K7SF5D8633-4AN Wireless Modem Router

User Manual F5D8633-4 N Wireless Modem Router Table of Contents 1. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Advantages of a Wireless Network . . . . . . . . . . . . . . . . . . .1 Placement of your N Wireless Modem Router. . . . . . . . . . . 3 2. Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 3. Knowing your Modem Router . . . . . . . . . . . . . . . . . . . . . . .11 Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Setup Assistant Software System Requirements. . . . . . . . 11 4. Connecting and Configuring your Modem Router . . . . . . . . 18 5. Alternate Setup Method . . . . . . . . . . . . . . . . . . . . . . . . . . .30 6. Using the Web-Based Advanced User Interface . . . . . . . . .42 Changing LAN Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Viewing the DHCP Client List Page. . . . . . . . . . . . . . . . . . 45 Configuring the Wireless Network Settings. . . . . . . . . . . . 45 Setting WPA Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Setting WEP Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Using the Access Point Mode. . . . . . . . . . . . . . . . . . . . . . 55 Setting MAC Address Control. . . . . . . . . . . . . . . . . . . . . 56 Configuring the Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Using Dynamic DNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Utilities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Restarting the Router . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Updating the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . 69 7. Manually Configuring Network Settings . . . . . . . . . . . . . . . 77 8. Recommended Web Browser Settings. . . . . . . . . . . . . . . . . 82 9. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 10. Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97 1 section Introduction 9 2 3 4 5 6 7 8 10 Thank you for purchasing the Belkin N Wireless Modem Router (the Router). Following are two short sections—the first discusses the benefits of home networking, and the other outlines best practices that maximize your wireless home network range and performance. Please be sure to read through this User Manual completely, and pay special attention to the section entitled “Placement of your Wireless Networking Hardware for Optimal Performance” on the next page. By following our simple setup instructions you will be able to use your Belkin Home Network to: • Share one high-speed Internet connection with all the computers in your home • Share resources, such as files and hard drives among all the connected computers in your home • Share a single printer with the entire family • Share documents, music, video, and digital pictures • Store, retrieve, and copy files from one computer to another • Simultaneously play games online, check Internet email, and chat Advantages of a Wireless Network Here are some of the advantages of setting up a Belkin Wireless Network: • Mobility – you’ll no longer need a dedicated “computer room”—now you can work on a networked laptop or desktop computer anywhere within your wireless range • Easy installation – Belkin’s Easy Installation Wizard makes setup simple • Flexibility – set up and access printers, computers, and other networking devices from anywhere in your home • Easy expansion – the wide range of Belkin networking products let you expand your network to include devices such as printers and gaming consoles • No cabling required – you can spare the expense and hassle of retrofitting Ethernet cabling throughout the home or office • Widespread industry acceptance – choose from a wide range of interoperable networking products 1 Introduction 32 32 Revolutionary N Wireless Technology with MIMO (N MIMO) Your Belkin N Wireless Modem Router uses a new smart-antenna technology called Multiple Input Multiple Output (MIMO). N1 MIMO complies with the IEEE draft 802.11n specification. It increases speed, range, reliability, and spectral efficiency for wireless networking systems. The element that makes Belkin’s N MIMO technology different from a conventional radio is the use of multiple antennas and two simultaneous data streams to deliver wireless transfers around your home or office. A conventional radio uses one antenna to transmit a data stream. Belkin’s N MIMO, on the other hand, uses two antennas. This design helps combat distortion and interference. Belkin’s N MIMO is multidimensional. It builds on one-dimensional smart-antenna technology by simultaneously transmitting two data streams through the same channel, which increases wireless capacity. Another element that enhances Belkin’s N MIMO is the use of aggregation as specified in the draft 802.11n specification. By shortening the space between packets and combining multiple smaller packets into one larger packet, Belkin’s N MIMO can transmit more data through available bandwidth. Think of conventional radio transmission as a two-lane highway. The speed limit governs the maximum allowable flow of traffic through that lane. Compared with conventional radios, one-dimensional smart antenna systems help move traffic through that lane faster and more reliably—analogous to a four-lane road on which traffic consistently moves at a rate closer to the speed limit. Belkin’s N MIMO helps traffic move at the speed limit and opens more lanes—to become the superhighway in this example. The rate of traffic flow is multiplied by the number of lanes that are opened. 32 1 section Introduction 9 2 3 4 5 6 7 8 10 32 Placement of your N Wireless Modem Router Important Factors for Placement and Setup Your w…

Text truncated - open the document above for the full version.

