JPZ0035Lighting Control Transceiver

Please Read Before Installing RF Lamp Dimmer HRT-3LD 120/127 V~, 50/60 Hz Installation Instructions Overview The HRT-3LD RF Lamp Dimmers are for use with HomeWorkssystems. The dimmer is used to provide local control of table and floor lamps and integrate them into the HomeWorkssystem. HRT-3LD Important Notes Codes:Install in accordance with all local and national electrical codes. Danger: The Lamp Dimmer must not be used to control equipment which is not visible from every control location. It must also not be used to control equipment which could create haz- ardous situations such as entrapment if operated acci- dentally. Examples of such equipment which must not be operated by the Lamp Dimmer include (but are not limit- ed to) motorized gates, garage doors, industrial doors, microwave ovens, heating pads, etc. It is the installer’s responsibility to ensure that the equipment being con- trolled is visible from every control location and that only suitable equipment is connected to the Lamp Dimmer. Overheat Damage:To reduce the risk of overheating and possibly damaging other equipment, do not install to control motor-operated appliances, transformer-sup- plied appliances, or other non-lighting loads. Environment:Ambient operating temperature: 0-40°C, 32-104°F, 0-90% humidity, non-condensing. Indoor use only. It is normal for a Lamp Dimmer to feel warm to the touch during operation. Lamp Type: Lamp Dimmers are designed for use with incandescent, magnetic low-voltage, and tungsten halo- gen lamps only. Do not use to control fluorescent lamps, touch lamps, or lamps with an integral dimmer. For lamps with integral 3-way switches, the switch should be set to full on. Lamp Dimmers may not work with dioded lamps (Sylvania Designer 16 TMor Philips PAR-16TM). Low-Voltage Applications:Use Lamp Dimmers with magnetic (core and coil) low-voltage lamps only. Not for use with electronic (solid-state) low-voltage transformers. Operation of a low-voltage circuit with lamps inoperative or removed may result in transformer overheating and premature failure. Lutron strongly recommends the fol- lowing: a. Do not operate low-voltage circuits without operative lamps in place. 1 b. Replace burned-out lamps as quickly as possible. c. Use transformers that incorporate thermal protection or fused transformer primary windings to prevent trans- former failure due to overcurrent. Load Specifications: Control Min. Load Max. Load HRT-3LD 10 W/VA300 W/VA Cleaning:To clean, wipe with a clean damp cloth. DO NOTuse any chemical cleaning solutions. Cordset: Cordset length is 6 ft. (1.8m). RF Device Placement:RF Lamp Dimmers must be located within 30 ft. (9m) of an RF Signal Repeater or an RF Processor. Setup:RF Lamp Dimmers cannot be controlled by the system until they are addressed and programmed. See the HomeWorksUtility online help. 2 Status LEDs Indicate light level; glow softly as night light when lamp is off 1.Find a suitable location for the Lamp Dimmer. Place the Lamp Dimmer in a convenient and accessible location. Note: Lamp Dimmer must be located within 30 feet of an RF Signal Repeater or an RF Processor. 2.Turn OFF lamp and unplug lamp cord from receptacle. 3.Plug lamp cord into back of Lamp Dimmer plug. 4.Plug Lamp Dimmer into any standard wall out- let. DANGER: To avoid risk of electrical shock, do not open, cut cord or rewire the Lamp Dimmer. DANGER: Unplug Lamp Dimmer when chang- ing light bulbs. CAUTION:This is a POLARIZEDcord set. It has a polarized plug (one blade is wider than the other). The polarized plug is not intended to be mated with nonpolarized outlets (having both slots the same size). A polarized outlet is intend- ed to mate with a polarized plug in only one way (the longer slot with the wider blade). Installation Local Operation Tapswitch Tap on/off Dimming Rocker Press to Brighten Press to Dim 5.Turn lamp switch ON and operate Lamp Dimmer. Pressing the Tapswitch on the Lamp Dimmer will alter- nately turn the lights ON and OFF. The ON level will be the level previously set using the Dimming Rocker to the right of the Tapswitch. The LED that is glowing slightly brighter than the others indicates the level to which the lights will turn ON. Press and hold the top or bottom of the Dimming Rocker to raise or lower the light level. Double-tapping the Tapswitch will turn the lights ON to full. Pressing and holding the Tapswitch for 1/2 second (while ON) activates a 10-sec- ond long fade-to-off. 3 Setting High /Low-End Trim High/Low-End levels may be adjusted with the following procedure: a.Press the Dimming Rocker to set the dimmer to the desired new High/Low-End level (>50% for high-end, <50% for low-end), and then turn OFF. Note: Middle LED cannot be used for High-End or Low-End set- tings. b.While pressing and holdingthe Tapswitch: 1. The dimmer will turn ON to its preset level, 2. The preset LED will light, 3. After 10 seconds, the load will turn OFF and then back ON, 4. The preset LED will begin to flash quickly (for two seconds). c.While the LED is flashing, release the Tapswitch. The LED will remain ON and the dimmer will be at its pre- set level. The High/Low-End value has been changed. High/Low-End levels may be restored to their factory default setting with the following procedure: a.Press the Dimming Rocker to set the dimmer to >50% to reset high-end, or to <50% to reset low-end, and then turn OFF. b.While pressing and holdingthe Tapswitch: 1. The dimmer will turn ON to its preset level, 2. The preset LED will light, 3. After 10 seconds, the load will turn OFF and then back ON, 4. The preset LED will begin to flash quickly (for two seconds) and then turn OFF. Continue holding the Tapswitch for at least six seconds after the LED stops flashing. c.The load will turn OFF then back ON to its preset level. The preset LED will flash (for two seconds) and then remain ON. The default High or Low-End value has been restored. Lutron Electronics Co., Inc. 7200 Suter Road Coopersburg, PA 18036-1299 Mad…

Text truncated - open the document above for the full version.

