JNZS00152Speaker

Read Manual Before Product Use. WARNING! FIRE & ELECTRIC SHOCK HAZARD: RISK OF FIRE OR ELECTRIC SHOCK WHICH MAY RESULT IN PERSONAL INJURY OR DEATH. Use as instructed. Safe Usage Guidelines for Products • Install in accordance with the manufacturer’s instructions. • Maintain a minimum distance of at least 6 inches (15 cm) around apparatus for sufficient ventilation. • Do not block any ventilation openings. • Ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table clothes, curtains, etc. • Do not push objects into apparatus vents or slots. • Place apparatus in a stable location so it will not fall. • No naked (open) flame sources, such as lighted candles, should be placed on or near the apparatus. • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one wider than the other. The wide blade is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. • Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. • Only use attachments/accessories specified by the manufacturer. • Unplug this apparatus during lightning storms or when unused for long periods of time. • Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. • The apparatus shall be disconnected from the mains by unplugging the power cord of the apparatus from the AC mains receptacle. • The socket-outlet shall be installed near the equipment and shall be easily accessible. • Do not use this apparatus near water.Do not expose this apparatus to rain or moisture. • This is not a Children’s Product and is not intended for use by children under 14 years old. POWER SUPPLY WARNING! The power supply is for indoor use only. Only use the power supply included with your product. Do not attempt to repair or use a damaged power supply. Do not immerse the power supply in water or subject it to physical abuse. Inspect the power supply regularly for cable, plug, and casing damage. BATTERY WARNING!: Improperly replaced batteries may present a risk of leak or explosion and personal injury. Mistreated rechargeable batteries may present a risk of fire or chemical burn. Do not disassemble or expose to conducting materials, moisture, liquid, or heat above 54°C (130°F). Do not use or charge the battery if it appears to be leaking, discolored, deformed, or in any way abnormal. Do not leave your battery discharged or unused for extended periods. Do not short circuit. Your device may contain an internal, rechargeable battery that is not replaceable. Battery life varies with usage. Non-operational batteries should be discarded according to local laws. If no laws or regulations govern, dispose of your device in a waste bin for electronics. Keep batteries away from children. Establish Safe Listening Volumes. WARNING! Avoid hearing damage. Listening to this product at high volumes or for extended time periods may cause permanent hearing loss. Protect your hearing by establishing safe volumes: • Start your product with the volume control at its lowest setting. • Slowly increase the volume until you can hear it comfortably and clearly without distortion. • Reduce the volume or stop listening if you experience ringing in your ears. Have your hearing checked by a physician. 620-006566.002 • Do not exceed 50% of the maximum volume for your audio playing device. Logitech Compliance. For Product Safety, EMC, and RF information, go to www.logitech.com/compliance. Maintenance is not required for product compliance. FCC statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates , uses and can radiate radio frequency energy. And, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Warning: Where shielded interface cables or accessories have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC. Changes or modifications to product not expressly approved by Logitech, Inc could void your right to use or operate your product by the FCC. IC statement : CAN ICES-003 (B) / NMB-003 Class (B) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is …

Text truncated - open the document above for the full version.

UE ROLL (How To) content englishenglish How To (UE ROLL screen shots) 1 23

LOGITECH FAR EAST LTD. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. AGENCY AUTHORIZATION LETTER April 23, 2015 To whom it may concern: We, the undersigned, hereby authorize Amanda Wu/ Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu/ Senior Specialist of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. FCC ID: JNZS00152 Sincerely yours, ----------------------------------- T.C. Chang / Sr. Manager AP Region Compliance LOGITECH FAR EAST LTD. Tel: +886 3 5778241* 2146 Fax: +886 3 5792393 E-mail: [email protected] 2015/4/23

Report No. : 150319E09 Page 1 CONSTRUCTION PHOTOS OF EUT Report No. : 150319E09 Page 11

FCC ID: JNZS00152 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No. : 150319E09 Page 2 Report No. : 150319E09 Page 3 Report No. : 150319E09 Page 4 Report No. : 150319E09 Page 5 Report No. : 150319E09 Page 6 Report No. : 150319E09 Page 7 Report No. : 150319E09 Page 8 Report No. : 150319E09 Page 9 Report No. : 150319E09 Page 10

