Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Business Unit: Program Manager: Packaging Engineer: Material: Blank Size (in): Side Shown: L x W x D (mm): DIE LAYOUT 0 Unit: Flute/Grain: REV Intermediate PRINT SIDE L x W x D (in): 21 [533.400] 7 1 / 2 [190.500] 3 1 / 2 [88.900] 21 [533.400] 7 1 / 2 [190.500] 3 1 / 2 [88.900] IN/MM Drawing Scale 1:1 Retail Outside Dimension (Including Hang Tab) DO NOT PRINT DIE LINES, PRINTERS NOTES PRINT SPECS: DIE/MATERIAL SPECS: 1809.366 x 888.628 71+15/64 x 34.985 Die Line File: Matthew Duffy Please refer to drawing IDL_WIZ002_WIN 201 DUAL WIRLESS CHARGING PAD Color Plates: Notes: Artwork File: horizontal 00 RELEASE DATE: 12/05/2019 Tolerance:+/- 1/32" - 0.8mm Blank Size (mm): Finish: DIELINE: THIS DOCUMENT & THE INFORMATION IN IT ARE THE CONFIDENTIAL PROPERTY OF BELKIN INTERNATIONAL AND MUST NOT BE COPIED, REPRODUCED OR USED IN ANY MANNER WITHOUT THE WRITTEN CONSENT OF BELKIN CORPORATION. IT MUST BE RETURNED UPON REQUEST This dieline works for following skus (if any): Universal QIG/RC Statement 70 gsm Wood Free Paper QIG/RC Statement 70 gsm Wood Free Paper 21 [533.400] 7 1 / 2 [190.500] 3 1 / 2 [88.900] Safety Instructions: 1. Please read these instructions before using the device to ensure safe and proper use. 2. Connect the wall adapter of the wireless charging pad into a socket outlet that is close by and is easy to disconnect from the source. 3. Use indoors and in a dry location only; keep away from wet or damp locations. 4. Keep wireless charging pad and wall adapter away from any liquids or moisture. 5. Unplug the wireless charging pad when unused for long periods of time. 6. Do not store your device in very hot or very cold areas. It is recommended to use your device at room temperatures. 7. Caution: If you experience problems with the wireless charging pad, please discontinue use, unplug the wall adapter of the wireless charging pad from the AC socket, and contact Belkin for assistance. 8. Do not use if visible defects are observed on the wireless charging pad or wall adapter. Do not attempt to service or disassemble. WARRANTY AND SUPPORT INFORMATION IMPORTANT! PLEASE RETAIN PROOF OF PURCHASE AND PRODUCT WARRANTY INFORMATION BELKIN PRODUCT AND CONNECTED EQUIPMENT LIMITED WARRANTY (CONNECTED EQUIPMENT WARRANTY NOT AVAILABLE IN LATIN AMERICA) This warranty is provided to you by Belkin International, Inc, or one of its subsidiaries or affiliates (“Belkin”) IMPORTANT NOTICE REGARDING YOUR CONSUMER RIGHTS The benefits we give in this manufacturer’s warranty are additional to any rights and remedies that you may have under local consumer protection laws. Nothing in this warranty limits or affects your legal rights. This manufacturer’s warranty is governed by the laws of the country in which you purchased your Belkin product. In many countries, consumers have rights under local consumer laws. Those consumer rights may differ between countries, states and provinces, and often cannot be excluded. Your local consumer rights organization can advise you on your legal rights. This manufacturer’s warranty is not intended to: • change or exclude any rights under consumer law that cannot be lawfully changed or excluded; or • limit or exclude any right you have against the person who sold the Belkin product to you if that person has breached their sales contract with you. WHAT DOES THIS WARRANTY COVER? Product Warranty: Belkin warrants that the product hardware and any software media (i.e., media on which the product software is provided) will be free from defects in materials and workmanship under normal use during the Warranty Period described below. This means that the product won’t be defective, and that it will look and work as advertised during the relevant period. Connected Equipment Warranty: Belkin also covers damage to any equipment which is connected through the Belkin product to a properly wired AC power line with protective ground (Connected Equipment) caused by failure of the Belkin product to operate as described in the product documentation and arising as a result of impulses from lightning, or other power transients, or by momentary (less than 1ms) voltage surges or spikes (an Occurrence) during the Warranty Period (Connected Equipment Warranty). The Connected Equipment Warranty will not apply if damage to the Connected Equipment resulted from: • telephone-line transients if the Connected Equipment was not properly connected to or was not directly connected to a Belkin product