K7S-03628Dual-Band 802.11ax Wireless Router

FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and devices • Connect the equipment to an outlet other than the receiver’s • Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. 2.4GHz operation of this product in the USA is firmware-limited to channels 1 through 11. The device for the band 5150-5250 MHz is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 47 cm between the radiator and your body. This device and its antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. Wireless Disclaimer The maximum performance for wireless is derived from IEEE Standard 802.11 specifications. Actual performance can vary, including lower wireless network capacity, data throughput rate, range and coverage. Performance depends on many factors, conditions and variables, including distance from the access point, volume of network traffic, building materials and construction, operating system used, mix of wireless products used, interference and other adverse conditions. EU Declaration of Conformity English Hereby, Belkin International, Inc. declares that the radio equipment is in compliance with Directive 2014/53/EU. 美國聯邦通訊委員會聲明 本裝置符合 美國聯邦通訊委員會規範第 15 條之規定。操作受必須符合以下兩種條件：(1) 本裝置不會產生有害的干擾，且 (2)本裝置必須能接收任何收到之干擾，包含可能導致不受期待的操作之干擾。 本產品已通過美國聯邦通訊委員會規範第 15 條規定之測試，且符合 B 類數位裝置規格之需求。這些限制是為合理避開在住 家安裝時的有害干擾的而設計。本設備會產生、使用且放射無線電波能量，且，如果未依據指示安裝和使用，可能會對無線 電通訊產生有害干擾。然而，無法保證在特殊安裝下不會發生干擾。若本裝置確實對無線電或電視收訊造成有害干擾（您可 以透過開關本裝置獲得確認），我們建議您透過下列其一或多種方法，嘗試改善干擾： • 重新調整或重新定位接收天線。 • 擴大設備和裝置之間的距離。 • 將設備連接至接收器以外的插座。 • 請洽經銷商或經驗豐富的無線電／電視技術人員，尋求協助。 美國聯邦通訊委員會注意事項：任何未經合規負責方的明確核准的變更或修改可能導致使用者無權操作此設備。 本產品在美國 2.4GHz操作的韌體僅限於第 1 到第 11 頻道。 5150-5250 MHz頻段的設備僅供室內使用，以減少對同頻道移動衛星系統造成有害干擾的潛在可能性。 美國聯邦通訊委員會幅射曝露聲明： 本設備符合美國聯邦通訊委員會訂立之未受控環境所訂的幅射曝露限值。本設備應在輻射源距離您的身體最少47公分處安 裝以及操作。 除非符合美國聯邦通訊委員會之多重發射產品的程序，否則本裝置與其天線不可與其他天線或發射器放置於同一地點或共同 使用。 關於無線傳輸的免責聲明 無線的最佳性能是依據IEEE 802.11 定義規範。實際性能可能有所不同，包含較低無線網路流量、數據輸出率、範圍與涵蓋 面積。性能取決於多種因素、條件與變數，包括與存取點之間的距離、網路流量、建築材料與結構、使用之作業系統、使用 之無線產品的混合、介面與其他不利條件。 歐盟合規聲明 Belkin International，Inc在此聲明無線電設備符合歐盟指令2014/53/EU。 安全性通知 警告：請勿於靠近水源處使用本產品，例如於潮濕的地下室或泳池附近。 警告：避免於雷雨期間使用本產品。可能有遭閃電電擊觸電的危險。 警告：電源變壓器為本設備的斷電裝置。電源插座必須位於設備附近，且必須容易觸及。 第三方軟體或韌體 使用Linksys產品不支援或提供的軟體或韌體可能導致設備不再符合法規之要求。 Safety Notices English WARNING: Do not use this product near water, for example, in a wet basement or near a swimming pool. WARNING: Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning. WARNING: The power adaptor is the equipment ́s disconnection device. The power outlet must be located nearby the equipment and its access must be easy. Third-Party Software or Firmware The use of software or firmware not supported/provided by Linksys products may result that the equipment is no longer compliant with the regulatory requirements. WARRANTY AND SUPPORT INFORMATION IMPORTANT! PLEASE RETAIN PROOF OF PURCHASE AND PRODUCT WARRANTY INFORMATION LIMITED WARRANTY (Asia Pacific) This warranty is provided to you by Belkin Asia Pacific Limited, a Hong Kong corporation and a wholly owned subsidiary of Belkin International, Inc., of Room 2601, 26th Floor, Octa Tower, No. 8 Lam Chak Street, Kowloon Bay, Kowloon, Hong Kong, phone: +852 3669 4000, in relation to Belkin and Wemo products (“Belkin”). In relation to Linksys products, this warranty is provided to you by Linksys Pte. Ltd., a Singapore corporation (registration number: 200106033K) and a wholly owned subsidiary of Belkin International, Inc., of 100 Beach Road #13-04/07 Shaw Tower Singapore 189702 (“Belkin”). In Australia and New Zealand, this warranty is provided to you by Belkin Limited (ACN: 095 402 663), an Australian corporation and a wholly owned subsidiary of Belkin International, Inc., of Unit E, 2 Reliance Drive, Tuggerah NSW 2259, phone: +61 (0) 2 4350 4600, in relation to Linksys, Belkin and Wemo products (“Belkin”). In the People’s R public of China, this warranty is provided to you by Belkin Trading (Shanghai) Co., Ltd., a company incorporated in the People’s Republic of China and a wholly owned subsidiary of Belkin International, Inc., of Unit 901, 903, 905, Tower A, GuangQi Culture Plaza, No.2899 XieTu Road, Xuhui District, Shanghai, P.R.C 200030 in relation to Belkin, Linksys and Wemo products (“Belkin”). IMPORTANT NOTICE REGARDING YOUR CONSUMER RIGHTS The benefits we give in this manufacturer’s warranty are additional to any …

