JNZVR0035Shared Desk Docking Station

English (US) Read Manual Before Product Use. POWER SUPPLY WARNING! The power supply is for indoor use only. Only use the power supply included with your product. Do not attempt to repair or use a damaged power supply. Do not immerse the power supply in water or subject it to physical abuse. Inspect the power supply regularly for cable, plug, and casing damage. Caution. Connect all power cords to a properly wired and grounded electrical outlet. Safe Usage Guidelines for Products –Do not open or modify the product except for battery removal and replacement. –Do not disassemble or attempt to service this product. –Use the product with listed/certified ITE computers and accessories. –Connect power supply or power cord to a properly wired and grounded electrical outlet. –This product is safe under normal and reasonably foreseeable operating conditions. –If product is operating improperly, please contact Logitech support. –Product must be returned to the manufacturer for any service or repair. –This is not a Children‘s Product and is not intended for use by children under 14 years old. –Warning: Not suitable for children under 36 months. Small parts. Choking hazard. –Install device according to provided instructions. Improper installation of this product may cause damage or injury. –Mount device properly according to the provided instructions. Improper installation of this product may cause damage or injury. Logitech Compliance: The product complies with all applicable requirements for Restriction of Hazardous Substances (RoHS) and Waste Electronic and Electrical Equipment (WEEE). For Product Safety, EMC, RF, Energy, RoHS and WEEE information, go to www.logitech.com/compliance. Maintenance is not required for product compliance. Packaging, batteries, electronic and electrical equipment and their accessories should not be disposed of with household waste. Wherever possible, they should be segregated and brought to an appropriate collection point to enable recycling and avoid potential impacts on the environment and human health. For more information, contact your local authorities or place of purchase, or visit www.logitech.com/recycling. FCC statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Warning: Where shielded interface cables or accessories have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC. Changes or modifications to product not expressly approved by Logitech, Inc could void your right to use or operate your product by the FCC. IC statement: CAN ICES-3 (A) / NMB-3 (A) Radiation Exposure Statement: This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Caution: (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; (ii) high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650- 5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. Warning This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Logitech Limited Hardware Product Warranty – A Summary Logitech warrants that its hardware product shall be free from defects in materials and workmanship for the length of time identified on your product package beginning from the date of the original retail purchase. See support.logitech.com for specific warranty information about your product and procedures to act on a warranty claim. Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, to repair or replace a functional equivalent of the product, or to refund the price paid, if the hardware is returned to the point of purchase or such other place as Logitech may direct along with a receipt. Warranty protections are in addition to rights provided under local consumer laws and may vary among countries. See full warranty information to know your consumer rights and the additional protections provided by this product warranty. Logitech Address: Logitech, Inc., 3930 North First Street, San Jose, California 95134. Full Warranty Information: support.logitech.com Français (Canada) Lire le manuel avant utilisation. AVERTISSEMENT RELATIF AU BOÎTIER D'ALIMENTATION! Le boîtier d'alimentation est conçu exclusivement pour une utilisation …

Text truncated - open the document above for the full version.

