JNZVR0032Micro Four Thirds Wireless Video Production Camera

V R0032 Quick St art Guide 1 2 3 4 5 6 Built in Microphones | Built in Microphones Tally Lights (x2) | Tally Lights (x2) Micro Four Thirds Lens Mount | Micro Four Thirds Lens Mount Body Cap | Body Cap Lens Release Button | Lens Release Button 1/4”-20 Mounting Points (x4) | 1/4”-20 Mounting Points (x4) PRODUCT OVERVIEW PRODUCT OVERVIEW 1 2 2 3 5 6 4 7 8 9 10 11 12 13 Power Button with 4 LEDs for Battery Status USB-C Ports Charging Ports (up to 20W) Power Out (5V/500mA) USB Audio In Ethernet In (requires adapter sold separately) USB-C Ports Wired Webcam (up to 4k 30fps) 3.5mm Audio In TRS 3.5mm Audio In TRS Reset Button Reset Button MicroSD Card Slot MicroSD Card Slot HDMI Output HDMI Output More info here: More info here: help.mevo.com 7 8 9 8 10 11 12 13 Power Button with 4 LEDs for Battery Status USB-C Ports Charging Ports (up to 20W) Power Out (5V/500mA) USB Audio In Ethernet In (requires adapter sold separately) USB-C Ports Wired Webcam (up to 4k 30fps) GETTING STARTED GETTING STARTED Remove the attached body cap. Remove the attached body cap. Align the dot on your lens with the alignment dot on Stratos. Align the dot on your lens with the alignment dot on Stratos. help.mevo.com Push gently the lens against the camera body and turn it clockwise until the lens locks into place. Push gently the lens against the camera body and turn it clockwise until the lens locks into place. Don’t have a lens yet? Learn about which lens we recommend for different use cases here: logitech.com/supported-lenses Don’t have a lens yet? Learn about which lens we recommend for different use cases here: logitech.com/supported-lenses USE WITH THE MEVO APP USE WITH THE MEVO APP Connect Stratos to power, using the provided cable and plugging it in one of the two USB-ports. Connect Stratos to power, using the provided cable and plugging it in one of the two USB-ports. Turn on Stratos, by holding down the power button for 3 seconds. Turn on Stratos, by holding down the power button for 3 seconds. Download the Mevo Multicam app on your tablet or smartphone. Download the Mevo Multicam app on your tablet or smartphone. Open the Mevo Multicam app and follow the instructions on your screen. Open the Mevo Multicam app and follow the instructions on your screen www.logitech.com/get-mevo-app www.logitech.com/get-mevo-app USE AS WIRED CONNECTION USE AS WIRED CONNECTION Turn on Stratos, by holding down the power button for 3 seconds. Turn on Stratos, by holding down the power button for 3 seconds. Do a quick double press on the power button. A chime will inform you Stra- tos is now in wired webcam mode. Do a quick double press on the power button. A chime will inform you Stra- tos is now in wired webcam mode. x2 Connect Stratos to your computer with the provided cable, using the USB-C port with the monitor icon. Connect Stratos to your computer with the provided cable, using the USB-C port with the monitor icon. To control your camera from your comput- er, download the Logitech desktop app: www.logitech.com/download To control your camera from your comput- er, download the Logitech desktop app: www.logitech.com/download Looking for a tutorial, need additional product information, or more? Visit: logitech.com/stratos/howtos Looking for a tutorial, need additional product information, or more? Visit: logitech.com/stratos/howtos ©2023 Logitech. Logitech, Logitech G, Logi and their respective logos are trademarks or registered trademarks of Logitech Europe S.A. and/or its affiliates in the U.S. and other countries. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. ©2023 Logitech. Logitech, Logitech G, Logi and their respective logos are trademarks or registered trademarks of Logitech Europe S.A. and/or its affiliates in the U.S. and other countries. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. 620-012123 00B Important Safety, Compliance and Warranty Information Informations importantes concernant la sécurité, la mise en conformité et la garantie English Read Manual Before Product Use. This product is intended to be supplied by a Listed/Certified power supply, rated 5-9V d.c. , 2A max , Tma (maximum ambient temperature) 35 degree C and altitude 2000 m. If needed, please contact the Manufacturer for further information. BATTERY WARNING!: Improperly replaced batteries may present a risk of leak or explosion and personal injury. Risk of fire or explosion if the battery is replaced by an incorrect type. Ensure batteries are installed correctly by following the instructions provided. Mistreated rechargeable batteries may present a risk of fire or chemical burn. Do not disassemble or expose to conducting materials, moisture, liquid, or heat above 54° C (130° F). A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas. Do not use or charge the battery if it appears to be leaking, discolored, deformed, or in any way abnormal. Do not leave your battery discharged or unused for extended periods. Do not short circuit. Your device may contain an internal, rechargeable battery that is not replaceable. Battery life varies with usage. Non-operational batteries should be discarded according to local laws. If no laws or regulations govern, dispose of your device in a waste bin for electronics. Keep batteries away from children. Safe Usage Guidelines for Products − Do not open or modify the product except for battery removal and replacement. − Do not disassemble or attempt to service this product. − Use the product with listed/certified ITE computers and accessories. − Connect power supply or power cord to a properly wired and grounded electrical outlet. − T…