Text truncated - open the document above for the full version.

USER GUIDE MAX-STREAM™ AX4500 DUAL-BAND WiFi 6 ROUTER Model EA9350 2 Contents Product Overview .........................................................................................................3 Front .................................................................................................................................................................... 3 Back ..................................................................................................................................................................... 4 Side ...................................................................................................................................................................... 5 Setting Up: Basics ........................................................................................................6 Where to find more help ............................................................................................................................... 6 How to install your router ............................................................................................................................ 7 www.LinksysSmartWiFi.com ................................................................................. 10 How to log in to www.LinksysSmartWiFi.com ................................................................................... 10 Network Map ................................................................................................................................................. 12 Guest Access ................................................................................................................................................ 12 Parental Controls......................................................................................................................................... 13 Media Prioritization ..................................................................................................................................... 13 Speed Test ..................................................................................................................................................... 14 External Storage ......................................................................................................................................... 14 Connectivity .................................................................................................................................................. 15 Troubleshooting ........................................................................................................................................... 15 Wireless ........................................................................................................................................................... 16 Security ........................................................................................................................................................... 16 Troubleshooting ......................................................................................................... 17 Your router was not successfully set up ............................................................................................. 17 Your Internet cable is not plugged in message ................................................................................. 18 Cannot access your router message .................................................................................................... 19 After setup ..................................................................................................................................................... 20 The internet appears to be unavailable ............................................................................................... 20 www.LinksysSmartWiFi.com does not open in your web browser ............................................ 21 Specifications ............................................................................................................. 22 Linksys EA9350 .......................................................................................................................................... 22 Environmental ............................................................................................................................................... 22 3 Product Overview Front Status light—Gives you information about the router’s operation. WPS light—The light provides information about WPS pairing activity. Light description Status Off Power off Blue (blinking) Router starting up Blue (solid) Read ready for setup / Connected to internet Red (solid) No internet from modem Red (blinking) Cable disconnected from modem WPS light description Status Off No WPS activity White (blinking) WPS in progress (blinks for up to 2 minutes) Orange (blinking) WPS error (blinks for 1 minute) White (solid) WPS success (goes off after 5 seconds) 4 Back Reset button (1)— To factory reset your router, press and hold while the light on front of the router blinks red. Do not release the button until the light goes out and then turns bright red. Internet port (2)—Connect an ethernet cable to this yellow gigabit (10/100/1000) port, and to a broadband or fiber modem. Note—For best performance, use CAT5e or higher rated cables on the internet port. Ethernet ports (3)—Connect ethernet cables to these blue gigabit (10/100/1000) ports, and to wired devices on your network. Note—For best performance, use CAT5e or higher rated cables on the ethernet ports. Power port (4)—Connect the included AC power adapter. USB 3.0 ports (5)—Connect and share a USB drive on your network or on the internet. Ethernet activity lights (6)—Blink when there is traffic over an ethernet port. Power switch (7)—Press | (on) to turn on the router. 5 Side Wi-Fi Protected Setup button— Press to connect WPS-enabled network devices. 6 Setting Up: Basics Where to find more help In addi…

Text truncated - open the document above for the full version.

