar a explorar. Français Ouvrez entièrement le plateau du touchpad pour activer le lapdesk. Vous pouvez immédiatement commencer à surfer! Português Abra a bandeja do touchpad completamente para ligar o lapdesk. Você agora já pode navegar! Getting started with Première utilisation Logitech® Touch Lapdesk N600 English Touchpad gestures Point, scroll, swipe 1. Point and slide one finger anywhere on the touchpad to move the on-screen pointer. 2. Scroll with two fingers, up or down. 3. Swipe left with three fingers to go back (page or picture); swipe right to go forward. Left and right click 4. Press for left button mouse click.* 5. Press for right button mouse click. *You can also tap the touchpad surface to perform a left button mouse click. Español Gestos de touchpad Apuntar, desplazar, pasar 1. Apunta y desliza un dedo en cualquier parte del touchpad para mover el puntero en pantalla. 2. Desplazamiento con dos dedos, arriba o abajo. 3. Pasa tres dedos hacia la izquierda para volver atrás (página o imagen); pasa hacia la derecha para avanzar. Click izquierdo y derecho 4. Pulsa para realizar un click con el botón izquierdo del mouse.* 5. Pulsa para realizar un click con el botón derecho del mouse. * También puedes tocar la superficie del touchpad para realizar un click con el botón izquierdo. Français Mouvements du touchpad Pointage, défilement, glissement 1. Pointez et glissez un doigt à n’importe quel endroit du touchpad pour déplacer le pointeur à l’écran. 2. Défilez vers le haut ou vers le bas en utilisant deux doigts. 3. Glissez vers la gauche avec trois doigts pour revenir en arrière (page ou image précédente); glissez vers la droite pour passer à l’élément suivant. Clic gauche et clic droit 4. Appuyez pour reproduire l’action du clic sur le bouton gauche de la souris.* 5. Appuyez pour reproduire l’action du clic sur le bouton droit de la souris. * Vous pouvez aussi tapoter la surface du touchpad pour reproduire l’action du clic gauche sur la souris. Português Gestos do touchpad Aponte, passe o dedo, efetue rolagem 1. Aponte e deslize o dedo em qualquer parte do touchpad para mover o ponteiro na tela. 2. Efetue rolagem com dois dedos, para cima e para baixo. 3. Deslize três dedos para a esquerda para voltar (página ou imagem); deslize-os para a direita para avançar. Clique esquerdo e direito 4. Pressione para a função de clique do botão esquerdo do mouse.* 5. Pressione para a função de clique do botão direito do mouse.* * Você também pode bater de leve na superfície do touchpad para executar um clique do botão esquerdo do mouse. 1 45 23 English Features 1. On/Off slider. To save battery power, turn off the lapdesk when you’re not using it. 2. Volume up 3. Volume down 4. Mute 5. Internet home Español Funciones 1. Botón de encendido/apagado. Para ahorrar energía de las baterías, apaga el soporte para las rodillas cuando no lo uses. 2. Subir volumen 3. Bajar volumen 4. Silencio 5. Inicio de Internet Français Fonctionnalités 1. Curseur de marche/arrêt. Pour économiser la batterie, éteignez le lapdesk lorsque vous ne l’utilisez pas. 2. Volume + 3. Volume - 4. Sourdine 5. Accueil Internet Português Recursos 1. Controle deslizante para ligar/ desligar. Para economizar energia, desligue o lapdesk quando não estiver em uso. 2. Mais volume 3. Menos volume 4. Mute 5. Internet Home English Plug it. Forget it. Add to it. Your new Logitech product ships with a Logitech® Unifying receiver. Did you know you can add a compatible Logitech wireless device that uses the same receiver as your current Logitech Unifying product? Are you Unifying-ready? If you have a Logitech wireless device that’s Unifying- ready, you can pair it with additional Unifying devices. Just look for the orange Unifying logo on the new device or its packaging. Build your ideal combo. Add something. Replace something. It’s easy, and you’ll use only one USB port for up to six devices. Getting started is easy If you’re ready to pair your device(s) via Unifying, here’s what you need to do: 1. Make sure your Unifying receiver is plugged in. 2. If you haven’t already, download the Logitech® Unifying software from www.logitech.com/unifying. 3. Start the Unifying software* and follow the onscreen instructions to pair the new wireless device with your existing Unifying receiver. *Go to Start / All Programs / Logitech / Unifying / Logitech Unifying Software Español Conéctalo. Olvídate de él. Agrega más. Tu nuevo producto Logitech se entrega con un receptor Logitech® Unifying. ¿Sabías que puedes agregar un dispositivo inalámbrico Logitech compatible que utiliza el mismo receptor que tu producto Logitech Unifying actual? ¿Estás listo para Unifying? Si tienes un dispositivo inalámbrico compatible con Unifying, puedes emparejarlo con otros dispositivos Unifying. Sólo debes buscar el logo naranja de Unifying en el nuevo dispositivo o en su embalaje. Crea la combinación ideal. Agrega algo. Sustituye algo. Es sencillo: sólo utilizarás un puerto USB para hasta seis dispositivos. Es muy sencillo Si estás listo para emparejar los dispositivos mediante Unifying, sigue estos pasos: 1. Comprueba que el receptor Unifying esté conectado. 2. Si no lo has hecho aún, descarga el software Logitech® Unifying desde www.logitech.com/ unifying. 3. Inicia el software* Unifying y sigue las instrucciones en pantalla para emparejar el nuevo dispositivo inalámbrico con el receptor Unifying existente. *Ve a Inicio / Todos los programas / Logitech / Unifying / Software Logitech Unifying Français Branchez-le. Oubliez-le. Ajoutez d’autres périphériques. Votre nouveau produit Logitech est livré avec un récepteur Logitech® Unifying. Saviez-vous qu’il est possible d’ajouter un dispositif sans fil Logitec…