29282928 Connecting and Configuring your Modem Router section 1 9 2 3 4 5 6 7 8 10 3.4 Verifying the Connection If all your wireless computers are able to connect to the Router, click “Next”. If you are having trouble, select “I had problem with at least one computer” and click “Next”. Then, follow on-screen instructions. Congratulations Once you have verified that your wireless computers are properly connected, your wireless network is set up and secured. You now can run your network wirelessly and securely. Click “Finish” to take you back to the main menu. 3130 Alternate Setup Method 3130 Step 1 Hardware Connections – Follow the Quick Installation Guide (QIG) See the QIG or Step 1: Hardware Connections from the previous section. Step 2 Set your Computer’s Network Settings to Work with a DHCP Server See the section in this User Manual called “Manually Configuring Network Settings” for directions. Step 3 Configuring the Router Using the Web-Based Advanced User Interface Using your Internet browser, you can access the Router’s Web-Based Advanced User Interface. In your browser, type “192.168.2.1” (do not type in anything else such as “http://” or “www”). Then press the “Enter” key. 31303130 Alternate Setup Method section 1 9 2 3 4 5 6 7 8 10 Logging into the Router You will see the Router’s home page in your browser window. The home page is visible to any user who wants to see it. To make any changes to the Router’s settings, you have to log in. Clicking the “Login” button or clicking on any one of the links on the home page will take you to the login screen. The Router ships with no password entered. In the login screen, leave the password blank and click the “Submit” button to log in. Logging out of the Router One computer at a time can log into the Router for the purposes of making changes to the settings of the Router. Once a user has logged in to make changes, there are two ways that the computer can be logged out. Clicking the “Logout” button will log the computer out. The second method is automatic. The login will time out after a specified period of time. The default login time-out is 10 minutes. This can be changed from one to 99 minutes. For more information, see the section in this manual titled “Changing the Login Time-Out Setting”. Understanding the Web-Based Advanced User Interface The home page (shown on the next page) is the first page you will see when you access the Advanced User Interface (UI). The home page shows you a quick view of the Router’s status and settings. All advanced setup pages can be reached from this page. 3332 Alternate Setup Method 3332 (13)(3) (4)(5) (11) (9) (1) (2) (8) (12) (7) (10) 1. Quick-Navigation Links You can go directly to any of the Router’s advanced UI pages by clicking directly on these links. The links are divided into logical categories and grouped by tabs to make finding a particular setting easier to find. Clicking on the purple header of each tab will show you a short description of the tab’s function. 2. Home Button The home button is available in every page of the UI. Pressing this button will take you back to the home page. 3. Help Button The “Help” button gives you access to the Router’s help pages. Help is also available on many pages by clicking “more info” next to certain sections of each page. 4. Login/Logout Button This button enables you to log in and out of the Router with the press of one button. When you are logged into the Router, this button will change to read “Logout”. Logging into the Router will take you to a separate login page where you will need to enter a password. When you are logged into the Router, you can make changes to the settings. When you are finished making changes, you can log out of the Router by clicking the “Logout” button. For more information about logging into the Router, see the section called “Logging into the Router”. (6) 33323332 Alternate Setup Method section 1 9 2 3 4 5 6 7 8 10 5. Internet-Status Indicator This indicator is visible in all pages of the Router, indicating the connection status of the Router. When the indicator says “Connected” in blue, the Router is connected to the Internet. When the Router is not connected to the Internet, the indicator will read “No Connection” in RED. The indicator is automatically updated when you make changes to the settings of the Router. 6. Connect/Disconnect Buttons Use these buttons to manually connect or disconnect your ADSL connection as needed. 7. Language Shows the active language for the Advanced User Interface. Select a desirable language by clicking one of the available languages. 8. Version Info Shows the firmware version, boot-code version, hardware version, and serial number of the Router. 9. LAN Settings Shows you the settings of the Local Area Network (LAN) side of the Router. Changes can be made to the settings by clicking on any one of the links (IP Address, Subnet Mask, DHCP Server) or by clicking the “LAN” quick- navigation link on the left side of the screen. 10. Internet Settings Shows the settings of the Internet/WAN side of the Router that connects to the Internet. Changes to any of these settings can be made by clicking on the links or by clicking on the “Internet/WAN” quick-navigation link on the left side of the screen. 11. Features Shows the status of the Router’s NAT, firewall, and wireless features. Changes can be made to the settings by clicking on any one of the links or by clicking the quick-navigation links on the left side of the screen. 12. ADSL Info Shows the ADSL status and transmission rates. 13. Page Name The page you are on can be identified by this name. This User Manual will sometimes refer to pages by name. For instance “LAN > LAN Settings” refers to the “LAN Settings” page. 3534 Alternate Setup Method 3534 Step 4 Configuring your Router for Connection to your Internet Service Provider (ISP) The “Internet/WAN” tab is where you will set up your Router to connect to your Internet Service Provider (ISP). The R…

