JNZYR0047B2.4GHz Cordless Keyboard

Logitech® Illuminated Living-Room Keyboard K830 Setup Guide Guide d’installation Logitech Illuminated Living-Room Keyboard K830 2 English                      3Français                      13 www.logitech.com/support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Logitech Illuminated Living-Room Keyboard K830 English 3 Know your product 7 11 8 9 1 12 13 23 4 56 10 Logitech® Illuminated Living-Room Keyboard K830 Setup Guide Guide d’installation 1. Left mouse click 2. Micro-USB charging port 3. On/off power switch 4. Function keys 5. Automatic light sensor 6. Battery status and Bluetooth® connection indicator 7. Hot keys 8. Touchpad 9. Mouse click buttons 10. Product documentation 11. Unifying receiver 12. USB extender cable 13. Micro-USB charging cable Logitech Illuminated Living-Room Keyboard K830 4 English Setting up your keyboard Using the Unifying receiver 1. Plug in the Unifying receiver into your laptop or desktop computer. You can use the USB extender cable provided to position the Unifying receiver away from metallic objects or devices that may cause interference. USB * Note: You can also use your keyboard to control an Android™ enabled TV. Refer to the documentation supplied by your TV manufacturer for compatibility information and further connection details. *HDMI cable is not included. 2. Turn on your keyboard. Logitech Illuminated Living-Room Keyboard K830 English 5 Using Bluetooth Smart without the Unifying receiver You have the option to connect your keyboard to a compatible Windows® 8 computer or TV running Android 5.0 or later using the latest generation Bluetooth Smart technology. To pair your Bluetooth Smart Ready PC or TV and keyboard: 1. Turn on your keyboard and ensure that the Unifying receiver is not connected to your PC or TV. 2. Press the Fn + Del buttons simultaneously. The Bluetooth connection indicator blinks to indicate the keyboard is discoverable. It remains discoverable for 2 minutes. 3. Complete Bluetooth Smart pairing on your compatible Windows® 8 computer: a. Go to Control Panel Devices and Printers. b. Click ‘Add a device’. A list of discoverable devices is displayed. c. Select ‘K830’ from the list. d. Click ‘Next’, and follow the on-screen instructions. You can also pair your keyboard to an Android enabled TV. Refer to the documentation supplied by your TV manufacturer for further connection details. Logitech Illuminated Living-Room Keyboard K830 6 English Bluetooth Smart connection indicator After successfully pairing the keyboard with your computer or TV, the Bluetooth Smart connection indicator turns solid green. LightDescription Blinking greenFast: The keyboard is in discovery mode, ready for pairing. Slow: The keyboard is trying to reconnect to your computer or TV. Software for your keyboard Download and install the Logitech software for your keyboard to: • Customize the function keys. • Adjust your touchpad experience. You can modify the pointer speed, adjust scrolling, and disable touchpad tap. • Connect additional devices to your Unifying receiver. • View videos explaining gestures and providing information about your keyboard’s behavior. • Reverse the requirement to press the Fn key when using function keys. Logitech software is available at www.logitech.com/support/k830. Logitech Illuminated Living-Room Keyboard K830 English 7 Using your keyboard Keyboard backlighting When you start using your keyboard, the automatic light sensor detects the light level in the room and adjusts the keyboard backlight intensity accordingly. There are three intensity levels: • In bright light: no keyboard illumination. • In poor light: full intensity backlight. • In the dark: half intensity backlight. You can manually override the automatic backlighting setting. Press the key to cycle between the three intensity levels. Please note: • When your battery charge level is low, backlighting turns off automatically to conserve battery power. • Automatic backlight control is restored automatically if the keyboard is idle for 30 minutes or more, or after turning the keyboard off and back on. Touchpad gestures 1 2 3 4 To point, scroll and click: 1. Point and slide one finger anywhere on the touchpad to move the screen pointer. 2. Scroll with two fingers, up or down. 3. Press for left mouse click.* 4. Press for right mouse click. *You can also tap the touchpad surface to perform a click. Note: To disable gestures and touchpad tap, press the Fn key plus the left mouse click button. To re-enable gestures and touchpad tap, press the Fn key plus the left mouse click button again. Logitech Illuminated Living-Room Keyboard K830 8 English Recharging your keyboard Your keyboard is rechargeable. There are no batteries to be replaced. A three-hour charge provides up to 10 days of use when you type about two hours a day with backlight on, or about one year without backlight. Note: The use you get between charges may vary depending on your usage pattern. When you turn on the keyboard the battery indicator shows the charge level. IndicatorExplanation Blinking greenThe battery is charging. Solid greenThe battery has adequate charge, or charging is complete. Blinking redBattery power is low. Recharge the battery. To charge the battery, connect the keyboard to a computer using the Micro-USB charging cable supplied. The battery indicator blinks green while charging takes place. Charge until the indicator light stops blinking. You can use the keyboard while it charges. Note: If the battery power is low (indicator blinking red), the keyboard backlight is disabled. USB Logitech Illuminated Living-Room Keyboard K830 English 9 Function keys Adjust backlight intensity Back Home Switch applications Menu Search Show / Hide desktop Maximize window Launch media player Previous track Play/pause track Next track Fn + ins: PC sleep Fn + del: Bluetooth Smart Connection Fn + backspace: Print screen Fn + caps lock: Scroll lock F…

