K7SF8Z618FM Transmitter

TuneBase ™ FM LIVE for iPhone and iPod User Manual 8820tt00532 F8Z618tt/F8Z618 TuneBase™ FM LIVEi sections1237564table of contents TaBLE oF conTEnTs 1 Introduction ....................................................................................................1 Features ...............................................................................................................1 What’s in the Box ................................................................................................2 Controls ...............................................................................................................2 2 Get the clearscan LIVE app .......................................................................3 3 set Up Your TuneBase ...................................................................................4 Plug In Your TuneBase ........................................................................................4 Dock Your iPhone/iPod .......................................................................................5 Dock Your iPhone/Pod After Initial Setup ........................................................10 4 Use Your TuneBase ......................................................................................12 Find a Clear Station ...........................................................................................12 Play Music ..........................................................................................................14 Use the PRO Button to Boost Sound ...............................................................14 5 Troubleshooting ...........................................................................................15 6 safety Warnings ...........................................................................................18 7 Information ....................................................................................................19 TuneBase™ FM LIVE1 sections237564table of contents1 InTrodUcTIon Features iPhone and iPod • Play your iPhone/iPod through your car’s FM stereo • Keep your iPhone/iPod in its case • Rotate your iPhone/iPod to horizontal view • One-touch tuning with ClearScan TuneBase™ FM LIVE2 sections237564table of contents1 InTrodUcTIon What’s in the Boxcontrols What’s in the Box 1. 2. 3. pro 2 1 1. 2. 3. 4. 5. 6. 1. TuneBase FM LIVE 2. Fit Ring 3. Cushion for iPod nano 1. ClearScan 2. Tune up 3. Tune down 4. Memory 1 5. Memory 2 6. PRO button TuneBase™ FM LIVE3 sections137564table of contents2 GET THE cLEarscan LIVE aPP ClearScan LIVE lets you control your TuneBase FM directly from your iPhone or iPhone/iPod touch. ClearScan LIVE also provides improved ClearScan results by: • Using your GPS location to find the best FM station in your area • Recommending open stations based on what other people in your area are using Look for ClearScan LIVE in the App Store on iTunes. See instructions in the app’s Help section for more information. TuneBase™ FM LIVE4 sections127564table of contents3 sET UP YoUr TUnEBasE Plug In Your TuneBase Follow the steps in this section to set up your TuneBase FM (the TuneBase). 1. Insert your TuneBase into the power outlet in your car. 2. Test the tightness of fit in the power outlet. The TuneBase should give some resistance when you try to rotate it inside the power outlet. It should not rotate or move on its own. If the TuneBase is too loose or too tight in the power outlet, see the troubleshooting section for instructions on adjusting the fit. Warning: Do not rotate the TuneBase in the power outlet. If you experience resistance, unplug the TuneBase and reinsert it in the desired position. Failure to do so may damage the cigarette lighter adapter or power outlet. TuneBase™ FM LIVE5 sections127564table of contents3 sET UP YoUr TUnEBasE 1. Push the button on the springboard and slide it to its maximum height. 2. If you have an iPod nano, insert the cushion into the slot on the springboard. The cushion works with most versions of the iPod nano. dock Your iPhone/iPod You can keep your iPhone/iPod in its case when you dock it. TuneBase™ FM LIVE6 sections127564table of contents3 sET UP YoUr TUnEBasE 3. Connect your iPhone/iPod to the TuneBase dock connector, making sure it is fully seated. 4. Push the front of the iPhone/iPod back until the back of the iPhone/iPod touches the front of the springboard. TuneBase™ FM LIVE7 sections127564table of contents3 sET UP YoUr TUnEBasE 5. Push down on the top of the springboard until it holds your iPhone/iPod securely in place. note: After you have adjusted the height of the springboard, there is no need to adjust the TuneBase to insert and remove your iPhone/iPod. TuneBase™ FM LIVE8 sections127564table of contents3 sET UP YoUr TUnEBasE 6. Bend the flexible neck to position your iPhone/iPod. Warning: Do not remove the TuneBase from the cigarette lighter adapter when an iPhone/iPod is in the cradle. do not position your TuneBase as follows: ok TuneBase™ FM LIVE9 sections127564table of contents3 sET UP YoUr TUnEBasE remove Your iPhone/iPod from Your TuneBase 1. Push back on the front of the springboard and tilt your iPhone/iPod forward until it clears the lip of the springboard. 2. Lift your iPhone/iPod out of the cradle. 12 TuneBase™ FM LIVE10 sections127564table of contents3 sET UP YoUr TUnEBasE 1. Seat your iPhone/iPod on the dock connector. 2. Push the face of the iPhone/iPod so that it snaps into place under the lip of the springboard. dock Your iPhone/iPod after Initial setup After you have adjusted the TuneBase to fit your iPhone/iPod, you can insert and remove your iPhone/iPod without further adjustment. You only need to adjust the height of the springboard when you are using a different iPhone/iPod or different case. TuneBase™ FM LIVE11 sections127564table of contents3 sET UP YoUr TUnEBasE Power behavior Your iPhone/iPod will automatically pause when you remove it from the TuneBase. Your TuneBase will automatically turn on when your i…

