KA22004050007-1802.11g/2.4GHz Wireless Gaming Adapter

Manual Building Networks for People D-Link AirPlus Xtreme G DWL-G820 TM 802.11g Wireless 108Mbps Gaming Adapter 2 Contents Package Contents................................................................................ 3 Introduction............................................................................................ 4 Wireless Basics.................................................................................... 6 Getting Started ...................................................................................... 9 Using the Configuration Menu.............................................................. 11 Troubleshooting................................................................................... 23 Technical Specifications...................................................................... 29 Contacting Technical Support.............................................................. 32 Warranty and Registration................................................................... 33 3 Package Contents Contents of Package: D-Link AirPlus Xtreme G DWL-G820 802.11g Wireless 108Mbps Gaming Adapter Manual and Warranty on CD Ethernet Cable System Requirements for Configuration:
A computer or laptop with an Ethernet adapter. (We recommend that you use an Ethernet connection to configure the DWL-G820.)
If any of the above items are missing, please contact your reseller.


TM Quick Installation Guide
A current web-browser (e.g., Internet Explorer 6.0 or Netscape Navigator 6.0 or later) for configuration For Use: You will need an Ethernet-enabled device such as a game console, laptop or desktop computer, or set top box. The DWL-G820 will transform virtually any Ethernet device into a wireless device, enabling wireless communication over your network or in an Ad-Hoc/Peer-to-Peer mode. 5V DC, 2A Power Adapter
4 Introduction D-Link announces its latest addition to the D-Link AirPlus Xtreme TM G series of wireless networking products–the DWL-G820 High-Speed Wireless Gaming Adapter. The DWL-G820 adds 802.11g wireless connectivity to your Ethernet-enabled gaming console. The DWL-G820 works with any Ethernet-ready game console, making it ideal for both head-to-head and online gaming. Use Wireless Gaming Adapters to wirelessly connect two game systems to each other or use one to connect your system to a wireless network. And when not gaming, you can use the DWL-G820 to make any Ethernet-enabled device, such as a media set-top box, wireless. The DWL-G820 is a true plug & play device that requires no configuration and is ready to work right out of the box. The Wireless Game Adapter is also highly configurable, using any Java-enabled Web browser. With support for several advanced features, including Wi-Fi Protected Access (WPA) and 128-bit WEP encryption, the Wireless Gaming Adapter also protects your wireless signal. The DWL-G820 uses D-Link 108 Technology for data transfer rates that are 15x faster than standard 802.11b rates and works with all 802.11g networks. The device is also backwards compatible with 802.11b wireless networks. This Gaming Adapter provides lag-free performance and allows your gaming console to join your wireless network. 5 Features & Benefits
Enables wireless connectivity for an Ethernet-enabled gaming console
Fully compliant with the 802.11b standard and interoperable with all existing 802.11b compliant and 802.11g compliant devices
Equipped with one 10/100 Ethernet port, Auto-MDI/MDIX
Quick and Simple connectivity via Ethernet Five times faster using 802.11g - achieve data transfer speeds up to 54Mbps (108Mbps in Super G mode); up to 5x faster than conventional 802.11b networks, when used with other 802.11g devices
Encryption provides a level of security for data transfers

Easy Web-based configuration when changing settings
Supports Ad-Hoc or Infrastructure modes Power – a steady light indicates a proper connection to a power source. LEDs WLAN – a steady light indicates a wireless connection. A blinking light indicates that the DWL-G820 is receiving/ transmitting from/to the wireless network. 6 Wireless Basics Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards. D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. D-Link wireless products will allow you access to the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking brings. A Wireless Local Area Network (WLAN) is a computer network that transmits and receives data with radio signals instead of wires. WLANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people to work and communicate more efficiently. Increased mobility and the absence of cabling and other fixed infrastructure have proven to be beneficial for many users. People use WLAN technology for many different purposes: Mobility - Productivity increases when people have access to data in any location within the operating range of the WLAN. Management decisions based on real-time information can significantly improve worker efficiency. Low Implementation Costs - WLANs are easy to set up, manage, change and relocate. Networks that frequently change can benefit from WLANs ease of implementation. WLANs can operate in locations where installation of wiring may be impractical. Installation and Network Expansion - Installing a WLAN system can be fast and easy and can eliminate the need to pull cable through walls and ceilings. Wireless technology allows the network to go where wires cannot go - even outside the home or office. Inexpensive Solution - Wireless network devices are as co…

Text truncated - open the document above for the full version.

