Page 1 CONSTRUCTION PHOTOS OF EUT Model No. : Y-R0016 Page 2 Page 3

(Fig.1) FCC ID: JNZYR0016 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Page 1 CONSTRUCTION PHOTOS OF EUT Model No. : Y-R0016 Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10

Report No.: RF990901E04 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990901E04 MODEL NO.: Y-R0016 FCC ID: JNZYR0016 RECEIVED: Sep. 01, 2010 TESTED: Sep. 02 to 04, 2010 ISSUED: Sep. 08, 2010 APPLICANT: LOGITECH FAR EAST LTD. ADDRESS: #2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. ISSUED BY : Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 25 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990901E04 2 Report Format Version 3.0.1 Table of Contents 1 CERTIFICATION.................................................................................................3 2 SUMMARY OF TEST RESULTS........................................................................4 2.1 MEASUREMENT UNCERTAINTY.....................................................................4 3 GENERAL INFORMATION.................................................................................5 3.1 GENERAL DESCRIPTION OF EUT..................................................................5 3.2 DESCRIPTION OF TEST MODES.....................................................................6 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL...................6 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS...................................8 3.4 DESCRIPTION OF SUPPORT UNITS...............................................................9 3.5 CONFIGURATION OF SYSTEM UNDER TEST...............................................9 4 TEST PROCEDURES AND RESULTS............................................................10 4.1 RADIATED EMISSION MEASUREMENT........................................................10 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT....................................10 4.1.2 TEST INSTRUMENTS......................................................................................11 4.1.3 TEST PROCEDURES......................................................................................12 4.1.4 DEVIATION FROM TEST STANDARD............................................................12 4.1.5 TEST SETUP....................................................................................................13 4.1.6 EUT OPERATING CONDITIONS.....................................................................13 4.1.7 TEST RESULTS................................................................................................14 4.2 CONDUCTED - OUT BAND MEASUREMENT...............................................21 4.2.1 LIMITS OF CONDUCTED - OUT BAND MEASUREMENT............................21 4.2.2 TEST INSTRUMENTS......................................................................................21 4.2.3 TEST PROCEDURE.........................................................................................21 4.2.4 DEVIATION FROM TEST STANDARD............................................................21 4.2.5 EUT OPERATING CONDITION.......................................................................21 4.2.6 TEST RESULTS................................................................................................22 5 INFORMATION ON THE TESTING LABORATORIES....................................24 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB...........................................................25 Report No.: RF990901E04 3 Report Format Version 3.0.1 1 CERTIFICATION PRODUCT : 2.4GHz Cordless keyboard BRAND NAME : Logitech MODEL NO. : Y-R0016 TESTED : Sep. 02 to 04, 2010 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : LOGITECH FAR EAST LTD. STANDARDS : 47 CFR Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 The above equipment (Model: Y-R0016) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 08, 2010 ( Carol Liao, Specialist ) TECHNICAL ACCEPTANCE : , DATE: Sep. 08, 2010 ( Hank Chung, Deputy Manager ) APPROVED BY : , DATE: Sep. 08, 2010 (May Chen, Deputy Manager ) Report No.: RF990901E04 4 Report Format Version 3.0.1 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Paragraph Test Type Result Remark 15.207 Conducted Emission Test NA Not Applicable 15.249 Radiated Emission Test PASS Meet the requirement of limit. Minimum passing margin is -8.0dB at 2400.00MHz 15.249 Conducted - Out Band Measurement PASS Meet the requirement of limit 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Value Radiated emissions (30MHz-1GHz) 3.94 dB Radiated emissions (1GHz -18GHz) 2.49 dB Radiated emissions (18GHz -40GHz) 2.70 dB Report No.: RF990901E04 5 Report Format Version 3.0.1 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUC…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
