JPZ0136Keypad

Keypad P/N 043545 REV A English Please read before installing. www.lutron.com/support Limited Warranty: For warranty information, please see the Warranty enclosed with the product, or visit www.lutron.com/resiinfo For FCC/IC information: Please visit: www.lutron.com/fcc-ic )Lutron, Lutron, HomeWorks, Claro, Satin Colors, Sunnata and the sunburst logo are trademarks or registered trademarks of Lutron Electronics Co., Inc. in the US and/or other countries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. All other product names, logos, and brands are property of their respective owners. ©2020 Lutron Electronics Co., Inc. OFF ON WARNING: ELECTRIC SHOCK HAZARD. May result in Serious Injury or Death. Turn off power at circuit breaker or fuse before installing. 1 Turn power OFF at circuit breaker 2 Prepare wires IMPORTANT NOTES Codes: Install in accordance with all local and national electrical codes. Environment: Ambient operating temperature: 32 °F to 104 °F (0 °C to 40 °C), 0 to 90% humidity, non-condensing. Indoor use only. Wallplates: Use only Lutron wallplates with these keypads. The mechanical design of the keypad MAY NOT be compatible with non-Lutron wallplates. Non-Lutron wallplates MAY NOT sit flush against the wall. Claro and Satin Colors wallplates are designed for best color match and clean aesthetic appearance. Do not paint controls, buttons, or wallplates. Cleaning: For disinfecting keypad, please refer to App Note #758 (048758). See HomeWorks Support Center link in Help Section. Wallboxes: All keypads require a U.S. wallbox. 3 ` in (89 mm) deep recommended, 2 1 in (57 mm) deep minimum. RF Device Placement: For reliable performance in a system, this device should be placed within 25 ft (7.6 m) of two additional compatible wireless devices, such as HomeWorks Sunnata products and the HomeWorks Processor. For more information and a full list of compatible wireless devices please refer to the Wireless Setup guide, , which can be found in the HomeWorks Support Center link in the HELP Section. System Programming: Programming and activation (addressing) must be accomplished through the HomeWorks software. Raise / Lower Default: Raise / lower the last button pressed. English Help 3 Wire control ON OFF 6 Turn power ON at circuit breaker Return to Factory Settings Troubleshooting Bare Ground Hot/Live Black Insert and twist to tighten Neutral 5 Mount dimmer and attach wall plate + HRST-W, HRST-W2B, HRST-W3RL & HRST-W4B 120–277 V~ 5 0 / 60 Hz Included Components Keypad Mounting Screws Wire Nut Yellow (x4) 4 Mount wall plate adapter Note: Returning a keypad to its factory settings will remove the keypad from the system and erase all programming. Step 1: Triple tap any button on the keypad (except raise / lower). DO NOT release after third tap. Step 2: Keep the button pressed on the third tap until all the status LEDs start to flash slowly (approximately 3 seconds). Step 3: Immediately release the button and triple tap the button again. The status LEDs on the keypad will flash quickly. The keypad has now been returned to its factory settings. 3 sec TTT 7 System setup This keypad must be used in a HomeWorks system with a main repeater for control of dimmers, switches, and shades. Use the HomeWorks programming software to setup the system (training required to access the software). SymptomCauseAction LEDs on the keypad don’t light up when buttons on it are pressed. Power not present at keypadCircuit breaker OFF. Turn ON breaker Incorrect wiringWire the keypad according to the Installation section A specific dimmer, switch or shade / drapery is not controlled when a button is pressed on the keypad. The dimmer, switch or shade / drapery is not assigned to the keypad Refer to the HomeWorks programming software and ensure the device is assigned to the keypad. Perform a transfer and make sure it is successful Failure has occurred on the lamp(s) controlled by the dimmer/switch Replace the lamp(s) There is no power to the dimmer, switch, shade/drapery Ensure that the device is powered and that the FASS switch is pushed in Devices are out of rangeEnsure this device is placed within 25 ft (7.6 m) of two additional compatible wireless devices, such as HomeWorks Sunnata products and the HomeWorks processor Dimmer, switch or shade / drapery does not go to the desired level or position when a button on the keypad is pressed. The button was not programmed correctly Refer to the HomeWorks programming software and ensure the device is assigned to the keypad. Perform a transfer and make sure it is successful Devices are out of rangeEnsure this device is placed within 25 ft (7.6 m) of two additional compatible wireless devices, such as HomeWorks Sunnata products and the HomeWorks processor All LEDs on the keypad flash when any button is pressed. The keypad is in the Factory Settings mode and has not been configured to work in a system Refer to the HomeWorks programming software and ensure the device is assigned to that keypad. Perform a transfer and make sure it is successful Note: Refer to the system setup guide for additional troubleshooting suggestions. When making wire connections, follow the recommended strip lengths and combinations for the supplied wire connectors. Note: Wire connectors provided are suitable for copper wire only. AWG 12 & 14 AWG (2.5 & 1.5 mm 2 ) 3/8 in (10 mm) 18 AWG (0.75 mm 2 )7/16 in (11 mm) HomeWorks Support Center For additional support in installing, programming, and troubleshooting lutron.com/HWsupport This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: FCC/IC/IFT Information This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interfer…