that offers telephone-line transient protection; • coaxial-line transients if the Connected Equipment was not properly connected to or was not directly connected to a Belkin product that offers coaxial-line transient protection; or • network-line transients if the Connected Equipment was not properly connected to or was not directly connected to a Belkin product that offers network-line transient protection. The Connected Equipment Warranty will remain effective for the Warranty Period set out below. The Connected Equipment Warranty automatically ends when the Product Warranty ends. This warranty does not apply to products purchased from a source other than Belkin or a Belkin Authorized Reseller. How long is the product warranted and what is the maximum value of the Connected Equipment Warranty? Belkin warrants that the hardware in this Belkin product, and any associated software media, will be free from defects in materials and workmanship under normal use during the Warranty Period. The Warranty Period begins on the date the product was purchased by the original end-user purchaser and lasts for the period set out in the table below. Belkin’s total liability under the Connected Equipment Warranty shall not exceed the maximum aggregate monetary limits set forth in the table below: Product TypeWarranty PeriodMaximum Monetary Limit (US Dollars) New products 2 years $2,500 USD Refurbished products 1 year Repaired productsThe longer of the original Warranty Period or 30 days Replacement productsThe longer of the original…
Text truncated - open the document above for the full version.
Declaration Letter For Model Similarity We Belkin International, Inc. , The undersigned hereby declare that our product: (BOOST CHARGE Wireless Charging Dual Pads 15W / Wireless Charging Dual Pads 15W ), the models WIZ008 (Brand: belkin) and PW0010 (Brand: playa) are fully identical in the electrical circuit design, layout, componentused, internal wiring and outward appearance (including cosmetic, size, colors), only the model name, Trade name are not the same. Best Regards! Belkin International, Inc. Date: 2020-9-18 Signer:
Search|RSS |Updates |E-Filing |Initiatives |Consumers |Find People Office of Engineering and Technology FCC > FCC E-filing > Inquiry System Home Page > View Inquiry FCC Site Map OET Home Page Site Options Basic KDB Search Advanced KDB Search Submit an Inquiry Reply to an Inquiry Response Category List FAQ Search Major Guidance Publications Draft Laboratory Division Publications Draft Laboratory Division Publications (Expired) Draft Publication Moderation Policy Related Sites Equipment Authorization Presentations Equipment Authorization System (EAS) Reply to an OET Inquiry Response Currently Displaying Inquiry Tracking Number: 786352 Contact Information: Customer First Name: Chris Customer Last Name: Chen Telephone Number: +86-769-89982098 Extension: 8007 E-mail Address: [email protected] Address : Line 1: No.34, Chenwulu Section, Guantai Rd., Houjie Town, Line 2: Dongguan City, Guangdong, China. P.O. Box: City: Dongguan State: Zip Code: 523942 Country: China Inquiry Details on 05/11/2020: First category: RF Exposure * Second category: Portable ( 2.1093) Third category: Subject: wireless charger RF exposure test method Inquiry: Dear Sir / Madam, At now, we has one new project which is a wireless charger, it's define as a portable device and have two coils. so it's not comply KDB 680106 Item 5b (3) & (5). so can you tell me how to apply FCC ID? any additional documents need provide except conventional documents ? For RF exposure testing, E-Field probe test with 15cm distance surrounding the device or 0cm distance ?? any additional testing need do ? FCC Response on 05/13/2020: Thank you for your inquiry. Please refer to slides 10-13 from the RF Exposure Procedures presentation at the November 2019 TCB Workshop. These slides give testing guidance for small, portable, wireless power transfer devices. They can be found online at: https://www.fcc.gov/general/equipment-authorization-presentations ---Reply from Customer on 05/14/2020--- Hi, Sir/Madam, thank you for reply quickly. workshop page 13 not showed very clearly for portable WPT, and our product E-Field measurement data less than 10% limit (61.4V/m), but H-Field measurement data more than 10% limit (0.163A/m) at test distance 15cm/20cm, so how can we do then comply related KDB, Can you help advise, tks remark:attachment is our MPE test report for you refer, tks ---Reply from Customer on 