JPZ0039Wireless Roller 64 for HomeWorks

Sivoia QED ™ Wireless Roller 64 ™ for HomeWorks® Installation Instructions Sivoia QEDTM | Wireless Roller 64 for HomeWorks Installation Instructions SIVOIA QED TM Wireless Roller 64 Installation Instructions 1 Tools Required: Tape Measure1/4” Hex-Head Driver Wire Cutter/StripperLevel PliersPower Drill #2 Phillips Screwdriver Sivoia QED ™ Wireless Roller 64 Standard Mounting Brackets with Retaining Screws (5) Mounting Screws (#8x1-3/4" (#8x44mm) Hex Head Screws) (1) 3 Pin Terminal Block (Actual Size) (1) Programming Stylus(1) Screwdriver (2) 4” (102mm) Cable Ties Notes: 1) For Wireless Roller 64 programming refer to the HomeWorks®Illumination Online Help. 2) The Electronic Drive Unit (EDU) will need to be powered to complete installation. Wireless Shades will not function until they are addressed and programmed using the HomeWorks ®Illumination Software. Box Contents: (2) Bracket Leveling Spacer (2) Cable Tie Anchor (2) Antenna Mounting Clips SIVOIA QED TM Wireless Roller 64 Installation Instructions 2 Warning:Incorrect installation can lead to severe injury, follow all installation instructions. Notes: • The Sivoia QED Wireless Roller 64 must be used only with window treatments approved by Lutron. • There must be a clearance of at least 1.3 feet (0.4 meters) between the fully lowered system and any permanent object. • Installation shall be executed by a qualified electrician according to national wiring rules. • Before shade installation, remove any unnecessary cords and disable any equipment not needed for powered operation. The Sivoia QED Wireless Roller 64 has a maximum rated operating time of 8 min. out of 20. • Codes: Install in accordance with all local and national electrical codes. • Environment: Ambient operating temperature: 0-40°C, 32-104°F, 0-90% humidity, non-condensing. Indoor use only. Sivoia QEDTM | Wireless Roller 64 for HomeWorks Installation Instructions (continued) SIVOIA QED TM Wireless Roller 64 Installation Instructions 3 Sivoia QEDTM | Wireless Roller 64 for HomeWorks Installation Instructions (continued) • RF Device Placement: Wireless shades must be located within 30 feet (9m) of an RF Signal Repeater or an RF Processor. The distance between repeater and processor must be less than 60 feet (18m). Wireless shades will not function until they are addressed and programmed. See the HomeWorks Illumination Software Online Help. Wireless shades are programmed with a personal computer using the HomeWorks Illumination Software. 30 feet (9m) 30 feet (9m) SIVOIA QED TM Wireless Roller 64 Installation Instructions 4 1 Confirm System Dimensions 1.1 1 System Width (Bracket to Bracket Width) System Height System Width System Height Compare system dimensions on the package label with the window dimensions to verify appropriate window/shade combination. 1.1 Package Label SIVOIA QED TM Wireless Roller 64 Installation Instructions 5 2 Position the Mounting Brackets Mark the location of the mounting brackets so that they are centered over the window. Note:Bracket to Bracket distance = Fabric Width + 1.5” (38 mm) = System Width. Note:For ceiling and jamb mount, allow clearance to prevent fabric from rubbing against trim, window, top treatment, etc. Note:Wall mount may require blocks (not provided) to clear trim. 2.1 AA A (System Width) SIVOIA QED TM Wireless Roller 64 Installation Instructions 6 3 Install the Mounting Brackets Install the first mounting bracket. 3.1 Install the second mounting bracket. Note:Put a screw in the center of each slot. Use slots as needed to ensure brackets are level and plumb as positioned. 3.2 4 Pre-drill for Cable Run Wall Mount Wall Mount SIVOIA QED TM Wireless Roller 64 Installation Instructions 7 DANGER - Locate and lock breaker to the shade power supply in the OFF position or unplug the power plug-in transformer before doing any wiring. Choose one of the options below to drill for cable access. Note:Cable should exit from wall, ceiling, or jamb on EDU side of system. Note:Leave 12-18” (30-45 cm) of cable exposed. Wall Mount with wires through: A) Wall: 1” in from end of system and .5” from top of bracket B) Ceiling: .5” in from end of system and .5” from mounting wall C) Jamb: 1” from top of bracket and .5” from mounting wall 4.1 ABC SIVOIA QED TM Wireless Roller 64 Installation Instructions 8 4 Pre-drill for Cable Run: (continued) Ceiling Mount Ceiling Mount with wires through: A) Wall: 1” in from end of system and .5” from ceiling B) Ceiling: 1” in from end of system and .5” from back of bracket C) Jamb: 1” from back of bracket and .5” from ceiling 4.2 Ceiling Mount ABC SIVOIA QED TM Wireless Roller 64 Installation Instructions 9 4 Pre-drill for Cable Run: (continued) Jamb Mount Jamb Mount with wires through: A) Wall: .5” from ceiling and .5” from outside of jamb B) Ceiling: .5” from wall and .5” from outside of jamb C) Jamb: .5” from ceiling and .5” from wall 4.3 Jamb Mount ABC SIVOIA QEDTMWireless Roller 64 Installation Instructions 10 5 Wire 3-Pin Terminal Block Strip 2” of jacket off cable run from the wall. 5.1 Wire 3-Pin terminal block (provided) to cable using the included screwdriver. 5.2 To EDU Connector EGND (Pin 3) 24 VAC (Pin 2) 24 VAC (Pin 1) SIVOIA QEDTMWireless Roller 64 Installation Instructions 11 6 Orient the Buttons and Wiring For the following bracket and button orientations, route the wires as shown. 6.1 Note: The buttons should be accessible when the shade is installed Note: The wires may go in either or both of the indicated slots Buttons Either Dir ection Either Dir ection Either Dir ection Either Dir ection SIVOIA QED TM Wireless Roller 64 Installation Instructions 12 7 Mount the Shade Install the idler side of the shade onto its bracket. 7.1 Depress the spring loaded idler by pressing the shade towards the idler, and install the EDU side of the shade onto its bracket. 7.2 SIVOIA QED TM Wireless Roller 64 Installation Instructions 13 8 Adjust the Shade Ensure that the shade is level and centered. 8.1 Adjust shade by remov…

