KA22002060009-12.4GHz Wireless Cardbus

D-Link Air WCB- B13 2.4 GHz Wireless Cardbus Adapter Manual Building Networks for People ® 2 Contents 1. Package Contents ...................................................................... 3 2. Introduction ................................................................................. 4 3. Wireless Basics .......................................................................... 6 4. Getting Started............................................................................ 9 5. Using the Configuration Utility................................................... 12 6. Troubleshooting ........................................................................ 18 7. Networking Basics .................................................................... 22 8. Technical Specifications ............................................................ 50 9. Contacting Technical Support ................................................... 52 10. Warranty and Registration........................................................ 53 3 1. Package Contents Contents of Package: • D-Link Air WCB-B13 2.4GHz Wireless Cardbus Adapter • Manual, QIG, and Drivers on CD • Printed Quick Installation Guide If any of the above items are missing, please contact your reseller. System Requirements: • A laptop computer with an available 32-bit Cardbus PC Card slot • Windows XP, Windows 2000, Windows Me, or Windows 98SE • Cardbus Controller, properly installed and working • At least 32 MB of memory and a 300 MHz processor • An 802.11b Access Poin W CB-B13 4 2. Introduction The D-Link Air WCB-B13 Wireless Cardbus Adapter is an 802.11b wireless adapter that supports high-speed wireless networking at home, at work or in public places. The WCB-B13 is compatible with existing 802.11b devices such as the D- Link Air and AirPlus family of products including the DWL-520 and DWL- 520+ Wireless PCI Adapters, the DI-614+ Wireless Router, DWL-900AP+ Wireless Access Point and the DWL-120 Wireless USB Adapter. The WCB-B13 is an ideal way to connect your laptop computer to a Wireless Local Area Network (WLAN.) After completing the steps outlined in the Quick Installation Guide (included in the package) you will have the ability to share information and resources, such as files and printers, and take full advantage of a “connected” environment for work or play! The WCB-B13 includes software drivers for the most popular Microsoft Windows operating systems (Windows XP, Windows 2000, Windows Me, Windows 98SE) and can be integrated into a larger network, running, in either Ad Hoc mode (without an Access Point) or Infrastructure mode (with an Access Point.) Please take a look at our Getting Started section in this manual to see examples of typical network setups using the WCB-B13 in both Infrastructure and Ad-Hoc modes. This manual provides a quick introduction to wireless technology and its application as it relates to networking. Take a moment to read through this manual and get acquainted with wireless technology. 5 Product Features • Provides high-speed wireless connection up to 11Mbps • Operates in the 2.4GHz frequency range • Maximum reliability, throughput and connectivity with automatic data rate switching • Supports Wired Equivalent Privacy (WEP) data encryption at 64 or 128-bit encryption • Supports infrastructure networks via an Access Point and peer-to- peer communication in ad-hoc mode • Built-in dual diversity antenna for reduced interference in a multi-path environment • 32-bit Cardbus Performance • User-friendly configuration and diagnostic utilities LEDs LED stands for Light-Emitting Diode. The WCB-B13 has two LEDs: • Link - Green LED lights on steady to indicate a proper connection to the network. • Activity - Amber LED flashes to indicate activity on the network. W CB-B13 Activity Link 6 3. Wireless Basics D-Link Air wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE 802.11b and other standards, the D-Link wireless products will allow you to access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers. A wireless local area network (WLAN) is a cellular computer network that transmits and receives data with radio signals instead of wires. Wireless LANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people to work and communicate more efficiently. Increased mobility and the absence of cabling and other fixed infrastructure have proven to be beneficial for many users. Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards. Under many circumstances, it may be desirable for mobile network devices to link to a conventional Ethernet LAN in order to use servers, printers or an Internet connection supplied through the wired LAN. A Wireless Access Point (AP) is a device used to provide this link. People use wireless LAN technology for many different purposes. Mobility - Productivity increases when people have access to data in any location within the operating range of the WLAN. Management decisions based on real-time information can significantly improve worker efficiency. Low Implementation Costs – WLANs (Wireless Local Area Networks) are easy to set up, manage, change and relocate. Networks that frequently change, both physically and logically, can benefit from WLANs ease of implementation. WLANs can operate in locations where installation of wiring may be impractical. Installation Speed and Simplicity - Installing a wireless LAN system can be fast and easy and can eliminate the need to pull cable through walls and ceilings. Network Expansion - Wir…

Text truncated - open the document above for the full version.