Text truncated - open the document above for the full version.

Logitech Far East Ltd. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: December 5, 2023 FCC ID:JNZVR0032 To the attention of: Federal Communications Commission Authorization and Evaluation Division Declaration Letter for Low Power Indoor Client Devices (6XD) We, Logitech Far East Ltd., attest that this device under FCC ID:JNZVR0032 complies with device protocol requirements and operational restrictions for Indoor Client Devices (6XD). a) This device will only associate and connect with a low-power indoor access point or subordinate device and never directly connects to other client devices. b) This device will always initiate transmission under the control of a low power indoor AP or subordinate except for brief transmissions before joining a network. These short messages will only occur if this client has detected an indoor AP or subordinate operating on a channel. These brief messages will have a time-out mechanism such that if it does not receive a response from an AP it will not continually repeat the request. c) All transmissions will be lower or equal to the power advertised by the indoor low-power access point or subordinate and never above the maximum output power allowed by the FCC grant for equipment class 6XD. d) This device employs a Contention-Based Protocol as demonstrated in the test report. e) We understand and acknowledge that this device is subject to the following restrictions, which are also documented within the user manual:  Device is limited to indoor use. This client device may connect to the internet via a wired connection (ethernet) but does not source the internet to other clients or subordinate devices or provide any direct peer to peer connections to other clients / subordinates.  This device is prohibited for control of or communications with unmanned aircraft systems, including drones. If you should have any questions regarding this declaration, please do not hesitate to contact us, thank you! Sincerely yours, ------------------------------------------------------------------ Paul Zahra, Senior Manager, Compliance Engineering Logitech Far East Ltd. Tel: +1-510-713-5436 E-mail: [email protected]

Logitech Far East Ltd. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2023-10-17 FCC ID:JNZVR0032 To the attention of Federal Communications Commission Authorization and Evaluation Division Attestation Statements Attestation Statements Part 2.911(d)(5)(i) Filing Logitech Far East Ltd. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receivingan equipment authorization pursuant to section 2.903 of the FCC rules. Attestation Statements Part 2.911(d)(5)(ii) Filing Logitech Far East Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely yours, ------------------------------------------------------------------ Paul Zahra Senior Manager, Compliance Engineering Logitech Far East Ltd. Tel: +1-510-713-5436 E-mail: [email protected]

Date: 10/17/2023 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation FCC ID: JNZVR0032 To whom it may concern: FCC US Agent Agent Company Name: Logitech, Inc. FCC FRN: 0005921077 Agent Contact Name: Paul Zahra Agent US Address: 3930 North First Street, San Jose, California 95134 Agent Email Address: [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Logitech Far East, Ltd. (“the applicant”) for the above referenced FCC ID. We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. Sincerely, Paul Zahra Senior Manager, Compliance Engineering Logitech, Inc.