Text truncated - open the document above for the full version.

Marie- I have attached our responses to the requests for additional information from the FCC. 1) Please demonstrate compliance with timing requirements of 15.231a. The transmission time of the SVQ-EDUH1-10 is limited by the embedded firmware in the device. A block diagram on the following page illustrates micro controller control of the Transmitter. Transmissions will occur when one of the following conditions are met: 1) The SVQ-EDUH1-10 will transmit an acknowledgement to a command received from the lighting control system that controls it. 2) The SVQ-EDUH1-10 will transmit a status update when the user presses a button on the SVQ- EDUH1-10. In both cases, the transmission time will be variable, not to exceed 8.7 milliseconds, and is dependent on the information contained in the transmission. 2) Please explain the two frequencies tested. Does this transmitter have variable tune capability or are there two models being sold? The transmitter in the SVQ-EDUH1-10 has variable tune capability, and is controlled via embedded firmware. There is only one model number, SVQ-EDUH1-10, that is capable of transmitting on one of 60 channels. The SVQ-EDUH1-10 leaves the factory tuned to 434.700 MHz, and when it is connected to the lighting control system that it is part of, the lighting control system may send a command to change to different channel. The 60 channels are arranged in order starting at 431.000 MHz, with a spacing of 100 kHz,and ending at 437.000 MHz. The nominal transmitter output power is the same for all channels. 3) Please explain the report statement "The 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver was tested at 431 MHz and 437 MHz for continuous transmission of a CW signal." Transmission with the operational signal is required for compliance testing. Retlif Laboratories who did the testing has indicated that the device was actually tested while operating in its normal pulsed mode. Retlif Laboratories has revised the report to state this. Please see attached report. 4) Please remove power and emission designator from form 731. It is not requested for these types of devices. This has been done. 5) Please provide the factory tune up procedure referenced. Our factory tuning procedure sends each device into constant wave mode and measures the unmodulated carrier frequency. The measured frequency is compared to the ideal frequency and an offset is calculated. This offset is then written into non-volatile memory on the device. The unit is again put into constant wave mode and re-measured to ensure the device is less than +/- 1 kHz from intended carrier frequency when it leaves our factory. Larry Carmen Lutron Electronics