Text truncated - open the document above for the full version.

59585958 Using the Web-Based Advanced User Interface section 1 9 2 3 4 5 6 7 8 10 Configuring Internal Forwarding Settings The Virtual Servers function will allow you to route external (Internet) calls for services such as a web server (port 80), FTP server (Port 21), or other applications through your Router to your internal network. Since your internal computers are protected by a firewall, computers outside your network (over the Internet) cannot get to them because they cannot be “seen”. A list of common applications has been provided in case you need to configure the Virtual Server function for a specific application. If your application is not listed, you will need to contact the application vendor to find out which port settings you need. Choosing an Application Select your application from the drop-down list. Click “Add”. The settings will be transferred to the next available space in the screen. Click “Apply Changes” to save the setting for that application. To remove an application, select the number of the row that you want to remove then click “Clear”. Manually Entering Settings into the Virtual Server To manually enter settings, enter the IP address in the space provided for the internal (server) machine, the port(s) required to pass (use a comma between multiple ports), select the port type (TCP or UDP), and click “Apply Changes”. You can only pass one port per internal IP address. Opening ports in your firewall can pose a security risk. You can enable and disable settings very quickly. It is recommended that you disable the settings when you are not using a specific application. 6160 Using the Web-Based Advanced User Interface 6160 Setting Client IP Filters The Router can be configured to restrict access to the Internet, email, or other network services at specific days and times. Restriction can be set for a single computer, a range of computers, or multiple computers. To restrict Internet access to a single computer for example, enter the IP address of the computer you wish to restrict access to in the IP fields (1). Next, enter “80” in both the port fields (2). Select “Both” (3). Select “Block” (4). You can also select “Always” to block access all of the time. Select the day to start on top (5), the time to start on top (6), the day to end on the bottom (7), and the time to stop (8) on the bottom. Select “Enable” (9). Click “Apply Changes”. The computer at the IP address you specified will now be blocked from Internet access at the times you specified. Note: Be sure you have selected the correct time zone under “Utilities> System Settings> Time Zone”. (1)(2) (3) (4)(7)(8)(9) (5) (6) 61606160 Using the Web-Based Advanced User Interface section 1 9 2 3 4 5 6 7 8 10 Enabling the Demilitarized Zone (DMZ) The DMZ feature allows you to specify one computer on your network to be placed outside of the firewall. This may be necessary if the firewall is causing problems with an application such as a game or video conferencing application. Use this feature on a temporary basis. The computer in the DMZ is NOT protected from hacker attacks. To put a computer in the DMZ, enter the last digits of its IP address in the IP field and select “Enable”. Click “Apply Changes” for the change to take effect. If you are using multiple static WAN IP addresses, it is possible to select which WAN IP address the DMZ host will be directed to. Type in the WAN IP address you wish the DMZ host to direct to, enter the last two digits of the IP address of the DMZ host computer, select “Enable” and click “Apply Changes”. 6362 Using the Web-Based Advanced User Interface 6362 Using Dynamic DNS The Dynamic DNS service allows you to alias a dynamic IP address to a static host name in any of the many domains DynDNS.org offers, allowing your network computers to be more easily accessed from various locations on the Internet. DynDNS.org provides this service, for up to five host names, free to the Internet community. The Dynamic DNS SM service is ideal for a home website, file server, or to make it easy to access your home PC and stored files while you’re at work. Using the service can ensure that your host name always points to your IP address, no matter how often your ISP changes it. When your IP address changes, your friends and associates can always locate you by visiting yourname.dyndns.org instead! To register free for your Dynamic DNS host name, please visit http://www.dyndns.org. Setting up the Router’s Dynamic DNS Update Client You must register with DynDNS.org’s free update service before using this feature. Once you have your registration, follow the directions below. 1. Select DynDNS.org from the “DNS Service” drop-down box (1). 2. Enter your DynDNS.org user name in the “User Name” field (2). 3. Enter your DynDNS.org password in the “Password” field (3). 4. Enter the DynDNS.org domain name you set up with DynDNS.org in the “Domain Name” field (4). 5. Click “Update Dynamic DNS” to update your IP address (5). Whenever your IP address assigned by your ISP changes, the Router will automatically update DynDNS.org’s servers with your new IP address. You can also do this manually by clicking the “Update Dynamic DNS” button (5). (1) (2) (3) (5) (4) 63626362 Using the Web-Based Advanced User Interface section 1 9 2 3 4 5 6 7 8 10 Blocking an ICMP Ping Computer hackers use what is known as “pinging” to find potential victims on the Internet. By pinging a specific IP address and receiving a response from the IP address, a hacker can determine that something of interest might be there. The Router can be set up so it will not respond to an ICMP ping from the outside. This heightens your Router’s security level. (1) To turn off the ping response, select “Block ICMP Ping” (1) and click “Apply Changes”. The Router will not respond to an ICMP ping. Utilities The “Utilities” screen lets you manage different parameters of the Router and perform certain administrative functions. 6564 Using the Web-Based Advanced User In…