31 Networking Basics Checking the IP Address in Windows XP/2000 Type Command Type ipconfig /all at the prompt. All the configuration settings are displayed as shown below. Type ipconfig /renew at the prompt to get a new IP Address, shown below. (Windows 98SE/Me users: go to Start > Run. Type Command. Type winipcfg at the prompt. Click Release and Renew to obtain a new IP Address.) D-Link Ai r WCB-B13 Wireless Cardbus Adap 32 Networking Basics Assigning a Static IP Address Note: Residential Gateways/Broadband Routers will automatically assign IP Addresses to the computers on the network, using DHCP (Dynamic Host Configuration Protocol) technology. If you are using a DHCP-capable Gateway/Router you will not need to assign Static IP Addresses. If you are not using a DHCP capable Gateway/Router, or you need to assign a Static IP Address, please follow these instructions: • Go to Start • Double-click on Control Panel • Double-click on Network Connections 33 Networking Basics Assigning a Static IP Address • Right-click on Local Area Connections. • Click Properties • Highlight Internet Protocol (TCP/IP) • Click Properties D-Link Air WCB-B13 Wireless Adapter 34 Networking Basics Assigning a Static IP Address • Select Use the following IP address in the Internet Protocol (TCP/IP) Properties window, • Input your IP address and subnet mask. (The IP Addresses on your network must be within the same range. For example, if one computer has an IP Address of 192.168.0.2, the other computers should have IP Addresses that are between 192.168.0.3 and 192.168.0.254. No two computes can have the same IP Address. The subnet mask must be the same for all the computers on the network.) • Input your DNS server address only if you plan to use the Internet. (Note: If you are entering a DNS server address, you must also enter the IP Address of the Default Gateway.) The DNS server information will be provided by your ISP (Internet Service Provider.) • Click OK You have completed the assignment of a Static IP Address. (You do not need to assign a Static IP Address if you have a DHCP-capable Gateway/Router.) 35 Networking Basics Checking the Wireless Connection by Pinging For Windows XP and 2000: Go to Start > Run > type cmd. A window similar to this will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP address of the Wireless Router or Access Point. A good wireless connection will show four replies from the wireless router or access point, as shown. For Windows Me and 98SE: Go to Start > Run > type command. A window similar to this will appear. Type ping xxx.xxx.xxx.xxx , where xxx is the IP address of the Wireless Router or Access Point. A good wireless connection will show four replies from the wireless router or access point, as shown. 36 Networking Basics Adding and Sharing Printers in Windows XP After you have run the Network Setup Wizard on all the computers in your network (please see the Network Setup Wizard section at the beginning of Networking Basics) you can use the Add Printer Wizard to add or share a printer on your network. Whether you want to add a local printer (a printer connected directly to one computer) share an LPR printer (a printer connected to a print server) or share a network printer (a printer connected to your network through a Gateway/Router) use the Add Printer Wizard. Please follow the directions below: First, make sure that you have run the Network Setup Wizard on all of the computers on your network. We will show you 3 ways to use the Add Printer Wizard 1. Adding a local printer 2. Sharing a network printer 3. Sharing an LPR printer 1. Adding a local printer (A printer connected directly to a computer) A printer that is not shared on the network and is connected directly to one computer is called a local printer . If you do not need to share your printer on a network, follow these directions to add the printer to one computer. • Go to Start> Printers and Faxes 37 Networking Basics Adding a local printer • Click on Add a printer • Click Next 38 Networking Basics Adding a local printer • Select Local printer attached to this computer • (Deselect Automatically detect and install my Plug and Play printer if it has been selected.) • Click Next • Select Use the following port: • From the pull-down menu select the correct port for your printer (Most computers use the LPT1: port, as shown in the illustration.) • Click Next • Select and highlight the correct driver for your printer. • Click Next (If the correct driver is not displayed, insert the CD or floppy disk that came with your printer and click Have Disk.) 39 Networking Basics Adding a local printer • At this screen, you can change the name of the printer (optional.) • Click Next • Select Yes, to print a test page. A successful printing will confirm that you have chosen the correct driver. • Click Next This screen gives you information about your printer. Click Finish 40 Networking Basics Adding a local printer When the test page has printed, • Go to Start> Printers and Faxes A successful installation will display the printer icon as shown at right. You have successfully added a local printer. Click OK 41 Networking Basics 2. Sharing a network printer After you have run the Network Setup Wizard on all the computers on your network, you can run the Add Printer Wizard on all the computers on your network. Please follow these directions to use the Add Printer Wizard to share the printer on your network: • Go to Start> Printers and Faxes • Click on Add a Printer • Click Next 42 Networking Basics Sharing a network printer • Select Network Printer • Click Next • Select Browse for a printer • Click Next 43 Networking Basics Sharing a network printer To check for proper installation: • Select the printer you would like to share. • Click Next • Click Finish • Go to Start> Printers and Faxes 44 Networking Basics Sharing a network printer The printer icon will appear at right, indicating proper installation. You have completed adding the pr…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3