DOC-FCC009 4/14/2005 Page 1 of 2 FEDERAL COMMUNICATIONS COMMISSION - FCC FORM 731 APPLICATION FOR EQUIPMENT AUTHORIZATION Approved by OMB 3060 - 0934 Expires 02/28/2005 Item 1. Applicant's complete, legal business name: Lutron Electronics Co., Inc. Item 2. Applicant's mailing address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg State: PA Country (if foreign address): USA Zip/Postal Code: 18036-1299 Item 3. FCC ID: JPZ0039 Grantee code: JPZ Equipment Product Code (14 characters maximum): 0039 Item 4. Person at the applicant's address to receive grant or for contact: First Name: Larry Last Name: Carmen Telephone: 610-282-3800 Ext: 6760 Title: Senior Electrical Engineer E-mail: [email protected] Fax No: 610-282-7711 Item 5. Instead of Applicant, the original Grant is authorized to be mailed to: N/A Item 6. Technical Contact: Firm Name: Lutron Electronics Co., Inc. Telephone: 610-282-3800 Ext:6760 Fax No: 610-282-7711 First Name: Larry Last Name: Carmen Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 E-mail: [email protected] Item 7. Non-Technical Contact: Firm Name: Lutron Electronics Co., Inc. Telephone: 610-282-3800 Ext: 7424 Fax No: 610-282-6457 First Name: Robert Last Name: Spehalski Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 E-mail: [email protected] Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules? If "Yes" see instructions. (please mark as appropriate) T Yes Ο No Item 9. Does the applicant request that the Commission defer grant of this application pursuant 47 CFR § 0.457(d)(1)(ii)? (See instructions) No If so, specify date when grant may be issued (MM/DD/YYYY format): Item 10. * Equipment Class: DXT * Description of Product as it is Marketed: Wireless Roller 64 for HomeWorks (NOTE: This text will appear below the equipment class on the grant) Item 11. * Application is for: (please mark as appropriate) T Original Equipment (See instructions) Ο Change in identification of presently authorized equipment: Original FCC ID: Grant Date (MM/DD/YYYY format): Ο Class II permissive change or modification of presently authorized equipment (See instructions) DOC-FCC009 4/14/2005 Page 2 of 2 Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered "Yes" complete section 12(c). Ο Yes T No T Yes Ο No (c) The related application: Ο has been granted under the FCC ID listed to the right Ο is in the process of being filed under the FCC ID listed to the right Ο is pending with the FCC under the FCC ID listed to the right FCC ID JPZ0033 JPZ0034 Item 13. Name of test firm and contact person on file with the FCC, if different from applicant or contact person: Firm Name: Retliff Testing Laboratories Last Name: Reitz Telephone631-737-1500 Ext Fax No. 631-737-1497 E-mail:[email protected] Item 14. Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization. N/A Read each certification carefully before answering and signing this application Equipment Specifications: Rule Part Frequency Range (MHz) Power (W) Frequency Tolerance and Units Emission Designator Note Codes 15 431-437 N/A N/A N/A WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTITUTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503). Item 15. *SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? T Yes Ο No Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. IN accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. * Signature of Authorized Person Filing: Larry Carmen Title of authorized signature: Senior Electrical Engineer