LOGI DOCK FLEX Setup Guide | Guide d’installation WHAT’S IN THE BOX FEATURES 1.Power/Reset Button 2.Power 3.USB-C Upstream 100W 4.HDMI 5.DisplayPort 6.USB-C (USB 3.1) 7.Gigabit Ethernet 8.Cable Retention Key 9.Cable Retention 10.USB-A (USB 3.1) 11.Kensington Security Slot 1.Bouton d’alimentation/de ré initialisation 2.Alimentation 3.USB-C en amont 100 W 4.HDMI 5.DisplayPort 6.USB-C (USB 3.1) 7.Gigabit Ethernet 8.Clé de ré tention de câ ble 9.Ré tention de câ ble 10.USB-A (USB 3.1) 11.Emplacement de sé curité Kensington 1.Ein-/Aus-/Reset-Taste 2.Stromversorgung 3.USB-C-Upstream 100 W 4.HDMI 5.DisplayPort 6.USB-C (USB 3.1) 7.Gigabit Ethernet 8.Kabelrü ckhalteschlü ssel 9.Kabelfixierung 10.USB-A (USB 3.1) 11.Kensington Sicherheitssteckplatz 1.Pulsante di accensione/ripristino 2.Accensione 3.Upstream USB-C 100 W 4.HDMI 5.DisplayPort 6.USB-C (USB 3.1) 7.Gigabit Ethernet 8.Tasto di fissaggio dei cavi 9.Fissaggio dei cavi 10.USB-A (USB 3.1) 11.Kensington Security Slot 1.Botó n de encendido/reinicio 2.Alimentació n 3.USB-C de subida de 100 W 4.HDMI 5.DisplayPort 6.USB-C (USB 3.1) 7.Gigabit Ethernet 8.Llave de retenció n de cables 9.Retenció n de cables 10.USB-A (USB 3.1) 11.Conector de seguridad Kensington 1.Botã o liga/desliga 2.Poder 3.USB-C upstream 100 W 4.HDMI 5.DisplayPort 6.USB-C (USB 3.1) 7.Gigabit Ethernet 8.Chave de Retenç ã o de Cabo 9.Retenç ã o de cabo 10.USB-A (USB 3.1) 11.Slot de Seguranç a Kensington 1.电源/重置按钮 2.电源 3.USB-C 上行100W 4.HDMI 5.DisplayPort 6.USB-C(USB 3.1) 7.千兆以太网 8.线缆固定钥匙 9.线缆固定装置 10.USB-A(USB 3.1) 11.Kensington 安全锁孔 1.电源/重置按钮 2.力量 3.USB-C 上游100W 4.HDMI 5.显示端口 6.USB-C (USB 3.1) 7.千兆以太网 8.电缆固定键 9.电缆固定 10.USB-A (USB 3.1) 11.Kensington 安全插槽 1.전원/리셋버튼 2.힘 3.USB-C 업스트림100W 4.HDMI 5.디스플레이포트 6.USB-C(USB 3.1) 7.기가비트이더넷 8.케이블고정키 9.케이블고정 10.USB-A(USB 3.1) 11.Kensington 보안슬롯 1.電源/リセットボタン 2.力 3.USB-C アップストリーム 100W 4.HDMI 5.ディスプレイポート 6.USB-C (USB 3.1) 7.ギガビットイーサネット 8.ケーブル保持キー 9.ケーブル保持 10.USB-A（USB3.1） 11.ケンジントンセキュリティス ロット

LOGITECH FAR EAST LTD. 3930 North First Street, San Jose, California 95134 Date: July 13, 2023 We, LOGITECH FAR EAST LTD. declare that the device does not support channel 12 ~ 13 in 2.4GHz band and any non-US channels in all the operational mode(s) for the following product. FCC ID: JNZVR0035 If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! ----------------------------------- Paul Zahra / Senior Manager, Compliance Engineering LOGITECH FAR EAST LTD. Tel: +1-510-713-5436 E-mail: [email protected]

Date: [2023/07/13] FCC ID: JNZVR0035 To the attention of Federal Communications Commission Authorization and Evaluation Division Attestation Statements Attestation Statements Part 2.911(d)(5)(i) Filing LOGITECH FAR EAST LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Attestation Statements Part 2.911(d)(5)(ii) Filing LOGITECH FAR EAST LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely yours, ----------------------------------------------- Paul Zahra / Senior Manager, Compliance Engineering LOGITECH FAR EAST LTD. Tel: +1-510-713-5436 E-mail: [email protected]

Date: 7/06/2023 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation FCC ID: JNZVR0035 To whom it may concern: FCC US Agent Agent Company Name: Logitech, Inc. FCC FRN: 0005921077 Agent Contact Name: Paul Zahra Agent US Address: 3930 North First Street, San Jose, California 95134 Agent Email Address: [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Logitech Far East, Ltd. (“the applicant”) for the above referenced FCC ID. We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. Sincerely, Paul Zahra Senior Manager, Compliance Engineering Logitech, Inc.

Data: 7/06/2023 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: JNZVR0035 Logitech Far East, Ltd., (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Contact Person: Paul Zahra Company Name: Logitech, Inc. Company Address: 3930 North First Street, San Jose, California 95134 Email: [email protected] Sincerely yours, Name: Rick Lien Job Title: Head of Product Compliance Company Name: Logitech Far East, Ltd. Mail address: [email protected] Tel: 886-3-612-2189

Date: 02/05/2024 FCC ID: JNZVR0035 To the attention of Federal Communications Commission Authorization and Evaluation Division Attestation Statements Attestation Statements Part 2.911(d)(5)(i) Filing LOGITECH FAR EAST LTD. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Attestation Statements Part 2.911(d)(5)(ii) Filing LOGITECH FAR EAST LTD. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely yours, ----------------------------------------------- David W Crawford / Senior Manager, Compliance Engineering LOGITECH FAR EAST LTD. Tel: +1-360-817-1253 E-mail: [email protected]