Text truncated - open the document above for the full version.

Saf ety , R egulator y, and Warranty English Important ergonomic information. Long periods of repetitive motion using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulders, neck, or back, see a qualified health professional. For more information, please read the Comfort Guidelines located on the Logitech® web site at http://www.logitech.com/comfort, or on the Logitech® Software CD. Do not immerse product in any liquid or expose it to heat or moisture. There are no serviceable parts. Class 1 LED products. The product contains Class 1 LED. Operating temperature between 5°C (41°F) to 40°C (104° F). Class 1 laser products. International standards and safety. Logitech Class 1 laser products comply with International Standard IEC/EN 60825-1: 2007, Class 1 Laser Product, and also comply with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007: 1) Emission of one parallel beam or two parallel beams (for devices that can track on glass) of infrared user- invisible light; 2) Maximum power of 716 microwatts CW, wavelength range 832 — 865 nanometers; 3) Operating temperature between 5°C (41°F) and 40°C (104° F). CAUTION! There is a risk of radiation exposure if product is misused or disassembled. Class 1M laser products. International standards and safety. Logitech Class 1M laser products comply with International Standard IEC/EN 60825-1: 2007, Class 1M Laser Product. Logitech Class 1M laser products also comply with 21 CFR 1040.10 and 1040.11, except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007, as follows: 1) Emission of diverging beam of minimum +/-2° of infrared user-invisible light; 2) Maximum power of 1.4 milliwatts CW, wavelength range 832 — 865 nanometers; 3) Operating temperature between 5°C (41°F) and 40°C (104° F). CAUTION! Invisible Laser Radiation. There is a risk of radiation exposure if product is misused or disassembled. Viewing the laser output with certain optical instruments (for example, eye loupes, magnifiers, and microscopes) within a distance of 100mm may pose an eye hazard. Additional compliance information. To obtain additional information about Class 1 LED, Class 1 lasers, Class 1M lasers, or other compliance-related matters, go to http://www.logitech.com/compliance, or call Logitech customer support. (Customer support telephone numbers are listed in the product documentation.) Battery warning! Risk of explosion or personal injury if batteries are replaced by incorrect type, mutilated, or exposed to conducting materials, liquid, fire, or heat (above 54° C or 130° F). Do not use or recharge damaged rechargeable batteries. Do not mix battery types. Dispose of spent or damaged batteries according to manufacturer instructions and local laws. Power supply warning! Caution electric shock/fire hazard! For indoor use only. Do not expose to moisture, liquid, or heat. Do not use any other power supply with your Logitech product. Device pairing limitations. Some Unifying devices may be limited in the number of times they can be paired (connected) to a Unifying receiver. Although the number of pairings possible may vary, the minimum number of available pairings is 45. UL statement. Your product is UL approved. Use only with UL listed ITE computers. FCC – United States and Canada This hardware device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Compliance Information Statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the receiving antenna. 2) Increase the separation between the equipment and receiver. 3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4) Consult the dealer or an experienced radio/TV technician for help. Modifications to this product not authorized by Logitech could void your right to use or operate this product by the FCC Where shielded interface cables or accessories have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canada (IC) Statements: Corded products: This Class B digital apparatus complies with Canadian ICES-003. Cordless (Radio Transmitter) products: Section A. RSS-310 (27 MHz transmitters and receivers): This Category II radio communication device complies with Industry Canada Standard RSS-310. Section B. RSS-210 (2.4 GHz transmitters or transceivers): This Category I radio communication device complies with RSS-210 of Industry Canada. Logitech hardware product limited warranty Logitech warrants to the original purchaser that your Logitech hardware product shall be free from defects in material and workmanship for the period of time, identified on your product packag…