Marie Confroy From: Liming Xu Sent: Tuesday, June 20, 2006 8:50 PM To: Marie Confroy Cc: Igor Kekovski Subject: RE: EMC19785 Lutron electronics FCC TCB request for additional information & proposed response Page 1 of 3EMC19785 Lutron electronics FCC TCB request for additional information & proposed r... 6/21/2006 Hello Marie, The Responses to FCC request for information is good Please forward to FCC BR Liming From: Marie Confroy Sent: Tue 6/20/2006 8:40 AM To: Liming Xu Cc: Igor Kekovski Subject: EMC19785 Lutron electronics FCC TCB request for additional information & proposed response <<Responses to FCC request for information.zip>> Hello Liming! Attached please find the documentation submitted by Lutron in response to the FCC's request for additional information. Please review the information and confirm that it is okay for me to go ahead and upload it to the FCC's website. If you believe additional information is required, please let me know exactly what so that I may request it from the customer. Please note that this information has to be approved and uploaded as soon as possible, as our deadline to upload is June 30, 2006. If you have any questions or concerns, please feel free to contact me. Thank you very much! Have a beautiful day! Best Regards, Marie Ann Confroy Quality and Certifications Administrator MET Laboratories (410) 949-1910 [email protected] "You must learn some of my philosophy. Think only of the past as its remembrance gives you pleasure." - Jane Austen -----Original Message----- From: Larry Carmen [mailto:[email protected] ] Sent: Tuesday, June 20, 2006 5:36 AM To: Marie Confroy Subject: RE: FW: Request for additional information Marie- I have updated responses to all of the questions from the FCC, please see attached. At this point we should have all of the information required to reply to the FCC. Please let me know if there is any additional information needed. -Larry Carmen >>> "Marie Confroy" <[email protected]> 6/5/06 1:38:37 PM >>> Larry, The thirty days is the date from which the original request was issued, in this case being 1 June 2006. So, we have to have our response finalized and to the FCC by the end of June. Please let me know if you have any additional questions or concerns. Thanks so much. Have a beautiful day! Best Regards, Marie Ann Confroy Quality and Certifications Administrator MET Laboratories (410) 949-1910 [email protected] -----Original Message----- From: Larry Carmen [mailto:[email protected] ] Sent: Monday, June 05, 2006 1:26 PM To: Marie Confroy Subject: Re: FW: Request for additional information when does our 30 day window to address these expire? >>> "Marie Confroy" <[email protected]> 6/1/06 11:53:23 AM >>> Hello Larry, I received the request for additional information from the FCC below this morning. There are five items that require attention and revised documentation to be uploaded to the FCC. They are as follows: 1) Please demonstrate compliance with timing requirements of 15.231a. 2) Please explain the two frequencies tested. Does this transmitter have variable tune capability or are there two models being sold? 3) Please explain the report statement "The 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver was tested at 431 MHz and 437 MHz for continuous transmission of a CW signal." Transmission with the operational signal is required for compliance testing. 4) Please remove power and emission designator from form 731. It is not requested for these types of devices. 5) Please provide the factor tune up procedure referenced. I have corrected the Form 731 and it is ready for upload. Item 4 is closed. I need you to address items 1,2,3, and 5. Please send the revised documentation or responses to the FCC's request to me in a single e-mail. Be sure that updated exhibits to be uploaded are in PDF form and under 4 MB. Please note that there is a window of thirty days during which we may reply. After thirty days, the application may be dismissed if we have not contacted the FCC with the additional information requested. So, it is important to address these matters and send a formalized response ASAP. Please feel free to contact me if you find you have any questions or concerns. I look forward to receiving your response and the information requested soon, so that we may reply to the FCC and upload all necessary information in a timely and efficient manner. Thank you very much! Have a beautiful day! Best Regards, Page 2 of 3EMC19785 Lutron electronics FCC TCB request for additional information & proposed r... 6/21/2006 Marie Ann Confroy Quality and Certifications Administrator MET Laboratories (410) 949-1910 [email protected] "You must learn some of my philosophy. Think only of the past as its remembrance gives you pleasure." - Jane Austen -----Original Message----- From: Generic Office of Engineering Technology [mailto:[email protected] ] Sent: Thursday, June 01, 2006 11:04 AM To: Marie Confroy Subject: Request for additional information To: Marie Confroy From: Martin Perrine [email protected] FCC Equipment Authorization Branch Re: FCC ID: JPZ0039 Applicant: Lutron Electronics Company Inc Correspondence Reference Number: 29043 731 Confirmation Number: TC417313 Date of Original Email: 06/01/2006 Subject: Request for additional information 1) Please demonstrate compliance with timing requirements of 15.231a. 2) Please explain the two frequencies tested. Does this transmitter have variable tune capability or are there two models being sold? 3) Please explain the report statement "The 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver was tested at 431 MHz and 437 MHz for continuous transmission of a CW signal." Transmission with the operational signal is required for compliance testing. 4) Please remove power and emission designator from form 731. It is not requested for these types of devices. 5) Please provide the factor tune up procedure referenced. The items indicated above must be submitted befor…