05/21/2020--- Hi, Sir / Madam, can you help us soon, we want to know how to testing, tks FCC Response on 05/27/2020: Thank you for your response. I am confused by your test report. In your report you have several tests with the device offset from the center of the charging coil. This is not in accord with the FCC guidance from either KDB Publication 680106 or the November 2019 TCB Workshop. The client device should be centered on the charging coil and then the measurements taken at the distances indicated in the November 2019 TCB Workshop slides. ---Reply from Customer on 05/28/2020--- Hi, Sir / Madam, thank you very much for professional reply. we retest and update test report already, can you help us check again, sorry to bother you~~~ ---Reply from Customer on 06/05/2020--- Hi, Sir / Madam, Can you help us check soon, our buyer Apple push us urgently, thank you very much!!! Attachment List: EUT photo RF exposure report RF exposure report user manual Arial (Arial) Arial Black (Arial Black) Arial Narrow (Arial Narrow) Book Antiqua (Book Antiqua) Bookman Old Style (Bookman Old Style) Century Gothic (Century Gothic) Comic Sans MS (Comic Sans MS) Courier New (Courier New) Modern (Modern) Monotype Corsiva (Monotype Corsiva) Palatino Linotype (Palatino Linotype) Roman (Roman) Script (Script) Small Fonts (Small Fonts) Σψμβολ (Symbol) Tahoma (Tahoma) Franklin Gothic Medium (Franklin Gothic Medium) Garamond (Garamond) Georgia (Georgia) Impact (Impact) Lucida Console (Lucida Console) Lucida Sans (Lucida Sans) Lucida Unicode (Lucida Unicode) Times New Roman (Times New Roman) Trebuchet MS (Trebuchet MS) Verdana (Verdana) (Webdings) (Wingdings) SUBMIT x More Colors... x More Colors... Proceed Clear Please use the Submit Inquiry link at www.fcc.gov/labhelp to send any comments or suggestions for this site Federal Communications Commission 445 12th Street, SW Washington, DC 20554 More FCC Contact Information... Phone: 888-CALL-FCC (225-5322) TTY: 888-TELL-FCC (835-5322) Fax: 202-418-0232 E- mail: [email protected] - Privacy Policy - Web Policies & Notices - Customer Service Standards - Freedom of Information Act
30 29: 2021 RF_160, Issue 04 Belkin International, Inc. Declaration of Authorization We Name: Belkin International, Inc. Address: 12045 East Waterfront Drive, Playa Vista, CA 90094,USA City: Playa Vista Country: USA . Declare that: Name Representative of agent: Jenny Guo Agent Company name: Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch Address: No. 96, Guantai Road (Houjie Section) Houjie Town Dongguan City, Guangdong 523942, China .. City: Dongguan .. Country: China . is authorized to apply for Certification of the following product(s): Product description: Type designation: . Trademark: belkin, playa . Validity/ expiry date-9- on our behalf. Date: 2020-9- .. City: Playa Vista .. Name: Jay Tu .. (2) Function: Manager, Regulatory Compliance ............................... Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent. ,Wireless Charging Dual Pads 15W WIZ008,PW0010
FCC, Request for non-disclosure Date: 21-Nov-2018 RF_501, Issue 8 Page 1 of 1 Company Name: Belkin International, Inc. Address:12045 East Waterfront Drive, Playa Vista, CA 90094,USA City: Playa Vista Country: USA To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: Reference number: Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Don’t showed these documents in FCC website before they appear on the market. Date: 2020/09/ Name and signature of applicant: Jay Tu, Manager, Regulatory Compliance Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should stated in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period K7SWIZ008 WIZ008,PW0010 3030
Belkin International, Inc. Date: 2020/09/18 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: K7SWIZ008 To Whom It May Concern: This letter is to ascertain that Belkin International, Inc. Product BOOST CHARGE Wireless Charging Dual Pads 15W / Wireless Charging Dual Pads 15W / WIZ008, PW0010, has been the units used for conducting FCC compliance testing, and it meets KDB 680106 D01, Clause 5(b) all 6 conditions as stated below hence PAG is not required. Requirements Statements 1,Power transfer frequency is less that 1 MHz The resonator system shall operate at 110KHz ~205KHz 2,Output power from each primary coil is less than or equal to 15 watts Max output Power for iPhone charging coil: 15W 3,The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils Two coil 4,Client device is placed directly in contact with the transmitter. Client device is placed directly in contact with the transmitter 5,Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Meet the requirements 6,The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surface from all simultaneous transmitting coils are demonstrated to be less than 50% of the MPE limit. Please refer to RF exposure report If you have any question or concerns, pls. contact us. Sincerely, Client’s signature Name: Belkin International, Inc. Address :12045 East Waterfront Drive, Playa Vista, CA 90094,USA
