JPZ0040Lighting Control Transceiver

RAMC-MFE, RBMC-MFE Setup and Installation Guide For a RadioRA® Multi-Function Entry Master Control ® A Comprehensive Step-by-Step Guide for Installing, Programming, and Operating the Lutron RadioRA® Multi-Function Entry Master Control Note: Please leave this manual with homeowner. Wireless Home Lighting Control English P/N 044-022 RadioRA® Setup Guide for the Entry Master Control 2 Notes on this Manual The procedures to setup a RadioRA® Multi-Function Entry Master Control are contained in this manual. For more information on programming the remainder of your RadioRA® System, or for advanced features, refer to the original RadioRA® Setup Guide (P/N 044-001). Consumer Information Notice This Visor Control System, consisting of a Multi-Function Entry Master Control and a Visor Control transmitter, must only be used to operate visible means of barrier entry such as garage doors and motorized gates. Do not use this Multi-Function Entry Master Control with any garage door opener that lacks the safety stop and reverse feature as required by federal safety standards. (This includes any garage door opener model manufactured before April 1, 1982.) A garage door opener which cannot detect an object, signaling the door to stop and reverse, does not meet current federal safety standards. Using a garage door opener without these features increases risk of serious injury or death. Warning This RadioRA® system must not be used to control equipment, other than lighting, which is not visible from every master or local control location. It also must not be used to control equipment which could create hazardous situations such as entrapment if operated accidentally. Examples of equipment which must not be controlled by this RadioRA ® system when not visible from a Multi-Function Entry Master Control or local control location include (but are not limited to) motorized gates, garage doors, industrial doors, and microwave ovens, heating pads, etc. It is the installer's responsibility to ensure that the equipment, other than lighting, being controlled is visible from every master or local control location and that only suitable equipment is connected to this RadioRA ® system. FCC Information NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by Lutron Electronics Co. could void the user's authority to operate this equipment. Important Application Note The Multi-Function Entry Master Control is a type of Master Control. The RadioRA® System can have a maximum of 12 Master Controls. Important Installation Notes 1. Install in accordance with all national and local electrical codes. 2. Do not paint the Multi-Function Entry Master Control. 3. Operate in ambient temperatures between 0°C (32°F) and 40°C (104°F). 4. Do not mount outside. Unit must not get wet. 5. Use only the AC adapter provided by Lutron with your Multi-Function Entry Master Control. Using an AC adapter not rated at the following specifications could damage the control and possibly overheat the AC adapter. • Input: AC 120V 60Hz • Output: AC 9V/500mA Class 2 6. The range and performance of the RadioRA ® System is highly dependent on a variety of complex factors such as: • Distance between system components • Geometry of the home • Construction of walls separating system components • Electrical equipment located near system components RadioRA® Setup Guide for the Entry Master Control 3 Table of Contents Section 1 - Overview Overview Multi-Function Entry Master Control.............................................................................................4 Application Examples Activating a “Home” Lighting Scene ............................................................................................ 6 Controlling a Garage Door ............................................................................................................. 6 Interfacing to a Timeclock .............................................................................................................. 7 Interfacing to a Security System ................................................................................................... 7 Section 2 - Installation Installing an Entry Master Control Installation ....................................................................................................................................... 8 Section 3 - Start-Up Activating an Entry Master Control Activating Control ........................................................................................................................... 10 Button Programming Assigning a Column of Buttons as ROOMS or SCENES ............................................................ 11 Assigning Dimmers, Switches, or GRAFIK Eye® Control Units to Buttons ............................... 12 Setting Light Levels/GRAFIK Eye® Scene Selection for Buttons ............................................... 13 Configuring General CCIs as Maintained or Momentary ............................................................. 14 Entry Master Control Learning a Visor Control ......................................…

Text truncated - open the document above for the full version.

Full Wave Bridge 9V DC Class2 Transformer Input Power Supply 120Hz +12V dc Vcc RF Splitter T/R switch Low Noise Amplifier Filter Power Amplifier Data Slicer IF 10.7MHz Transmit Oscillator 418MHz X Local Oscillator 407.3MHz Transmit Data Transmit Enable Receive Data Mixer Low Noise Amplifier Filter Data Slicer IF 10.7MHz X Local Oscillator 379.3MHz 390 Receive Data Mixer Receive Data Micro 4MHz 390 Receive Data Transmit Data Transmit Enable LED and Switch Network CCI/CCO Vcc Vcc Vcc +12V dc RAMC-MFEBlock Diagram