Page 4 Page 5 Page 6

FCC ID Label Location

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Node ID: S/N: WCB-B13 FCC ID: KA22002060009-1 WCB-B13 2.4GHz Wireless Cardbus Adapter Tested To Comply With FCC Standards FOR HOME OR OFFICE USE

Page 7 Page 8

FCC ID: KA22002060009-1 ADT No.911210R01 Operational Description This device is a 2.4GHz Wireless Cardbus which is powered by host equipment via a PCMCIA interface. The antenna type is PIFA and there is no antenna connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: KA22002060009-1 Report No.: SA911210R01 1 Issued: March. 10 th 2003 SAR TEST REPORT REPORT NO.: SA911210R01 MODEL NO.: WCB-B13 (for Brand: D-Link) DWL-650 (for Brand: D-Link) LD-WL11/PCCL (for Brand: Elecom) RECEIVED: March. 06, 2003 TESTED: March. 06, 2003 APPLICANT:D-Link Corporation ADDRESS:No.8,Li-Hsin VII Road Science Based Industrial Park Hsin-Chu,Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 15 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. FCC ID: KA22002060009-1 Report No.: SA911210R01 2 Issued: March. 10 th 2003 Table of Contents 1.CERTIFICATION .................................................................................................................3 2.GENERAL INFORMATION ................................................................................................. 4 2.1GENERAL DESCRIPTION OF EUT ................................................................................... 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................... 4 2.3GENERAL INOFRMATION OF THE SAR SYSTEM .......................................................... 5 2.4GENERAL DESCRIPTION OF THE PROBE SCAN RULE................................................ 7 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ........................................... 8 4.DESCRIPTION OF SUPPORT UNITS ............................................................................... 9 5.TEST RESULTS................................................................................................................ 10 5.1TEST PROCEDURES....................................................................................................... 10 5.2MEASURED SAR RESULT .............................................................................................. 10 5.3SAR LIMITS ...................................................................................................................... 11 5.4EUT CONDUCTED POWER VARIATION ........................................................................ 11 5.5TISSUE ............................................................................................................................. 12 5.6TEST EQUIPMENT FOR TISSUE PROPERTY ............................................................... 12 6.SYSTEM VALIDATION...................................................................................................... 13 7.MEASUREMENT UNCERTAINTIES ................................................................................ 14 8.INFORMATION ON THE TESTING LABORATORIES ..................................................... 15 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: KA22002060009-1 Report No.: SA911210R01 3 Issued: March. 10 th 2003 1. CERTIFICATION PRODUCT : 2.4GHz Wireless Cardbus MODEL NO. : WCB-B13 (for Brand: D-Link) DWL-650 (for Brand: D-Link) LD-WL11/PCCL (for Brand: Elecom) APPLICANT : D-Link Corporation STANDARDS : 47 CFR Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on 06 th March. 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate, and it was tested according to the standards listed above. This device was found to be in compliance with the Specific Absorption Rate (SAR) requirement specified in FCC part 2.1093 under General Population / Uncontrolled Exposure condition. FCC ID: KA22002060009-1 Report No.: SA911210R01 4 Issued: March. 10 th 2003 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT2.4GHz Wireless Cardbus MODEL NO.WCB-B13, DWL-650, LD-WL11/PCCL POWER SUPPLY3.3VDC powered by host equipment CLASSIFICATIONPortable device, production unit MODULATION TYPEBPSK, QPSK, CCK RADIO TECHNOLOGYDSSS TRANSFER RATE1/2/5.5/11Mbps FREQUENCY RANGE2412MHz ~ 2462MHz NUMBER OF CHANNEL11 CONDUCTED OUTPUT POWER 59.56mW ANTENNA TYPEInternal Printed Antenna PEAK SAR0.503W/kg DATA CABLENA I/O PORTSPCMCIA ASSOCIATED DEVICESNA 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS According to the specifications of the manufacturer, this product must comply with the requirements of the following standards: FCC 47 CFR Part 2 (2.1093) FCC OET Bulletin 65, Supplement C (01- 01) RSS-102 All tests have been performed and recorded as per the above standards. FCC ID: KA22002060009-1 Report No.: SA911210R01 5 Issued: March. 10 th 2003 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM DASY3 (software 3.1d) consists of high precision robtics system, probe alignment sensor, phantom, robot controller, controlled PC and near-field probe. The robot includes six axis that can move to the precision position of the DASY3 software defined. The DASY3 software can define the area which is detected by the probe. The robot is connected to controlled box. Controlled PC is connected to the controlled robot box. The DAE includes amplifier, signal multiplexing, AD converter, offset measurement, surface detection. It is connected to the Electro-optical coupler (ECO). The ECO performs the conversion form the optical into digital electric signal of the DAE and transfers data to the PC. ET3DV6 ISOTROPIC E-FIELD PROBE Construction Symmetrical design with triangular core. Built-in optical fiber for surface detection system. Built-in shielding against static charges. PEEK enclosure material (res…

Text truncated - open the document above for the full version.

