KA2AP1560A1Media Streaming Adapter / Media Streaming Kit

D-Link Corporation

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 20, 2010
Application Purpose: Original Equipment
Date of Application: Jul 20, 2010
Equipment Note: Media Streaming Adapter / Media Streaming Kit
Frequency Range: 5745.00000000 - 5825.00000000
Company: D-Link Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

2D-Link DAP-1560 User Manual Table of Contents Product Overview .............................................................. 4 Package Contents......................................................................... 4 System Requirements ................................................................. 5 Introduction ................................................................................... 6 Features.................................................................................... 7 Hardware Overview ..................................................................... 8 Connections ........................................................................... 8 LEDs ........................................................................................... 9 Installation ....................................................................... 10 Wireless Modes............................................................................10 AP Mode.................................................................................10 Bridge Mode .........................................................................11 Wireless Installation Considerations....................................13 Configuration (AP Mode) ................................................ 14 Web-based Configuration Utility ..........................................14 Setup Wizard ................................................................................15 Wireless Setup Wizard .......................................................16 Add Wireless Device With WPS ..............................................23 Manual Configuration...............................................................25 Wireless Settings .................................................................25 Network Settings ................................................................27 DHCP ..................................................................................27 Static IP ..............................................................................28 Advanced ......................................................................................29 MAC Address Filter .............................................................29 Advanced Wireless .............................................................30 Guest Zone............................................................................31 Maintenance ................................................................................32 Admin .....................................................................................32 System ....................................................................................33 Language Pack.....................................................................34 Firmware ................................................................................34 Time .........................................................................................36 Schedules ..............................................................................37 Watchdog ..............................................................................38 Status ..............................................................................................39 Device Info ............................................................................39 Logs .........................................................................................40 Statistics .................................................................................41 Wireless ..................................................................................42 Help .................................................................................................43 Configuration (Bridge Mode).......................................... 44 Web-based Configuration Utility ..........................................44 Setup Wizard ........................................................................45 Wireless ..................................................................................53 Wireless MAC Cloning ...............................................................54 Network Settings ................................................................55 Static...................................................................................55 DHCP ..................................................................................56 Advanced ......................................................................................57 Advanced Wireless .............................................................57 Maintenance ................................................................................58 Admin .....................................................................................58 Table of Contents 3D-Link DAP-1560 User Manual Table of Contents System ....................................................................................59 Language Pack.....................................................................60 Firmware ................................................................................60 Time .........................................................................................62 Watchdog ..............................................................................63 Status ..............................................................................................64 Device Info ............................................................................64 Logs .........................................................................................65 Statistics .................................................................................66 Help .................................................................................................67 Wireless Security ............................................................. 68 What is WEP? ................................................................................68 What is WPA? ..…

Text truncated - open the document above for the full version.