Date: 02/05/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) FCC US Agent Letter of Attestation FCC ID: JNZVR0035 Applicant (Grantee) FRN: 0007134034 To whom it may concern: FCC US Agent Agent Company Name: Logitech, Inc. Agent FRN: 0005921077 Agent Contact Name: David W Crawford Agent US Address: 4700 NW Camas Meadows Drive, Camas, WA 98607 Agent Email Address: [email protected] This letter is to confirm that we have accepted the responsibility to act as US Agent on behalf of Logitech Far East, Ltd. (“the applicant”) for the above referenced FCC ID. We are aware of the requirements and responsibilities of the applicant’s agent for service of process as outlined in the FCC section 2.911(d)(7) and Report and Order FCC 22-84 paragraph 63. This letter supersedes the previous version for purposes of updating the U.S. Agent contact information due to changes in responsibilities. Sincerely, ______ David W Crawford Senior Manager, Compliance Engineering Logitech, Inc.

Date: 02/05/2024 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: JNZVR0035 Applicant (Grantee) FRN: 0007134034 Logitech Far East, Ltd., (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. This letter supersedes the previous version for purposes of updating the U.S. Agent contact information due to changes in responsibilities. U.S. Agent Information: Contact Person: David W Crawford Company Name: Logitech, Inc. Company FRN: 0005921077 Company Address: 4700 NW Camas Meadows Drive, Camas, WA 98607 Email: [email protected] Sincerely yours, ________ Name: Rick Lien Job Title: Head of Product Compliance Company Name: Logitech Far East, Ltd. Email: [email protected] Tel: +886-3-5778241 #2189

LOGITECH FAR EAST LTD. 3930 North First Street, San Jose, California 95134 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: JNZVR0035 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Software Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant of Equipment Authorization. External Photos Internal Photos User Manual Test Setup photos It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Paul Zahra / Senior Manager, Compliance Engineering LOGITECH FAR EAST LTD. Tel: +1-510-713-5436 E-mail: [email protected] 07/06/2023

LOGITECH FAR EAST LTD. 3930 North First Street, San Jose, California 95134 Date: 2023-07-13 FCC ID: JNZVR0035 A U T H O R I Z A T I O N L E T T E R To Whom It May Concern: LOGITECH FAR EAST LTD. hereby authorizes Emerald Chen / Specialist of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”), to act on its behalf in all matters relating to the Federal Communication Commission (“FCC”) application for equipment authorization in connection with the FCC ID listed above, including signing of all documents relating to these matters. Any and all acts carried out by Emerald Chen / Specialist of BV CPS Taoyuan on LOGITECH FAR EAST LTD.’s behalf, within the scope of the powers granted herein, shall have the same effect as acts of its own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------------------- Paul Zahra / Senior Manager, Compliance Engineering LOGITECH FAR EAST LTD. Tel: +1-510-713-5436 E-mail: [email protected]

LOGITECH FAR EAST LTD. #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. Date: 2024-02-16 A U T H O R I Z A T I O N L E T T E R To whom it may concern: I, the undersigned Rick Lien of LOGITECH FAR EAST LTD. hereby authorize David W Crawford of Logitech, Inc. to act on my behalf in all matters relating to all processes required in FCC and any communication needed with the national authority. Any and all acts carried out by David W Crawford on my behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ----------------------------------- Rick Lien / Head of Product Compliance Tel: +886-3-5778241 #2189 Fax: +886-3-5792394 Email: [email protected]

Reference No.: BDKG-WTW-P23060048_EXT Page 1/8 CONSTRUCTION PHOTOS OF EUT Reference No.: BDKG-WTW-P23060048_EXT Page 2/8 Reference No.: BDKG-WTW-P23060048_EXT Page 3/8 Reference No.: BDKG-WTW-P23060048_EXT Page 4/8 Reference No.: BDKG-WTW-P23060048_EXT Page 5/8 Reference No.: BDKG-WTW-P23060048_EXT Page 6/8 Reference No.: BDKG-WTW-P23060048_EXT Page 7/8 Reference No.: BDKG-WTW-P23060048_EXT Page 8/8

Label & Label location The label is permanently affixed at a conspicuous location on the device. Bottom M/N : VR0035 I C : 4418A-VR0035 FC C ID: JNZVR0035