55 44 33 22 11 D D C C B B A A Digital Signal ==> only POP DR5 DR10Analog Signal ==> only NO POP DR5 DR10DEFAULT: Digital Signal POWER 1A1 8WCBB13_1A1 C 13 Saturday, November 23, 2002 TitleSize Document Number Rev Date: Sheet of RF_RXI+ BB_RXI+ RF_RXI- BB_RXI- RF_RXQ+ BB_RXQ+ RF_RXQ- BB_RXQ- BB_TXI+ RF_TXI+ BB_TXI- RF_TXI- BB_TXQ+BB_TXQ- RF_TXQ-RF_TXQ+ PE1/PHITXQ VCOPD/PHITXI/9356SEL VDD2400 VDD2411 VDD18 AGND AGND AGNDAGND VCC33 AGND AGND VDD33 AGND AGND DR850R/NO POP CC1310U T3TP 1 PAD CC18 10U DR22 0R/NO POP DC6NP DC10 0.01U/NO POP CC1910U LL2 MPZ2012S221AT CC110.1U T7TP 1 PAD DR10 0R CC90.1U T4TP 1 PAD LL4 MPZ2012S221AT UU3 XC6204B182MR 123 45 INPUTGROUNDSHTDN N/C OUTPUT T9TP 1 PAD DC7NP DR260R/NO POP T10TP 1 PAD T5TP 1 PAD CC30.1U CC1410U DR650R/NO POPDR750R/NO POP DC12 0.01U/NO POP DR210R/NO POP DR250R/NO POP DR270R/NO POP CC17 10U T2TP 1 PAD CC80.1U DC3NP DR9 50R/NO POP DC4NP CC100.1U DR50R DR230R/NO POP CC120.1U T8TP 1 PAD 55 44 33 22 11 D D C C B B A A PIN114 PIN30 PIN26 PIN1 PIN71 PIN78 PIN100 PIN36 PIN57 PIN99 PIN118 place power de-coupling capacitors (DC19-26,DC41-50) to each power pins as close as PIN48 PIN82 PIN12 PIN80 12 keep layout trace of this area as short as possible and placepad 2 of DC17 to pin 63 (VDDBG)as close as possible DR91 /NO POP ==> 93C46 DR91 /POP ==> 93C56 DEFAULT DR91/NO POP DR112/NO POP for cardbus interface RTL8180 1A1 8WCBB13_1A1 C 23 Saturday, November 23, 2002 TitleSize Document Number Rev Date: Sheet of IRDYBINTAB AD[0:31] STOPB FRAMEB CSTCHGSERRBRSTBCBE3B IDSEL CLKPERRB VMAIN GNTB TRDYB PAR GNTBVCOPD/PHITXI/9356SELIDSEL FRAMEBDEVSELB CBE1BCBE0B RIFSD REQB CBE2B VMAIN CCMP EECSEESKEEDIEEDO VDD33GNTBINTAB VREFI ISOLATEB VCOPD/PHITXI/9356SEL AGND AGND CBE2B R34k DGNDDGND AVDD33 RXI+ TXDET VDDVG VDD18VDD33VDD18PE2/AUX RXQ- VDD18 DGND STOPB EEDI VDD33 AGND R10K DGND TRSW+ RXQ+ AVDD33 AGND TXQ- SERRB DGND VDD33 RXI- AGNDTXQ+ IRDYB ISOLATEB PE1/PHITXQ PAPE ANTSEL- VDD33 CBE1B CLKRUNB AGND RSSI AVDD33 FRAMEB RSTB DGND