Text truncated - open the document above for the full version.

February 12, 2021 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 To whom it may concern: I, the undersigned, hereby authorize MET Laboratories, Inc. and hereafter referred to as (MET), to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by MET on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MET as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. Sincerely Yours, Daniel Schlegel Standards Compliance Supervisor Lutron Electronics Co., Inc. REMARK:

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 February 12, 2021 Subject: Long Term Request for Confidentiality – JPZ0136 Dear Sir or Madam: This letter is to formally request long term confidentiality, per the FCC Rules 47 CFR 0.457 and 0.459, for materials or information submitted to the Commission to be withheld from public inspection. For all models in this submission, the following items are Lutron Electronics Co., Inc. confidential information that must be from public inspection by potential competitors to protect our business. 1. Schematic 2. Operation Description 3. Block Diagram 4. Parts List (BOM) Thank you for your cooperation. Sincerely, Daniel Schlegel Standards Compliance Supervisor

February 12, 2021 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 To whom it may concern: Regarding model number equivalency of the Lutron Keypad which are model numbered differently for marketing purposes but utilize the same hardware and communication software. All devices are identical in construction and wireless communication aspects but are designed and offered for sale with different Lutron lighting control systems. These different model numbers have unique Product Marketing Names (PMN) and depending on the device utilize different product features which are independent of the device’s wireless communication. As all devices are constructed identically testing on the evaluated sample is equivalent for this family certification. Models (PMN): HRST-W HRST-W2B HRST-W3RL, HRST-W4B HRST-W3B RRST-W RRST-W2B RRST-W3RL RRST-W4B RRST-3B ARST-W Sincerely Yours, Daniel Schlegel Standards Compliance Supervisor Lutron Electronics Co., Inc.

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 February 12, 2021 Subject: Short Term Request for Confidentiality – JPZ0136 Dear Sir or Madam: This letter is to formally request short term confidentiality, per the FCC Rules 47 CFR 0.457 and 0.459, for materials or information submitted to the Commission to be withheld from public inspection. For all models in this submission, Lutron Electronics Co., Inc. requests that materials or information submitted to the Commission be withheld from public inspection for 180 days from grant issuance. 1. Internal Photos 2. External Photos 3. Test Setup Photos 4. User Manual Thank you for your cooperation. Sincerely, Daniel Schlegel Standards Compliance Supervisor

Manufacture’s Letter Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 RE: Certification Application Reference FCC ID: JPZ0136 To Whom It May Concern: Please be advised that the manufacture will ensure that devices covered by the above referenced FCC ID will be constructed in accordance with FCC rules and regulations. Authorized signature: ____________________ Date: ____2021-02-12______ Daniel Schlegel Standards Compliance Supervisor Lutron Electronics Co., Inc.

