K7SF8E845MSERechargeable Wireless Optical Mouse

Rechargeable Wireless Optical Mouse Belkin Tech Support US: 800-223-5546, ext. 2263 310-898-1100, ext. 2263 Europe: 00 800 223 55 460 Australia: 1800 235 546 New Zealand: 0800 235 546 Belkin Corporation 501 West Walnut Street Compton, CA 90220, USA Tel: 310-898-1100 Fax: 310-898-1111 © 2004 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. P74720 Belkin Ltd. Express Business Park, Shipton Way Rushden, NN10 6GL, United Kingdom Tel: +44 (0) 1933 35 2000 Fax: +44 (0) 1933 31 2000 Belkin B.V. Boeing Avenue 333 1119 PH Schiphol-Rijk,The Netherlands Tel: +31 (0) 20 654 7300 Fax: +31 (0) 20 654 7349 Belkin Ltd. 7 Bowen Crescent, West Gosford NSW 2250, Australia Tel: +61 (0) 2 4372 8600 Fax: +61 (0) 2 4372 8603 Rechargeable Wireless Optical Mouse User Manual Navigate, input data, and charge for advanced wireless functionality F8E845-MSE Table of Contents 1 Introduction ...............................................................1 System Requirements ............................................2 Packaging Includes ................................................2 Overview ................................................................2 2 Hardware Installation ...............................................3 Connecting the USB Mouse ..................................4 Connecting the PS/2 Mouse ..................................5 Synchronizing your Mouse to your Receiver .........6 3 Software Installation ................................................7 Software Features ..................................................8 Button Functions ....................................................8 Charging .................................................................8 4 Troubleshooting ........................................................9 5 Information .............................................................12 Introduction 1 Congratulations and thank you for purchasing the Rechargeable Wireless Optical Mouse from Belkin. You are about to experience a whole new world of computing convenience with superior input features and navigating accuracy. The Mouse works from up to six feet away without a cord, giving you unencumbered freedom of movement. It provides five customizable buttons, including the convenient scroll wheel, to make repetitive tasks simpler than ever. Please review this User Manual thoroughly to ensure your safe, long-term use of the Mouse, and for help in getting the most from its advanced features. 1 ___ 2 ___ 3 ___ 4 ___ 5 Introduction 2 System Requirements • Windows ® 98 SE, Me, 2000, or XP • CD-ROM drive • 5MB of available disk space • USB or PS/2 port Packaging Includes • Rechargeable Wireless Optical Mouse • Charging Cradle • Software CD • User Manual • 2 NiMH Batteries • PS/2 Adapter Overview Before starting the installation of the hardware and software for the Mouse, please remove any drivers or software from any mice that were previously installed on your computer. This is to avoid any conflicts they may create, which could result in an improper installation of your Mouse. Please consult the documents that came with your previous mouse for proper instructions on how to uninstall the software and drivers. 1 ___ 2 ___ 3 ___ 4 ___ 5 Hardware Installation 3 Important: Before connecting your Mouse or installing software, be sure to identify the type of mouse port you are using (USB or PS/2). Refer to the diagrams below if you have difficulty determining which kind of port your Mouse uses. Important: Do not install the software until the Mouse is connected to your computer. If you have not yet connected the Mouse, please follow the Hardware Installation instructions. Note: Your Mouse is functional without installing the software provided. However, we recommend software installation because the software allows you to program the Mouse buttons for various functions, adding personalized efficiency and enjoyment to your computing experience. PS/2 PortUSB Port 1 ___ 2 ___ 3 ___ 4 ___ 5 Hardware Installation 4 Connecting the USB Mouse USB in Windows 98 SE, Me, 2000, and XP 1. Make sure your computer is turned on before installing the Mouse. 2. Connect the receiver to an available USB port on your computer. 3. A New Hardware Wizard will start automatically. Note: Windows 98 SE may require you to insert your Windows 98 SE Installation CD into your computer’s CD-ROM drive to complete the install. 4. When your Installation is complete, insert the batteries into the Mouse and the Mouse should sync up with the receiver automatically. Note: If the Mouse does not sync up with the receiver automatically, please see instructions titled “Synchronizing your Mouse to your Receiver”. 5. When your Mouse is properly connected and functioning as a standard mouse, you can start the software installation for the extra button features. 1 ___ 2 ___ 3 ___ 4 ___ 5 Hardware Installation 5 Connecting the PS/2 Mouse PS/2 in Windows 98 SE, Me, 2000, and XP 1. Turn off your computer. 2. Connect the USB-to-PS/2 connector to the mouse cable on the receiver. 3. Insert the cable with the connector to the PS/2 (6-pin) mouse port on your computer. 4. Place the batteries into the Mouse. 5. Turn the computer on. 6. When the computer finishes starting up, it will automatically detect the Mouse and make it function. Note: If the Mouse does not work, please see instructions under “Synchronizing your Mouse to your Receiver”. 7. When your Mouse is properly connected, you can start the software installation. 1 ___ 2 ___ 3 ___ 4 ___ 5 Hardware Installation 6 Synchronizing your Mouse to your Receiver If the Mouse does not automatically sync with the receiver, press the connect button on the front of the receiver. The light on the receiver will blink rapidly. Then sync the Mouse to the receiver by pushing the sync button on the bottom of the Mouse. The light on the receiver will stop blinking and light brightly. Note: Each time you repeat this step, the…

Text truncated - open the document above for the full version.

