FCC ID: K7SF5D7050A Report No.: RF930820L10 Operational Description This device is a 54Mbps Wireless USB Network Adapter which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment via a USB interface. The antenna is Printed Inverted F antenna without a connector. The other instruction, please have a look at the users manual.

FCC ID: K7SF5D7050A Report No.: SA930820L101Issued: Sep. 16, 2004 SAR TEST REPORT REPORT NO.: SA930820L10 MODEL NO.: F5D7050 RECEIVED: Aug. 08, 2004 TESTED: Aug. 08, 2004 APPLICANT: Belkin Corporation ADDRESS: 501 West Walnut Avenue, Compton, CA 90220, U.S.A ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 31 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: K7SF5D7050A Report No.: SA930820L102Issued: Sep. 16, 2004 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ...................................................5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................13 4.DESCRIPTION OF SUPPORT UNITS ......................................................................14 5.TEST RESULTS ........................................................................................................15 5.1 TEST PROCEDURES ...............................................................................................15 5.2 MEASURED SAR RESULT .......................................................................................16 5.3 SAR LIMITS...............................................................................................................18 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................18 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................20 6.SYSTEM VALIDATION ..............................................................................................21 6.1 TEST EQUIPMENT ...................................................................................................21 6.2 BEFORE STARTING THE MEASUREMENT, ALL TEST EQUIPMENT SHALL BE WARMED UP FOR 30MIN.TEST PROCEDURE ......................................................21 6.3 VALIDATION RESULT...............................................................................................23 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................24 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................25 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................25 7.2 ISOTROPY UNCERTAINTY......................................................................................25 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................26 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................26 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................26 7.6 RESPONSE TIME UNCERTAINTY...........................................................................27 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................28 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................28 7.9 PROBE POSITIONING .............................................................................................29 7.10 PHANTOM UNCERTAINTY ......................................................................................29 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................30 8.INFORMATION ON THE TESTING LABORATORIES ..............................................31 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: K7SF5D7050A Report No.: SA930820L103Issued: Sep. 16, 2004 1. CERTIFICATION PRODUCT : 54Mbps Wireless USB Network Adapter MODEL NO. : F5D7050 BRAND NAME : Belkin APPLICANT : Belkin Corporation TESTED : Aug. 08, 2004 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Sep. 16, 2004 ( Windy Chou ) TECHNICAL ACCEPTANCE :, DATE:Sep. 16, 2004 Responsible for RF ( Ansen Lei ) APPROVED BY:, DATE:Sep. 16, 2004 ( Cody Chang, Deputy Manager ) FCC ID: K7SF5D7050A Report No.: SA930820L104Issued: Sep. 16, 2004 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT 54Mbps Wireless USB Network Adapter MODEL NO. F5D7050 POWER SUPPLY 5.0Vdc powered by host equipment CLASSIFICATION Portable device, production unit MODULATION TYPE BPSK, QPSK, CCK, 16QAM, 64QAM RADIO TECHNOLOGY DSSS, OFDM TRANSFER RATE 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps FREQUENCY RANGE 2412MHz ~ 2462MHz NUMBER OF CHANNEL 11 MA…

Text truncated - open the document above for the full version.

APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION Mode 1 Bottom Position The bottom of the EUT to the flat phantom distance 8 mm Mode 2 Tip Position The tip of the EUT to the flat phantom distance 0 mm Mode 3 Bottom Position The bottom of the EUT to the flat phantom distance 8 mm Mode 4 Tip Position The tip of the EUT to the flat phantom distance 0 mm EUT Photo Liquid Level Photo MSL 2450MHz D=150mm Date/Time: 08/08/04 10:06:32 Test Laboratory: Advance Data Technology F5D7050A 11b Bottom Mode 1 Ch 1 DUT: 54Mbps Wireless USB Network Adapter ; Type: F5D7050A ; Test Channel Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 (σ = 1.9239 mho/m, ε r = 52.5073, ρ = 1000 kg/m 3 ) ; Liquid level : 150mm Phantom section: Flat Section ; Separation distance : 8 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.4, 4.4, 4.4) ; Calibrated: 2003/8/29 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2003/8/15 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.1 Build 47 ; Postprocessing SW: SEMCAD, V1.6 Build 115 Low Channel/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 0.468 V/m Power Drift = 0.2 dB Maximum value of SAR = 0.0112 mW/g Low Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.0358 W/kg SAR(1 g) = 0.0111 mW/g; SAR(10 g) = 0.00494 mW/g Reference Value = 0.468 V/m Power Drift = 0.2 dB Maximum value of SAR = 0.0113 mW/g Date/Time: 08/08/04 10:31:32 Test Laboratory: Advance Data Technology F5D7050A 11b Bottom Mode 1 Ch 6 DUT: 54Mbps Wireless USB Network Adapter ; Type: F5D7050A ; Test Channel Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 (σ = 1.9766 mho/m, ε r = 52.4335, ρ = 1000 kg/m 3 ) ; Liquid level : 155mm Phantom section: Flat Section ; Separation distance : 8 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.4, 4.4, 4.4) ; Calibrated: 2003/8/29 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2003/8/15 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.1 Build 47 ; Postprocessing SW: SEMCAD, V1.6 Build 115 Middle Channel/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 0.711 V/m Power Drift = -0.08 dB Maximum value of SAR = 0.0126 mW/g Middle Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.032 W/kg SAR(1 g) = 0.0122 mW/g; SAR(10 g) = 0.00572 mW/g Reference Value = 0.711 V/m Power Drift = -0.08 dB Maximum value of SAR = 0.013 mW/g Date/Time: 08/08/04 10:59:48 Test Laboratory: Advance Data Technology F5D7050A 11b Bottom Mode 1 Ch 11 DUT: 54Mbps Wireless USB Network Adapter ; Type: F5D7050A ; Test Channel Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 (σ = 2.0129 mho/m, ε r = 52.4154, ρ = 1000 kg/m 3 ) ; Liquid level : 150mm Phantom section: Flat Section ; Separation distance : 8 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.4, 4.4, 4.4) ; Calibrated: 2003/8/29 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579 ; Calibrated: 2003/8/15 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.1 Build 47 ; Postprocessing SW: SEMCAD, V1.6 Build 115 High Channel/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 0.792 V/m Power Drift = -0.2 dB Maximum value of SAR = 0.0136 mW/g High Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.0342 W/kg SAR(1 g) = 0.0138 mW/g; SAR(10 g) = 0.00618 mW/g Reference Value = 0.792 V/m Power Drift = -0.2 dB Maximum value of SAR = 0.0144 mW/g Date/Time: 08/08/04 12:50:44 Test Laboratory: Advance Data Technology F5D7050A 11b Tip Mode 2 Ch 1 DUT: 54Mbps Wireless USB Network Adapter ; Type: F5D7050A ; Test Channel Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz; Duty Cycle: 1:1; Modulation type: CCK Medium: MSL2450 (σ = 1.9239 mho/m, ε r = 52.5073, ρ = 1000 kg/m 3 ) ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 0 mm (The tip of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.4, 4.4, 4.4) ; Calibrated: 2003/8/29 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn579; Calibrated: 2003/8/15 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.1 Build 47; Postprocessing SW: SEMCAD, V1.6 Build 115 Low Channel/Area Scan (5x6x1): Measurement grid: dx=15mm, dy=15mm Reference Value = 0.743 V/m Power Drift = -0.1 dB Maximum value of SAR = 0.0014 mW/g Low Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Peak SAR (extrapolated) = 0.00705 W/kg SAR(1 g) = 0.00119 mW/g; SAR(10 g) = 0.00091 mW/g Reference Value = 0.743 V/m Power Drift = -0.1 dB Maximum value of SAR = 0.00315 mW/g Date/Time: 08/08/04 13:12:24 Test Laboratory: Advance Data Technology F5D7050A 11b Tip Mode 2 Ch 6 DUT: 54Mbps Wireless USB Network Adapter ; Type: F5D7050A ; Test Channel Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz; Duty Cycle: 1:1; Modulation type: CCK Medium: MSL2450 (σ = 1.9766 mho/m, ε r = 52.4335, ρ = 1000 kg/m 3 ) ; Liquid leve…

Text truncated - open the document above for the full version.