AGND CBE3B TRSW- CBE0B CCMP DGND TXI+ CLK VDDREG DGNDEEDO RIFSCK VDD33 AVDD33 44MHz DGND DEVSELB DGND TXI- VDD18 IDSEL CALEN/AGCRESET R10k REQB R34K DGND CSTCHGEESK PAR PERRB TRDYB VDD33 VDDPLL EECS AD12 AD8 AD15 AD14 AD17 AD11 AD11AD6 AD24 AD0 AD7 AD3 AD20AD22 AD4 AD30AD28 AD22 AD25 AD10 AD27 AD14AD9AD29 AD6 AD1 AD16 AD5AD0 AD19 AD4 AD18 AD19 AD13 AD30 AD20 AD17 AD31 AD26 AD10 AD21 AD28 AD3 AD2 AD31 AD16 AD27 AD12AD9 AD29 AD13 AD23 AD23 AD1 AD25 AD15 AD26 AD24 AD18 AD7AD5 AD2AD8 AD21 44MHZ CLKRUNB DGND IFLE/AGCSETRFLE ANTSEL+ DGND AVDD33 RIFSD BB_RXI-BB_RXQ+RSSI BB_TXI- PE2/AUX ANTSEL-TRSW+RFLEPAPEANTSEL+ RIFSCKBB_RXI+ BB_TXQ- CALEN/AGCRESET BB_RXQ- BB_TXI+ VCOPD/PHITXI/9356SEL VREFI PE1/PHITXQ TXDET IFLE/AGCSETTRSW- BB_TXQ+ RF_REF_OUTRF_REF_IN AGND VCC33 VDD33 VDD33 AGND VDD18 VDD33 AGND VCC33 VDD33 VCC33 AGND AGND AGND AGND AVDD33 VDD33 VDD33 VDD33 VDD33 VDD33 VDD33 AGND AGND AGND VDD33 AGND AGND RR100R DC210.1U RR90R DC250.1U DC410.1U DC220.1U DC420.1U DU3 44MHz 12 34 NCGND OUT VCC DC440.1U RR8 0R/NO POP DC230.1U DR891K/NO POPDR901K DC28NP DR1130R/NO POP DR9215K DC510.1U/NO POP DC180.1U DC240.1U DC1527P RR11 0R/NO POP RR7 0R/NO POP DC52 0.1U/NO POP DC17 0.1U DR9310K DC90.01UF DR9734K DC10.1U DC260.1U DC1468P DR9810K DU1 RTL8180 1 2 3 4 5 31 29 28 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 30 32 3334353637383940414243444546474849505152535455565758596064 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 979899 100101102103104105106107108109110111112113114115116117118119120121122123124125126127128 616263 VDD CBE3B IDSEL AD23 AD22 AD13 AD14 AD15 AD21 GND AD20 AD19 AD18 AD17 VDD AD16 CBE2B GND FRAMEB IRDYB GND CLKRUNB TRDYB DEVSELB STOPB PERRB SERRB PAR VDD CBE1B VDD18 GND18 AD12AD11AD10 VDD AD9AD8 CBE0B GND18 AD7AD6 GND AD5AD4AD3AD2 VDD18 AD1AD0 GNDPLL XO XI VDDPLL RXAGC TXAGC VDD TXQ- TXQ+ GND R34K R10K GNDBG CCMP VREFI TXDET RSSI VDD RXQ- RXQ+ GND GND RXI- RXI+ VDD GNDVSUB VDDDIG GNDDIG VDD RIFSCK RIFSD RFLE IFLE/AGCSET CALEN/AGCRESET