Text truncated - open the document above for the full version.

DOC-FCC009 4/14/2005 Page 1 of 2 FEDERAL COMMUNICATIONS COMMISSION - FCC FORM 731 APPLICATION FOR EQUIPMENT AUTHORIZATION Approved by OMB 3060 - 0934 Expires 02/28/2005 Item 1. Applicant's complete, legal business name: Lutron Electronics Co., Inc. Item 2. Applicant's mailing address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg State: PA Country (if foreign address): USA Zip/Postal Code: 18036-1299 Item 3. FCC ID: JPZ0039 Grantee code: JPZ Equipment Product Code (14 characters maximum): 0039 Item 4. Person at the applicant's address to receive grant or for contact: First Name: Larry Last Name: Carmen Telephone: 610-282-3800 Ext: 6760 Title: Senior Electrical Engineer E-mail: [email protected] Fax No: 610-282-7711 Item 5. Instead of Applicant, the original Grant is authorized to be mailed to: N/A Item 6. Technical Contact: Firm Name: Lutron Electronics Co., Inc. Telephone: 610-282-3800 Ext:6760 Fax No: 610-282-7711 First Name: Larry Last Name: Carmen Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 E-mail: [email protected] Item 7. Non-Technical Contact: Firm Name: Lutron Electronics Co., Inc. Telephone: 610-282-3800 Ext: 7424 Fax No: 610-282-6457 First Name: Robert Last Name: Spehalski Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 E-mail: [email protected] Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules? If "Yes" see instructions. (please mark as appropriate) T Yes Ο No Item 9. Does the applicant request that the Commission defer grant of this application pursuant 47 CFR § 0.457(d)(1)(ii)? (See instructions) No If so, specify date when grant may be issued (MM/DD/YYYY format): Item 10. * Equipment Class: DXT * Description of Product as it is Marketed: Wireless Roller 64 for HomeWorks (NOTE: This text will appear below the equipment class on the grant) Item 11. * Application is for: (please mark as appropriate) T Original Equipment (See instructions) Ο Change in identification of presently authorized equipment: Original FCC ID: Grant Date (MM/DD/YYYY format): Ο Class II permissive change or modification of presently authorized equipment (See instructions) DOC-FCC009 4/14/2005 Page 2 of 2 Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered "Yes" complete section 12(c). Ο Yes T No T Yes Ο No (c) The related application: Ο has been granted under the FCC ID listed to the right Ο is in the process of being filed under the FCC ID listed to the right Ο is pending with the FCC under the FCC ID listed to the right FCC ID JPZ0033 JPZ0034 Item 13. Name of test firm and contact person on file with the FCC, if different from applicant or contact person: Firm Name: Retliff Testing Laboratories Last Name: Reitz Telephone631-737-1500 Ext Fax No. 631-737-1497 E-mail:[email protected] Item 14. Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization. N/A Read each certification carefully before answering and signing this application Equipment Specifications: Rule Part Frequency Range (MHz) Power (W) Frequency Tolerance and Units Emission Designator Note Codes 15 431-437 N/A N/A N/A WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTITUTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503). Item 15. *SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? T Yes Ο No Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. IN accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. * Signature of Authorized Person Filing: Larry Carmen Title of authorized signature: Senior Electrical Engineer

External Photo of SVQ-EDUH1-10 April 2006 FCC: JPZ0039 1 of 1 Lutron: SVQ-EDUH1-10 IC: 2851A-JPZ0039

