User Manual TuneCommand ™ AV for iPod ® Introduction Designed to let you roam and control your audio and video content from virtually anywhere in your home, TuneCommand AV delivers the flexibility and convenience that iPod users desire. Using wireless radio frequency technology, TuneCommand AV works from up to 120 feet away from your stereo. Please review this User Manual carefully so that you can be sure to get the most from your new Belkin product. What’s in the Box Introduction | 01 TuneCommand AV Dock for iPod TuneCommand AV Remote Control 5 Insert Trays AC Power AdapterMulti-Clip Surface-Mount Hook AV CableLanyard Battery (Model CR 2032) Lanyard Adjuster Legend Legend| 02 Battery-life and range indicator Skip backward Shuffle button Repeat button Volume up Play/pause Skip forward Volume down Battery door release button (on the back) Battery door (on the bottom) iPod connectorSignal indicatorDock adapter Stereo AV out Stereo line out Video out S-video Power in DC 12V/0.8A STEP 1 - TuneCommand AV Dock Setup 1. Place the TuneCommand AV Dock in the desired location on your home entertainment system. 2. Insert the barrel plug of the included AC power adapter into the “power in” port on the TuneCommand AV Dock. Plug the other end of the AC power adapter into your wall socket or surge protector. 3. Insert the 3.5mm end of the included AV cable into the “Stereo AV Out” port on the TuneCommand AV Dock. Plug the other end of the AV cable into the input ports on the back of your TV or stereo receiver. NOTE: For optional connectivity, you can use your own 2-RCA-to-2-RCA and S-video cables in lieu of the included AV cable. Connecting through the RCA outputs disables the volume-control functionality of the Remote Control. 4. Select the appropriate insert tray for your iPod and insert it into the top well of the TuneCommand AV Dock (Fig. 1). Inserts for the iPod video and iPod nano are included with your purchase of the iPod. 5. Insert the iPod into the TuneCommand AV Dock. Operating Instructions Operating Instructions | 03 Pull up here to remove the insert iPod mini 4GB 6GB iPod 20GB U2 Special Edition iPod 40GB iPod with color display 20GB 30GB U2 Special Edition iPod with color display 40GB 60GB �� SNAPSNAP Fig. 1 Operating Instructions Operating Instructions | 04 STEP 2 - TuneCommand AV Remote Control Setup 1. Turn the Remote Control so that the buttons are facing down. Press the release button to open the battery tray, and gently pull it out of the housing until it stops (Fig. 2). Please do not force the battery tray completely out of the housing. 2. Insert the battery with the (+) side facing up and push the battery cover back into the Remote Control until the button snaps back into place and the battery tray is securely shut. 3. Now press any of the Remote Control’s buttons for the TuneCommand AV Remote Control and Dock to pair up. The green lights on the Dock and the Remote Control blink when the first button-press command from the Remote Control reaches the Dock correctly. NOTE: If the battery is removed or replaced, you will need to unplug the AC power adapter from the TuneCommand AV Dock and plug it back in to reestablish connection with the Remote Control. 1 2 3 Fig. 2 You can now use your TuneCommand AV Remote Control to control the iPod’s play/ pause, skip forward, skip backward, and volume up/down functions. In addition, you can conveniently control the shuffle and repeat functions, using the two small round buttons. Each press of a button advances the setting to the next stage. When used with the iPod video, nano, or photo, TuneCommand AV lets you scroll through your videos (iPod video only), slideshows, or presentations, wirelessly! NOTE: • Slideshows must be started manually on the iPod before the TV will display them When using the iPod video: • Videos must be placed in a playlist in order to use the Remote Control (play/pause, forward/back, etc.) • The iPod video settings need to be switched to “TV Out > NTSC or PAL” The shuffle key ( ) advances the iPod’s shuffle settings as follows: shuffle off > shuffle songs > shuffle albums. The repeat button ( ) advances the iPod’s repeat settings like this: repeat off > repeat one > repeat all. Follow the icons on the iPod’s screen to see the current settings, represented by small icons on the upper right, below the battery-status indicator. Operating Instructions | 05 Operating Instructions LED Chart LED Chart Every time you push a button on the Remote Control, the green lights on the Remote Control and the Dock will blink, indicating that the signal has been received correctly. If the Remote Control and the Dock are too far apart to communicate, the light on the Remote Control blinks orange (after a short delay) instead of green when you press a button. The light on the Dock will not blink. The Remote Control’s battery level is automatically checked after every button press. If the battery level is low, the Remote Control’s red light will blink, following the green or amber blink. If you see this happen, the low battery should be replaced soon with a new one of the same type (CR 2032). Your TuneCommand AV will continue to function normally until the battery is exhausted. | 06 GREEN ORANGE The receiver receives the signal Out of range The battery is out GREENReceived the signal Using the Multi-Clip | 07 Using the Multi-Clip How to wear on a belt Attaching the multi-clip to the Remote Control � � � � Do not slide on � � SNAP � � Using the surface mount � � The clip allows you to wear the Remote Control on a belt, or around your neck with the lanyard. � � Troubleshooting Troubleshooti…

