K7SF5D8630-4ADSL Modem with Wireless Pre-N Router

1 Introduction 1 2 1 3 4 5 6 7 8 9 10 11 12 section Thank you for purchasing the Belkin ADSL Modem with High-Speed Mode Wireless G Router (the Router). In minutes you will be able to share your Internet connection and network your computers with your new Router. The following is a list of features that make your Router an ideal solution for your home or small office network. Please be sure to read through this User Manual completely, and pay special attention to Appendix B entitled “Important Factors for Placement and Setup”. Benefits of a Home Network By following our simple setup instru ctions, you will be able to use your Belkin home network to: • Share one high-speed Internet connection with all the computers in your home • Share resources, such as files, and hard drives among all the connected computers in your home • Share a single printer with the entire family • Share documents, music, video, and digital pictures • Store, retrieve, and copy files from one computer to another • Simultaneously play games online, check Internet email, and chat Advantages of a Belkin Wireless Network Mobility – you’ll no longer need a dedicated “computer room”— now you can work on a networked laptop or desktop computer anywhere within your wireless range Easy installation – Belkin’s Easy Installation Wizard makes setup simple Flexibility – set up and access printers, computers, and other networking devices from anywhere in your home Easy Expansion – the wide range of Belkin networking products let you expand your network to include devices such as printers and gaming consoles No cabling required – you can spare the expense and hassle of retrofitting Ethernet cabling throughout the home or office Widespread industry acceptance – choose from a wide range of interoperable networking products 3232 Package Contents • MIMO ADSL Modem Router • RJ11 Telephone Cord - Gray • RJ45 Ethernet Networking Cable - Yellow • ADSL Microfilter* • Power Adapter • User Manual CD *ADSL microfilter varies by country. If it’s not included, you will need to purchase one. System Requirements • An active ADSL service with a telephone wall jack for connecting the Router • At least one computer with a Network Interface Card (NIC) and Internet browser installed and correctly configured • TCP/IP networking protocol installed on each computer connected to the Router • No other DHCP server on your local network assigning IP addresses to computers and devices Internet Connection Settings Please collect the following information from your Internet Service Provider (ISP) before setting up the ADSL Modem Wireless G Router. • Internet connection protocol: _________ (PPPoE, PPPoA, Dynamic IP, Static IP) • Multiplexing method or Encapsulation: __________ (LLC or VC MUX) • Virtual circuit: VPI (Virtual Path Identifier) __________ (a number between 0 and 255) • VCI (Virtual Channel Identifier) __________ (a number between 1 and 65535) • For PPPoE and PPPoA users: ADSL account user name _____________ and password _______________ • For static IP users: IP Address ___ . ___ . ___ . ___ Subnet Mask ___ . ___ . ___ . ___ Default Gateway Server ___ . ___ . ___ . • IP address for Domain Name Server ___ . ___ . ___ . ___ (If given by your ISP) Note: See Appendix C in this User Manual for some common DSL Internet setting parameters. If you are not sure, please contact your ISP. Make Sure You Have the Following 3 Knowing your Router 3 The Router is designed to be placed on a desktop. All of the cables exit from the rear of the Router for better organization and utility. The LED indicators are easily visible on the front of the Router to provide you with information about network activity and status. Front Panel 1. Power LED When you apply power to the Router or restart it, a short period of time elapses while the Router boots up. When the Router has completely booted up, the Power LED becomes a SOLID light, indicating the Router is ready for use. OFFRouter is OFF GreenRouter is ON RedRouter failed to start 2. LAN Status LED These LAN Status LEDs are labeled 1–4 and correspond to the numbered ports on the rear of the Router. When a computer is properly connected to one of the LAN ports on the rear of the Router, the LED will light. Solid GREEN means a computer or a network-enabled device is connected. When information is being sent over the port, the LED blinks rapidly. ORANGE indicates a 10Base-T connection. OFFNo device is connected or computer is powered off OrangeEthernet link is up and 10Base-T device connected Orange - blinkingWhen 10Base-T device transmitting or receiving data GreenEthernet link is up and 100Base-T connected Green - blinkingWhen 100Base-T device transmitting or receiving data ������������� ���������������������������� (1)(4)(5)(3) (2) section 2 1 3 4 5 6 7 8 9 10 11 12 54 Knowing your Router 54 Knowing your Router 3. WLAN Status LED The WLAN Status LED is solid GREEN when you enable the wireless LAN function. It flashes when the Router is transmitting or receiving data wirelessly. OFFWLAN is off GreenWLAN is up and connected Green - blinkingWhen transmitted or receiving data 4. ADSL LED The ADSL LED flashes GREEN during negotiation with your ISP. It stays GREEN when the Router is connected properly to your ADSL service. OFFno ADSL connection GreenADSL link is up and connected Green - blinkingnegotiating connection 5. Internet LED The Internet LED shows you when the Router is connected to the Internet. When the LED is OFF, the Router is NOT connected to the Internet. When the LED is solid GREEN, the Router is connected to the Internet. When the LED is blinking, the Router is transmitting or receiving data from the Internet. OFFNo Internet connection GreenConnected to the Internet Green - blinkingWhen transmitting or receiving data RedFailed to get IP 5 Knowing your Router 5 section 2 1 3 4 5 6 7 8 9 10 11 12 Back Panel 6. DSL Line This port is for connection to your ADSL line. Connect your ADSL line to this port. 7. Ethernet Ports …