Date: 10/17/2023 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: JNZVR0032 Applicant (Grantee) FRN: 0007134034 Logitech Far East, Ltd., (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Contact Person: Paul Zahra Company Name: Logitech, Inc. Company Address: 3930 North First Street, San Jose, California 95134 Email: [email protected] Sincerely yours, Name: Rick Lien Job Title: Head of Product Compliance Company Name: Logitech Far East, Ltd. Email: [email protected] Tel: +886-3-5778241 #2189

Date: 02/05/2024 FCC ID: JNZVR0032 To the attention of Federal Communications Commission Authorization and Evaluation Division Attestation Statements Attestation Statements Part 2.911(d)(5)(i) Filing LOGITECH FAR EAST LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Attestation Statements Part 2.911(d)(5)(ii) Filing LOGITECH FAR EAST LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely yours, ----------------------------------------------- David W Crawford / Senior Manager, Compliance Engineering LOGITECH FAR EAST LTD. Tel: +1-360-817-1253 E-mail: [email protected]

Date: 02/05/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation FCC ID: JNZVR0032 Applicant (Grantee) FRN: 0007134034 To whom it may concern: FCC US Agent Agent Company Name: Logitech, Inc. Agent FRN: 0005921077 Agent Contact Name: David W Crawford Agent US Address: 4700 NW Camas Meadows Drive, Camas, WA 98607 Agent Email Address: [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Logitech Far East, Ltd. (“the applicant”) for the above referenced FCC ID. We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. This letter supersedes the previous version for purposes of updating the U.S. Agent contact information due to changes in responsibilities. Sincerely, ______ David W Crawford Senior Manager, Compliance Engineering Logitech, Inc.

Date: 02/05/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: JNZVR0032 Applicant (Grantee) FRN: 0007134034 Logitech Far East, Ltd., (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. This letter supersedes the previous version for purposes of updating the U.S. Agent contact information due to changes in responsibilities. U.S. Agent Information: Contact Person: David W Crawford Company Name: Logitech, Inc. Company FRN: 0005921077 Company Address: 4700 NW Camas Meadows Drive, Camas, WA 98607 Email: [email protected] Sincerely yours, ________ Name: Rick Lien Job Title: Head of Product Compliance Company Name: Logitech Far East, Ltd. Email: [email protected] Tel: +886-3-5778241 #2189

Logitech Far East Ltd. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2023-10-17 FCC ID:JNZVR0032 To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ------------------------------------------------------------------ Paul Zahra Senior Manager, Compliance Engineering Logitech Far East Ltd. Tel: +1-510-713-5436 E-mail: [email protected]

Logitech Far East Ltd. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2023-10-17 FCC ID:JNZVR0032 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until (2024/2/6) in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ------------------------------------------------------------------ Paul Zahra Senior Manager, Compliance Engineering Logitech Far East Ltd. Tel: +1-510-713-5436 E-mail: [email protected]

Logitech Far East Ltd. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2023-10-17 FCC ID:JNZVR0032 AUTHORIZATION LETTER To Whom It May Concern: Logitech Far East Ltd. hereby authorizes Amanda Wu / Senior Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Amanda Wu / Senior Specialist of BV CPS Taoyuan on Logitech Far East Ltd.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ------------------------------------------------------------------ Paul Zahra Senior Manager, Compliance Engineering Logitech Far East Ltd. Tel: +1-510-713-5436 E-mail: [email protected]

LOGITECH FAR EAST LTD. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2023-10-16 AUTHORIZATION LETTER To whom it may concern: I, the undersigned Rick Lien of Logitech Far East Ltd. hereby authorize Paul Zahra of Logitech, Inc. to act on my behalf in all matters relating to all processes required in FCC and any communication needed with the national authority. Any and all acts carried out by Paul Zahra on my behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------------- Rick Lien / Head of Product Compliance LOGITECH FAR EAST LTD. Tel: +886-03(6122189) Fax: +886-03(5792394) E- mail: [email protected]

LOGITECH FAR EAST LTD. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2024-02-16 A U T H O R I Z A T I O N L E T T E R To whom it may concern: I, the undersigned Rick Lien of LOGITECH FAR EAST LTD. hereby authorize David W Crawford of Logitech, Inc. to act on my behalf in all matters relating to all processes required in FCC and any communication needed with the national authority. Any and all acts carried out by David W Crawford on my behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------------- Rick Lien / Head of Product Compliance Tel: +886-3-5778241 #2189 Fax: +886-3-5792394 Email: [email protected]

Reference No.: BDKG-WTW-P23080624_EXT Page 1/5 CONSTRUCTION PHOTOS OF EUT Reference No.: BDKG-WTW-P23080624_EXT Page 2/5 Reference No.: BDKG-WTW-P23080624_EXT Page 3/5 Reference No.: BDKG-WTW-P23080624_EXT Page 4/5 Reference No.: BDKG-WTW-P23080624_EXT Page 5/5 Type C Cable