Report No.: SA150319E09 R1 Page No. 1 / 6 Report Format Version: 6.1.1 Cancels and replaces the report No.: SA150319E09 dated Apr. 30, 2015 RF Exposure Report Report No.: SA150319E09 R1 FCC ID: JNZS00152 Test Model: S-00152 Received Date: Mar. 19, 2015 Test Date: Apr. 21 to 27, 2015 Issued Date: May 05, 2015 Applicant: LOGITECH FAR EAST LTD. Address: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA150319E09 R1 Page No. 2 / 6 Report Format Version: 6.1.1 Cancels and replaces the report No.: SA150319E09 dated Apr. 30, 2015 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 Evaluation Result .................................................................................................................................. 5 3 SAR Test Exclusion Thresholds .......................................................................................................... 6 4 Conclusion ............................................................................................................................................ 6 Report No.: SA150319E09 R1 Page No. 3 / 6 Report Format Version: 6.1.1 Cancels and replaces the report No.: SA150319E09 dated Apr. 30, 2015 Release Control Record Issue No. Description Date Issued SA150319E09 Original release. Apr. 30, 2015 SA150319E09 R1 Modified the product name May 05, 2015 Report No.: SA150319E09 R1 Page No. 5 / 6 Report Format Version: 6.1.1 Cancels and replaces the report No.: SA150319E09 dated Apr. 30, 2015 2 Evaluation Result Following FCC KDB 447498 D01 “General SAR test exclusion guidance” The corresponding SAR Exclusion Threshold condition, listed below: 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit freq uency in GHz.  Power and distance are rounded to the nearest mW and mm before calculation .  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2) At 100 MHz to 6 GHz and for test separation distances > 50 mm, the SAR test exclusion threshold is determined according to the following: a) [Threshold at 50 mm in step 1) + (test separation distance - 50mm)·( f(MHz)/150)] mW, at 100MHz to 1500 MHz b) [Threshold at 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500 MHz and ≤ 6 GHz 3) At frequencies below 100 MHz, the following may be considered for SAR test exclusion. a) The threshold at the corresponding test separation distance at 100 MHz in step 2) is multiplied by [1 + log(100/f(MHz))] for test separation distances > 50 mm and < 200 mm. b) The threshold determined by the equation in a) for 50 mm and 100 MHz is multiplied by ½ for test separation distances ≤ 50 mm. c) SAR measurement procedures are not established below 100 MHz. When SAR test exclusion cannot be applied, a KDB inquiry is required to determine SAR evaluation requirements for any test results to be acceptable. Report No.: SA150319E09 R1 Page No. 6 / 6 Report Format Version: 6.1.1 Cancels and replaces the report No.: SA150319E09 dated Apr. 30, 2015 3 SAR Test Exclusion Thresholds Maximum measured transmitter power: BT-EDR Frequency (GHz) Max. Power (mW) Min. test separation distance (mm) SAR test exclusion calculation value (NOTE 2) 1-g SAR test exclusion thresholds Result 2.402 ~ 2.480 7.638 5 2.406 3 Pass NOTE: 1. The antenna type is Quarter wave dipole antenna with 0.01dBi gain. 2. Calculate SAR test exclusion thresholds from condition “1” formulas. BT-LE Frequency (GHz) Max. Power (mW) Min. test separation distance (mm) SAR test exclusi…

Text truncated - open the document above for the full version.

Report No.: RF150319E09 R1 Page No. 1 / 44 Report Format Version: 6.1.1 Cancels and replaces the report No.: RF150319E09 dated Apr. 30, 2015 FCC Test Report (BT-EDR) Report No.: RF150319E09 R1 FCC ID: JNZS00152 Test Model: S-00152 Received Date: Mar. 19, 2015 Test Date: Apr. 22 to 28, 2015 Issued Date: May 05, 2015 Applicant: LOGITECH FAR EAST LTD. Address: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agenci Report No.: RF150319E09 R1 Page No. 2 / 44 Report Format Version: 6.1.1 Cancels and replaces the report No.: RF150319E09 dated Apr. 30, 2015 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 7 2.2 Modification Record ............................................................................................................................ 7 3 General Information .............................................................................................................................. 8 3.1 General Description of EUT (BT-EDR) ................................................................................................ 8 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Description of Support Units ............................................................................................................. 12 3.3.1 Configuration of System under Test .................................................................................................. 12 3.4 General Description of Applied Standards ........................................................................................ 13 4 Test Types and Results ...................................................................................................................... 14 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 14 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 14 4.1.2 Test Instruments ................................................................................................................................ 15 4.1.3 Test Procedures ................................................................................................................................. 16 4.1.4 Deviation from Test Standard ............................................................................................................ 16 4.1.5 Test Setup .......................................................................................................................................... 17 4.1.6 EUT Operating Conditions ................................................................................................................. 17 4.1.7 Test Results ....................................................................................................................................... 18 4.2 Conducted Emission Measurement .................................................................................................. 25 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 25 4.2.2 Test Instruments ................................................................................................................................ 25 4.2.3 Test Procedures ...............................................…

Text truncated - open the document above for the full version.

Report No.: RF150319E09-1 R1 Page No. 1 / 36 Report Format Version: 6.1.1 Cancels and replaces the report No.: RF150319E09-1 dated Apr. 30, 2015 FCC Test Report (BT-LE) Report No.: RF150319E09-1 R1 FCC ID: JNZS00152 Test Model: S-00152 Received Date: Mar. 19, 2015 Test Date: Apr. 21 to 28, 2015 Issued Date: May 05, 2015 Applicant: LOGITECH FAR EAST LTD. Address: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agenc Report No.: RF150319E09-1 R1 Page No. 2 / 36 Report Format Version: 6.1.1 Cancels and replaces the report No.: RF150319E09-1 dated Apr. 30, 2015 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT (BT-LE) ................................................................................................... 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Description of Support Units .............................................................................................................. 11 3.3.1 Configuration of System under Test ................................................................................................... 11 3.4 Duty Cycle of Test Signal .................................................................................................................. 12 3.5 General Description of Applied Standards ........................................................................................ 13 4 Test Types and Results ...................................................................................................................... 14 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 14 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 14 4.1.2 Test Instruments ................................................................................................................................ 15 4.1.3 Test Procedures ................................................................................................................................. 16 4.1.4 Deviation from Test Standard ............................................................................................................ 16 4.1.5 Test Setup .......................................................................................................................................... 17 4.1.6 EUT Operating Conditions ................................................................................................................. 18 4.1.7 Test Results ....................................................................................................................................... 19 4.2 Conducted Emission Measurement .................................................................................................. 23 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 23 4.2.2 Test Instruments ........................................…

Text truncated - open the document above for the full version.

Report No.: 140717E01A-1 1 of 3 Reference No.: 140805E09 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 140717E01A-1 2 of 3 Reference No.: 140805E09 RADIATED EMISSION TEST (Below 1GHz) Report No.: 140717E01A-1 3 of 3 Reference No.: 140805E09 RADIATED EMISSION TEST (Above 1GHz)