JPZ0136 product photos Product Label Location

BR 3D4 SVC FCC ID: JPZ0136 IC: 2851A-JPZ0136 HVIN:DKP1 MODEL NUMBER Ratings Assemble | Ensamblado | Assemblé: USA Pat./Brevets: lu tron.com/patents lutron.com 50019835a

JPZ0136 product photos: Antenna is highlighted with a yellow block on the below pictures. Product Label Location

Electromagnetic Compatibility Criteria for Intentional Radiators § 15.247(i) Maximum Permissible Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit: EUT’s operating frequencies @ 2400-2483.5 MHz; Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 Equation from page 18 of OET 65, Edition 97-01 S = PG / 4R 2 or R = √(PG / 4S) where, S = Power Density (mW/cm 2 ) P = Power Input to antenna (mW) G = Antenna Gain (numeric value) R = Distance (cm) Test Results: Worst-case manufacturing power including tolerance. The safe distance where Power Density is less than the MPE Limit listed above was found to be 20 cm. Tolerance is 1dBm. 240219.589.125-10.7940.0140810.9859220Pass Con. Pwr. (mW) Re sult FCC Con. Pwr. (dBm) Fre que ncy (MHz) Distance (cm) Margin Limit (mW/cm 2 ) Pwr. De nsity (mW/cm 2 ) Ant. Gain nume ric Ant. Gain (dBi)

HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Maryland | California | Texas www.metlabs.com 02/18/2021 Lutron Electronics Co., Inc. 7200 Suter Road Coopersburg, PA 18036 Dear Andrew Vaughn, Enclosed is the EMC Wireless test report for compliance testing of the Lutron Electronics Co., Inc., Darter Keypad as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-06 ed.), Part 15 Subpart C for Intentional Radiators. Thank you for using the services of Eurofins E&E North America. If you have any questions regarding these results or if Eurofins can be of further service to you, please feel free to contact me. Sincerely yours, EUROFINS E&E NORTH AMERICA Joel Huna Documentation Department Reference: (\Lutron Electronics Co., Inc.\WIR110653A-FCC247 Rev. 3) Certificates and reports shall not be reproduced except in full, without the written permission of Eurofins E&E North America While use of the A2LA logo in this report reflects Eurofins accreditation under these programs, the report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the Federal Government. This letter of transmittal is not a part of the attached report. Eurofins MET Laboratories Inc. (Eurofins E&E North America) is part of the Eurofins Electrical & Electronics (E&E) global compliance network. Electromagnetic Compatibility Lutron Electronics Co., Inc. Cover Page Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page ii of ix DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Lutron Electronics Co., Inc. Darter Keypad Tested under the FCC Certification Rules contained in 15.247 Subpart C for Intentional Radiators Report: WIR110653A-FCC247 Rev. 3 02/18/2021 Prepared For: Lutron Electronics Co., Inc. 7200 Suter Road Coopersburg, PA 18036 Prepared By: Eurofins E&E North America 914 West Patapsco Avenue, Baltimore, MD 21230 Electromagnetic Compatibility Lutron Electronics Co., Inc. Cover Page Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page iii of ix DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Lutron Electronics Co., Inc. Darter Keypad Tested under the FCC Certification Rules contained in 15.247 Subpart C for Intentional Radiators Deepak Giri, Project Engineer Joel Huna Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules Part 15.247 under normal use and maintenance. Steve Pitta, Manager, Electromagnetic Compatibility Lab Electromagnetic Compatibility Lutron Electronics Co., Inc. Report Status Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page iv of ix DOC-EMC702 6/18/2009 Report Status Sheet Revision Report Date Reason for Revision  01/22/2021 Initial Issue. 1 01/29/2021 Customer Comments. 2 02/05/2021 Updates per TCB Comments 3 02/18/2021 Updated MPE Calculation Electromagnetic Compatibility Lutron Electronics Co., Inc. Table of Contents Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page v of ix DOC-EMC702 6/18/2009 Table of Contents I. Executive Summary ................................................................................................................................................. 1 A. Purpose of Test ................................................................................................................................................... 2 B. Executive Summary ............................................................................................................................................ 2 II. Equipment Configuration ....................................................................................................................................... 3 A. Overview ............................................................................................................................................................. 4 B. References ........................................................................................................................................................... 5 C. Test Site .............................................................................................................................................................. 5 D. Measurement Uncertainty ................................................................................................................................... 5 E. Description of Test Sample ................................................................................................................................. 6 F. Equipment Configuration .................................................................................................................................... 6 G. Support Equipment ............................................................................................................................................. 6 H. Ports and Cabling Information ............................................................................................................................ 7 I. Mode of Operation .............................................................................................................................................. 7 J. Method of Monitoring EUT Operatio…

Text truncated - open the document above for the full version.