Text truncated - open the document above for the full version.

4746 Manually Configuring your Router 4746 Manually Configuring your Router Setting WPA (with radius server) Settings If your network uses a radius server to distribute keys to the clients, use this setting. 1. From the “Security Mode” drop-down menu, select “WPA—Radius server)”. 2. For Encryption Technique, select “TKIP” or “AES”. This setting will have to be identical on the clients that you set up 3. Enter the IP address of the radius server into the “Radius Server” fields. 4. Enter the radius key into the “Radius Key” field. 5. Enter the key interval. Key interval is how often the keys are distributed (in packets). 6. Click “Apply Changes” to finish. You must now set all clients to match these settings. Configuring your Belkin Wireless G Network Cards to Use Security Please Note: This section provides information on how to configure your Belkin Wireless G Network Cards to use security. At this point, you should already have your Wireless Router or access point set to use WPA or WEP. In order for you to gain a wireless connection, you will need to set your wireless notebook card and wireless desktop card to use the same security settings. 47 Manually Configuring your RouterManually Configuring your Router 47 Manually Configuring your Router section 2 1 3 4 5 6 7 8 9 10 11 12 Connecting your Computer to a Wireless Network that Requires a 64-Bit or 128-Bit WEP Key 1. Double-click the “Signal Indicator” icon to bring up the “Wireless Network” screen. The “Advanced” button will allow you to view and configure more options of your wireless card. 2. Under the “Wireless Network Properties” tab, select a network name from the “Available networks” list and click “Configure”. 3. Under “Data Encryption” select “WEP”. 4. Ensure the check box “Network key is provided for me automatically” at the bottom is unchecked. If you are using this computer to connect to a corporate network, please consult your network administrator if this box needs to be checked. 5. Type your WEP key in the “Network key” box. Important: A WEP key is a mixture of numbers and letters from A–F and 0–9. For 128-bit WEP, you need to enter 26 characters. For 64- bit WEP, you need to enter 10 characters. This Network key needs to match the key you assign to your Wireless Router or access point. 6. Click “OK” to save the settings. 4948 Manually Configuring your Router 4948 Manually Configuring your Router Connecting your Computer to a Wireless Network that Requires WPA-PSK (no server) 1. Double-click the “Signal Indicator” icon to bring up the “Wireless Network” screen. The “Advanced” button will allow you to view and configure more options of your wireless card. 2. Under the “Wireless Networks” tab, select a network name from the “Available networks” list and click “Configure”. 3. Under “Network Authentication” select “WPA-PSK (No Server)”. 4. Type your WPA key in the “Network key” box. Important: WPA-PSK is a mixture of numbers and letters from A–Z and 0–9. For WPA-PSK you can enter eight to 63 characters. This Network key needs to match the key you assign to your Wireless Router or access point. 5. Click “OK” to save the settings. 49 Manually Configuring your RouterManually Configuring your Router 49 Manually Configuring your Router section 2 1 3 4 5 6 7 8 9 10 11 12 Connecting your Computer to a Wireless Network that Requires WPA (with radius server) 1. Double-click the “Signal Indicator” icon to bring up the “Wireless Network” screen. The “Advanced” button will allow you to view and configure more options of your wireless card. 2. Under the “Wireless Networks” tab, select a network name from the “Available networks” list and click “Configure”. 3. Under “Network Authentication” select WPA. 4. Under the “Authentication” tab, select the settings that are indicated by your network administrator. 5. Click “OK” to save the settings. Setting Up WPA for a Non-Belkin Wireless Desktop and Wireless Notebook Cards For non-Belkin WPA Wireless Desktop and Wireless Notebook Cards that are not equipped with WPA-enabled software, a file from Microsoft called “Windows XP Support Patch for Wireless Protected Access” is available as a free download. Please Note: The file that Microsoft has made available works only with Windows XP. Other operating systems are not supported at this time. 5150 Manually Configuring your Router 5150 Manually Configuring your Router Important: You also need to ensure that the wireless card manufacturer supports WPA and that you have downloaded and installed the latest driver from their support site. Supported Operating Systems: • Windows XP Professional • Windows XP Home Edition Setting Up Windows XP Wireless Network Utility to Use WPA-PSK In order to use WPA-PSK, ensure you are using Windows Wireless Network Utility by doing the following: 5. For a home or small business user, select “WPA-PSK” under “Network Authentication”. Note: Select “WPA” if you are using this computer to connect to a corporate network that supports an authentication server such as a radius server. Please consult your network administrator for further information. 1. Under Windows XP, click “Start > Control Panel > Network Connections”. 2. Right-click on “Wireless Network Connection”, and select “Properties”. 3. Clicking on the “Wireless Networks” tab will display the following screen. Ensure the “Use Windows to configure my wireless network settings” check box is checked. 4. Under the “Wireless Networks” tab, click the “Configure” button, and you will see the following screen. 51 Manually Configuring your RouterManually Configuring your Router 51 Manually Configuring your Router section 2 1 3 4 5 6 7 8 9 10 11 12 6. Select “TKIP” or “AES” under “Data Encryption”. This setting will have to be identical to the Router that you set up. 7. Type in your encryption key in the “Network Key” box. Important: Enter your Pre-Shared key. This can be from eight to 63 characters and can be letters, numbers, or symbols. This same key must be used on all of th…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID : K7SF5D8630-4 Label Location