Users Manual

82D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network Using Windows Vista ® Windows Vista ® VTFSTNBZVTFUIFDPOWFOJFOU CVJMUJOXJSFMFTTVUJMJUZ'PMMPXUIFTFJOTUSVDUJPOT 'SPNUIF4UBSUNFOV HPUP$POUSPM1BOFM BOEUIFODMJDLPO Network and Sharing Center. The utility will display any available wireless networks in your area. Click on a network (displayed using the SSID) under Select a network to connect to and then click the Connect button. 83D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network ClickConnect Anyway to continue. The utility will display the following window to indicate a connection is being made. The final window indicates the establishment of a successful connection. 5IFOFYUUXPQBHFTEJTQMBZUIFXJOEPXTVTFEUPDPOOFDUUPFJUIFS a WEP or a WPA-PSK wireless network. 84D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network Click on a network (displayed using the SSID) using WEP under Select a network to connect to and then click the Connect button. Enter the appropriate security key or passphrase in the field provided and then click the Connect button. Configure WEP It is recommended to enable WEP on your wireless bridge or access point before configuring your wireless adapter. If you are KPJOJOHBOFYJTUJOHOFUXPSL ZPVXJMMOFFEUPLOPXUIF8&1LFZCFJOHVTFE 85D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network Click on a network (displayed using the SSID) using WPA-PSK under Select a network to connect to and then click the Connect button. Enter the appropriate security key or passphrase in the field provided and then click the Connect button. Configure WPA-PSK It is recommended to enable WEP on your wireless bridge or access point before configuring your wireless adapter. If you are KPJOJOHBOFYJTUJOHOFUXPSL ZPVXJMMOFFEUPLOPXUIF8&1LFZCFJOHVTFE 86D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network Using Windows ® XP Windows® XP users may use the built-in wireless utility (Zero Configuration Utility). The following instructions are for Service 1BDLVTFST*GZPVBSFVTJOHBOPUIFSDPNQBOZTVUJMJUZPS8JOEPXT QMFBTFSFGFSUPUIFVTFSNBOVBMPGZPVSXJSFMFTT adapter for help with connecting to a wireless network. Most utilities will have a “site survey” option similar to the Windows XP utility as seen below. Right-click on the wireless computer icon in your system tray (lower-right DPSOFSOFYUUPUIFUJNF 4FMFDUView Available Wireless Networks. If you receive the Wireless Networks DetectedCVCCMF DMJDLPOUIF center of the bubble to access the utility. or The utility will display any available wireless networks in your area. Click on a network (displayed using the SSID) and click the Connect button. *GZPVHFUBHPPETJHOBM CVUDBOOPUBDDFTTUIF*OUFSOFU DIFDLZPV5$1 IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. 87D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network Configure WEP It is recommended to enable WEP on your wireless bridge or access point before configuring your wireless adapter. If you are KPJOJOHBOFYJTUJOHOFUXPSL ZPVXJMMOFFEUPLOPXUIF8&1LFZCFJOHVTFE 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. 1. Open the Windows® XP Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 88D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network 3. The Wireless Network Connection CPYXJMMBQQFBS&OUFSUIFTBNF8&1 key that is on your access point and click Connect. It may take 20-30 seconds to connect to the wireless network. If the DPOOFDUJPOGBJMT QMFBTFWFSJGZUIBUUIF8&1TFUUJOHTBSFDPSSFDU5IF8&1 LFZNVTUCFFYBDUMZUIFTBNFBTPOUIFXJSFMFTTBDDFTTQPJOU 89D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network Configure WPA-PSK It is recommended to enable WEP on your wireless bridge or access point before configuring your wireless adapter. If you are KPJOJOHBOFYJTUJOHOFUXPSL ZPVXJMMOFFEUPLOPXUIF8&1LFZCFJOHVTFE 2. Highlight the wireless network (SSID) you would like to connect to and click Connect. 1. Open the Windows® XP Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower-right corner of screen). Select View Available Wireless Networks. 90D-Link DAP-1560 User Manual Section 5 - Connecting to a Wireless Network 3. The Wireless Network Connection CPYXJMMBQQFBS&OUFSUIF81"14, passphrase and click Connect. It may take 20-30 seconds to connect to the wireless network. If the DPOOFDUJPOGBJMT QMFBTFWFSJGZUIBUUIF81"14,TFUUJOHTBSFDPSSFDU5IF 81"14,QBTTQISBTFNVTUCFFYBDUMZUIFTBNFBTPOUIFXJSFMFTTBDDFTT point. 91D-Link DAP-1560 User Manual Section 6 - Troubleshooting Troubleshooting This chapter provides solutions to problems that can occur during the installation and operation of the DAP-1560. Read the GPMMPXJOHEFTDSJQUJPOTJGZPVBSFIBWJOHQSPCMFNT 5IFFYBNQMFTCFMPXBSFJMMVTUSBUFEJO8JOEPXT ® XP. If you have a different PQFSBUJOHTZTUFN UIFTDSFFOTIPUTPOZPVSDPNQVUFSXJMMMPPLTJNJMBSUPUIFGPMMPXJOHFYBNQMFT 1. Why can’t I access the web-based configuration utility? 8IFOFOUFSJOHUIF*1BEESFTTPGUIF%-JOLBDDFTTQPJOU GPSFYBNQMF ZPVBSFOPUDPOOFDUJOHUPBXFCTJUFPO the Internet or have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility. t .BLFTVSFZPVIBWFBOVQEBUFE+BWBFOBCMFEXFCCSPXTFS8FSFDPNNFOEUIFGPMMPXJOH .JDSPTPGU*OUFSOFU&YQMPSFS¥BOEIJHIFS .P[JMMB'JSFGPYBOEIJHIFS - Google Chrome 2.0 and higher - Apple Safari 3.0 and higher t 7FSJGZQIZTJDBMDPOOFDUJWJUZCZDIFD…