Belkin International, Inc. 12045 East Waterfront Dr. Playa Vista, California 90094, United States Date: 2020-11-06 FCC ID: K7S-03628 Declaration for DFS master devices We, Belkin International, Inc. hereby declare that the device meets all the other requirements specified in Part 15E Section 15.407. If you should have any question(s) regarding this declaration, please don’t hesitate to contact us. Thank you! __________________________________ Po-Wen Cheng / Manager, Regulatory Compliance Belkin International, Inc. Tel: +1 949 238-4518 E-mail: [email protected]

Belkin International, Inc. 12045 East Waterfront Dr. Playa Vista, California 90094, United States Date: 2020-11 -06 FCC ID: K7S-03628 To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, __________________________________ Po-Wen Cheng / Manager, Regulatory Compliance Belkin International, Inc. Tel: +1 949 238-4518 E-mail: [email protected]

Belkin International, Inc. 12045 East Waterfront Dr. Playa Vista, California 90094, United States Date: 2020-11-06 FCC ID: K7S-03628 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, __________________________________ Po-Wen Cheng / Manager, Regulatory Compliance Belkin International, Inc. Tel: +1 949 238-4518 E-mail: [email protected]

Belkin International, Inc. 12045 East Waterfront Dr. Playa Vista, California 90094, United States POWER OF ATTORNEY Date: November 6, 2020 FCC ID: K7S-03628 To whom it may concern: We, Belkin International, Inc. the undersigned, hereby authorize Debby Lin of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Debby Lin of BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you. Sincerely yours, __________________________________ Po-Wen Cheng / Manager, Regulatory Compliance Belkin International, Inc. Tel: +1 949 238-4518 E-mail: [email protected]

Belkin International, Inc. 12045 East Waterfront Dr. Playa Vista California United States 90094 Date: 2020-07-02 A U T H O R I Z A T I O N L E T T E R To whom it may concern: I, the undersigned Jay Tu of Belkin International, Inc. hereby authorize Po-Wen Cheng of Belkin International, Inc. to act on my behalf in all matters relating to all processes required in FCC and any communication needed with the national authority. Any and all acts carried out by Po-Wen Cheng on my behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, --------- Jay Tu / Manager, Regulatory Compliance Belkin International, Inc. Tel: +1 310 633 9309*9142 E-mail: [email protected]

Reference No.: 200605E14-1 Page 1/18 CONSTRUCTION PHOTOS OF EUT Reference No.: 200605E14-1 Page 2/18 Reference No.: 200605E14-1 Page 3/18 Reference No.: 200605E14-1 Page 4/18 MU48AY120400-A1 Reference No.: 200605E14-1 Page 5/18 KSAS0501200400HU Reference No.: 200605E14-1 Page 6/18 Reference No.: 200605E14-1 Page 7/18 DA-48T12 Reference No.: 200605E14-1 Page 8/18 Reference No.: 200605E14-1 Page 9/18 Reference No.: 200605E14-1 Page 10/18 Reference No.: 200605E14-1 Page 11/18 Reference No.: 200605E14-1 Page 12/18 KSAS0501200400M2 Reference No.: 200605E14-1 Page 13/18 Reference No.: 200605E14-1 Page 14/18 Reference No.: 200605E14-1 Page 15/18 Reference No.: 200605E14-1 Page 16/18 Reference No.: 200605E14-1 Page 17/18 Reference No.: 200605E14-1 Page 18/18

