JPZ0016Lighting Control System
Lutron Electronics Company Inc
Click to zoom
Application Details
- Equipment Class
- DSC - Part 15 Security/Remote Control Transmitter
- Date of Grant
- Feb 01, 2000
- Application Purpose
- Original Equipment
- Date of Application
- Dec 29, 1999
- Equipment Note
- Lighting Control System
- Frequency Range
- 433.77000000 - 434.07000000
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Users Manual
78873 FCC ID: JPZ0016 RB-IR 1 User’s Manual (instruction sheet) 78873 FCC ID: JPZ0016 RB-IR 2 User’s Manual (instruction sheet) 78873 FCC ID: JPZ0016 RB-IR 3 User’s Manual (instruction sheet)
Block Diagram
78870 FCC ID: JPZ0016 RB-IR 1 Block Diagram
Cover Letter(s)
LUTRON ELECTRONICS CO., INC.78867 7200 SUTER ROAD TELEPHONE 610-282-3800 COOPERSBURG, PA 18036-1299 FAX 610-282-3691 May 4, 2001 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Dear Sir / Madam: This submittal is in support of an Application for Certification in accordance with Part 2, Subpart J and Part 15, Subpart C of the Federal Communications Commission’s Rules and Regulations. The equipment is identified as the Lutron RB-IR (FCC ID: JPZ0016). The submitted material is organized in separate files as listed below: ID Label/Location InfoRBdiLAB.doc External PhotosRBdiEXP.doc Block DiagramsRBdiBLK.doc SchematicsRBdiSCH.doc Test Report5229e.pdf Test Set-up Photos5229e.pdf User’s ManualRBdiINS.doc Internal PhotosRBdiINP.doc Operational DescriptionRBdiOPD.doc Respectfully Submitted, Scott Miller, ISO Manager Global Standards Department Lutron Electronics Co., Inc.
External Photos
78869 FCC ID: JPZ0016 RB-IR 1 External Photos (top view) 78869 FCC ID: JPZ0016 RB-IR 2 External Photos (bottom view) 78869 FCC ID: JPZ0016 RB-IR 3 External Photos (side view)
ID Label/Location Info
78868 FCC ID: JPZ0016 RB-IR 1 ID Label/Location Info (proposed FCC ID label) 78868 FCC ID: JPZ0016 RB-IR 2 ID Label/Location Info (bottom view)
ID Label/Location Info
80724 FCC ID: JPZ0016 RB-IR 1 ID Label/Location Info (proposed FCC ID label) 80724 FCC ID: JPZ0016 RB-IR 2 ID Label/Location Info (bottom view)
Internal Photos
78874 FCC ID: JPZ0016 RB-IR 1 Internal Photos ( PCB top side) 78874 FCC ID: JPZ0016 RB-IR 2 Internal Photos (PCB bottom side) 78874 FCC ID: JPZ0016 RB-IR 3 Internal Photos (Antenna)
Contact Information
Applicant
Daniel Schlegel(Standards Compliance Supervisor)
Test Firm
Radiation Sciences IncorporatedDaniel Signore
215-256-4133Fax: 215-256-0775
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 433.77 MHz - 434.07 MHz | - |