Reference No.: BDKG-WTW-P23060048_INT Page 1/18 CONSTRUCTION PHOTOS OF EUT Reference No.: BDKG-WTW-P23060048_INT Page 2/18 Reference No.: BDKG-WTW-P23060048_INT Page 3/18 Reference No.: BDKG-WTW-P23060048_INT Page 4/18 Reference No.: BDKG-WTW-P23060048_INT Page 5/18 Reference No.: BDKG-WTW-P23060048_INT Page 6/18 Reference No.: BDKG-WTW-P23060048_INT Page 7/18 Reference No.: BDKG-WTW-P23060048_INT Page 8/18 Reference No.: BDKG-WTW-P23060048_INT Page 9/18 Reference No.: BDKG-WTW-P23060048_INT Page 10/18 Reference No.: BDKG-WTW-P23060048_INT Page 11/18 Antenna Reference No.: BDKG-WTW-P23060048_INT Page 12/18 Reference No.: BDKG-WTW-P23060048_INT Page 13/18 Reference No.: BDKG-WTW-P23060048_INT Page 14/18 Reference No.: BDKG-WTW-P23060048_INT Page 15/18 Antenna Reference No.: BDKG-WTW-P23060048_INT Page 16/18 Reference No.: BDKG-WTW-P23060048_INT Page 17/18 Reference No.: BDKG-WTW-P23060048_INT Page 18/18

Report No.: MFBDKG-WTW-P23060048 Page No. 1 / 9 Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23060048 RF EXPOSURE REPORT CERTIFICATE OF CONFORMITY FCC Rule Part: FCC Part 2 (Section 2.1091) Report No.: MFBDKG-WTW-P23060048 FCC ID: JNZVR0035 Product: Shared Desk Docking Station Brand: logi Model No.: VR0035 Received Date: 2023/4/20 Test Date: 2023/6/22 Issued Date: 2023/7/20 Applicant: Logitech Far East Ltd. Address: 3930 North First Street, San Jose, California 95134 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 Approved by: , Date: 2023/7/20 Wen Yu / Assistant Manager This test report consists of 9 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Prepared by : Vito Lung / Specialist This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: MFBDKG-WTW-P23060048 Page No. 2 / 9 Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23060048 Table of Contents Release Control Record ....................................................................................................................................................... 3 1 Certificate .................................................................................................................................................................... 4 2 Applicable RF Exposure Limit .................................................................................................................................. 5 3 Test Results ................................................................................................................................................................ 7 4 Conclusion .................................................................................................................................................................. 8 5 Information of the Testing Laboratories .................................................................................................................. 9 Report No.: MFBDKG-WTW-P23060048 Page No. 3 / 9 Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23060048 Release Control Record Issue No. Description Date Issued MFBDKG-WTW-P23060048 Original release. 2023/7/20 Report No.: MFBDKG-WTW-P23060048 Page No. 4 / 9 Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23060048 1 Certificate Product: Shared Desk Docking Station Brand: logi Test Model: VR0035 Sample Status: PB2 Applicant: Logitech Far East Ltd. Test Date: 2023/6/22 FCC Rule Part: FCC Part 2 (Section 2.1091) Standard: KDB 447498 D04 Interim General RF Exposure Guidance v01 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s RF characteristics under the conditions specified in this report. Report No.: MFBDKG-WTW-P23060048 Page No. 5 / 9 Report Format Version: 7.1.0 Reference No.: BDKG-WTW-P23060048 2 Applicable RF Exposure Limit § 1.1310 Radiofrequency radiation exposure limits. (a) Specific absorption rate (SAR) shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in § 1.1307(b) of this part within the frequency range of 100 kHz to 6 GHz (inclusive). (b) The SAR limits for occupational/controlled exposure are 0.4 W/kg, as averaged over the whole body, and a peak spatialaverage SAR of 8 W/kg, averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the parts of the human body treated as extremities, such as hands, wrists, feet, ankles, and pinnae, where the peak spatial-average SAR limit for occupational/controlled exposure is 20 W/kg, averaged over any 10 grams of tissue (defined as a tissue volume in the s…

Text truncated - open the document above for the full version.

