FCC ID: K7SF5D9050B Report No. RF940630L02 Operational Description This device is a Wireless G Plus MIMO USB Network Adapter which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is Printed antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

Report no.: SA940630L021Report Format Version 2.0.3 SAR TEST REPORT REPORT NO.: SA940630L02 MODEL NO.: F5D9050 v3000 RECEIVED: Mar. 02, 2006 TESTED: Mar. 09, 2006 ISSUED: Mar. 13, 2006 APPLICANT: Belkin Corporation ADDRESS: 501 West Walnut Avenue Compton, CA 90220 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 36 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report no.: SA940630L022Report Format Version 2.0.3 TABLE OF CONTENTS 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ...................................................5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................8 3.DESCRIPTION OF SUPPORT UNITS ......................................................................12 4.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................13 4.1. DESCRIPTION OF ANTENNA LOCATION ...............................................................13 4.2. DESCRIPTION OF ASSESSMENT POSITION ........................................................14 4.3. DESCRIPTION OF TEST MODE ..............................................................................15 4.4. SUMMARY OF TEST RESULTS ...............................................................................15 5.TEST RESULTS ........................................................................................................16 5.1 TEST PROCEDURES ...............................................................................................16 5.2 MEASURED SAR RESULTS ....................................................................................18 5.3 SAR LIMITS...............................................................................................................20 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................21 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................23 6.SYSTEM VALIDATION ..............................................................................................24 6.1 TEST EQUIPMENT ...................................................................................................24 6.2 TEST PROCEDURE .................................................................................................25 6.3 VALIDATION RESULTS ............................................................................................27 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................28 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................29 7.1. PROBE CALIBRATION UNCERTAINTY...................................................................29 7.2. ISOTROPY UNCERTAINTY .....................................................................................30 7.3. BOUNDARY EFFECT UNCERTAINTY.....................................................................30 7.4. PROBE LINEARITY UNCERTAINTY ........................................................................31 7.5. READOUT ELECTRONICS UNCERTAINTY ............................................................31 7.6. RESPONSE TIME UNCERTAINTY ..........................................................................31 7.7. INTEGRATION TIME UNCERTAINTY ......................................................................32 7.8. PROBE POSITIONER MECHANICAL TOLERANCE ...............................................33 7.9. PROBE POSITIONING .............................................................................................33 7.10. PHANTOM UNCERTAINTY ......................................................................................34 7.11. DASY4 UNCERTAINTY BUDGET ............................................................................35 8.INFORMATION ON THE TESTING LABORATORIES ..............................................36 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report no.: SA940630L023Report Format Version 2.0.3 1. CERTIFICATION PRODUCT: Wireless G Plus MIMO USB Network Adapter MODEL: F5D9050 v3000 BRAND: Belkin APPLICANT: Belkin Corporation TESTED: Mar. 09, 2006 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093), RSS-102 FCC OET Bulletin 65, Supplement C (01-01) The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Mar. 13, 2006 Jessie Wang TECHNICAL ACCEPTANCE :, DATE:Mar. 13, 2006 Responsible for RF Stanely Hsu APPROVED BY:, DATE:Mar. 13, 2006 Gary Chang / Supervisor Report no.: SA940630L024Report Format Version 2.0.3 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Wireless G Plu…

Text truncated - open the document above for the full version.