LNAHL GND ANTSEL+ ANTSEL- TRSW+ TRSW- VCOPDN/TXI/9356SEL PAPE PE1/TXQ PE2GND18VDD18VDDEEDOEEDIEESKEECSLED0LED1GNDISOLATEBLWAKE/CSTCHGVDDREGINTABRSTBPCICLKVDD18GNTBREQBPMEBVDDAD31AD30AD29GND18AD28GNDAD27AD26AD25AD24 TXI- TXI+ VDDBG DC210U DR19470R DR12 10R DC450.1U DC470.1U LED0 LED 2 1 LED1 LED 2 1 U16 CB1 12345678910111213141516171819202122232425262731282930323334 35363738394041424344454647484950515253545556575859606162636465666768 69 70 71 72 73 74 75 76 GND CAD0CAD1CAD3CAD5CAD7 CBE0B CAD9 CAD11CAD12CAD14 CBE1B CPAR CPERRB CGNTB CINTAB VCC VPP1 CCLK CIRDYB CBE2B CAD18CAD20CAD21CAD22CAD23CAD24CAD29CAD25CAD26CAD27 RFU CLKRUNB GND GNDCCD1BCAD2CAD4CAD6RFUCAD8CAD10CVS1BCAD13CAD15CAD16RFUCBLOCKBCSTOPBCDEVSELBVCCVPP2CTRDYBCFRAMEBCAD17CAD19CVS2BCRSTBCSERRBCREQBCBE3BCAUDIOBCSTSCHGCAD28CAD30CAD31CCD2BGND GND GND GND GND GND GND GND GND DR94 10K DR95 10K DR96 10K DR11 10K DR91 10K/NO POP DC490.1U DR1120R/NO POP DR110510RDR111510R DC460.1U DU2 IS93C46-3GR 1234 8765 CSSKDIDO VCC NCNC GND DR114 10K DC480.1U T14TP 1 PAD DC190.1U DC500.1U T15TP 1 PAD DC270.01UF DC200.1U DR115 10K DC430.1U 55 44 33 22 11 D D C C B B A A TRSW- RX 1 FRONT-END 10 TRSW+ TX 0 Philips SA2400 RF Chip No pop,just for debuging Power for SA2400 TX or RX control pin current con sume < 100 uA Floating: High gain mode(15dB),19dBm output consumes 200mA SA2400 1A1 8WCBB13_1A1 C 33 Saturday, November 23, 2002 TitleSize Document Number Rev Date: Sheet of AVDD2400 DVDD2400 AVDD2400 AVDD2400 AVDD2400 VDD_PLL2400 VDD_PLL2400 VDD_VCO2400 VDD_VCO2400 DVDD2400 TRSW- IFLE/AGCSET CALEN/AGCRESET VREFI RSSI RF_REF_IN RF_TXI+RF_TXI-RF_TXQ+RF_TXQ-RF_RXQ+RF_RXQ-RF_RXI+RF_RXI-RF_REF_OUTPE2/AUXRIFSCKRIFSDRFLE TXDET PAPE TRSW+ANTSEL-ANTSEL+ AGND AGND AGND AGND AGND AGND AGND AGND AGND AGND VDD2400 VDD2411 AGND AGND AGND VDD2400 AGND AGND AGND AGND AGND AGND AGND AGNDAGND AGND AGND AGND AGND AGND AGND AGND AGND AGND AGND AGND AGNDAGND AGND AGND AGND AGND AGND AGND PL10 22nH PC3556P PR125.6K PU4LFTC15N19E2450B…

