JOYKWS2000SWLL PHS 1-Line Subscriber Terminal

FCC ID: JOYKWS2000S September 25, 2000 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attention:Applications Examiner Applicant:Kyocera Corporation 2-1-1 Kagahara, Tsuzuki-ku, Yokohama-shi 224 Japan Equipment:WLL Single Line Subscriber Unit (SLSU), KWS-2000SL FCC ID: JOYKWS2000S Specification:for a 47 CFR 24 Licensed Certification Dear Examiner: The following application for Grant of Equipment Authorization is presented on behalf of Kyocera Corporation. for the Licensed Certification of their Model: KWS-2000SL. Enclosed, please find a complete data and documentation package demonstrating that this device complies with the technical requirements of 47 CFR 24. If you have any questions, please contact the undersigned, who is authorized to act as Agent. Sincerely, Chris Harvey, Director EMC Laboratory MET Laboratories, Inc. FCC ID: JOYKWS2000S MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE !! BALTIMORE, MARYLAND 21230-3432 !! PHONE (410) 354-3300 !! FAX (410) 354-3313 ENGINEERING TEST REPORT in support of the Application for Grant of Equipment Authorization EQUIPMENT: WLL Single Line Subscriber Unit KWS-2000SL FCC ID:JOYKWS2000S Specification:47 CFR 24 On Behalf of the Applicant:Kyocera Corporation 2-1-1, Kagahara, Tsuzuki-ku Yokohama-shi 224 Japan Manufacturer:Kyocera Corporation 2-1-1, Kagahara, Tsuzuki-ku Yokohama-shi 224 Japan Manufacturer’s RepresentativeMr.Nobuyuki hayashida Test Date(s):August 14-25, 2000 ENGINEERING STATEMENT I ATTEST: the measurements shown in this report were made in accordance with the procedures indicated, and that the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements. On the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 24 of the FCC Rules under normal use and maintenance. _____________________________ Liming Xu Project Engineer, MET Laboratories FCC ID: JOYKWS2000S EMC1366B- 3 -September 25, 2000 1.0INTRODUCTION The following data is presented on behalf of the Applicant, Kyocera Corporation, as verification of the compliance of the Kyocera KWS-2000SL to the requirements of 47 CFR 24. 2.0TEST SITE All testing was conducted at AKZO KASHIMA MATSUDA Site. The radiated emissions measurements were performed on a three-meter open area test site (OATS). A complete site description is on file with the FCC Laboratory Division as 31040/SIT/AKZO and also on file with the NVLAP No. 100290-4. 3.0TEST EQUIPMENT USED ManufacturerEquipmentCalibration Due Date @ time of testing Cal. Interval Hewlett Packard8563E Spectrum Analyzer04/04/01annual HPPre-Amp 8449B4/21/01annual A.R.A.BB Antenna LPB-2513/A05/15/01annual EMCODouble Ridge Guided Horn04/05/01annual SUHNER3dB Attenuator 6803.17.B01/14/01annual ADVANTESTR3271A Spectrum Analyzer01/31/02annual ADVANTESTR5363 Frequency Counter09/30/01annual 4.0EQUIPMENT UNDER TEST CONFIGURATION The WLL Single Line Subscriber Unit (SLSU) was configured with AC power supply modules and an external PC to program the EUT to output a PHS RF signal. The EUT with host external computer was configured for maximum signal gain and bandwidth. The EUT was operated in a manner representative of the typical usage of the equipment. During all testing, system components were manipulated within the confines of typical usage to maximize each emission. 5.0TEST TYPE(S) 5.1Radiated Emissions: 47 CFR2.1053, , 24.238(a) 5.2Occupied Bandwidth: 47 CFR2.1049 5.3RF Power Output: 47 CFR 2.1046, 24.232(a), (c) 5.4Spurious Emission at Antenna Terminals: 47 CFR 2.1051, 24.238(a) 5.5Spurious Emission at Antenna Terminals at Frequency Block edges +/- 1 MHz, 47 CFR 2.1051, 24.238(b) 5.6Frequency Stability over temperature variations: 47 CFR 2.1055(a)(1) 5.7Frequency Stability over variations in supply voltage: 47 CFR 2.1055(d)(1) 5.8AC Line Conducted Emissions: 47 CFR 15.107 5.9 Modulation Characteristics: 47 CFR 2.1047(a) FCC ID: JOYKWS2000S EMC1366B- 4 -September 25, 2000 E(V/m) 1m ' 49.2X0.07 1 E(V/m) 1m '1.8558V/mor125.4dbμV/m@1m 43%10Log(0.07)'31.46dB 125.4dBμV/m&31.46dB'93.9dBμV/m@1m E(V/m) 3m ' 49.2X0.07 3 E(V/m) 3m '0.6186V/mor115.4dbμV 115.4&31.46'83.9dBμV/m@3m 6.0TEST RESULTS 6.1TEST TYPE: Radiated Emissions 6.1.1TECHNICAL SPECIFICATION:2.1053; 24.238(a) 6.1.2TEST DATE(S):8/21/00 6.1.3MEASUREMENT PROCEDURES: As required by §2.1053, field strength of spurious radiation measurements were made in accordance with the general procedures of ANSI C63.4-1992 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". Preliminary radiated emission measurements were performed inside a shielded chamber with all digital signal generators on and terminated. The frequency list from the preliminary measurements was used as a guide for making final measurements on a 3 meter open area test site. The unit was scanned over the frequency range of the system operation frequency to 20 GHz. The Radiated Spurious Emissions Limit is obtained by the following: Based on an output power (as measured at the output of the Amplifier) of 0.07 watts: P o = 0.07 W As per 2.1053 (a), it is assumed this power is to be fed to a half-wave tuned dipole. Using a conversion formula for distance, the field strength at one meter can be derived: As per 24.238(a), the spurious emissions must be attenuated by 43 + 10log(P) which is: Therefore, the limit for spurious emissions is: At 3 meters measurement distance, the limit is; According to 24.238(a), all signals must be attenuated by 43.41 dB. Therefore, the limit for spurious emissions for a test distance of 3 meters is: FCC ID: JOYKWS2000S EMC1366B- 5 -September 25, 2000 6.1.4RESULTS: Frequency (MHz) PolarityHeight (m) Raw Amplitude (dBμV) A.C.F. (dB/m) D.C.F. (dB) Correct…