Label & Label location The label is permanently affixed at a conspicuous location on the device. Bottom M/N: VR0032 IC:4418A-VR0032 FCC ID:JNZVR0032

Reference No.: BDKG-WTW-P23080624_INT Page 1/26 CONSTRUCTION PHOTOS OF EUT Reference No.: BDKG-WTW-P23080624_INT Page 2/26 Reference No.: BDKG-WTW-P23080624_INT Page 3/26 Reference No.: BDKG-WTW-P23080624_INT Page 4/26 Reference No.: BDKG-WTW-P23080624_INT Page 5/26 Reference No.: BDKG-WTW-P23080624_INT Page 6/26 Reference No.: BDKG-WTW-P23080624_INT Page 7/26 Reference No.: BDKG-WTW-P23080624_INT Page 8/26 Reference No.: BDKG-WTW-P23080624_INT Page 9/26 Reference No.: BDKG-WTW-P23080624_INT Page 10/26 Reference No.: BDKG-WTW-P23080624_INT Page 11/26 Reference No.: BDKG-WTW-P23080624_INT Page 12/26 Reference No.: BDKG-WTW-P23080624_INT Page 13/26 Reference No.: BDKG-WTW-P23080624_INT Page 14/26 ANT 0 ANT 1 Reference No.: BDKG-WTW-P23080624_INT Page 15/26 Reference No.: BDKG-WTW-P23080624_INT Page 16/26 Reference No.: BDKG-WTW-P23080624_INT Page 17/26

Reference No.: BDKG-WTW-P23080624_INT Page 18/26 Reference No.: BDKG-WTW-P23080624_INT Page 19/26 Reference No.: BDKG-WTW-P23080624_INT Page 20/26 Reference No.: BDKG-WTW-P23080624_INT Page 21/26 Battery (Model: 533-000231) Reference No.: BDKG-WTW-P23080624_INT Page 22/26 Battery (Model: 533-000230) Reference No.: BDKG-WTW-P23080624_INT Page 23/26 Antenna 1 Reference No.: BDKG-WTW-P23080624_INT Page 24/26 Reference No.: BDKG-WTW-P23080624_INT Page 25/26 Antenna 0 Reference No.: BDKG-WTW-P23080624_INT Page 26/26

Report No.: MFBDKG-WTW-P23080624 Page No. 1 / 11Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23080624 RF EXPOSURE REPORT CERTIFICATE OF CONFORMITY FCC Rule Part: FCC Part 2 (Section 2.1091) Report No.: MFBDKG-WTW-P23080624 FCC ID: JNZVR0032 Product: Micro Four Thirds Wireless Video Production Camera Brand: Logitech Model No.: VR0032 Received Date: 2023/8/28 Test Date: 2023/12/21 Issued Date: 2023/12/27 Applicant: Logitech Far East Ltd. Address: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laborator y Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Desi gnation Number: 723255 / TW2022 Approved by: , Date:2023/12/27 May Chen / Manager This test report consists of 11 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Phoenix Huang This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBDKG-WTW-P23080624 Page No. 2 / 11Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23080624 Table of Contents Release Control Record ....................................................................................................................................................... 3 1 Certificate .................................................................................................................................................................... 4 2 Applicable RF Exposure Limit .................................................................................................................................. 5 3 Test Results ................................................................................................................................................................ 8 4 Conclusion ................................................................................................................................................................ 10 5 Information of the Testing Laboratories ................................................................................................................ 11 Report No.: MFBDKG-WTW-P23080624 Page No. 3 / 11Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23080624 Release Control Record Issue No. Description Date Issued MFBDKG-WTW-P23080624 Original release. 2023/12/27 Report No.: MFBDKG-WTW-P23080624 Page No. 4 / 11Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23080624 1 Certificate Product: Micro Four Thirds Wireless Video Production Camera Brand: Logitech Test Model: VR0032 Sample Status: Engineering sample Applicant: Logitech Far East Ltd. Test Date: 2023/12/21 FCC Rule Part: FCC Part 2 (Section 2.1091) Standard: KDB 447498 D04 Interim General RF Exposure Guidance v01 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Report No.: MFBDKG-WTW-P23080624 Page No. 5 / 11Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23080624 2 Applicable RF Exposure Limit § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatialaverage SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit for occupational/controlled exposure is 20 W/kg, av…

Text truncated - open the document above for the full version.