Text truncated - open the document above for the full version.

FCC ID: KA22002060009-1 Report No.: RF911210R01 1 Issued: Feb. 25, 2003 FCC TEST REPORT REPORT NO.: RF911210R01 MODEL NO.: WCB-B13 (for Brand: D-Link) DWL-650 (for Brand: D-Link) LD-WL11/PCCL (for Brand: Elecom) RECEIVED: Nov. 29, 2002 TESTED: Dec. 10, 2002 ~ Feb. 21, 2003 APPLICANT:D-Link Corporation ADDRESS:No.8,Li-Hsin VII Road Science Based Industrial Park Hsin-Chu,Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: KA22002060009-1 Report No.: RF911210R01 2 Issued: Feb. 25, 2003 Table of Contents 1CERTIFICATION ..................................................................................................................... 4 2SUMMARY OF TEST RESULTS ............................................................................................ 5 3GENERAL INFORMATION ..................................................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ....................................................................................... 6 3.2DESCRIPTION OF TEST MODES ......................................................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................ 7 3.4DESCRIPTION OF SUPPORT UNITS ................................................................................... 8 4TEST TYPES AND RESULTS ................................................................................................ 9 4.1CONDUCTED EMISSION MEASUREMENT ......................................................................... 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................................... 9 4.1.2TEST INSTRUMENTS ............................................................................................................ 9 4.1.3TEST PROCEDURES...........................................................................................................10 4.1.4DEVIATION FROM TEST STANDARD................................................................................. 10 4.1.5TEST SETUP .........................................................................................................................11 4.1.6EUT OPERATING CONDITIONS ..........................................................................................11 4.1.7TEST RESULT ...................................................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT............................................................................. 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT .......................................................... 18 4.2.2TEST INSTRUMENTS ..........................................................................................................19 4.2.3TEST PROCEDURES...........................................................................................................20 4.2.4DEVIATION FROM TEST STANDARD................................................................................. 20 4.2.5TEST SETUP ........................................................................................................................ 21 4.2.6EUT OPERATING CONDITIONS ......................................................................................... 21 4.2.7TEST RESULT ...................................................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .................................................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................. 26 4.3.2TEST INSTRUMENTS ..........................................................................................................26 4.3.3TEST PROCEDURE .............................................................................................................27 4.3.4DEVIATION FROM TEST STANDARD...........................................................................…

Text truncated - open the document above for the full version.
