JPZ0073HVAC controller

Setup Power HVAC Out W1 O/B W2 G Y1 LinkTest Y2 Y1 G W1W2 O/B HVAC Controller HVAC System Status Y2 Remote R1 R2 RS485 S1 S2 C Rh Rc Remote Sensor Status Active Battery Low Rc/Rh Jumper 24 V Sensor Setup Setup LinkTest Y2 Y1 G W1W2 O/B HVAC System Status Remote Sensor Status Active Battery Low 1 2 ON English Important Notes Environment HVAC Controller: Ambient operating temperature: 32 °F to 160 °F (0 °C to 71 °C), 0% to 90% humidity, non-condensing. Indoor use only. Codes Install in accordance with all local and national electrical codes. Cleaning To clean, wipe with a clean damp cloth. DO NOT use any chemical cleaning solutions. RF Device Placement The Receiver must be within 30 ft (9 m) of an RF signal repeater. Installation of an HVAC Controller HVAC Controller should be installed by a climate control specialist. 1. Find a suitable location for the HVAC Controller near an HVAC system and within 30 ft (9 m) of a repeater. 2. Mount vertically or horizontally, as shown in the Mounting Diagram, using two #6 (M3) screws (included). When mounting, allow 7 in (177.8 mm) clearance for the antenna and ensure convenient access to the contact closures and front buttons. In order to achieve proper RF performance, do not mount unit in a metal enclosure. Programming After installation, the HVAC controller (LR-HVAC) will only function when programmed to a system with a seeTemp ™ Wall Display (LRD-WST). For full functionality, the HVAC Controller must be programmed to a RadioRA® 2 Main Repeater (RR-MAIN-REP) and PC software must be used by a Lutron factory-trained installer. For questions on how to become a qualified installer, please contact your local Lutron representative. Temporary Programming Since the HVAC system may need to function before a Lutron factory- trained installer is available for programming, temporary programming may be used to provide climate control. To complete the steps below, the following are required: RadioRA 2 Main Repeater (RR-MAIN-REP) within 30 ft of the HVAC controller, seeTemp unit(s), and Wireless Temperature sensor(s). 1. Enter Add Mode: Press and hold the “Add” button on Main Repeater for 3 seconds until green “Add” LED begins to rapid-flash (ten times per second) and repeater beeps. Wait 10 seconds. 2. Add the devices to the Main Repeater: a. For the HVAC controller, press and hold the Link button for 3 seconds until all LEDs normal-flash (once per second). b. For the seeTemp, press and hold the Eco button for 3 seconds until all LEDs normal-flash (once per second). c. For the Wireless Temperature Sensor, press and hold the Link button for 6 seconds until the hidden LED flashes (once per second). 3. Exit Add Mode: Press and hold the “Add” button on any Repeater for 3 seconds until “Add” LED begins to rapid-flash. After LED turns off (can take up to 30–60 seconds), system has exited Add Mode. 4. Test the system: a. Set the seeTemp to Heat or Cool mode. b. Tap the link button on the Wireless Temperature Sensor. The Temperature will update on the seeTemp. c. As the temperature changes, the HVAC controller will control the HVAC equipment when required. * Typical Power Consumption test conditions: two LEDs on. Troubleshooting Guide for HVAC Controller Returning an HVAC Controller to Factory Settings Note: Returning the HVAC Controller to factory settings will erase all system programming from the HVAC Controller and will require the HVAC Controller to be reprogrammed into a system. 1. Triple tap and hold either button on an HVAC Controller. DO NOT release the button after the third tap. 2. Keep the button pressed on the third tap until the LED(s) start to flash slowly (approximately 3 seconds). 3. Release the button and immediately triple tap it again. The LEDs will flash quickly. When the LEDs stop flashing, the HVAC Controller has been returned to factory settings. Lutron and the sunburst logo are registered trademarks and seeTemp is a trademark of Lutron Electronics Co., Inc. ©2010 Lutron Electronics Co., Inc. Installation Instructions Please Read Before Installing Lutron Elec tron ics Co., Inc. 7200 Suter Road | Coopersburg, PA 18036-1299 Print ed in the U.S.A. 11/2010 P/N 041-299 Rev. A Technical Assistance | 24 hours a day, 7 days a week | www.lutron.com U.S.A. / Canada: 1.800.523.9466 | Mexico: +1.888.235.2910 | Other Countries: +1.610.282.3800 HVAC Controller: RR-HVAC-1 24 V 250 mA Typical Power Consumption*: 3.2 W Setup Power HVAC Out W1 O/B W2 G Y1 LinkTest Y2 Y1 G W1W2 O/B HVAC Controller HVAC System Status Y2 Remote R1 R2 RS485 S1 S2 C Rh Rc Remote Sensor Status Active Battery Low Rc/Rh Jumper 24 V Sensor Setup Front View Side View 2 3 ⁄4 (70) 6 1 ⁄4 (159) 1/4 (6) 4 1 ⁄4 (108) 1 1 ⁄16 (27) 3 3 ⁄4 (95) Mounting Holes 5 1 ⁄4 (133) Dimensions Measurements shown in inches (mm). Mounting Diagram VerticalHorizontal Wall Level Surface #6 (M3) screw recommended (2 included) Ceiling Relay Contact Ratings Power 24 V (from HVAC system transformers) NEC® Class 2 / PELV cable Wired Sensor Connection for 2 wired sensors Maximum 100 ft (30.5 m) Contact Closure Terminal Blocks NEC Class 2 / PELV cable Maximum 1000 ft (305 m) Each terminal holds up to one 16 AWG (1.0 mm 2 ) or two 18 AWG (0.75 mm 2 ) or smaller wire. W1 - Heat stage 1, auxiliary heat W2 O/B - Heat stage 2, changeover valve G - Fan Y1 - Compressor stage 1 Y2 - Compressor stage 2 HVAC Out Terminal connections for connecting to the HVAC system PC Connection Lutron use only. S1 S2 HVAC Setup 2 dipswitches for selecting HVAC system type Jumper required in single transformaer systems Rc/Rh Jumper Off On HVAC Controller HVAC Controller Diagnostic Mode The diagnostic mode is used to ensure the relays on the HVAC controller are functioning and wired properly to your HVAC system. Follow the steps below to test your wiring using diagnostic mode. There are three Diagnostic Mode tests. The test that is cycled is determined by the 2 dipswitches on the HVAC Controller. The dipswitches define whether the HVAC system is us…