1 st Nov. 2006 Subject: Request for Confidentiality – RAMC-MFE JPZ0040 Dear Sir or Madam: This letter is to formally request confidentiality per the FCC Rules 47 CFR Chapter 1, subpart C, section 0.459 - requests that materials or information submitted to the Commission be withheld from public inspection. For model RAMC-MFE, the following items are Lutron Electronics Co., Inc. confidential information that must be withheld from public inspection by potential competitors to protect our business. 1. Schematics 2. Operational Description Thank you for your cooperation. Sincerely, R. S. Spehalski Engineering Leader

DOC-FCC009 4/14/2005 Page 1 of 2 FEDERAL COMMUNICATIONS COMMISSION - FCC FORM 731 APPLICATION FOR EQUIPMENT AUTHORIZATION Approved by OMB 3060 - 0934 Expires 02/28/2005 Item 1. Applicant's complete, legal business name: Lutron Electronics Co., Inc. Item 2. Applicant's mailing address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg State: PA Country (if foreign address): USA Zip/Postal Code: 18036-1299 Item 3. FCC ID: JPZ0040 Grantee code: JPZ Equipment Product Code (14 characters maximum): 0040 Item 4. Person at the applicant's address to receive grant or for contact: First Name: Matthew Last Name: Cardoni Telephone: (610) 282-7316 Title: E ngineering Technician E-mail: [email protected] Fax No: (610) 282-6457 Item 5. Instead of Applicant, the original Grant is authorized to be mailed to: N/A Item 6. Technical Contact: Firm Name: Lutron Electronics Co., Inc. Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 First Name: Matthew Last Name: Cardoni Telephone: (610) 282-7316 Title: E ngineering Technician E-mail: [email protected] Item 7. Non-Technical Contact: Firm Name: Lutron Electronics Co., Inc. Address Line 1: 7200 Suter Road P.O.Box: 900 City: Coopersburg Country (if foreign address): USA Zip/Postal Code: 18036-1299 First Name: Matthew Last Name: Cardoni Telephone: (610) 282-7316 Title: E ngineering Technician E-mail: [email protected] Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules? If "Yes" see instructions. (please mark as appropriate) Τ Yes Ο No Item 9. Does the applicant request that the Commission defer grant of this application pursuant 47 CFR § 0.457(d)(1)(ii)? (See instructions) If so, specify date when grant may be issued (MM/DD/YYYY format): Item 10. * Equipment Class: DXT * Description of Product as it is Marketed: Lighting Control Transceiver (NOTE: This text will appear below the equipment class on the grant) Item 11. * Application is for: (please mark as appropriate) Τ Original Equipment (See instructions) Ο Change in identification of presently authorized equipment: Original FCC ID: Grant Date (MM/DD/YYYY format): Ο Class II permissive change or modification of presently authorized equipment (See instructions) DOC-FCC009 4/14/2005 Page 2 of 2 Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered "Yes" complete section 12(c). Ο Yes Τ No Τ Yes Ο No (c) The related application: Τ has been granted under the FCC ID listed to the right Ο is in the process of being filed under the FCC ID listed to the right Ο is pending with the FCC under the FCC ID listed to the right FCC ID JPZ0031 Item 13. Name of test firm and contact person on file with the FCC, if different from applicant or contact person: Firm Name: MET Laboratories Address: 914 West Patapsco Avenue City: Baltimore State & Zip: MD 21230 Last Name: Confroy First Name: Marie Telephone: 410-354-3300 Ext: 412 Fax No.: 410-354-3313 E-mail: [email protected] Item 14. Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization. N/A Read each certification carefully before answering and signing this application Equipment Specifications: Rule Part Frequency Range (MHz) Power (W) Frequency Tolerance and Units Emission Designator Note Codes 15C 418 MHz 0.1 W +/-0.25% F7D WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTITUTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503). Item 15. *SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? ➽ Yes Ο No Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. IN accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. * Signature of Authorized Person Filing: Matthew Cardoni Title of au…

Text truncated - open the document above for the full version.

1 November 2006 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: LETTER OF AGENT AUTHORIZATION- RAMC-MFE JPZ0040 Dear Sir or Madam: We, the undersigned, hereby authorize MET Laboratories, Inc. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Matthew Cardoni Engineering Technician

External Photos FCC: JPZ0040 RAMC-MFE IC: 2851A-JPZ0040

Label Photos FCC: JPZ0040 RAMC-MFE IC: 2851A-JPZ0040

Internal Photos FCC: JPZ0040 RAMC-MFE IC: 2851A-JPZ0040

30 November 2006 MET Laboratories 914 West Patapsco Avenue Baltimore, MD 21230 RE: Antenna Tuning – RAMC-MFE JPZ0040 Dear Sir or Madam: The RAMC-MFE is factory tuned. Sincerely, Matthew Cardoni Engineering Technician