A - 1 APPENDIX A: TEST DATA Liquid Level Photo MSL 2450MHz D=150mm A - 2 Date/Time: 2006/3/9 13:56:38 Test Laboratory: Advance Data Technology D600-11b-Ch1-Mode 1 DUT: Wireless G Plus MIMO USB Network Adapter ; Type: F5D9050 v3000 ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 51; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 0 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.2 degrees ; Liquid temp. : 21.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 Low Channel 1/Area Scan (5x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.16 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 16.0 V/m Peak SAR (extrapolated) = 3.27 W/kg SAR(1 g) = 1.39 mW/g; SAR(10 g) = 0.616 mW/g Maximum value of SAR (measured) = 1.56 mW/g A - 3 A - 4 Date/Time: 2006/3/9 14:14:05 Test Laboratory: Advance Data Technology D600-11b-Ch6-Mode 1 DUT: Wireless G Plus MIMO USB Network Adapter ; Type: F5D9050 v3000 ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 2 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 0 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.2 degrees ; Liquid temp. : 21.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 Mid Channel 6/Area Scan (5x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.961 mW/g Mid Channel 6/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 14.6 V/m Peak SAR (extrapolated) = 2.79 W/kg SAR(1 g) = 1.18 mW/g; SAR(10 g) = 0.522 mW/g Maximum value of SAR (measured) = 1.34 mW/g A - 5 Date/Time: 2006/3/9 14:30:57 Test Laboratory: Advance Data Technology D600-11b-Ch11-Mode 1 DUT: Wireless G Plus MIMO USB Network Adapter ; Type: F5D9050 v3000 ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2462 MHz; σ = 2.04 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 0 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.2 degrees ; Liquid temp. : 21.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 High Channel 11/Area Scan (5x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.730 mW/g High Channel 11/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 12.6 V/m Peak SAR (extrapolated) = 2.03 W/kg SAR(1 g) = 0.875 mW/g; SAR(10 g) = 0.391 mW/g Maximum value of SAR (measured) = 0.992 mW/g A - 6 Date/Time: 2006/3/9 14:49:27 Test Laboratory: Advance Data Technology D600-11g-Ch1-Mode 2 DUT: Wireless G Plus MIMO USB Network Adapter ; Type: F5D9050 v3000 ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 51; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 0 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.2 degrees ; Liquid temp. : 21.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 160 Low Channel 1/Area Scan (5x10x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.383 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.34 V/m Peak SAR (extrapolated) = 1.10 W/kg SAR(1 g) = 0.467 mW/g; SAR(10 g) = 0.207 mW/g Maximum value of SAR (measured) = 0.535 mW/g A - 7 Date/Time: 2006/3/9 15:36:48 Test Laboratory: Advance Data Technology C600-11b-Ch1-Mode 3 DUT: Wireless G Plus MIMO USB Network Adapter ; Type: F5D9050 v3000 ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 51; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 5 mm (The edge side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 22.2 degrees ; Liquid temp. : 21.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1790 ; ConvF(4.35, 4.35, 4.35) ; Calibrated: 2004/12/20 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: S…

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM D4：DAE3 (Cal Date：August 17.2005)

Report No.: RF940630L021Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF940630L02 MODEL NO.: F5D9050 v3000 RECEIVED: Mar. 02, 2006 TESTED: Mar. 03 ~ Mar. 07, 2006 ISSUED: Mar. 09, 2006 APPLICANT: Belkin Corporation ADDRESS: 501 West Walnut Avenue Compton, CA 90220 ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 65 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. No. 2177-01 Report No.: RF940630L022Report Format Version 2.0.4 Table of Contents 1CERTIFICATION ..........................................................................................................4 2SUMMARY OF TEST RESULTS ..................................................................................5 2.1MEASUREMENT UNCERTAINTY ...............................................................................5 3GENERAL INFORMATION...........................................................................................6 3.1GENERAL DESCRIPTION OF EUT.............................................................................6 3.2DESCRIPTION OF TEST MODES...............................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ..........................................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ...............................8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................................10 3.4DESCRIPTION OF SUPPORT UNITS .......................................................................10 4TEST TYPES AND RESULTS .................................................................................... 11 4.1CONDUCTED EMISSION MEASUREMENT .............................................................11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 11 4.1.2 TEST INSTRUMENTS................................................................................................ 11 4.1.3 TEST PROCEDURES ................................................................................................12 4.1.4 DEVIATION FROM TEST STANDARD ......................................................................12 4.1.5 TEST SETUP .............................................................................................................13 4.1.6 EUT OPERATING CONDITIONS ...............................................................................13 4.1.7 TEST RESULTS .........................................................................................................14 4.2RADIATED EMISSION MEASUREMENT ..................................................................20 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................20 4.2.2 TEST INSTRUMENTS................................................................................................21 4.2.3 TEST PROCEDURES ................................................................................................22 4.2.4 DEVIATION FROM TEST STANDARD ......................................................................22 4.2.5 TEST SETUP .............................................................................................................23 4.2.6 EUT OPERATING CONDITIONS ...............................................................................23 4.2.7 TEST RESULTS .........................................................................................................24 4.36dB BANDWIDTH MEASUREMENT .........................................................................32 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .......................................................32 4.3.2 TEST INSTRUMENTS................................................................................................32 4.3.3 TEST PROCEDURE...................................................................................................33 4.3.4 DEVIATION FROM TEST STANDARD ......................................................................33 4.3.5 TEST SETUP .............................................................................................................33 4.3.6 EUT OPERATING CONDITIONS ...............................................................................33 4.3.7 TEST RESULTS .........................................................................................................34 4.4MAXIMUM PEAK OUTPUT POWER .........................................................................40 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT..........................40 Report No.: RF940630L023Report Format Version 2.0.4 4.4.2 TEST INSTRUMENTS................................................................................................40 4.4.3 TEST PROCEDURES ................................................................................................41 4.4.4 DEVIATION FROM TEST STANDARD ......................................................................41 4.4.5 TEST SETUP .............................................................................................................41 4.4.6 EUT OPERATING CONDITIONS ...............................................................................41 4.4.7 TEST RESULTS .........................................................................................................42 4.5POWER SPECTRAL DENSITY MEASUREMENT ....................................................43 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ..................................43 4.5.2…