FCC ID: K7SF5D8630-4 IC ID: 3623A-F5D8630 model # F5D8630-4 WAN MAC Address L AN MAC Address ADSL Modem with Wireless Pre-N Router 0560 P10737 F5D8630-4 WLAN MAC Address Made in China Z528

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9

FCC ID: K7SF5D8630-4 Report No.: RF941025L06 Technical Description The ADSL Modem with Wireless Pre-N Router with standards-based Wireless-G (802.11g) networking. By overlaying the signals of two Wireless-G compatible radios, the "Multiple In, Multiple Out" (MIMO) technology effectively achieve greater throughput. Unlike ordinary wireless networking technologies that are confused by signal reflections, MIMO actually uses these reflections to increase the range and reduce "dead spots" in the wireless coverage area. The robust signal travels farther, maintaining wireless connections up to three times farther than standard Wireless-G. And the farther away you are, the more advantage you get—the higher data rate and reflection-friendly technology can yield up to better throughput than Wireless-G in some situations. The network avoids interference by dynamically switching to the clearest channel available. Even your standard Wireless-G and Wireless-B equipment will work better when communicating with SRX-enabled devices. The transmitter of the EUT is powered by AC adapter. The antenna is Dipole antenna with UFL connector. The other instruction, please have a look at the users manual.