Text truncated - open the document above for the full version.

Belkin International, Inc. 501 West Walnut Street, Compton CA, 90220-5221, U.S.A. Date: 2007/11/16 GENERAL DECLARATION We, Belkin International, Inc. declares that device does not have “Ad Hoc on non-US frequencies” and/or “on DFS frequencies” while applying for the follow product. FCC ID: K7SF5D8633-4A If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Marc S. Matejka Belkin International, Inc. TEL：1 (310) 604-2448 FAX：1 (310) 631-3629 [email protected]

Belkin International, Inc. 501 West Walnut St. Compton, CA, 90220-5221, USA Power of Attorney 2007/11/28 To whom it may concern: We, the undersigned Belkin International, Inc. hereby authorize Advance Data Technology Corporation (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, -------------------------------------------------- Marc Matejka Belkin International, Inc. TEL：1 (310) 604-2448 FAX：1 (310) 631-3629 [email protected]

Belkin International, Inc. 501 West Walnut Street, Compton CA, 90220-5221, U.S.A. 2007/11/16 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: K7SF5D8633-4A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, -------------------------------------------------- Marc S. Matejka Belkin International, Inc. TEL：1 (310) 604-2448 FAX：1 (310) 631-3629 [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID： ：： ：K7SF5D8633-4A LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

AR7505QW 1-A-LF-AK 146000051901J UL LabelR02 2007 11 22 CHECK: APPROVAL: Celeste Sary QW-RD-003-06-A UL approve--Acrylic NOTE: 1.Printing Ink and material must base on WEEE environment protect standard 2.The part of weight about 0.62g(include liner) 3.The material must follow up the RoHS requirement 1SVA accton technology CO LTD.GZ 2Accton Joytech CO LTDAC 3Accton Technology CO LTD.None 4Compal Corp.(Kunshan)CI Background: Transpartent Wording: 100%Black XX 146000051901J R02 XX Transparent polyester (25#) + MATT PP(KK Material) 0.088mm R 9.0mm*4 2.5mm 9.0mm 38*25 label here FCC ID:K7SF5D8633-4A US:BKCDL01BF5D8633A 1 Add FCC logo 2 Add A-tick logo 3 Add New Zealand ID This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation.