Text truncated - open the document above for the full version.

Cover Letter(s)

BELKIN.501W.WalnutStreet-Compton-California90220USA FederalCommunicationsCommission EquipmentApprovalServices P.O.Box358315 Pittsburgh,PA15251-5315 USA Date:2005-04-26 FCC10:K7SF8Z065-TXandK7SF8Z065-RX ToWhomIt MayConcern: Dueto theactualproductis toosmalltoputtheFCCpart15section15.19 statement,sowewillplacein usermanual. SignaturewithCompanyChop: PrintedName:TacPham DATE:4/26/2006 F5D8011-ICContinuousCompliancyDeclaration

Cover Letter(s)

DOC-FCC009 4/14/2005 Page 1 of 2 FEDERAL COMMUNICATIONS COMMISSION - FCC FORM 731 APPLICATION FOR EQUIPMENT AUTHORIZATION Approved by OMB 3060 - 0934 Expires 02/28/2005 Item 1. Applicant's complete, legal business name: Belkin Corporation Item 2. Applicant's mailing address Line 1: 501 West Walnut Street, Compton, Line 2: P.O.Box: City: California State: Country (if foreign address): United States Zip/Postal Code: CA 90220 Item 3. FCC ID: Grantee code: K7S Equipment Product Code (14 characters maximum): F8Z065-TX Item 4. Person at the applicant's address to receive grant or for contact: First Name: KC Mail Stop: Last Name: Lee Telephone: 852 26661807 Ext: Title: Manager E-mail: [email protected] Fax No: Item 5. Instead of Applicant, the original Grant is authorized to be mailed to: The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Tai Po Industrial Estate, N.T., Hong Kong. Contact: KC Lee E-mail: [email protected] Item 6. Technical Contact: Firm Name: The Hong Kong Standards and Testing Centre Ltd. Telephone: 852 26661807 Ext: Fax No: 852 2665 0848 First Name: KC Middle Initial: Last Name: Lee Address Line 1: 10 Dai Wang Street, P.O.Box: Address Line 2: Tai Po Industrial Estate City: Country (if foreign address):Hong Kong Zip/Postal Code: E-mail: [email protected] Item 7. Non-Technical Contact: Firm Name: The Hong Kong Standards and Testing Centre Ltd. Telephone: 852 26661807 Ext: Fax No: 852 2665 0848 First Name: KC Middle Initial: Last Name: Lee Address Line 1: 10 Dai Wang Street, P.O.Box: Address Line 2: Tai Po Industrial Estate City: Country (if foreign address):Hong Kong Zip/Postal Code: E-mail: [email protected] Item 8. * Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules? If "Yes" see instructions. (please mark as appropriate) x Yes Item 9. Does the applicant request that the Commission defer grant of this application pursuant 47 CFR § 0.457(d)(1)(ii)? (See instructions) If so, specify date when grant may be issued (MM/DD/YYYY format): Item 10. * Equipment Class: DXX * Description of Product as it is Marketed: Part 15 Low Power Communication Device Transmitter (NOTE: TuneCommand AV) Item 11. * Application is for: (please mark as appropriate) x Original Equipment (See instructions) Ο Change in identification of presently authorized equipment: Original FCC ID: Grant Date (MM/DD/YYYY format): Ο Class II permissive change or modification of presently authorized equipment (See instructions) Item 12. Is the equipment in this application: * (a) a composite device subject to an additional equipment authorization? * (b) part of a system that operates with, or is marketed with, another device that requires an equipment authorization? If either of the above questions is answered "Yes" complete section 12(c). Ο Yes x No Ο Yes x No DOC-FCC009 4/14/2005 Page 2 of 2 (c) The related application: Ο has been granted under the FCC ID listed to the right Ο is in the process of being filed under the FCC ID listed to the right Ο is pending with the FCC under the FCC ID listed to the right FCC ID Item 13. Name of test firm and contact person on file with the FCC, if different from applicant or contact person: Firm Name: The Hong Kong Standards & Testing Centre Ltd. Last Name: KC Telephone 26661852 Ext Fax No. 26650848 E-mail: [email protected] Item 14. Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization. Read each certification carefully before answering and signing this application Equipment Specifications: Rule Part Frequency Range (MHz) Power (W) Frequency Tolerance and Units Emission Designator Note Codes 15 2433 WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTITUTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503). Item 15. *SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? x Yes Ο No Item 16. APPLICANT/AGENT CERTIFICATION: I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. IN accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. * Sig…