D-Link Corporation NO.8,Li Hsing Rd VII ,SCIENCE-BASED INDUSTRIAL PARK,HSINCHU,TAIWAN,R.O.C. TEL: ++886 3-577-9110 FAX: +886 3-578-1861 FCC ID: KA22004050007-1 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, --------------------------------------------------- Leeming Li / Manager D-Link Corporation Tel: 886-3-563-6666 ext.6613 Fax: 886-3-578-1861 E-mail: [email protected]

dwlg820_FCC_DoC letter.jpg (1000 x 1434 x 24)

D-Link Corporation NO.8, Li Hsing Rd VII, SCIENCE-BASED INDUSTRIAL PARK, HSINCHU, TAIWAN, R.O.C. TEL: ++886 3-563-6666 FAX: +886 3-578-1861 POWER OF ATTORNEY To whom it may concern: We, the undersigned, D-Link Corporation, hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 15C. Any and all acts carried out by ADT on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------------------------- Leeming Li / Manager D-Link Corporation Tel: 886-3-563-6666 ext.6613 Fax: 886-3-578-1861 E-mail: [email protected]

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

Device with label.jpg (1280 x 960 x 24)


Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10

FCC ID: KA22004050007-1 Report No. 930518L04 Operational Description This device is a 802.11g/2.4GHz Wireless Gaming Adapter, the maximum data rate could be up to 54Mbps (108Mbps for Turbo mode, channel 6 ) which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT (802.11g/2.4GHz Wireless Gaming Adapter) is powered by power adapter. The antenna type used in this product are dipole Antenna with R-SMA connector and printed antenna without connector. The other instruction, please have a look at the users manual.

FCC ID: KA22004050007-1 ADT No.: 930518L041 RF EXPOSURE REPORT REPORT NO.: RF930518L04 MODEL NO.: WAP-G06, DWL-G820, DWL-G810, DWL-G800AP ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: D-LINK CORPORATION ADDRESS: NO.8,Li Hsing Rd VII ,SCIENCE-BASED INDUSTRIAL PARK,HSINCHU,TAIWAN,R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. FCC ID: KA22004050007-1 ADT No.: 930518L042 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: KA22004050007-1 ADT No.: 930518L043 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This is a stand alone radio device. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: KA22004050007-1 ADT No.: 930518L044 6 Test Results 6.1 Antenna Gain Antenna 1: The maximum Gain of the antenna is 2.0dBi. Antenna 2: The maximum Gain of the antenna is 0dBi. 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For Part 802.11b: Antenna 1 ( Gain 2.0dBi) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 124121000.0315303741.0 624371000.0315303741.0 1124621000.0315303741.0 Antenna 2 ( Gain 0dBi) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 124121000.0198943211.0 624371000.0198943211.0 1124621000.0198943211.0 For Part 802.11g: Antenna 1 ( Gain 2.0dBi) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 124121000.0315303741.0 624371000.0315303741.0 1124621000.0315303741.0 Turbo 624371000.0315303741.0 Antenna 2 ( Gain 0dBi) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 124121000.0198943211.0 624371000.0198943211.0 1124621000.0198943211.0 Turbo 624371000.0198943211.0

Report No. 930518L04 1 The Measurement of Conducted Spurious Emissions CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 1. LIMITS OF CONDUCTED SPURIOUS EMISSIONS EASUREMENT Below 20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth, see Section 15.247(c)). Emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the limits specified in Section 15.209(a) (see Section 15.205(c)). 2. TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until R&S SPECTRUM ANALYZERFSP40100036Nov. 27, 2004 High pass filter 2.4G WHK3.1/18G- 10SS SN4Jun. 12, 2004 NOTE: 1.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 3. TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. Report No. 930518L04 2 4. TEST SETUP 5. EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Report No. 930518L04 3 TEST RESULTS – For 802.11b The spectrum plots are attached on the following 2 pages. It shows compliance with the requirement in part 15.247(C),.15.205 and 15.209. Report No. 930518L04 4 Ch1 Report No. 930518L04 5 Ch11 Report No. 930518L04 6 TEST RESULTS – For 802.11g The spectrum plots are attached on the following 2 pages. It shows compliance with the requirement in part 15.247(C),.15.205 and 15.209. Report No. 930518L04 7 Ch1 Report No. 930518L04 8 Ch11