Report No: AGY-700-032073 Page 1 of 27 Logitech Antenna Under Test (AUT) Report Antenna P/N: 420-006520 - Antenna 0 ; 420-006521- Antenna 1 Equipment Type: Antenna Manufacturer: Novocomms (Suzhou) Limited Test Location: Novocomms (Suzhou) Limited No.5 Zhonghong road, SND, Suzhou city, Jiangsu Province, China Tested by: Duke Huang Test Date: June, 30, 2023 Report No: AGY-700-032073 Page 2 of 27 Report Release History Report version Description Date Issued V1 Original release V2 Updated antenna test site info, added antenna part numbers V3 Updated antenna chamber test software asterisk note. Replaced “Model Name” with antenna part number. Added antenna manufacturer address. 12/13/2023 Table of Contents 1. EUT Antenna Information 3 2. 3D Radiation Pattern Measurement 3 2.1 Test Location 3 2.2 Description of the anechoic chamber 3 2.3 Test Instruments 4 2.4 Test Procedure 5 2.6 Test Setup photos 6 2.7 Antenna Gain 9 Report No: AGY-700-032073 Page 3 of 27 1. EUT Antenna Information 1) Antenna Material：FPC 2) Antenna Type：Printed F (connector : IPEX MHF I) 3) Antenna Dimension: 4) Operating Frequency：2.4 GHz - 2.4835 GHz; 5.1GHz – 7.125GHz 5) Input Impedance：50 Ω 6) Standing-Wave Ratio：< 2.6 2. 3D Radiation Pattern Measurement 2.1 Test Location 3D radiation pattern measurement in the anechoic chamber 2.2 Description of the anechoic chamber Length: 3.062m Width: 3.120m Height: 2.932m Report No: AGY-700-032073 Page 4 of 27 2.3 Test Instruments Report No: AGY-700-032073 Page 5 of 27 Description Model No. Last Calibration^ Vector Network Analyzer Keysight E5071C Feb/2023 Chamber GTS Rayzone 2800* March/2023 Notes: ^The calibration interval of the above test instruments is 12 months * Test software used is GTS MaxSign Libra version 1.1.8 2.4 Test Procedure i. Measure loss of the RF test cable. ii. Solder the test RF cable to the Antenna. iii. Mount the DUT on the mast of the chamber, record the coordinates and take pictures. iv. Calibrate the chamber where the connection to source from the VNA Port 1. v. Compensate for the loss from the test cable from item 2.4.i. vi. Read the channel power level on the Network analyzer and record in the following positions. 1. The mast is then stepped between 0 to 360 degrees along the horizontal plane in 15-degree increments. 2. Data is recorded using the VNA for both theta (Port2) and phi (Port3) polarizations at each position. Report No: AGY-700-032073 Page 9 of 27 2.7 Antenna Gain Ant0 Frequency Efficiency (dB) Efficiency% Gain 2412 -3.64 43.29 4.18 2437 -3.44 45.32 4.49 2462 -2.71 53.64 4.50 5180 -2.41 57.39 5.92 5210 -2.18 60.58 6.08 5240 -1.97 63.49 6.4 5260 -2.09 61.87 6.31 5290 -1.86 65.19 6.40 5320 -1.74 66.99 6.3 5500 -2.70 53.7 6.91 Report No: AGY-700-032073 Page 10 of 27 5600 -3.12 48.75 6.93 5720 -3.89 40.81 6.43 5745 -3.8 41.67 6.53 5775 -3.97 40.05 6.25 5825 -3.73 42.40 6.15 6115 -3.72 42.43 4.33 6275 -3.83 41.40 2.80 6415 -1.89 64.75 5.31 6435 -1.54 70.11 5.64 6475 -1.98 63.35 5.47 6515 -1.46 71.52 6.38 6535 -0.85 82.16 7.03 6695 -1.49 70.88 6.03 6855 -3.47 44.98 4.55 6895 -5.24 29.91 2.81 7015 -3.92 40.56 2.89 7095 -3.90 40.79 2.83 ANT1 Frequency Efficiency (dB) Efficiency% Gain 2412…