客 客 戶 戶 名 名 稱 稱 C C U U S S T T O O M M E E R R 承 承 認 認 書 書 A A P P P P R R O O V V A A L L S S H H E E E E T T 產 產 品 品 品 品 名 名 / / P P r r o o d d u u c c t t M M o o d d e e l l N N o o . . : : WA-P-LB-02-974 Model Name:Coily 客 客 戶 戶 料 料 號 號 / / C C u u s s t t o o m m e e r r N N o o . . ： ： 025.9028G.0001 發 發 行 行 日 日 期 期 / / I I s s s s u u e e D D a a t t e e : : 2023/04/07 承 承 認 認 日 日 期 期 / / A A p p p p r r o o v v e e d d D D a a t t e e : : A A p p p p r r o o v v e e d d b b y y c c u u s s t t o o m m e e r r : : ( ( s s i i g g n n i i n n g g o o r r s s t t a a m m p p i i n n g g h h e e r r e e ) ) ■350苗栗縣竹南鎮公義里11鄰科義街11號 電話：037-585-555 傳真：037-585-511 □428台中市大雅區科雅路27號4樓 電話：04-2560-6555 傳真：04-2560-5151 No. 11, Ke-Yi St., Chunan, Miaoli 350, Taiwan, R.O.C. Tel.：+886-37-585-555 Fax：+886-37-585-511 4F,No.27,Keya Road,Daya Dist.,Taichung City 428, Taiwan,R.O.C. Tel.：+886-4-25606555 Fax：+886-4-25605151 ： :緯創資通 D D o o c c u u m m e e n n t t N N o o . . : : . . E E N N S S 0 0 0 0 0 0 1 1 7 7 7 7 4 4 8 8 0 0 A A p p p p r r o o v v a a l l S S h h e e e e t t R R e e v v . . : : A A 3 3 S S p p e e c c . . R R e e v v . . : : P P 4 4 佳邦科技股份有限公司 INPAQ TECHNOLOGY CO., LTD. I-FM-19-03D INPAQ TECHNOLOGY CO., LTD 2023/04/07 UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：黃建棠 CHECKED BY：鄭榮謀 DESIGNED BY：陳彥吉 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-974 DOCUMENT ENS000177480 SPEC REV. NO. P4 PAGE 1 OF 8 Embedded Dual-Band Antenna for WA-P-LB-02-974 1.Explanation of part number： (1)(2 )(3 )(4) (5) (1)Product Type：Wireless Antenna (2)Material：PCB (3)Frequency/Band code：2400-2500MHz / 5150-5850MHz (4)Coaxial Cable Type：Black (5)Suffix：974 2.Electrical Specification： 2-1. Frequency Band： Band Frequency WIFI 2400-2500MHz / 5150-5850MHz 2-2. Impedance： 50 ohm nominal 2- 3. Matching circuit ： None W A P L B 0 2 9 7 4 INPAQ TECHNOLOGY CO., LTD 2023/04/07 UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：黃建棠 CHECKED BY：鄭榮謀 DESIGNED BY：陳彥吉 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-974 DOCUMENT ENS000177480 SPEC REV. NO. P4 PAGE 2 OF 8 2-4. List： Antenna Physical Type: PCB Antenna Antenna Radiation Type: PIFA Connector Type I-PEX Connector for 1.13 cable Cable Type OD 1.13 RF Cable Impedance 50Ω Polarization Linear Frequency 2.40～2.50 GHz 5.15～5.85 GHz Return Loss 2.40～2.50 GHz -10dB(max) 5.15～5.85 GHz Peak gain(dBi) 2.40～2.50 GHz 3.68 dBi(Max) 5150～5250 MHz 4.36 dBi(Max) 5250～5350 MHz 4.36 dBi(Max) 5470～5725 MHz 4.40 dBi(Max) 5725～5850 MHz 4.32 dBi(Max) Cable length 150 mm, Black 2-5. Return Loss： INPAQ TECHNOLOGY CO., LTD 2023/04/07 UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：黃建棠 CHECKED BY：鄭榮謀 DESIGNED BY：陳彥吉 APPROVED BY：謝立庭 TITLE：Embedded Dual-Band Antenna for WA-P-LB-02-974 DOCUMENT ENS000177480 SPEC REV. NO. P4 PAGE 3 OF 8 2-6. Peak gain and Effciency ： 2-7. 2D Radiation pattern ： INPAQ TECHNOLOGY CO., LTD 2023/04/07 UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝N/A X.X＝N/A X.XX＝N/A ANGLES＝N/A HOLEDIA＝N/A SCALE：N/A UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：黃建棠 CHECKED BY：鄭榮謀 DESIGNED BY：陳彥吉 APP…

Text truncated - open the document above for the full version.
