K7SF8Z015TuneFM - Model F8Z015

Belkin Corporation 501 West Walnut Street Compton, CA, 90220, USA 310-898-1100 310-898-1111 fax Belkin Ltd. Express Business Park, Shipton Way Rushden, NN10 6GL, United Kingdom +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax Belkin B.V. Boeing Avenue 333 1119 PH Schiphol-Rijk, The Netherlands +31 (0) 20 654 7300 +31 (0) 20 654 7349 fax Belkin Ltd. 7 Bowen Crescent, West Gosford NSW 2250, Australia +61 (0) 2 4372 8600 +61 (0) 2 4372 8603 fax Tech Support US: 310-898-1100 ext. 2263 800-223-5546 ext. 2263 Europe: 00 800 223 55 460 Australia: 1800 235 546 New Zealand: 0800 235 546 © 2005 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. F8Z015P74820 User Manual TuneFM ™ for iPod ® Setup Instructions Introduction Congratulations and thank you for purchasing the TuneFM for iPod. This innovation from Belkin makes it easy to play your iPod tunes through any FM stereo receiver. It plugs into the remote/headphone jack on your iPod. Then, you simply tune your stereo to any clear FM frequency, and enjoy your iPod music anywhere with full sound and fewer wires. Please be sure to read through this User Manual thoroughly so that you can get the most from your TuneFM’s advanced features. 1. Plug the TuneFM into the remote/headphone connector on the top of the iPod. Make sure the iPod device’s Hold switch is in the OFF position. 2. The TuneFM will power on automatically when attached to the iPod and will start transmitting on the last used station. 3. Tune your car or home stereo frequency to a channel with a weak broadcast signal. The ideal channel is one that is not broadcasting a radio program, or is doing so weakly. 4. Press the or button on the top of the TuneFM to match the transmission frequency you chose in Step 3, above. Press and hold either button for fast-forward or backward tuning. 5. To memorize a specifi c frequency (two stations maximum) for easy selection: a. Select the desired frequency using the and buttons. buttons. b. Press and hold the 1 or 2 button for two seconds. The LED display will indicate which memory preset was used by showing a P1 or P2. By repeating these steps, the previously saved frequency will be overwritten by the next entry. 6. To recall a station, tap the 1 or 2 button. The display will show the previously stored frequency. 7. Adjust the volume on your iPod to a medium level. 8. Adjust the volume of your FM radio to the desired listening level.* 9. Setting the Hold switch on the back of the TuneFM prevents the station adjustment buttons from activating. The LED display momentarily displays “HLD” to indicate the Hold switch has been activated. NOTE: The TuneFM’s Hold switch does not affect the iPod device’s controls. For Best Results: • Try to keep the TuneFM close to the antenna of your FM radio. While the TuneFM often works at distances of 30 feet or more, a distance of 10 feet or less minimizes interference and provides the strongest signal. *Due to characteristics of FM transmission, you will experience better sound quality by adjusting the volume on your home or car stereo when necessary, and by leaving your iPod or other portable music player volume set at a medium level. Information Belkin Corporation Limited Three-Year Product Warranty Belkin Corporation warrants this product against defects in materials and workmanship for its warranty period. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of purchase may be required. This warranty does not apply if the product has been damaged by accident, abuse, misuse, or misapplication; if the product has been modified without written permission of Belkin; or if any Belkin serial number has been removed or defaced. THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS, WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. No Belkin dealer, agent, or employee is authorized to make any modification, extension, or addition to this warranty. BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED TO, LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING OR REPRODUCING, ANY PROGRAM OR DATA STORED IN OR USED WITH BELKIN PRODUCTS. Some states do not allow the exclusion or limitation of incidental or consequential damages or exclusion of implied warranties, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit diff…

Text truncated - open the document above for the full version.

501W.WalnutStreet- Compton- California90220USA August16,2005 FederalCommunicationsCommission EquipmentApprovalServices P.O.Box358315 Pittsburgh,PA15251 Attn.:GenericOfficeofEngineeringTechnology Re.FCCID:K7SF8Z015 ToWhomIt MayConcern: ThankyouforthenotificationregardingtheFCCIDmarkingpursuanttoSection2.925ofthe FCCRules.Attachedis a revisedlabellocationthatincludedthecorrectionforyourreview. Kindregards, TacV.Pham InternationalRegulatoryComplianceManager

BELKI N~ 501w.WalnutStreet- Compton- California90220USA August22,2005 FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA FCCill:K7SF8Z015 ToWhomIt MayConcern: Thisletteris tocomplywithSection0.457and0.459pertainingtoconfidentialmaterial.BelkinCorporation wouldlikethefollowingdocumentsregardingthissubmissionforFCCill:K7SF8Z015tobekeptconfidential. 1.Schematicofunitundertest 2.Blockdiagram Theabovematerialcontainstradesecretsortechnicaldata,whichwouldcustomarilybeguardedfrom competitors.Wedonotwantthesedocumentstobeaccessibletothegeneralpublic. Sincerely, TacV.Pham InternationalRegulatoryComplianceManager

BELKI N~ 501W.WalnutStreet- Compton- California90220USA August29,2005 FederalCommunicationsCommission EquipmentApprovalServices P.O.Box358315 Pittsburgh,PA15251 Attn.:GenericOfficeofEngineeringTechnology Re.FCCill:K7SF8Z015 CorrespondenceRef.Number:29417and29418 ToWhomIt MayConcern: Thepurposeofthisletteris toresponsetoyourrequestin yourletterreferencenumber29417and 29418. WehaveuploadourrevisedFCCillformatasrequiredofSection2.925oftheFCCRulesintothe EAS.Pleasereviewandadviseif youhaveanyadditionalquestionsorcomments. Kindregards, TacV.Pham InternationalRegulatoryComplianceManager

BELKI N~501W.WalnutStreet-Compton-California90220USA August29,2005 FederalCommunicationsCommission EquipmentApprovalServices P.O.Box358315 Pittsburgh,PA15251 Attn.:GenericOfficeofEngineeringTechnology Re.FCCill:K7SF8Z015 CorrespondenceRef.Number:29438and29439 ToWhomIt MayConcern: Thepurposeofthisletteris to responseto yourrequestinyourletterreferencenumber29438and 29439. WehaveuploadourconfidentialityrequestletterintotheEASastherequirementofSection0.457 and0.459oftheFCCRules.Pleasereviewandadviseif youhaveanyadditionalquestionsor comments. Kindregards, TacV.Pham InternationalRegulatoryComplianceManager

501 W. Walnut Street – Compton – California 90220 USA Operation Description: The Belkin Corporation TuneFM model F8Z015 is a device that wirelessly transmits audio signals from an iPod to a FM receiver. It also allows the user to set the transmission frequency in the band 88.1MHz to 107.9MHz in 0.1MHz intervals. The TuneFM model F8Z015 is a battery powered device. It operates on 3.3Vdc supplied by the iPod. It receives both serial communication and audio signal from the iPod.