Text truncated - open the document above for the full version.

Model name: Y-R0019 Product name: 2.4GHz Cordless Keyboard Brand name: Logitech Model name: Y-R0021 Product name: Bluetooth Keyboard Brand name: Logitech Model name: P-U0004 Product name: 2.4GHz Cordless Touch Lapdesk Brand name: Logitech

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

(Fig.1) FCC ID: JNZPU0004 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

Report No.: RF110317E08 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110317E08 MODEL NO.: P-U0004 FCC ID: JNZPU0004 RECEIVED: Mar. 17, 2011 TESTED: Mar. 21 to 24, 2011 ISSUED: Mar. 31, 2011 APPLICANT: LOGITECH FAR EAST LTD. ADDRESS: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 27 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110317E08 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD.................................................................................3 1 CERTIFICATION.............................................................................................4 2 SUMMARY OF TEST RESULTS.....................................................................5 2.1 MEASUREMENT UNCERTAINTY..................................................................5 3 GENERAL INFORMATION.............................................................................6 3.1 GENERAL DESCRIPTION OF EUT................................................................6 3.2 DESCRIPTION OF TEST MODES..................................................................7 3.3 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................7 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS.................................9 3.5 DESCRIPTION OF SUPPORT UNITS..........................................................10 3.6 CONFIGURATION OF SYSTEM UNDER TEST...........................................10 4 TEST PROCEDURES AND RESULTS..........................................................11 4.1 RADIATED EMISSION MEASUREMENT......................................................11 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT....................................11 4.1.2 TEST INSTRUMENTS..................................................................................12 4.1.3 TEST PROCEDURES...................................................................................14 4.1.4 DEVIATION FROM TEST STANDARD.........................................................14 4.1.5 TEST SETUP................................................................................................15 4.1.6 EUT OPERATING CONDITIONS..................................................................15 4.1.7 TEST RESULTS............................................................................................16 4.2 CONDUCTED - OUT BAND MEASUREMENT.............................................23 4.2.1 LIMITS OF CONDUCTED - OUT BAND MEASUREMENT..........................23 4.2.2 TEST INSTRUMENTS..................................................................................23 4.2.3 TEST PROCEDURE.....................................................................................23 4.2.4 DEVIATION FROM TEST STANDARD.........................................................23 4.2.5 EUT OPERATING CONDITION....................................................................23 4.2.6 TEST RESULTS............................................................................................24 5 INFORMATION ON THE TESTING LABORATORIES..................................26 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.........................................................27 Report No.: RF110317E08 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release NA Mar. 31, 2011 Report No.: RF110317E08 4 Report Format Version 4.0.0 1 CERTIFICATION PRODUCT : 2.4GHz Cordless Touch Lapdesk BRAND NAME : Logitech MODEL NO. : P-U0004 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : LOGITECH FAR EAST LTD. TESTED : Mar. 21 to 24, 2011 STANDARDS : FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment (Model: P-U0004) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Mar. 31, 2011 ( Midoli Peng, Specialist ) APPROVED BY : , DATE: Mar. 31, 2011 ( May Chen, Deputy Manager ) Report No.: RF110317E08 5 Report Format Version 4.0.0 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C Standard Paragraph Test Type Result Remark 15.207 Conducted Emission Test NA Not Applicable 15.249 Radiated Emission Test PASS Minimum passing margin is -5.6dB at 2400.0MHz 15.249 Conducted - Out Band Measurement PASS Meet the requirement of limit 15.203 Antenna Requirement PASS No antenna connector is used. 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Value Radiated emissions (30MHz-1GHz) 3.76 dB Radiated emissions (1GHz-18GHz) 2.19 dB Radiated emissions (18G…