Text truncated - open the document above for the full version.

Cover Letter(s)

501 W. Walnut Street – Compton – California 90220 USA Date: March 24, 2006 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 USA Dear Sirs, Re.: Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. as agent for Belkin Corporation, 501 West Walnut Street, Compton, CA 90220 to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of Belkin Corporation Product name : Ipod TuneCommand AV * Dock W/ Cradle Model : F8Z065 This authorization will expire one year from the date of this letter. _____________________________ Tac Pham Int’l Regulatory Compliance Manager

Cover Letter(s)

501 W. Walnut Street – Compton – California 90220 USA Date: March 24, 2006 The Hong Kong Standards and Testing Centre Ltd., 10 Dai Wang Street, Taipo Industrial Estate, Taipo, N.T., Hong Kong. Attn.: Mr. Patrick Wong Dear Sir, Re. : Letter of Attestation This equipment has been tested in accordance with the requirements contained in the appropriate Commission Regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that the equipment complies with the appropriate standards. Each unit manufactured, imported or marketed, as defined in the Commission’s regulations, will conform to the samples tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made by the Hong Kong Standards and Testing Centre Ltd., 10 Dai Wang Street, Taipo Industrial Estate, Taipo, N.T., Hong Kong. Yours sincerely, _____________________________ Tac Pham Int’l Regulatory Compliance Manager

External Photos

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

Internal Photos

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

Operational Description

F8Z065-Transceiver F8Z065-Tx Photo Model number :F8Z065-Tx F8Z065-Transceiver CONTENTS Date of preparation: 2006/3/29 Product Name: F8Z065-Tx 1. Product Photo 2. Contents of document 3. PCB Layout 4. Schematic 5. Block diagram 6. Environmental and Reliability test 7. Product – Specification Sheet 8. Regulatory approval 9. BOM 10. Exploded View F8Z065-Transceiver F8Z065-Tx TOP Layout F8Z065-Transceiver F8Z065-Tx BOTTOM Layout F8Z065-Transceiver F8Z065-Tx Middle layer1 F8Z065-Transceiver F8Z065-Tx Middle layer2 F8Z065-Transceiver F8Z065TX SCH F8Z065-Transceiver F8Z065(Tx) Block diagram F8Z065-Transceiver 1. Temperature Cycle test Chamber temperature is set for -20° C. to +45° C. Each temperature extreme is held for one hour before transitioning to the other extreme. The units are powered under normal real-world conditions and electrically loaded while in this chamber. Total times in the chamber is 32 hours. 2. High temperature storage test Chamber temperature is set for +60,°C then put the unit into chamber for 48H . 3. Burn IN Test (bare unit) Conditions and electrically while in this burn in The burn in room is set for 40~45°C°C, the unit be powered under normal real-world room. Total testing time in the chamber keeps 4. Printed/Coated reliability Test Using the alcohol to wipe the surface screen of unit, the force about 300g . Then using the 3M tape to stick the screen for 3 times in same location . 5. Button / Switch Life Test (bare unit) Using a special test jig to push the button or switch for 5000 times, then check the button if in condition & requirements still. 6. Hi-Low Temperature Storage (Packing unit) Chamfer is set for 55, then put packing unit into chamfer for 48H. Chamfer is set for 40, 40 90% °C°C°C for 48H. 7. Drop Test (Packing unit) Drop the packing unit from a height of 120cm onto concrete. 8. Vibration Test (Packing unit) Put the packing unit on vibration equipment, then set the testing parameter for equipment. (The test duration is 30 minutes. All three 9. Emission Frequency Test 20°C~40°C~10°C~5°C~0°C~-10°C~-20°C,changing one time in one hour ,total 13H. F8Z065-Transceiver F8Z065-Tx Product specification F8Z065-Transceiver l Regulator Approval - US shipment : FCC - Europe shipment : CE - Australia shipment : C-tick l BOM - Please refer to attached document. l Exploded View - Please refer to attached document.