Report No: SA 941025L06 1 FCC ID: K7SF5D8630-4 RF EXPOSURE REPORT REPORT NO.: SA941025L06 MODEL NO.: F5D8630-4 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Belkin Corporation ADDRESS: 501 West Walnut Avenue Compton, CA 90220 ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. Report No: SA 941025L06 2 FCC ID: K7SF5D8630-4 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz Report No: SA 941025L06 3 FCC ID: K7SF5D8630-4 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This modular is specified to be installed in access point or router which is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. Report No: SA 941025L06 4 FCC ID: K7SF5D8630-4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 2dBi or 1.585(numeric) and 7dBi or 5.012(numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: Signal Chain 802.11b DSSS modulation Gain: 2dBi Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241240.3650.0131.0 6243765.0130.0201.0 11246240.0870.0131.0 802.11g OFDM modulation Gain: 2dBi Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241232.1370.0101.0 6243732.2850.0101.0 11246232.2110.0101.0 Dual Chain Gain: 2dBi PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 0 CHAIN 1 TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM2)) LIMIT OF POWER DENSITY (mW/CM2) 1241222.38721.77713.5013.3844.16416.450.0091.0 6243732.06331.26115.0614.9563.32418.020.0131.0 11246231.76931.47715.0214.9863.24618.010.0131.0

FCC ID: K7SF5D8630-4 Report No.: RF941025L061Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF941025L06 MODEL NO.: F5D8630-4 RECEIVED: Nov. 09, 2005 TESTED: Nov. 15 ~ Nov. 22, 2005 ISSUED: Nov. 24, 2005 APPLICANT: Belkin Corporation ADDRESS: 501 West Walnut Avenue Compton, CA 90220 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 104 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: K7SF5D8630-4 Report No.: RF941025L062Report Format Version 2.0.4 TABLE OF CONTENTS 1.CERTIFICATION ............................................................................................................5 2.SUMMARY OF TEST RESULTS ....................................................................................6 2.1 MEASUREMENT UNCERTAINTY ..................................................................................6 3.GENERAL INFORMATION.............................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ...............................................................................7 3.2 DESCRIPTION OF TEST MODES .................................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.............................................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..................................9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ..............................................13 3.4 DESCRIPTION OF SUPPORT UNITS .........................................................................13 4. TEST TYPES AND RESULTS (FOR SINGLE CHAIN (TX)).........................................14 4.1 CONDUCTED EMISSION MEASUREMENT ................................................................14 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .............................................14 4.1.2 TEST INSTRUMENTS ..................................................................................................14 4.1.3 TEST PROCEDURES ...................................................................................................15 4.1.4 DEVIATION FROM TEST STANDARD .........................................................................15 4.1.5 TEST SETUP ................................................................................................................16 4.1.6 EUT OPERATING CONDITIONS..................................................................................16 4.1.7 TEST RESULTS ............................................................................................................17 4.2 RADIATED EMISSION MEASUREMENT .....................................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ..................................................23 4.2.2 TEST INSTRUMENTS ..................................................................................................24 4.2.3 TEST PROCEDURES ...................................................................................................25 4.2.4 DEVIATION FROM TEST STANDARD .........................................................................26 4.2.5 TEST SETUP ................................................................................................................26 4.2.6 EUT OPERATING CONDITIONS..................................................................................26 4.2.7 TEST RESULTS ............................................................................................................27 4.3 6dB BANDWIDTH MEASUREMENT.............................................................................34 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT .........................................................34 4.3.2 TEST INSTRUMENTS ..................................................................................................34 4.3.3 TEST PROCEDURE .....................................................................................................35 4.3.4 DEVIATION FROM TEST STANDARD .........................................................................35 4.3.5 TEST SETUP ................................................................................................................35 4.3.6 EUT OPERATING CONDITIONS..................................................................................35 4.3.7 TEST RESULTS ............................................................................................................36 4.4 MAXIMUM PEAK OUTPUT POWER.............................................................................42 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ............................42 4.4.2 TEST INSTRUMENTS ..................................................................................................42 4.4.3 TEST PROCEDURES...................................................................................................43 4.4.4 DEVIATION FROM TEST STANDARD .........................................................................43 4.4.5 TEST SETUP ................................................................................................................43 4.4.6 EUT OPERATING CONDITIONS .................................................................................43 FCC ID: K7SF5D8630-4 Report No.: RF941025L063Report Format Version 2.0.4 4.4.7 TEST RESULTS............................................................................................................44 4.5 POWE…

Text truncated - open the document above for the full version.

FCC ID: K7SF5D8630-4 Report No.: RF941025L06Report Format Version 2.0.4 101 6. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: K7SF5D8630-4 Report No.: RF941025L06Report Format Version 2.0.4 102 RADIATED EMISSION TEST
