Applicant: Belkin International, Inc. FCC ID: K7SWIA002 RF Exposure Requirements ( FCC KDB 680106 D01 V03) Requirements Statements (a) Power transfer frequency is less that 1 MHz The resonator system shall operate at 111-130KHz (b) Output power from each primary coil is less than 15 watts 15W (c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils Single coil (d) Client device is inserted in or placed directly in contact with the transmitter Client device is placed directly in contact with the transmitter (e) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). It’s mobile device, and had provided RF exposure report to evaluate. (f) The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Please refer to RF Exposure Report. ----------------------------------------- Jay Tu Regulatory Compliance Engineer Belkin International, Inc. TEL: +1 310 633 9309*9142 E-mail: [email protected] Date: 2020-03-12