Test Report

STC Test Report Date : 2006-04-18 TEST REPORT Page 1 of 17 No. : HM156357 This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Applicant: Belkin Corporation 501 West Walnut Street, Compton, California 90220 United States Description of Samples: Model name: TuneCommand AV Model no.: F8Z065 Brand name: BELKIN FCC ID: K7SF8Z065-TX Date Samples Received: 2006-03-29 Date Tested: 2006-04-10 Investigation Requested: FCC Part 15 Regulations-Subpart C Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- LEE Kam Chuen, EMD For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2006-04-18 Page 2 of 17 No. : HM156357 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 17 Content Page 2-3 of 17 1.0 General Details 1.1 Test Laboratory Page 4 of 17 1.2 Applicant Details Page 4 of 17 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 17 Description of EUT operation 1.4 Date of Order Page 5 of 17 1.5 Submitted Sample Page 5 of 17 1.6 Test Duration Page 5 of 17 1.7 Country of Origin Page 5 of 17 2.0 Technical Details 2.1 Investigations Requested Page 6 of 17 2.2 Test Standards and Results Summary Page 6 of 17 3.0 Test Results 3.1 Radiated Emission Page 7-9 of 17 3.2 Conducted Emission Page 10 of 17 3.3 Bandwidth Measurement Page 11-12 of 17 STC Test Report Date : 2006-04-18 Page 3 of 17 No. : HM156357 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage Appendix A List of Measurement Equipment Page 13 of 17 Appendix B Duty Cycle Correction During 100 msec Page 14-15 of 17 Appendix C Photographs Page 16-17 of 17 STC Test Report Date : 2006-04-18 Page 4 of 17 No. : HM156357 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong 1.2 Applicant Details Applicant Belkin Corporation 501 West Walnut Street, Compton, California 90220 United States Manufacturer N/A STC Test Report Date : 2006-04-18 Page 5 of 17 No. : HM156357 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.3 Equipment Under Test [EUT] Description of Sample Model Name: TuneCommand AV Manufacturer: N/A Brand Name: BELKIN Model Number: F8Z065 Input Voltage: 3Vd.c. (“CR2032” button cell x 1) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a Belkin Corporation. TuneCommand AV, the transmission signal is frequency hopping with channel frequency 2.433GHz. 1.4 Date of Order 2006-03-29 1.5 Submitted Sample(s): 1 Sample per model 1.6 Test Duration 2006-04-10 1.7 Country of Origin China STC Test Report Date : 2006-04-18 Page 6 of 17 No. : HM156357 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform Electromagnetic Interference measurements in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2005 Regulations and ANSI C63.4:2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Fail N/A Field Strength of Fundamental & Harmonics Emissions FCC 47CFR 15.249 ANSI C63.4:2003 N/A Radiated Emissions FCC 47CFR 15.209 ANSI C63.4:2003 N/A Conducted Emissions on AC, 0.15MHz to 30MHz FCC 47CFR 15.207 ANSI C63.4:2003 N/A Note: N/A - Not Applicable STC Test Report Date : 2006-04-18 Page 7 of 17 No. : HM156357 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kon…

Text truncated - open the document above for the full version.

Test Setup Photos

LABEL LOCATION BOTTOM VIEW OF THE DEVICE WITH FCC ID LABEL