Block Diagram April, 2006 F 917 I 919 JPZ0035 HRT-3LD Page 1 of 1

26 April, 2006 Subject: Request for Confidentiality – HRT-3LD 2851A-JPZ0035 Dear Sir or Madam: This letter is to formally request confidentiality per the FCC Rules 47 CFR Chapter 1, subpart C, section 0.459 - requests that materials or information submitted to the Commission be withheld from public inspection. For model HRT-3LD, the following items are Lutron Electronics Co., Inc. confidential information that must be withheld from public inspection by potential competitors to protect our business. 1. Schematics 2. Operational Description Thank you for your cooperation. Sincerely, R. S. Spehalski Engineering Leader

23 March, 2006 Attn: Reviewing Engineer MET Laboratories 914 West Patapsco Ave. Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION- HRT-3LD JPZ0035 Dear Sir or Madam: We, the undersigned, hereby authorize MET Laboratories, Inc. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Matthew Cardoni Engineering Technician

FEDERAL COMMUNICATIONS COMMISSION - FCC FORM 731 APPLICATION FOR EQUIPMENT AUTHORIZATION Approved by OMB 3060 - 0934 Expires 02/28/2005 Item 1. Applicant's complete, legal business name: Lutron Electronics Co., Inc. Item 2. Applicant's mailing address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg State: PA Country (if foreign address): USA Zip/Postal Code: 18036-1299 Item 3. FCC ID: Grantee code: JPZ Equipment Product Code (14 characters maximum): 0035 Item 4. Person at the applicant's address to receive grant or for contact: First Name: Matthew Last Name: Cardoni Telephone: 610-282-3800 Ext: 7316 Title: Engineering Technician E-mail: [email protected] Fax No: 610-282-6457 Item 5. Instead of Applicant, the original Grant is authorized to be mailed to: N/A Item 6. Technical Contact: Firm Name: Lutron Electronics Co., Inc. Telephone: 610-282-3800 Ext: 6509 Fax No: 610-282-6457 First Name: Robert Last Name: Bollinger Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 E-mail: [email protected] Item 7. Non-Technical Contact: Firm Name: Lutron Electronics Co., Inc. Telephone: 610-282-3800 Ext: 7424 Fax No: 610-282-6457 First Name: Robert Last Name: Spehalski Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 E-mail: [email protected] Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules? If "Yes" see instructions. (please mark as appropriate) √ Yes Ο No Item 9. Does the applicant request that the Commission defer grant of this application pursuant 47 CFR § 0.457(d)(1)(ii)? (See instructions) NO If so, specify date when grant may be issued (MM/DD/YYYY format): Item 10. * Equipment Class: Part 15 Low Power Transceiver, Rx Verified * Description of Product as it is Marketed: Lighting Control Transceiver (NOTE: This text will appear below the equipment class on the grant) Item 11. * Application is for: (please mark as appropriate) √ Original Equipment (See instructions) Ο Change in identification of presently authorized equipment: Original FCC ID: Grant Date (MM/DD/YYYY format): Ο Class II permissive change or modification of presently authorized equipment (See instructions) DOC-FCC009 4/14/2005 Page 1 of 3 Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered "Yes" complete section 12(c). Ο Yes √ No √ Yes Ο No (c) The related application: √ has been granted under the FCC ID listed to the right Ο is in the process of being filed under the FCC ID listed to the right Ο is pending with the FCC under the FCC ID listed to the right FCC ID JPZ0034 Item 13. Name of test firm and contact person on file with the FCC, if different from applicant or contact person: Firm Name: Radiation Sciences Incorporated Last Name: Telephone: 215 256 4133 Ext Fax No. E-mail: Item 14. Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization. N/A Read each certification carefully before answering and signing this application Equipment Specifications: Rule Part Frequency Range (MHz) Power (W) Frequency Tolerance and Units Emission Designator Note Codes 15 431-437 MHz 100 μW +/- 0.25% F7D WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTITUTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503). Item 15. *SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? √ Yes Ο No Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. IN accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. * Signature of Authorized Person Filing: Marie Ann Confroy Title of authorized signature: TCB Administrator DOC-FCC009 4/14/2005 Page 2 of 3 Complete items below if an agent sig…

Text truncated - open the document above for the full version.

Mar/Apr 2006 JPZ0035 HRT-3LD Page 1 of 2 External Photo F 917 I 919 Mar/Apr 2006 JPZ0035 HRT-3LD Page 2 of 2 External Photo (bottom side) F 917 I 919

Mar/Apr 2006 JPZ0035 HRT-3LD Page 1 of 1 ID label location F 917 I 919

Mar/Apr 2006 JPZ0035 HRT-3LD Page 1 of 2 Internal Photo (top side) F 917 I 919 Mar/Apr 2006 JPZ0035 HRT-3LD Page 2 of 2 Internal Photo (bottom side) F 917 I 919

May 2005 JPZ0035 HRT-3LD Page 1 of 2 Test Set-up Photo F 917 I 919 May 2005 JPZ0035 HRT-3LD Page 2 of 2 Test Set-up Photo