Text truncated - open the document above for the full version.

Cover Letter(s)

No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. TEL.:+ 886-2-66000123 FAX:+ 886-2-55509988 AUTHORIZATION LETTER Date:2010-07-14 To whom it may concern: We, the undersigned D-Link Corporation hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all matters relating to all processes required in FCC Part 15C/15E and any communication needed with the national authority. Any and all acts carried out by BV CPS Taoyuan on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, ------------------------------------------------- Shinglin Chung / Director D-Link Corporation TEL.:+ 886-2-66000123 # 5819 FAX:+ 886-2-55509988 E-mail: [email protected]

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

ID Label/Location Info

Label location

Internal Photos

Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10

Operational Description

FCC ID: KA2AP1560A1 Report No.: RF990602C04 Operational Description This device are Media Streaming Adapter and Media Streaming Kit, which operates in both of the 2.4GHz and 5GHz bands and can’t transmitting simultaneously, the maximum data rate could be up to 600Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 600Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by AC adapter. The antenna is Dipole antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

RF Exposure Info

Report No.: SA990602C04 Report Format Version 3.0.1. 1 RF EXPOSURE REPORT REPORT NO.: SA990602C04 MODEL NO.: DAP-1560, DAP-1562 FCC ID: KA2AP1560A1 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. Report No.: SA990602C04 Report Format Version 3.0.1. 2 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 4. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 28.7 2 20 0.232 1.00 5180-5240 16.7 2 20 0.015 1.00 5745-5825 29.1 2 20 0.256 1.00

