JPZ0011Lighting Control Transmitter

Lutron Electronics Company Inc

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: May 28, 2003
Application Purpose: Original Equipment
Date of Application: Dec 13, 1999
Equipment Note: Lighting Control Transmitter
Frequency Range: 433.77000000 - 434.07000000
Company: Lutron Electronics Company Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

75979 FCC ID: JPZ0011 RB-REP 1 User’s Manual (instruction sheet) 75979 FCC ID: JPZ0011 RB-REP 2 User’s Manual (instruction sheet)

Block Diagram

75976 FCC ID: JPZ0011 RB-REP 1 Block Diagram

Cover Letter(s)

correctid.doc May 8, 2001 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Dear Sir / Madam, Per my conversation with Bette Taube today, this is a correction to Form 731. The FCC identifier on Form 731 is not correct as electronically submitted. The FCC identifier was incorrectly entered as follows: JPZRB-REP The correct FCC identifier is as follows: JPZ0011 (where 00 are zeroes) Sorry for any inconvenience this may have caused. Very best regards, Robert Spehalski, Senior Project Engineer Global Standards Lutron Electronics Co., Inc.

Cover Letter(s)

LUTRON ELECTRONICS CO., INC.75983 7200 SUTER ROAD TELEPHONE 610-282-3800 COOPERSBURG, PA 18036-1299 FAX 610-282-6314 May 8, 2001 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Dear Sir / Madam: This submittal is in support of an Application for Certification in accordance with Part 2, Subpart J and Part 15, Subpart C of the Federal Communications Commission’s Rules and Regulations. The equipment is identified as the Lutron RB-REP (FCC ID: JPZ0011). The submitted material is organized in separate files as listed below: ID Label/Location InfoRBrepLAB.doc External PhotosRBrepEXP.doc Block DiagramsRBrepBLK.doc SchematicsRBrepSCH.doc Test Report5225e.pdf Test Set-up Photos5225e.pdf User’s ManualRBrepINS.doc Internal PhotosRBrepINP.doc Operational DescriptionRBrepOPD.doc Respectfully Submitted, Mark Clouser, Engineering

External Photos

75982 FCC ID: JPZ0011 RB-REP 1 External Photos (top view) 75982 FCC ID: JPZ0011 RB-REP 2 External Photos (bottom view)

ID Label/Location Info

75975 FCC ID: JPZ0011 RB-REP 1 ID Label/Location Info (proposed FCC ID label) 75975 FCC ID: JPZ0011 RB-REP 2 ID Label/Location Info (bottom view)

Internal Photos

75980 FCC ID: JPZ0011 RB-REP 1 Internal Photos (combined PCB) 75980 FCC ID: JPZ0011 RB-REP 2 Internal Photos (RF and power supply section) 75980 FCC ID: JPZ0011 RB-REP 3 Internal Photos (switch and micro section)
