Waggin’ Whitetail TM Instruction Manual Model No.62606 (Includes: Decoy Housing, Tail, Remote, Lanyard, Hardware, Strap & Batteries) IMPORTANT For your protection, please carefully read these warnings, precautions and safety/operating instructions completely before operating this product. Follow these instructions closely and keep this manual for future reference. WARNING To reduce the risk of fire, electrical shock or product damage/failure, - Do not expose unit with the battery door open to rain, moisture, dripping or splashing. Do not open or close the battery door with wet hand. Completely wipe off water on unit and door before opening. - Do not lay product on moist ground or submerge in water. - DO NOT OPEN CASE HOUSING. UNINSULATED, ‘DANGEROUS VOLTAGE’ WITHIN PRODUCTS ENCLOSURE. DO NOT REMOVE HOUSING COVER. THERE ARE NO USER - SERVICEABLE PARTS INSIDE, REFER SERVICING TO PRIMOS® CUSTOMER SERVICE. - Only use batteries as specified in this user manual and install according to correct polarization. Failure to follow may result in leaking or exploding batteries, damage to product, fire or personal injury. Do not handle damaged or leaking batteries. - Do not expose to extreme heat. Do not leave product and/or batteries exposed in direct sunlight inside a vehicle, or other contained environment for a long period of time. WARNING Primos decoys are so accurate you might attract other hunters, as well as game. The user of this product assumes all risk of injury in association with the use of this product. MODIFICATION WARNING You are cautioned that any changes or modifications not expressly approved in this manual could void your warranty of this equipment. OPERATING TEMPERATURE - Recommended storage temperature range -10°F to 140°F - Recommended operating temperature range 20°F to 120°F WARNING To avoid possible product damage and/or injury, NEVER INSTALL DIFFERENT TYPES OF BATTERIES in the product at the same time. Failure to follow may result in leaking or exploding batteries, damage to product, fire or personal injury. Do not handle damaged or leaking batteries. . BATTERY INSTALLATION (1 L1028 (A23) & 2 AA Batteries Not Included). Remote Remove battery cover and install 1 L1028 or A23 12V battery following polarity instructions in battery compartment. Reinstall battery cover and tighten with screw driver or coin. Decoy Housing Remove battery cover and install 2 AA batteries following polarity instructions in battery compartment. Reinstall battery cover and tighten with screw driver or coin. . OPERATION INSTRUCTIONS . IMPORTANT NOTE: Check your local and state hunting laws for legal and recommended use of electronic motion decoys. Attach tail to decoy housing so tail is pointed down. Turn power on both decoy housing and remote before using. NOTE: Remote control buttons are designed to activate command when button is completely pressed down on the remote. TWITCH MOTION [Located in center of remote] – Produces short single tail twitch motion. Motion gives approaching deer confidence to continue their approach. Note: When signal is sent LED activates. WAG MOTION [Located toward bottom of remote] – Produces single tail wagging motion. Motion gives distant deer confidence all is well to move in closer. Note: When signal is sent LED activates. POWER BUTTON – Standard ON/OFF functionality RED LED LIGHT IN BUTTON – Indicates power is on. .ATTACHING WAGGIN’ WHITETAIL TM TO DEER DECOY (DEER DECOY NOT INCLUDED). NOTE: Primos does not recommend transporting Waggin’ Whitetail TM attached to decoy in and out of field. Remove Waggin’ Whitetail TM and transport separately. 1. Using included decoy hole pattern, attach 4 screws to deer decoy so bolt head stands off decoy approximately 3/8 inch. 2. Attach motor housing by aligning holes with 4 bolts and sliding housing down so housing is locked into slots. Note: May need to adjust bolt height depending on deer decoy design. .ATTACHING WAGGIN’ WHITETAIL TM TO TREE OR POST. 1. Thread strap thru 2 slots on decoy housing. 2. Wrap strap around tree / post and connect buckles together. Pull strap thru buckle to secure to tree / post. . WAGGIN’ WHITETAIL TM PLACEMENT . Place decoy within 40 yards of your location. Hunting Tip: Keeping decoy within 25 yards allows for closer shots. IMPORTANT NOTE: If decoy is placed at long distances, on the ground, in thick cover, in under brush, or has obstructions between remote and decoy always check remote function with decoy. If remote does not operate decoy, decrease decoy distance. . CARING FOR YOUR WAGGIN’ WHITETAIL TM . Your caller contains sensitive electronic components that can be permanently damaged if exposed to excessive shock or vibration. To minimize the risk of damage to your unit, avoid dropping your unit and operating it in high- shock and high-vibration environments. - Do not store your unit where prolonged exposure to extreme temperatures can occur, because it can cause permanent damage. - Do not expose to prolonged exposure to moisture. This can cause this unit to malfunction. - Never use a hard or sharp object to operate this unit or damage may result. Cleaning the Unit: The Waggin’ Whitetail TM Decoy is constructed of high-quality materials and does not require user maintenance other than cleaning. Clean the outer casings using a cloth dampened with a mild detergent solution, and then wipe dry and allow to air dry. Avoid chemical cleaners and solvents that can damage plastic components or faux fur tail. Caution: The decoy is water resistant - not waterproof. . TROUBLE SHOOTING . Check batteries in decoy and remote control if decoy is not functioning properly. Remote is not controlling decoy properly. Move remote closer to decoy until remote properly controls decoy. If decoy continues to function incorrectly, call Customer Service at 601-879-9323 or email [email protected]. . FCC STATEMENT . Changes not expressly approved by Primos could void the user's authority to operate the equipment. Note: This equip…

