K7SF8V3080ATune Cast II Personal FM Transmitter

SubstantiationofK7SF8V3080A Here is our feedback to your question from our factory . Question:"Can you please answer the following question on October 25?This device appears different fromthe devicesubmitted for FCCtesting.One difference is that there is a ferrite core on the cable.What did the applicant state?" Reply:The firstsample thatwesubmitted theapplied ID number isK7SF8V3080A. It hasa ferrite core on the cableand applyFCC testing . the testing resultis OK . Afterwardwe foundthe ferritethatcould be cancelledandstill be able topassed by adjusting some components value to sure thetransmitter compliedwith the FCC standards.Sowe cancelledth e ferrite core on the cable andadjustedsome components value of RF sectionto passbyFCC testing . Thereforewe submitted the secondsample of K7SF8V3080Awithout the ferritetothe test lab for retest again and it passed the FCC requirement. Therefore, the test lab uses the revised report for FCC submission. Thanks Arthury Chau Director of Product Development Date : 2006-11-22

501 W. Walnut Street – Compton – California 90220 USA Agency Authorization Letter FCC ID: K7SF8Z049-1, K7SF8V7101-1, K7SF8V3080A Date: October 10 th , 2006 To whom it may concern: We, the undersigned, hereby authorize Shenzhen Academy of Metrology and Quality Inspection (SMQ) to act on our behalf, as our agent , in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by SMQ within the scope of this authorization shall have the same effects as our own. This authorization shall expire 6 months from original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thanks! Sincerely, Marc Matejka Manager Document Control & Regulatory Compliance Office: (310) 604-2448 Fax: (310) 898-1107 [email protected]

501 W. Walnut Street – Compton – California 90220 USA Confidentiality Request Date : October 10 th , 2006 Federal Communications Commission Authorization and Evaluation Division FCC ID: K7SF8Z049-1, K7SF8V7101-1, K7SF8V3080A Pursuant to Sections 0.457 and 0.459 of the commission’s rules, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: 1, Block diagram 2, Schematics 3, Operation description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands the pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Marc Matejka Manager Document Control & Regulatory Compliance Office: (310) 604-2448 Fax: (310) 898-1107 [email protected]

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 25, 2006 RE: Belkin Corporation FCC ID: K7SF8V3038A I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) FCC has had a lot of complaints about personal FM broadcast transmitters over the last year. Consequently before any TCB can issue approval for these devices they must seek permission from the commission. Please provide the following as a separate document for forwarding to the Commission a. How does this device operate? b. Provide information on the device and its antenna. c. How is it installed? d. What test procedure was used? e. If tested in a car, how was it configured/tested? f. Was the tuning range properly verified? The test lab should indicate in the report that the tuning controls were manually adjusted to verify maximum tuning range. g. Was the bandwidth properly tested with maximum audio input?. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

FCC Home | Search | Updates | E-Filing | Initiatives | For Consumers | Find People Office of Engineering and Technology FCC > FCC E-filing > Inquiry System Home Page > Inquiry Confirmation FCC Site Map OET Home Page Site Options Knowledge DataBase Search Detail Criteria Search Submit An Inquiry Reply to an Inquiry Response Category List FAQ Search View Instructions Related Sites Equipment Authorization System (EAS) Telecommunications Certification Bodies (TCB) Your inquiry has been submitted to the Laboratory Division of the FCC Office of Engineering and Technology. You will receive a response within two business days. Please be sure to retain the inquiry tracking number displayed for future reference and questions concerning the status of this inquiry. Inquiry Tracking Number: 658923 Date of Submission: 11/10/2006 Question: Gentlemen, This is a continuation of mail initiated by ATCB on October 18 and which generated a followup for information by FCC on October 25, 2006. This is regarding a personal FM broadcast transmitter to be filed under 15.239. This correspondence was begun prior to thepublication of the formalized Permit but Ask procedure. Attached is a copy of the revised documentation supplied by Applicant for this device Please send any comments or suggestions for this site to OET Systems Support Federal Communications Commission 445 12th Street, SW Washington, DC 20554 More FCC Contact Information... Phone: 888-CALL-FCC (225-5322) TTY: 888-TELL-FCC (835-5322) Fax: 202-418-0232 E-mail: [email protected] - Privacy Policy - Web Policies & Notices - Customer Service Standards - Freedom of Information Act