APPENDIX B : ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM D2: DOSIMETRIC E-FIELD PROBE

D3: DAE

D4: 2450MHZ SYSTEM VALIDATION DIPOLE

FCC ID: K7SF5D7050A Report No.: RF930820L101Issued: Sep. 14, 2004 FCC TEST REPORT REPORT NO.: RF930820L10 MODEL NO.: F5D7050 RECEIVED: Jun. 02, 2004 TESTED: Jun. 02~ Sep. 10, 2004 APPLICANT: Belkin Corporation ADDRESS: 501 West Walnut Avenue, Compton, CA 90220, U.S.A ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 79 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: K7SF5D7050A Report No.: RF930820L102Issued: Sep. 14, 2004 Table of Contents 1CERTIFICATION .......................................................................................................4 2SUMMARY OF TEST RESULTS ...............................................................................5 2.1MEASUREMENT UNCERTAINTY.............................................................................5 3GENERAL INFORMATION........................................................................................6 3.1GENERAL DESCRIPTION OF EUT ..........................................................................6 3.2DESCRIPTION OF TEST MODES ............................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ...........................................7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................................8 3.5CONFIGURATION OF SYSTEM UNDER TEST.......................................................9 4TEST TYPES AND RESULTS .................................................................................10 4.1CONDUCTED EMISSION MEASUREMENT ..........................................................10 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................10 4.1.2TEST INSTRUMENTS.............................................................................................10 4.1.3TEST PROCEDURES ............................................................................................. 11 4.1.4DEVIATION FROM TEST STANDARD ................................................................... 11 4.1.5TEST SETUP...........................................................................................................12 4.1.6EUT OPERATING CONDITIONS ............................................................................12 4.1.7TEST RESULTS ......................................................................................................13 4.2RADIATED EMISSION MEASUREMENT ...............................................................25 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.............................................25 4.2.2TEST INSTRUMENTS.............................................................................................26 4.2.3TEST PROCEDURES .............................................................................................27 4.2.4DEVIATION FROM TEST STANDARD ...................................................................27 4.2.5TEST SETUP...........................................................................................................28 4.2.6EUT OPERATING CONDITIONS ............................................................................28 4.2.7TEST RESULTS ......................................................................................................29 4.2.8TEST RESULTS (A) ................................................................................................33 4.2.9TEST RESULTS (B) ................................................................................................36 4.36dB BANDWIDTH MEASUREMENT.......................................................................39 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................39 4.3.2TEST INSTRUMENTS.............................................................................................39 4.3.3TEST PROCEDURE................................................................................................40 4.3.4DEVIATION FROM TEST STANDARD ...................................................................40 4.3.5TEST SETUP...........................................................................................................40 4.3.6EUT OPERATING CONDITIONS ............................................................................40 4.3.7TEST RESULTS (A) ................................................................................................41 4.3.8TEST RESULTS (B) ................................................................................................45 4.4MAXIMUM PEAK OUTPUT POWER ......................................................................49 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT .......................49 FCC ID: K7SF5D7050A Report No.: RF930820L103Issued: Sep. 14, 2004 4.4.2TEST INSTRUMENTS.............................................................................................49 4.4.3TEST PROCEDURES .............................................................................................50 4.4.4DEVIATION FROM TEST STANDARD ...................................................................50 4.4.5TEST SETUP...........................................................................................................50 4.4.6EUT OPERATING CONDITIONS ............................................................................50 4.4.7TEST RESULTS (A) ............................................................................................…

Text truncated - open the document above for the full version.

FCC ID: K7SF5D7050A Report No.: RF930820L1075Issued: Sep. 14, 2004 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Test Mode 1) FCC ID: K7SF5D7050A Report No.: RF930820L1076Issued: Sep. 14, 2004 (Test Mode 2) FCC ID: K7SF5D7050A Report No.: RF930820L1077Issued: Sep. 14, 2004 RADIATED EMISSION TEST (Test Mode 1) FCC ID: K7SF5D7050A Report No.: RF930820L1078Issued: Sep. 14, 2004 (Test Mode 2)
