JPZ0012Wireless Lighting Control
Lutron Electronics Company Inc
Click to zoom
Application Details
- Equipment Class
- DSC - Part 15 Security/Remote Control Transmitter
- Date of Grant
- Jun 19, 2003
- Application Purpose
- Original Equipment
- Date of Application
- Dec 15, 1999
- Equipment Note
- Wireless Lighting Control
- Frequency Range
- 433.77000000 - 434.07000000
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
76515 FCC ID: JPZ0012 RB-600LM 1 User’s Manual (instruction sheet) 76515 FCC ID: JPZ0012 RB-600LM 2 User’s Manual (instruction sheet)
Block Diagram
76511 FCC ID: JPZ0012 RB-600LM 1 Block Diagram
Cover Letter(s)
LUTRON ELECTRONICS CO., INC.76507 7200 SUTER ROAD TELEPHONE 610-282-3800 COOPERSBURG, PA 18036-1299 FAX 610-282-6314 May 8, 2001 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Dear Sir / Madam: This submittal is in support of an Application for Certification in accordance with Part 2, Subpart J and Part 15, Subpart C of the Federal Communications Commission’s Rules and Regulations. The equipment is identified as the Lutron RB-600LM (FCC ID: JPZ0012). The submitted model number, RB-600LM, is being used for brevity, and encompasses the following Lutron model numbers: RB-1000LM, RBLV-600LM, RBLV-1000LM, & RBS-8LM. The submitted material is organized in separate files as listed below: ID Label/Location InfoRBdimLAB.doc External PhotosRBdimEXP.doc Block DiagramsRBdimBLK.doc SchematicsRBdimSCH.doc Test Report5226e.pdf Test Set-up Photos5226e.pdf User’s ManualRBdimINS.doc Internal PhotosRBdimINP.doc Operational DescriptionRBdimOPD.doc Respectfully Submitted, Robert Spehalski, Senior Project Engineer Lutron Electronics Co., Inc
External Photos
76510 FCC ID: JPZ0012 RB-600LM 1 External Photos (top view) 76510 FCC ID: JPZ0012 RB-600LM 2 External Photos (bottom view) 76510 FCC ID: JPZ0012 RB-600LM 3 External Photos (antenna)
ID Label/Location Info
76508 FCC ID: JPZ0012 RB-600LM 1 ID Label/Location Info (proposed FCC ID label) 76508 FCC ID: JPZ0012 RB-600LM 2 ID Label/Location Info (side view)
ID Label/Location Info
82747 FCC ID: JPZ0012 RB-600LM 1 Proposed Unit Label (with JPZ number) 82747 FCC ID: JPZ0012 RB-600LM 2 Proposed location of unit label (left side view) 82747 FCC ID: JPZ0012 RB-600LM 3 Proposed FCC Warning Label 82747 FCC ID: JPZ0012 RB-600LM 4 FCC Warning Label location (right side view)
Internal Photos
76516 FCC ID: JPZ0012 RB-600LM 1 Internal Photos ( PCB top side) 76516 FCC ID: JPZ0012 RB-600LM 2 Internal Photos (RF and power supply section)
Contact Information
Applicant
Daniel Schlegel(Standards Compliance Supervisor)
Test Firm
Radiation Sciences IncorporatedDaniel Signore
215-256-4133Fax: 215-256-0775
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 433.77 MHz - 434.07 MHz | - |