William Graff From: Generic Office of Engineering Technology [[email protected]] Sent: Wednesday, December 20, 2006 11:43 PM To: [email protected] Subject: Response to Inquiry to FCC (Tracking Number 658923) Follow Up Flag: Follow up Flag Status: Red 12/29/2006 Inquiry: Gentlemen, This is a continuation of mail initiated by ATCB on October 18 and which generated a followup for information by FCC on October 25, 2006. This is regarding a personal FM broadcast transmitter to be filed under 15.239. This correspondence was begun prior to thepublication of the formalized Permit but Ask procedure. Attached is a copy of the revised documentation supplied by Applicant for this device ---Reply from Customer on 12/18/2006--- The applicant has submitted the following response. Please see attachment. Response: I think we are probably ok but before I open the GC I just want to make sure we had: 1) resolved the issue of why the grant you are filing had the different cable attachment from the one we tested here at the FCC during the pre grant testing and 2) you provided the answers to the required questions that we are asking all applicants for FM transmitters (15.239) i.e. questions for FM transmitters in the KDB inquiry. 1) How does this device operate? 2) Provide information on the device and its antenna. 3) How is it installed? 4) What test procedure was used? 5) If tested in a car, how was it configured/tested? At the present time, FM transmitters (subject to 15.239) tested in vehicles must also be tested on a test table. Provide both sets of data. All data must be compliant 6) Was the tuning range properly verified? The test lab should indicate in the report that the tuning controls were manually adjusted to verify maximum tuning range. 7) Was the bandwidth properly tested with maximum audio input? Use a typical audio file from a typical device. e.g. Do not use a 1 kHz signal from a signal generator. 8) Provide the test report. If you have provided this info already just give me a copy for the record. Same with (1) above ...it you resolved this with Joe Dichoso already that's fine. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry. 12/29/2006

Photo 1 Appearance of EUT Photo 2 Appearance of EUT 1 Photo 3 Appearance of DC Adaptor 1

Photo 1 Inside of EUT Photo 2 Inside of EUT 1 Photo 3 Inside of EUT Photo 4 Inside of DC adaptor 2

EMC TEST REPORT For Tunecast Auto for iPod Model Number: F8V3080 FCC ID: K7SF8V3080A Report Number : WT068002022 Guangdong EMC Compliance Test Center Tel : 0086-755-26941637, 26941529, 26941531 Email : Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory Site Location : Bldg. of Metrology &Quality Inspection, Longzhu Road, Shenzhen, Guangdong, China Fax : 0086-755-26941545 [email protected] Report No.: WT068002022 Page 2/49 TABLE OF CONTENTS TEST REPORT DECLARATION........................................................................................................3 1. TEST RESULTS SUMMARY...................................................................................................4 2. GENERAL INFORMATION....................................................................................................5 2.1. Report information............................................................................................................5 2.2. Laboratory Accreditation and Relationship to Customer.................................................5 2.3. Measurement Uncertainty.................................................................................................6 3. PRODUCT DESCRIPTION......................................................................................................6 3.1. EUT Description...............................................................................................................6 3.2. Related Submittal(s) / Grant (s)........................................................................................7 3.3. Block Diagram of EUT Configuration..............................................................................7 3.4. Operating Condition of EUT............................................................................................7 3.5. Special Accessories...........................................................................................................7 3.6. Equipment Modifications..................................................................................................7 3.7. Support Equipment List....................................................................................................8 3.8. Test Conditions.................................................................................................................8 4. TEST EQUIPMENT USED.......................................................................................................8 4.1. Test Equipment Used to Measure Conducted Disturbance..............................................8 4.2. Test Equipment Used to Measure Radiated Disturbance and bandwidth.........................8 5. CONDUCTED DISTURBANCE TEST....................................................................................9 5.1. Test Standard and Limit....................................................................................................9 5.2. Test Procedure..................................................................................................................9 5.3. Test Arrangement..............................................................................................................9 5.4. Test Data.........................................................................................................................10 6. RADIATED DISTURBANCE TEST......................................................................................13 6.1. Test Standard and Limit..................................................................................................13 6.2. Test Procedure................................................................................................................13 6.3. Test Arrangement............................................................................................................13 6.4. Test Data.........................................................................................................................13 7. OCCUPIED BANDWIDTH.....................................................................................................28 7.1. Test Standard and Limit..................................................................................................28 7.2. Test Procedure................................................................................................................28 7.3. Test Arrangement............................................................................................................28 7.4. Test Data.........................................................................................................................28 Report No.: WT068002022 Page 3/49 TEST REPORT DECLARATION Applicant : Belkin Corporation Address : 501 West Walnut Street, Compton, CA90220, U.S.A. Manufacturer : Belkin Corporation Address : 501 West Walnut Street, Compton, CA90220, U.S.A. EUT Description : Tunecast Auto for iPod Model Number F8V3080 FCC ID Number K7SF8V3080A Test Standards: FCC Part 15 15.239 :2006 The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the maximum emissions from the EUT.Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.239. The test report is valid for above tested sample only and shall not be reproduced in part without written approval of the laboratory. Tested by: Date: Sep. 13,2006 (Dewelly Yang) Checked by: Date: Sep. 13,2006 (Louis Lin) Approved by: Date: Sep. 13, 2006 (Peter Lin) Report No.: WT068002022 Page 4/49 1. TEST RESULTS SUMMARY Table 1 Test Res…