Request for Confidentiality Federal Communications Commission Authorization and Evaluation Division Subject: Confidentiality Request regarding application for certification of FCC ID: K7SF8E845MSE Dear Madam or Sir: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: l Schematics l Part List l Block diagram l Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA 04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: l External Photos l Internal Photos l Test Setup Photos l User’s Manual Sincerely, Mark Freeman, Product Manager Belkin Corporation

0 2ECHARGEABLE7IRELESS /PTICAL-OUSE "ELKIN&% -3% 3. &##)$+3&%-3% -ADEIN#HINA &% -3% 4HISDEVICECOMPLIESWITH0ARTOFTHE&##2ULES

Test Report ----------------------------------------------------------------------------- 1/17 Report No.: B1515447 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Report No. B1515447 FCC ID K7SF8E845MSE Specifications FCC Part 15, Class B Test Method ANSI C63.4 Application ■Original □Class II Changes Applicant Belkin Corporation Applicant 501 West Walnut Street Compton, CA 90220-5221, USA address Product name Rechargeable Wireless Optical Mouse Items tested Wireless Mouse Model No. F8E845-MSE Sample No. C31142 EUT Condition ■Engineering sample □Pre-production □Final production Frequency Range 26.96MHz to 27.28MHz Results Passed (As detailed within this report) Date 09/18/2004 (month / day / year)(Sample received) 10/13/2004 (month / day / year)(Tested) Prepared by Project Engineer Authorized by V. General Manager (Jacob Lin) Issue date December 13, 2004 (month / day / year) Modified by TRC None Tested by Training Research Co., Ltd. (Accredited by NVLAP) Office at 1F, No. 255, Nan Yang Street, Hsichih, Taipei Hsien 221, Taiwan Open site at No. 15, Lane 530, Pa-Lian RD., Sec. 1, Hsichih City, Taipei Hsien, Taiwan, R.O.C. Conditions of issue : z This test report shall not be reproduced except in full, without written approval of TRC. And the test result contained within this report only relate to the sample submitted for testing. z The test data in this test report are following the procedures in accordance with the terms of accreditation. z This test report and measurements made by TRC are traceable to the NIST only Conducted and Radiated Method (TRC is accredited by NVLAP, code No.: 200174-0). z The device has been tested is fully complied with the requirements the Directive FCC Part 15. Test Report ----------------------------------------------------------------------------- 2/17 Report No.: B1515447 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Contents Chapter 1 Introduction Description of EUT ................................................................................................................... 3 Configuration of Test Setup ...................................................................................................... 4 List of Support Equipment ........................................................................................................ 6 Chapter 2 Conducted Emission Test Test Condition and Setup .......................................................................................................... 8 Conducted Test Placement ........................................................................................................9 Chapter 3 Peak Power Measurement (Frequency Band: 26.96 ~ 27.28) Test Setup ................................................................................................................................. 10 Test Procedure.......................................................................................................................... 10 Chapter 4 Radiated Emission Test Test Condition and Setup ......................................................................................................... 11 Radiated Test Placement .......................................................................................................... 12 Appendix A : Conducted test result ................................................................................................................ 13 Appendix B: Peak Power and Radiated test result ........................................................................................ 14 Appendix C: Band Edge of Measurement ..................................................................................................... 16 Test Report ----------------------------------------------------------------------------- 3/17 Report No.: B1515447 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Chapter 1 Introduction EUT : Wireless Mouse Model No. : F8E845-MSE Product name : Rechargeable Wireless Optical Mouse Frequency Range : 26.96 – 27.28 MHz Power Type : Powered by two 1.5VDC AA batteries *This EUT has one channel (each with 256 IDs): 27.1010MHz Test method: Pretest was found that the emission of operating mode is worse than standby mode. So, The final test is made at the operating mode. During the measurement, the following mode were tested: #1 Stand-alone Transmitting #2 Charging by Adaptor. The conduction pretest was found out “#2 Charging by Adaptor” was the worst case. The radiation pretest was found out “#1 Stand-alone transmitting” was the worst case. We only recorded this data in this report. While testing, the EUT was made to transmit continuously and adjusted at a position, which transmitted the maximum emission. The test placement as the photographs showed is the worst case emission placed. (If the emission is close to the ambient, the resolution BW and view resolution will be reduced and the data will be recorded by detection of maximum hold peak mode.) The testing configuration of test setup is showing in the next page. There is no deviation from standard test method. Test Report ----------------------------------------------------------------------------- 4/17 Report No.: B1515447 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Configuration of Test Setup (Test mode: “#1”) EUT: *Put two AA size, 1.5V battery into the battery cell of EUT, powers the subject device. The EUT does not be connected with any product. EUT Test Report ----------------------------------------------------------------------------- 5/17 Report No.: B1515447 Training Research Co., Ltd., TEL: 886-2-26461146, Fax: 886-2-26461778 Configuration of Test Setup (Test mode: #2) Connections: PC: *Serial Port --- via a 110cm shielded RS-232 cable to an external modem. *Monitor Port --- a monitor with 1.5m length data cable. *Keyboard port --- a keyboard with 1.5m length data cable. *Mouse port --- to EUT. *USB port A --- an US…

Text truncated - open the document above for the full version.

Conducted Test Placement: (Photographs) Radiated Test Placement: (Photographs)