Text truncated - open the document above for the full version.

501 W. Walnut Street – Compton – California 90220 USA Letter Of Agency Date: Aug. 28, 2008 CETCB 114 Olinda drive Brea, CA 92823 To Whom It May Concern: Please be advised that Belkin International Inc. authorizes Compatible Electronics and its employees to act on our behalf, until otherwise notified, for applications submitted to CETCB. We certify that we are not subject to denial of federal benefits that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse ACT of 1988, U.S.C. 862. Further, no party as defined in 47 CFR 1.2002(b), for this application is subject to denial of federal benefits that includes FCC benefits. Thank you for your attention to this matter. Sincerely Yours, EMC Regulatory Compliance Engineer Belkin International Inc.

BELKIN INTERNATIONAL INC. 501West Walnut Street, Compton, CA; 90220, USA Declaration of non-duplicate submittal 12/09/08 Compatible Electronics TCB, 114 Olinda Drive Brea, CA 92828 Subject: TCB application submittal Gentlemen: We Belkin International would like to declare that the application being submitted for the device with FCC ID: K7SF8Z618, has not been submitted to another TCB or FCC. If you have any question, please do not hesitate to contact us at (310) 604-2315 Sincerely, Daniel Wesey/EMC Regulatory Compliance Engineer Belkin International Inc. 501 West Walnut Street, Compton, CA, 90220, U.S.A. Tel: +1-310-604-2315 Fax: +1-310-898-1503 E-Mail: [email protected]

12045 East Waterfront Drive, Playa Vista, CA 90094 USA Request for non-disclosure RF_501_02 To: CETCB Subject: Request for non-disclosure (FCC ID:K7SF8Z618) Reference number:F8Z618 Dear CETCB, Date: 2010-08-20 Pursuant to 47 CFR Section 0.459(a) & (b), Belkin International Inc. Hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID: (K7SF8Z618) a. b. c. Schematic diagrams Operational description Block Diagram Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Belkin International Inc. Understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Name/ Title: Daniel Wesey/ EMC Regulatory Compliance Engineer Signature:

INNOVATION DESIGN GROUP SCALE 1:1 ELEMENTS SHOWN IN RED: PRINTED IN Pantone 8401 DATE: 06/30/2010REVISION: 1.0 DESIGNER: MS REVISION NOTES: DO NOT MAKE CHANGES WITHOUT PERMISSION FROM BELKIN IDG. F8Z618 SPECIFICATIONS FOR PRODUCT GRAPHICS TuneBaseFM 6 -TBFM6 ALL DIMENSIONS IN MM. ELEMENTS SHOWN IN GREEN: PRINTED IN Pantone 430 model # F8Z618 Made in China U.S. Patent No. 7,292,881 N10117 Z528 FCC ID: K7SF8Z618 IC: 3623A-F8Z618 TuneBase FM Live + App
