En Bluetooth ™ USB Adapter F8T008 - F8T009 Connect your peripherals and computing devices, without cables Quick Installation Quide P74768_F8T008-9_QIG.indd 13/23/05 2:46:51 PM Introduction PC System Requirements • PC-compatible computer, CPU speed of 200MHz or above • Memory: 64MB or above, 128MB recommended • One available USB port, USB 1.1 standard • Windows ® 98 SE, Me, 2000, and XP Mac ® System Requirements • One available USB port, USB 1.1 standard • Mac OS ® X v10.3 and higher* Product Contents • Bluetooth USB Adapter • CD-ROM for installation software and documentation • User Manual • Quick Installation Guide *Mac OS X driver and software provided by Apple ® . 1 P74768_F8T008-9_QIG.indd 13/23/05 2:46:53 PM 232 Step 1: Software Setup Software Setup for Windows 98 SE, Me, 2000, and XP To install the software for the USB Adapter, follow the instructions below: Note: The installation process for Windows XP may look slightly different from Windows 98 SE, Me, and 2000. Note: Do not insert the USB Adapter into the USB port prior to software installation. 1. Insert the software installation CD-ROM into the PC’s CD-ROM drive. 2. The “Software InstallShield Wizard” window appears. Click on “Next” to begin the installation process. P74768_F8T008-9_QIG.indd 23/23/05 2:46:54 PM 232 3. Choose “I accept the terms in the license agreement” to accept the license agreement. Click on “Next” to continue. 4. Specify the location where the software files will be installed on your hard drive. It is recommended that you install the software in the default directory “C:\Program Files\belkin\Bluetooth\ Software\”. Click on “Next” to continue. Step 1: Software Setup P74768_F8T008-9_QIG.indd 33/23/05 2:46:55 PM 454 Step 1: Software Setup 5. Confirm that the device software is ready to be installed and click on “Install”. 6. The InstallShield Wizard will begin to install the Belkin Bluetooth Software. This may take several minutes. P74768_F8T008-9_QIG.indd 43/23/05 2:46:56 PM 454 Step 1: Software Setup 7. During the installation process you may be prompted to insert your USB Adapter. If your USB Adapter is not plugged into your computer at this time, you may insert it into an available USB 1.1-compliant port on your desktop or notebook computer, then click “OK” to continue. Click on “Cancel” to continue installation without the Bluetooth device inserted. Refer to the “Hardware Installation” section of this User Manual for instructions for installing the hardware. Note: If at any time during the installation process you receive a “Driver Signature Notice”, click “OK” to continue the installation process. P74768_F8T008-9_QIG.indd 53/23/05 2:46:57 PM 676 Step 1: Software Setup 8. Confirm the completion of the software installation; click “Finish” and restart the system if prompted to do so. P74768_F8T008-9_QIG.indd 63/23/05 2:46:57 PM 676 Step 2: Hardware Setup Hardware Setup for Windows 98 SE, Me, 2000, and XP Follow these instructions to install your USB Adapter on your PC. Note: Your USB Adapter is sensitive to static electricity, which can damage its delicate electrical components. To protect your device, always touch the metal chassis of your computer before handing the USB Adapter. This will ground any potential electrostatic discharge. Avoid touching the metal connector when handling the USB Adapter. Dry weather conditions or walking across carpeted floors may cause you to acquire an electrostatic charge. 1. Connect the USB Adapter directly to an available USB A-type connector on your desktop or notebook computer. Your system should register a new USB device found. 2. Choose “Install from a list or specific location”; then click “Next”. P74768_F8T008-9_QIG.indd 73/23/05 2:46:58 PM 898 Step 2: Hardware Setup 3. Browse for the location of the device driver “:\Program Files\Belkin\ Bluetooth\Software\bin\” then click “Next”. 4. If you receive the following “Hardware installation notice”, click on “Continue Anyway” to continue with the installation process. P74768_F8T008-9_QIG.indd 83/23/05 2:46:59 PM 898 Step 2: Hardware Setup 5. A window will appear that confirms the completion of the hardware installation; click on “Finish” to complete the installation process. P74768_F8T008-9_QIG.indd 93/23/05 2:47:00 PM 1010 Step 3: Uninstalling the Software Uninstalling the Software for Windows 98 SE, Me, 2000, and XP Follow these instructions to uninstall your USB Adapter on your PC. 1. Insert the CD-ROM included with your USB Adapter. 2. This “InstallShield Wizard” should automatically load. If it does not load, explore the CD and run the “Setup.exe” file. 3. The “InstallShield” window should now appear. Click “Next” to continue with the uninstall process. P74768_F8T012-13_QIG.indd 103/23/05 2:47:00 PM © 2005 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. The Bluetooth name and the Bluetooth trademarks are owned by Bluetooth SIG, Inc. and are used by Belkin Corporation under license. Mac, Mac OS, and Apple are trademarks of Apple Computer, Inc., registered in the U.S. and other countries. Belkin Corporation 501 West Walnut Street, Compton, CA 90220-5221, USA +1 310 898 1100 +1 310 898 1111 fax Belkin Ltd. Express Business Park, Shipton Way Rushden NN10 6GL, United Kingdom +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax Belkin B.V. Boeing Avenue 333 1119 PH Schiphol-Rijk, The Netherlands +31 (0) 20 654 7300 +31 (0) 20 654 7349 fax Belkin Ltd. 7 Bowen Crescent, West Gosford NSW 2250, Australia +61 (0) 2 4372 8600 +61 (0) 2 4372 8603 fax Belkin Tech Support US: 310-898-1100, ext. 2263 800-223-5546, ext. 2263 Europe: 00 800 223 55 460 Australia: 1800 235 546 New Zealand: 0800 235 546 Singapore: 800 616 1790 Bluetooth ™ USB Adapter P74768 P74768_F8T008-9_QIG.indd 123/23/05 2:47:00 PM Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 …