FCC ID: KA22004050007-1 Report No.: RF930518L041 Issued: Jun. 07, 2004 FCC TEST REPORT REPORT NO.:RF930518L04 MODEL NO.:WAP-G06, DWL-G820, DWL-G810, DWL-G800AP RECEIVED:May 18, 2004 TESTED:May 26 to Jun. 2, 2004 APPLICANT: D-LINK CORPORATION ADDRESS:NO.8,Li Hsing Rd VII ,SCIENCE-BASED INDUSTRIAL PARK,HSINCHU,TAIWAN,R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 77 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, or any government agencies. The test results in the report only apply to the tested sample. 0536 ILAC MRA FCC ID: KA22004050007-1 Report No.: RF930518L042 Issued: Jun. 07, 2004 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT.............................................................. 6 3.2DESCRIPTION OF TEST MODES................................................................ 8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ............................... 8 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 9 3.5CONFIGURATION OF SYSTEM UNDER TEST ......................................... 10 4TEST TYPES AND RESULTS......................................................................11 4.1CONDUCTED EMISSION MEASUREMENT ...............................................11 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................11 4.1.2TEST INSTRUMENTS .................................................................................11 4.1.3TEST SETUP .............................................................................................. 12 4.1.4EUT OPERATING CONDITIONS................................................................ 13 4.1.5TEST RESULTS.......................................................................................... 14 4.2Radiated Emission Measurement ............................................................... 16 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 16 4.2.2TEST INSTRUMENTS ................................................................................ 17 4.2.3TEST PROCEDURES................................................................................. 18 4.2.4TEST SETUP .............................................................................................. 19 4.2.5EUT OPERATING CONDITIONS................................................................ 19 4.2.6TEST RESULTS.......................................................................................... 20 4.2.7TEST RESULTS – Antenna 1, DSSS .......................................................... 21 4.2.8TEST RESULTS – Antenna 2, DSSS .......................................................... 24 4.2.9TEST RESULTS - Antenna 1, OFDM .......................................................... 27 4.2.10 TEST RESULTS - Antenna 2, OFDM .......................................................... 31 4.36dB BANDWIDTH MEASUREMENT .......................................................... 35 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 35 4.3.2TEST INSTRUMENTS ................................................................................ 35 4.3.3TEST PROCEDURE ................................................................................... 36 4.3.4TEST SETUP .............................................................................................. 36 4.3.5EUT OPERATING CONDITIONS................................................................ 36 4.3.6TEST RESULTS-DSSS............................................................................... 37 4.3.7TEST RESULTS-OFDM .............................................................................. 41 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 46 FCC ID: KA22004050007-1 Report No.: RF930518L043 Issued: Jun. 07, 2004 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 46 4.4.2TEST INSTRUMENTS ................................................................................ 46 4.4.3TEST PROCEDURES................................................................................. 47 4.4.4TEST SETUP .............................................................................................. 47 4.4.5EUT OPERATING CONDITIONS................................................................ 47 4.4.6TEST RESULTS- DSSS.............................................................................. 48 4.4.7TEST RESULTS- OFDM ............................................................................. 49 4.5POWER SPECTRAL DENSITY MEASUREMENT...................................... 50 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 50 4.5.2TEST INSTRUMENTS ................................................................................ 50 4.5.3TEST PROCEDURE ................................................................................... 51 4.5.4TEST SETUP .............................................................................................. 51 4.5.5EUT OPERATING CONDITIONS................................................................ 51 4.5.6TEST RESULTS-DSSS............................................................................... 52 4.5.7TEST RESULTS-OFDM .............................................................................. 56 4.6BAND EDGES MEASUREMENT ...............…

Text truncated - open the document above for the full version.

FCC ID: KA22004050007-1 Report No.: RF930518L0475 Issued: Jun. 07, 2004 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: KA22004050007-1 Report No.: RF930518L0476 Issued: Jun. 07, 2004 RADIATED EMISSION TEST