Test Report

Report No.: RF990602C04 1 Report Format Version 3.0.1 FCC TEST REPORT (15.247) REPORT NO.: RF990602C04 MODEL NO.: DAP-1560 (Refer to item 3.1 for more detail) RECEIVED: Jun. 02, 2010 TESTED: Jun. 03 ~ Jul. 19, 2010 ISSUED: Jul. 21, 2010 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 115 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF990602C04 2 Report Format Version 3.0.1 TABLE OF CONTENTS 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY................................................................................ 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 14 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 14 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ................................................. 15 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 15 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 15 4.1.2 TEST INSTRUMENTS................................................................................................ 16 4.1.3 TEST PROCEDURES ................................................................................................ 17 4.1.4 DEVIATION FROM TEST STANDARD....................................................................... 17 4.1.5 TEST SETUP.............................................................................................................. 18 4.1.6 EUT OPERATING CONDITIONS ............................................................................... 18 4.1.7 TEST RESULTS ......................................................................................................... 19 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 32 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 32 4.2.2 TEST INSTRUMENTS................................................................................................ 32 4.2.3 TEST PROCEDURES ................................................................................................ 33 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 33 4.2.5 TEST SETUP.............................................................................................................. 34 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 34 4.2.7 TEST RESULTS ......................................................................................................... 35 4.3 6dB BANDWIDTH MEASUREMENT.......................................................................... 37 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................... 37 4.3.2 TEST INSTRUMENTS................................................................................................ 37 4.3.3 TEST PROCEDURE................................................................................................... 37 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 37 4.3.5 TEST SETUP.............................................................................................................. 38 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 38 4.3.7 TEST RESULTS ......................................................................................................... 39 4.4 MAXIMUM OUTPUT POWER .................................................................................... 43 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT..................................... 43 4.4.2 INSTRUMENTS .......................................................................................................... 43 4.4.3 TEST PROCEDURES ................................................................................................ 43 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 44 4.4.5 TEST SETUP.............................................................................................................. 44 4.4.6 EUT OPERATING CONDITIONS ............................................................................... 44 4.4.7 TEST RESULTS ......................................................................................................... 45 4.5 POWER SPECTRAL DEN…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF990602C04-1 1 Report Format Version 3.0.1 FCC TEST REPORT (15.407) REPORT NO.: RF990602C04-1 MODEL NO.: DAP-1560 (Refer to item 3.1 for more detail) RECEIVED: Jun. 02, 2010 TESTED: Jun. 03 ~ Jun. 25, 2010 ISSUED: Jun. 29, 2010 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 67 pages. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF990602C04-1 2 Report Format Version 3.0.1 TABLE OF CONTENTS 1. CERTIFICATION........................................................................................................... 4 2. SUMMARY OF TEST RESULTS .................................................................................. 5 2.1 MEASUREMENT UNCERTAINTY................................................................................ 5 3. GENERAL INFORMATION ........................................................................................... 6 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 6 3.2 DESCRIPTION OF TEST MODES ............................................................................... 7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................... 8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 10 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 10 4. TEST TYPES AND RESULTS .................................................................................... 11 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 11 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 11 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 11 4.1.3 TEST INSTRUMENTS................................................................................................ 12 4.1.4 TEST PROCEDURES ................................................................................................ 13 4.1.5 DEVIATION FROM TEST STANDARD....................................................................... 13 4.1.6 TEST SETUP.............................................................................................................. 14 4.1.7 EUT OPERATING CONDITION.................................................................................. 14 4.1.8 TEST RESULTS ......................................................................................................... 15 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 24 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 24 4.2.2 TEST INSTRUMENTS................................................................................................ 24 4.2.3 TEST PROCEDURES ................................................................................................ 25 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 25 4.2.5 TEST SETUP.............................................................................................................. 26 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 26 4.2.7 TEST RESULTS ......................................................................................................... 27 4.3 MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT ............................... 29 4.3.1 LIMITS OF MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT............. 29 4.3.2 TEST INSTRUMENTS................................................................................................ 29 4.3.3 TEST PROCEDURE................................................................................................... 30 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 30 4.3.5 TEST SETUP.............................................................................................................. 30 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 30 4.3.7 TEST RESULTS ......................................................................................................... 31 4.4 PEAK POWER EXCURSION MEASUREMENT ........................................................ 35 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT...................................... 35 4.4.2 TEST INSTRUMENTS................................................................................................ 35 4.4.3 TEST PROCEDURE................................................................................................... 35 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 36 4.4.5 TEST SETUP.............................................................................................................. 36 4.4.6 EUT OPERATING CONDITIONS ............................................................................... 36 4.4.7 TEST RESULTS ......................................................................................................... 3…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST

Contact Information

Applicant

Brett Adair(General Counsel)

[email protected]714-885-6000Fax: 866-743-4589

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchGary Chang

[email protected]886-3-3183232

No. 19, Hwa Ya 2nd Rd., Kwei Shan Hsiang · Taoyuan Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchWendy Liao

[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen

[email protected]886-3-3183232Fax: 886-3-2115834

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	5.75 GHz - 5.83 GHz	812.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum combined conducted output power. Device is a draft 802.11a/b/g/n Adapter operating in a 4x4 Spatial Multiplexing MIMO configuration as described in this filing. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
