Technical Specifications
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|
| 18 | 27 | 779.5 MHz - 784.5 MHz | 169.00 mW | 4M49D7W | 2.5
ppm |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesModular approval. Power output is conducted. Values listed for LTE operations are for the highest power
and the widest bandwidth for each band and modulation.
This device supports LTE bandwidths of 1.4/3/5/10 MHz in Band 5 (Part 22), 1.4/3/5/10/15/20 MHz in Band 2 and
Band 4 (Part 24 and 27), 5 MHz and 10 MHz in Band 13 (Part 27).
The maximum antenna gain is 4.9dBi in 1850-1910 MHz, 3.8dBi in 824-849 MHz, 4.0dBi in 1710-1755 MHz and 3.7dBi
in 777-787 MHz.
This transmitter is approved for use in mobile RF exposure use condition with the antenna(s) installed
providing a separation distance of at least 20 cm from all persons.