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 7 Report Version 1 Reference No.: 2007WDG0133 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 7 Report Version 1 Reference No.: 2007WDG0133 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 7 Report Version 1 Reference No.: 2007WDG0133 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 7 Report Version 1 Reference No.: 2007WDG0133 Adapter: Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 7 Report Version 1 Reference No.: 2007WDG0133 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 6 of 7 Report Version 1 Reference No.: 2007WDG0133 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 7 of 7 Report Version 1 Reference No.: 2007WDG0133
DESIGNER: MS REVISION: A062020-09-04 REVISION NOTES: IDS-xxxxxxxxx WIN209E PW0010 WIN209EMIDNIGHT BLACK / SNOWCAP WHITE CMFG SPECIFICATION DO NOT MAKE CHANGES WITHOUT PERMISSION FROM BELKIN IDG. WHITE VERSION BLACK VERSION SILICONE RING - Snowcap White - sample to be provided TEXTURE: VDI 12 MATERIAL : Sheet Silicone 50A diecut Silkscreened Pantone 428c SILICONE FOOT PADS: Snowcap White - sample to be provided 14 DIGIT SERIAL NUMBER Print Color: PMS 428C (Match silicone foot pad color) MATERIAL: PET 0.15 mm, Self Adhesive, Matte Finish TEXTURE: VDI-12 or matte finish MATERIAL : Sheet Silicone 50A diecut BOTTOM HOUSING - Snowcap White - sample to be provided TEXTURE: High Polish - SPi-A1 (ON THE ROUNDED EDGE) MATERIAL : PC/ABS TOP COVER - Snowcap White - sample to be provided TEXTURE: YS20046 B MATERIAL : PC/ABS FOOT PAD GRAPHICS COLOR: PANTONE 428C (MATTE FINISH) Playa LOGO LIGHT PIPES - CLEAR PC TEXTURE: MT11004 (DULL) on visible surface only All other parts of lightpipe should be high polish SILICONE RING - Midnight Black - sample to be provided TEXTURE: VDI 12 MATERIAL : Sheet Silicone 50A diecut Silkscreened Pantone Cool gray 11c SILICONE FOOT PADS: Midnight Black - sample to be provided 14 DIGIT SERIAL NUMBER Print Color: PMS COOLGREY 11C (Match silicone foot pad color) MATERIAL: PET 0.15 mm, Self Adhesive, Matte Finish TEXTURE: VDI-12 or matte finish MATERIAL : Sheet Silicone 50A diecut BOTTOM HOUSING - Midnight Black - sample to be provided TEXTURE: High Polish - SPi-A1 (ON THE ROUNDED EDGE) MATERIAL : PC/ABS TOP COVER - Midnight Black- sample to be provided TEXTURE: YS20046 B MATERIAL : PC/ABS FOOT PAD GRAPHICS COLOR: PANTONE COOLGREY 11C (MATTE FINISH) Playa LOGO LIGHT PIPES - CLEAR PC TEXTURE: MT11004 (DULL) on visible surface only All other parts of lightpipe should be high polish SN Label: 0.15mm Material: Matt e PET Color:Snowcap white/Midnight black Graphics: Coolgrey 11c (match sample) PRELIMINAR Y CER TIFIC ATION GR APHICS THE GUIDLINE NEEDS TO BE UPD ATED TO NE W SERIAL LABEL DESIGN Designed in California. Made in Vietnam. XXXXXXXXXXXXXX Made in Vietnam. XXXXXXXXXXXXXX A02: Input: 15V 3A RC) A03/04Adjust certificationRC) A05: Remove Belkin logoRC A06: Adjust KC numberRC
41mm 白色外壳 428C印字 黑色外壳 冷灰11C印字 21x7.8mm 80x49.2mm 工厂自行镭雕 XXXX表示生产年, 如:2020年生产,镭雕2020 yy表示生产月, 如:8月份生产,镭雕08 随生产变化 30.4mm 57.2mm
WAVE #1 白色外壳 428C印字 黑色外壳 冷灰11C印字 80x59.5mm 12x17.6mm 工厂自行镭雕 XXXX表示生产年, 如:2020年生产,镭雕2020 yy表示生产月, 如:8月份生产,镭雕08 工厂自行镭雕 19mm 57.6mm 37.5mm WAVE #1
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 4 Report Version 1 Reference No.: 2007WDG0133 PHOTOGRAPHS OF THE EUT Loop ANT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 4 Report Version 1 Reference No.: 2007WDG0133 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 4 Report Version 1 Reference No.: 2007WDG0133 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 4 Report Version 1 Reference No.: 2007WDG0133