R0.93 185 26 SCALE 1:1 DATE: 2020.08.31 REVISION: A00 Revision Notes: A00 INITIAL RELEASE DESIGNER: MW ALL DIMENSIONS IN MM. 8840-03253 LINKSYS MR9600V2 Router US-CA PRODUCT ID LABEL DO NOT MAKE CHANGES WITHOUT PERMISSION FROM BELKIN IDG. ELEMENTS IN ORANGE PRINTED IN PMS WHITE, MATTE FINISH ELEMENTS IN BLUE: PRINTED IN CARBON BLACK #SDBK0908_D01, MATTE FINISH ELEMENTS IN GREEN: PRINTED IN PMS COOL GRAY 8C, MATTE FINISH ARTWORK TO PRINT ON LAYER ‘ARTWORK’ ELEMENTS IN ORANGE PRINTED IN PMS WHITE, MATTE FINISH ELEMENTS IN BLUE: PRINTED IN PMS BLACK C, MATTE FINISH ELEMENTS IN GREEN PRINTED IN PMS COOL GRAY 8C, MATTE FINISH

Reference No.: 200605E14-2 Page 1/17 CONSTRUCTION PHOTOS OF EUT Reference No.: 200605E14-2 Page 2/17 Reference No.: 200605E14-2 Page 3/17 Reference No.: 200605E14-2 Page 4/17 Reference No.: 200605E14-2 Page 5/17 Reference No.: 200605E14-2 Page 6/17 Reference No.: 200605E14-2 Page 7/17 Reference No.: 200605E14-2 Page 8/17 Reference No.: 200605E14-2 Page 9/17 Reference No.: 200605E14-2 Page 10/17 Reference No.: 200605E14-2 Page 11/17 Antenna 1 Reference No.: 200605E14-2 Page 12/17 Antenna 2 Reference No.: 200605E14-2 Page 13/17 Reference No.: 200605E14-2 Page 14/17 Antenna 3 Reference No.: 200605E14-2 Page 15/17 Antenna 4 Reference No.: 200605E14-2 Page 16/17 Reference No.: 200605E14-2 Page 17/17 Antenna Bluetooth

Report No.: SA200605E14 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA200605E14 FCC ID: K7S-03628 Test Model: MR9600 V2 Series Model: MR9610 V2, EA9350 V2 Received Date: June 05, 2020 Test Date: Sep. 26, 2020 Issued Date: Nov. 09, 2020 Applicant: Belkin International, Inc. Address: 12045 East Waterfront Drive Playa Vista, CA. 90094, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan Test Location: E-2, No.1, Li Hsin 1st Road, Hsinchu Science Park, Hsinchu City 300, Taiwan FCC Registration / Designation Number: 723255 / TW2022 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA200605E14 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 2.4 Antenna Gain ...................................................................................................................................... 6 2.5 Calculation Result of Maximum Conducted Power ............................................................................. 7 Report No.: SA200605E14 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA200605E14 Original release. Nov. 09, 2020 Report No.: SA200605E14 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Dual-Band 802.11ax Wireless Router Brand: Linksys Test Model: MR9600 V2 Series Model: MR9610 V2, EA9350 V2 Sample Status: ENGINEERING SAMPLE Applicant: Belkin International, Inc. Test Date: Sep. 26, 2020 Standards: FCC Part 2 (Section 2.1091) IEEE C95.3 -2002 References Test Guidance: KDB 447498 D01 General RF Exposure Guidance v06 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date: Nov. 09, 2020 Cherry Chuo / Specialist Approved by : , Date: Nov. 09, 2020 Clark Lin / Technical Manager Report No.: SA200605E14 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f 2 )* 30 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 f = Frequency in MHz ; *Plane-wave equivalent power density 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 47 cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA200605E14 Page No. 6 / 7 Report Format Version: 6.1.1 2.4 Antenna Gain Antenna No. Antenna Net Gain (dBi) Frequency Range (GHz) Antenna Type Connector Type 1 4.04 3.31 2.4~2.4835 5.15-5.85 Dipole i-pex(MHF) 2 3.66 3.31 2.4~2.4835 5.15-5.85 Dipole i-pex(MHF) 3 3.66 3.25 2.4~2.4835 5.15-5.85 Dipole i-pex(MHF) 4 3.33 3.23 2.4~2.4835 5.15-5.85 Dipole i-pex(MHF) Bluetooth 2.7 2.4~2.4835 PIFA none Note: The above Antenna information is declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications, the laboratory shall not be held responsible. Report No.: SA200605E14 Page No. 7 / 7 Report Format Version: 6.1…