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: K7SF5D8633-4A Report No. RF960726H09 Operational Description This device is a N Wireless Modem Router, which operates in the 2.4GHz frequency spectrum with throughput of up to 270Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 270Mbps, the 11Mbps data rate with DSSS technique will be applied. 1. There are two antennas provided to this EUT, please refer to the following table: No. Antenna Type Gain (dBi) Antenna Connector 1 Dipole 2 NA 2 Dipole 2 NA 2. The EUT incorporates a MIMO function with 802.11b, 802.11g, draft 802.11n. Physically, the card provides two completed transmit and two completed receivers. 3. The EUT is 2 * 2 spatial MIMO without beam forming function. The antenna configurations are two transmitter antennas and two receiver antennas, as there are 2 dipole antennas. Spatial multiplexing modes for simultaneous transmission using 2 antennas, and for simultaneous receiver using 2 antennas. 4. When the EUT operating in draft 802.11n, the software operation, which is defined by manufacturer, MCS (Modulation and Coding Schemes) from 0 to 15. 5. The EUT complies with draft 802.11n standards and backwards compatible with 802.11b, 802.11g products. 6. The EUT operates in the 2.4GHz frequency spectrum with data rate up to 270Mbps. 7. The EUT must be supplied with a power adapter as following: Brand: Leader Model No.: 481508OO3CT Input power : AC120, 220mA, 60Hz Output power : 15VDC, 0.8A Cable : unshielded , 1.6m 8. The EUT, operates in the 2.4GHz frequency range, lets you connect IEEE 802.11g or IEEE 802.11b and draft 802.11n technique devices to the network. 9. The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or user's manual.

Report No.: SA960718H04C Reference No.:961105H03 1 RF EXPOSURE REPORT REPORT NO.: SA960718H04C MODEL NO.: F5D8633-4 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Belkin International, Inc. ADDRESS: 501 West Walnut Street, Compton CA, 90220-5221, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. Report No.: SA960718H04C Reference No.:961105H03 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Report No.: SA960718H04C Reference No.:961105H03 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device Report No.: SA960718H04C Reference No.:961105H03 4 6. Test Results 6.1 Antenna Gain There are two antennas provided to this EUT, please refer to the following table: No. Antenna Type Gain (dBi) Antenna Connector 1 Dipole 2 NA 2 Dipole 2 NA 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For Part 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 112.202 0.035 1.0 6 2437 118.850 0.037 1.0 11 2462 118.850 0.037 1.0 For Part 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 95.499 0.030 1.0 6 2437 105.925 0.033 1.0 11 2462 105.925 0.033 1.0 Report No.: SA960718H04C Reference No.:961105H03 5 DRAFT 802.11n (20MHz) OFDM : Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 183.176 0.058 1.0 6 2437 182.402 0.058 1.0 11 2462 186.700 0.059 1.0 DRAFT 802.11n (40MHz) OFDM : Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2422 147.510 0.047 1.0 4 2437 147.241 0.046 1.0 7 2452 147.241 0.046 1.0

Report No.: RF960718H04C 1 Report Format Version 2.0.6 Reference No.:961105H03 FCC TEST REPORT REPORT NO.: RF960718H04C MODEL NO.: F5D8633-4 RECEIVED: Nov. 05, 2007 TESTED: Nov. 12 to 22, 2007 ISSUED: Nov. 26, 2007 APPLICANT: Belkin International, Inc. ADDRESS: 501 West Walnut Street, Compton CA, 90220-5221, U.S.A. ISSUED BY: Advance Data Technology Corporation TEST LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 103 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report No.: RF960718H04C 2 Report Format Version 2.0.6 Reference No.:961105H03 Table of Contents 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY...................................................................6 3. GENERAL INFORMATION...........................................................................7 3.1 GENERAL DESCRIPTION OF EUT..............................................................7 3.2 DESCRIPTION OF TEST MODES................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................13 3.4 DESCRIPTION OF SUPPORT UNITS........................................................14 3.5 CONFIGURATION OF SYSTEM UNDER TEST.........................................15 4. TEST TYPES AND RESULTS.....................................................................17 4.1 CONDUCTED EMISSION MEASUREMENT..............................................17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................17 4.1.2 TEST INSTRUMENTS................................................................................17 4.1.3 TEST PROCEDURES.................................................................................18 4.1.4 DEVIATION FROM TEST STANDARD.......................................................18 4.1.5 TEST SETUP...................…