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 27 Report Version 1 Test Report No.: FS2007WDG0133 RF EXPOSURE TEST REPORT Applicant Belkin International, Inc. Address 12045 East Waterfront Drive, Playa Vista, CA 90094 USA Manufacturer or Supplier Belkin International, Inc. Address 12045 East Waterfront Drive, Playa Vista, CA 90094 USA Product BOOST↑CHARGE™ Wireless Charging Dual Pads 15W Additional Product Wireless Charging Dual Pads 15W Brand Name belkin, playa Model WIZ008 Additional Model & Model Difference PW0010, See item 1.1 Date of tests Aug. 01, 2020 ~ Sep. 02, 2020 The submitted sample of the above equipment has been tested according to the requirements of the following standard: 47 CFR PART 1, Subpart I, Section 1.1310 KDB 680106 D01 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Lucas Chen Project Engineer / EMC Department Approved by Glyn He Assistant Manager/ EMC Department Data: Sep. 29, 2020 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 27 Report Version 1 Test Report No.: FS2007WDG0133 TABLE OF CONTENTS RF EXPOSURE TEST REPORT ................................................................................................................1 RELEASE CONTROL RECORD ..................................................................................................................3 1. GENERAL INFORMATION ..................................................................................................................4 1.1. GENERAL DESCRIPTION OF EUT ............................................................................................4 2. RF EXPOSURE MEASUREMENT ......................................................................................................5 2.1 LIMITS .........................................................................................................................................5 2.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................5 2.3 CONFIGURATION OF SYSTEM UNDER TEST .........................................................................6 2.4 TEST SETUP FOR WPC .............................................................................................................6 2.5 EQUIPMENTS USED DURING TEST.........................................................................................7 2.6 TEST POINT DESCRIPTION ......................................................................................................7 2.7 TEST RESULTS ..........................................................................................................................8 3. PHOTOGRAPHS OF THE TEST CONFIGURATION....................................................................... 27 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 27 Report Version 1 Test Report No.: FS2007WDG0133 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED FS2007WDG0133 Original release Sep. 29, 2020 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel.: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 27 Report Version 1 Test Report No.: FS2007WDG0133 1. GENERAL INFORMATION 1.1. GENERAL DESCRIPTION OF EUT FCC ID K7SWIZ008 PRODUCT BOOST↑CHARGE™ Wireless Charging Dual Pads 15W ADDITIONAL PRODUCT Wireless Charging Dual Pads 15W MODEL NO. WIZ008 ADDITIONAL MODEL PW0010 POWER SUPPLY Input: DC 15V 3A from adapter Output:30W (2*15W) MODULATION TECHNOLOGY FSK OPERATING FREQUENCY RANGE 110KHz ~ 205KHz ANTENNA TYPE Loop Antenna I/O PORTS Refer to user’s manual CABLE SUPPLIED Refer to user’s manual NOTES: 1. For a more detailed features description, please refer to the manufacturer’s specifications o…
Text truncated - open the document above for the full version.
Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 76 Report Version 1 Test Report No.: RF2007WDG0133 TEST REPORT Applicant Belkin International, Inc. Address 12045 East Waterfront Drive, Playa Vista, CA 90094 USA Manufacturer or Supplier Belkin International, Inc. Address 12045 East Waterfront Drive, Playa Vista, CA 90094 USA Product BOOST↑CHARGE™ Wireless Charging Dual Pads 15W Additional Product Wireless Charging Dual Pads 15W Brand Name belkin, playa Model WIZ008 Additional Model & Model Difference PW0010, See items 3.1 Date of tests Aug. 01, 2020 ~ Sep. 02, 2020 The submitted sample of the above equipment has been tested for according to the requirements of the following standards: FCC Part 15, Subpart C CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Lucas Chen Project Engineer / EMC Department Approved by Glyn He Assistant Manager/ EMC Department Date: Sep. 29, 2020 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expr…
Text truncated - open the document above for the full version.
No. 96, Guantai Road (Houjie Section) · China
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 0.11 MHz - 0.205 MHz | - |