Text truncated - open the document above for the full version.

English Important ergonomic information. Long periods of repetitive motion using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiffness in your hands, wrists, arms, shoulders, neck, or back, see a qualified health professional. For more information, please read the Comfort Guidelines located on the Logitech® web site at http://www.logitech.com/comfort, or on the Logitech® Software CD. Do not immerse product in any liquid or expose it to heat or moisture. There are no serviceable parts. WARNING! Logitech gaming products should be used under the supervision of an adult. WARNING! CHOKING HAZARD: Logitech steering wheels have small parts and are not for children under 3 years. Battery warning! Risk of explosion or personal injury if batteries are replaced by incorrect type, mutilated, or exposed to conducting materials, liquid, fire, or heat (above 54° C or 130° F). Do not use or recharge damaged rechargeable batteries. Do not mix battery types. Dispose of spent or damaged batteries according to manufacturer instructions and local laws. Power supply warning! Caution electric shock/fire hazard! For indoor use only. Do not expose to moisture, liquid, or heat. Do not use any other power supply with your Logitech product. Device paring limitations. Some Unifying devices may be limited in the number of times they can be paired (connected) to a Unifying receiver. Although the number of parings possible may vary, the minimum number of available pairings is 45. Accessory statement. Your product is safety approved. Use only with listed ITE computers. Operating temperature. Maximum 40°C (104° F). FCC—United States This hardware device complies with Part 15 of the FCC Rules. Operation is subject t o the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference tha t may cause undesired operation. Compliance Information Statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the receiving antenna. 2) Increase the separation between the equipment and receiver. 3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4) Consult the dealer or an experienced radio/ TV technician for help. Modifications to this product not authorized by Logitech could void y our right to use or operate this product by the FCC. Where shielded interface cables or accessories have been provided with the product or specified additional components or accessories elsewhere defined to be used with the installation of the product, they must be used in order to ensure compliance with FCC regulations. Canada (IC) Statements: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Corded products: This Class B digital apparatus complies with Canadian ICES-003. Cordless (Radio Transmitter) products: Section A. RSS-310 (27 MHz transmitters and receivers): This Category II radio communication device complies with Industry Canada Standard RSS-310. Section B. RSS-210 (2.4 GHz transmitters or transceivers): This Category I radio communication device complies with RSS-210 of Industry Canada. Logitech compliance For additional compliance information, go to http://www.logitech.com/compliance. Logitech hardware product limited warranty Logitech warrants to the original purchaser that your Logitech hardware product shall be free from defects in material and workmanship for the period of time, identified on your product package and/or contained in the user documentation, from the date of purchase. You may also find this information by selecting your product in the Online Support section of our website at www.logitech.com/support. Except where prohibited by applicable law, this warranty is nontransferable and is limited to the original purchaser. This warranty gives you specific legal rights, and you may also have other rights that vary under local laws. Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, (1) to repair or replace the hardware, or (2) to refund the price paid, provided that the hardware is returned to the point of purchase or such other place as Logitech may direct with a copy of the sales receipt or dated itemized receipt. Shipping and handling charges may apply, except where prohibited by applicable law. Logitech may, at its option, use new or refurbished or used parts in good working condition to repair or replace any hardware product. Any replacement hardware product will be warranted for the remainder of the original warranty period or thirty (30) days, whichever is longer or for any additional period of time that may be applicable in your jurisdiction. This warranty does not cover problems or damage resulting from (1) accident, abuse, misapplica…

Text truncated - open the document above for the full version.

Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A1 OF A5 TEL : 886-3-327-3456 FAX : 886-3-327-0973 APPENDIX A. Photographs of EUT Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A2 OF A5 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A3 OF A5 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A4 OF A5 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A5 OF A5 TEL : 886-3-327-3456 FAX : 886-3-327-0973 USB cable

Label size: 140mm X 30mm FCC ID: JNZYR0047B

Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A1 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 APPENDIX A. Photographs of EUT Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A2 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A3 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A4 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A5 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A6 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A7 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A8 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A9 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A10 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A11 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A12 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No.:3D1752-01 SPORTON International Inc. PAGE NUMBER : A13 OF A13 TEL : 886-3-327-3456 FAX : 886-3-327-0973

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company LOGITECH FAR EAST LTD. Applicant Address No. 2, Creation Road IV Science-Based Industrial Park Hsin-Chu, Taiwan FCC ID JNZYR0047B Manufacturer’s company LOGITECH FAR EAST LTD. Manufacturer Address No. 2, Creation Road IV Science-Based Industrial Park Hsin-Chu, Taiwan Product Name 2.4GHz Cordless Keyboard Brand Name Logitech Model Name Y-R0047b Test Rule Part(s) 47 CFR FCC Part 15 Subpart C § 15.249 Test Freq. Range 2400 ~ 2483.5MHz Received Date Feb. 26, 2015 Final Test Date Mar. 09, 2015 Submission Type Original Equipment Statement The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2013 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR3D1752-01AA Report Format Version: 01 Page No. : i of ii FCC ID: JNZYR0047B Issued Date : Mar. 16, 2015 Table of Contents 1. VERIFICATION OF COMPLIANCE ....................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT .......................................................................................................................... 2 3. GENERAL INFORMATION .................................................................................................................................. 3 3.1. Product Details....................................................................................................................................................................................3 3.2. Accessories .........................................................................................................................................................................................3 3.3. Table for Filed Antenna.......................................................................................................................................................................3 3.4. Table for Carrier Frequencies .............................................................................................................................................................4 3.5. Table for Test Modes ...........................................................................................................................................................................4 3.6. Table for Testing Locations..................................................................................................................................................................5 3.7. Table for Supporting Units ...................................................................................................................................................................5 3.8. Test Configurations .............................................................................................................................................................................6 4. TEST RESULT ..................................................................................................................................................... 9 4.1. AC Power Line Conducted Emissions Measurement...........................................................................................................................9 4.2. Field Strength of Fundamental Emissions Measurement ...................................................................................................................13 4.3. 20dB Spectrum Bandwidth Measurement ........................................................................................................................................16 4.4. Radiated Emissions Measurement ....................................................................................................................................................19 4.5. Band Edge Emissions Measurement .................................................................................................................................................29 4.6. Antenna Requirements .....................................................................................................................................................................31 5. LIST OF MEASURING EQUIPMENTS ................................................................................................................... 32 6. MEASUREMENT UNCERTAINTY.......................................................................................................................... 33 APPENDIX A. PHOTOGRAPHS OF EUT.........................................................................................................A1 ~ A17 APPENDIX B. TEST PHOTOS.......................................................................................................................... B1 ~ B6 Report No.: FR3D1752-01AA Report Format Version: 01 Page No. : ii of ii FCC ID: JNZYR0047B Issued Date : Mar. 16, 2015 History of This Test Report REPORT NO. VERSION DESCRIPTION ISSUED DATE FR3D1752-01AA Rev. 01 Initial issue of report Mar. 16, 2015 47 CFR FCC Part 15 Subpart C 15.205(a) 15.209(a) Further, this requirement does not apply to intentional radiators that must be professionally installed. Report No.: FR3D1752-01AA Report Format Version: 01 Page No. : 2 of 33 FCC ID: JNZYR0047B Issued Date : Mar. 16, 2015 2. SUMMARY OF THE TEST RESULT Applied Standard: 47 CFR FCC Part 15 Subpart C Part Rule Section Description of Test Result Under Limit 4.1 15.207 A…