Label Location for SVQ-EDUH1-10 May 2006 Label Location FCC: JPZ0039 1 of 1 Lutron: SVQ-EDUH1-10 IC: 2851A-JPZ0039

Unit Label for SVQ-EDUH1-10 April 2006 FCC: JPZ0039 1 of 1 Lutron: SVQ-EDUH1-10 IC: 2851A-JPZ0039

Internal Photos of SVQ-EDUH1-10 April 2006 FCC: JPZ0039 1 of 1 Lutron: SVQ-EDUH1-10 IC: 2851A-JPZ0039

Test Results No. R-11378 Page 3 of 44 Retlif Testing Laboratories R Test Program Summary Test Results Number: R-11378 Customer: Lutron Electronics Co., Inc. P.O. Number: NP 0058239 Test Sample: 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver Part Number: RF-EDU-10 Model Number: SVQ-EDUH1-10 Test Specification: FCC Part 15, Federal Communications Commissions Part 15, Radio Frequency Devices, Subpart B and Subpart C, Unintentional Radiators. Mode of Operation: (1) The 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver was tested at 431 MHz and 437 MHz for continuous transmission of a CW signal. (2) The 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver was tested in receiver mode (Standby Mode). Acceptability Criteria: Not applicable. Test Methods: The following table depicts the test methods that were performed on the 431 MHz - 437 MHz RF Motorized Roller Shade Transceiver and the corresponding test results: Testing Date(s) Test Method FCC Paragraph Test Results March 24, 2006 Occupied Bandwidth 15.231(c) Complied March 24, 2006 Duty Cycle 15.35 Complied March 27, 2006 Fundamental and Harmonics 15.231(b) Complied March 27, 2006 Spurious 15.109(a), 15.231(b) Complied March 27, 2006 Conducted Emissions 15.107(a), 15.207(a) Complied Test Results No. R-11378 Page 4 of 44 Retlif Testing Laboratories R Revision History Revision Date Pages Affected Test Results No. R-11378 Page 5 of 44 Retlif Testing Laboratories R Occupied Bandwidth 431 MHz Transmitter Test Data Test Results No. R-11378 Page 6 of 44 Retlif Testing Laboratories R Customer Lutron Electronics Co., Inc. Test Sample 431 – 437 MHz RF Motorized Roller Shade Transceiver Part Number RF-EDU-10 Model No.: SVQ-EDUH1-10 Date: March 25, 2006. Tech: R. Soodoo Sheet 1 of 2 Test Method: FCC Part 15, Subpart C, 15.231(c), Occupied Bandwidth. Notes: Measured Bandwidth of 483 kHz does not exceed 0.25% of center frequency at the 20 dBc points (1.076 MHz) Notes: EUT transmitting at 431 MHz. Test Results No. R-11378 Page 7 of 44 Retlif Testing Laboratories R Test Method: FCC Part 15, Subpart C, 15.231(c), Occupied Bandwidth. Notes: Bandwidth does not exceed 0.25% of center frequency at the 20 dBc points (1.076 MHz) Notes: EUT transmitting at 431 MHz. Customer Lutron Electronics Co., Inc. Test Sample 431 – 437 MHz RF Motorized Roller Shade Transceiver Part Number RF-EDU-10 Model No.: SVQ-EDUH1-10 Date: March 25, 2006. Tech: R. Soodoo Sheet 2 of 2 Test Results No. R-11378 Page 8 of 44 Retlif Testing Laboratories R Occupied Bandwidth 437 MHz Transmitter Test Data Test Results No. R-11378 Page 9 of 44 Retlif Testing Laboratories R Customer Lutron Electronics Co., Inc. Test Sample 431 – 437 MHz RF Motorized Roller Shade Transceiver Part Number RF-EDU-10 Model No.: SVQ-EDUH1-10 Date: March 25, 2006. Tech: R. Soodoo Sheet 1 of 2 Test Method: FCC Part 15, Subpart C, 15.231(c), Occupied Bandwidth. Notes: Measured Bandwidth of 468 kHz does not exceed 0.25% of center frequency at the 20 dBc p…

Text truncated - open the document above for the full version.