HEADQUARTERS: 914 WEST PATAPSCO AVENUE • BALTIMORE, MARYLAND 21230 • PHONE (410) 354-3300 • FAX (410) 354-3313 Maryland | California | Texas www.metlabs.com 02/18/2021 Lutron Electronics Co., Inc. 7200 Suter Road Coopersburg, PA 18036 Dear Andrew Vaughn, Enclosed is the EMC Wireless test report for compliance testing of the Lutron Electronics Co., Inc., Darter Keypad as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-06 ed.), Part 15 Subpart C for Intentional Radiators. Thank you for using the services of Eurofins E&E North America. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, EUROFINS E&E NORTH AMERICA Joel Huna Documentation Department Reference: (\Lutron Electronics Co., Inc.\WIR110653B-FCC247 Rev. 3) Certificates and reports shall not be reproduced except in full, without the written permission of Eurofins E&E North America While use of the A2LA logo in this report reflects Eurofins accreditation under these programs, the report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the Federal Government. This letter of transmittal is not a part of the attached report. Eurofins MET Laboratories Inc. (Eurofins E&E North America) is part of the Eurofins Electrical & Electronics (E&E) global compliance network. Electromagnetic Compatibility Lutron Electronics Co., Inc. Cover Page Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page ii of viii DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Lutron Electronics Co., Inc. Darter Keypad Tested under the FCC Certification Rules contained in 15.247 Subpart C for Intentional Radiators Report: WIR110653B-FCC247 Rev. 3 02/18/2021 Prepared For: Lutron Electronics Co., Inc. 7200 Suter Road Coopersburg, PA 18036 Prepared By: Eurofins E&E North America 914 West Patapsco Avenue, Baltimore, MD 21230 Electromagnetic Compatibility Lutron Electronics Co., Inc. Cover Page Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page iii of viii DOC-EMC702 6/18/2009 Electromagnetic Compatibility Criteria Test Report for the Lutron Electronics Co., Inc. Darter Keypad Tested under the FCC Certification Rules contained in 15.247 Subpart C for Intentional Radiators Deepak Giri, Project Engineer Joel Huna Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of the FCC Rules Part 15.247 under normal use and maintenance. Steve Pitta, Manager, Electromagnetic Compatibility Lab Electromagnetic Compatibility Lutron Electronics Co., Inc. Report Status Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page iv of viii DOC-EMC702 6/18/2009 Report Status Sheet Revision Report Date Reason for Revision  01/22/2021 Initial Issue. 1 01/29/2021 Customer Comments. 2 02/05/2021 Updates per TCB Comments 3 02/18/2021 Updated MPE Calculation Electromagnetic Compatibility Lutron Electronics Co., Inc. Table of Contents Darter Keypad CFR Title 47, Part 15.247 Report: WIR110653A-FCC247 Rev. 3 © 2021, Eurofins E&E North America Page v of viii DOC-EMC702 6/18/2009 Table of Contents I. Executive Summary ................................................................................................................................................. 1 A. Purpose of Test ................................................................................................................................................... 2 B. Executive Summary ............................................................................................................................................ 2 II. Equipment Configuration ....................................................................................................................................... 3 A. Overview ............................................................................................................................................................. 4 B. References ........................................................................................................................................................... 5 C. Test Site .............................................................................................................................................................. 5 D. Measurement Uncertainty ................................................................................................................................... 5 E. Description of Test Sample ................................................................................................................................. 6 F. Equipment Configuration .................................................................................................................................... 6 G. Support Equipment ............................................................................................................................................. 6 H. Ports and Cabling Information ............................................................................................................................ 7 I. Mode of Operation .............................................................................................................................................. 7 J. Method of Monitoring EUT Opera…

Text truncated - open the document above for the full version.

Figure 1: Conducted Emissions, 15.207(a) Test Setup Figure 2: Radiated Spurious Emission Test Setup 30MHz-1GHz Figure 3: Radiated Spurious Emission Test Setup 1GHz-18GHz Figure 4: Radiated Spurious Emission Test Setup 18GHz-25GHz