Text truncated - open the document above for the full version.

Label size: 2mm*8mm FCC ID: K2R62606R This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Label Location

Global United Technology Services Co., Ltd. Report No.: GTSE13010001802 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS International Electrical Approvals or testing done by GTS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by GTS International Electrical Approvals in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” TEST REPORT Applicant: Primos Inc Address of Applicant: 604 First Street Flora Mississippi United States 39071 Equipment Under Test (EUT) Product Name: WAGGIN’ WHITETAIL Model No.: 62606 FCC ID: K2R62606R Applicable standards: FCC CFR Title 47 Part 15 Subpart B:2011 Date of sample receipt: January 05, 2013 Date of Test: January 06-08, 2013 Date of report issue: January 09, 2013 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE13010001802 Global United Technology Services Co., Ltd. Project No.: GTSE130100018RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 20 2 Version Version No. Date Description 00 January 09, 2013 Original Prepared By: Date: January 09, 2013 Project Engineer Check By: Date: January 09, 2013 Reviewer Report No.: GTSE13010001802 Global United Technology Services Co., Ltd. Project No.: GTSE130100018RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 20 3 Contents Page 1 COVER PAGE .......................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE....................................................................................................................................... 5 5.4 TEST FACILITY.................................................................................................................................... 6 5.5 TEST LOCATION................................................................................................................................. 6 5.6 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 6 5.7 DEVIATION FROM STANDARDS............................................................................................................. 6 5.8 ABNORMALITIES FROM STANDARD CONDITIONS................................................................................... 6 5.9 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 6 6 TEST INSTRUMENTS LIST ..................................................................................................................... 7 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 8 7.1 RADIATED EMISSION........................................................................................................................... 8 8 TEST SETUP PHOTO ............................................................................................................................ 14 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................15 Report No.: GTSE13010001802 Global United Technology Services Co., Ltd. Project No.: GTSE130100018RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 20 4 Test Summary Test Item Section in CFR 47 Result Conducted Emission Part15.107 N/A Radiated Emissions Part15.109 PASS PASS: The EUT complies with the essential requirements in the standard. N/A: not applicable. Report No.: GTSE13010001802 Global United Technology Services Co., Ltd. Project No.: GTSE130100018RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixi…
