KA2AP2690B1DAP-2690 AirPremier N Dual Band Concurrent PoE Access Point

2DAP-2690 Install Guide Minimum System Requirements: • CD-ROM Drive • Computers with Windows ® , Macintosh ® , or Linux-based operating systems • Installed Ethernet Adapter • Internet Explorer version 6.0, Chrome 2.0. Safari 3.0, or Firefox 3.0 and above System Requirements Package Contents Note: Using a power supply with a different voltage than the one included with the DAP-2690 will cause damage and void the warranty for this product. If any of the above items are missing, please contact your reseller. DAP-2690 802.11n Access Point Power Adapter Ethernet Cable PoE Base Unit CD-ROM Console CableMounting Plate DAP-2690 Install Guide3 Hardware Overview LEDs 5 GHz - When lit, the access point is operating at 5GHz. This light will blink when there is wireless traffic. 2.4 GHz - When lit, the access point is operating at 2.4GHz. This light will blink when there is wireless traffic. LAN - Solid light when the Ethernet port is connected to a working port, such as a router or switch. The light will blink when there is traffic through LAN port. POWER - The light will blink during boot up. Once solid, the access point is ready. 4DAP-2690 Install Guide Installing the Hardware 5GHz Antenna Connectors* * 2.4GHz antenna connectors are located on the bottom of the access point. Reset Button Console Port Power Receptor LAN Port (PoE) DAP-2690 Install Guide5 To p ower the access point, you can use one of the following 3 methods: Method 1 - Use i f y ou h ave a P oE s witch. Method 2 - Use if you do not have a PoE switch and do not have a power outlet near the location of the access p oint. Method 3 - Use if you do not have a PoE switch and have a power outlet near the location of the access point. Method 1 1. Connect one end of your Ethernet cable into the LAN (PoE) port on the DAP-2690. 2. Connect the other end into one port on a PoE switch. 6DAP-2690 Install Guide Method 2 1. Connect one end of an Ethernet cable into the Data In port on the PoE base unit and the other end into one port on your switch, router, or computer. 2. Connect one end of an Ethernet cable into the P+Data Out port on the PoE base unit and the other end into the LAN (PoE) port on the DAP-2690 access point. 3. Use the supplied power adapter. Connect the power adapter to the Power In receptor on the PoE adapter. 4. Connect the power cable to the power adapter and then connect the other end into a power outlet. DAP-2690 Install Guide7 Method 3 1. Connect one end of your Ethernet cable into the LAN (PoE) port on the DAP-2690 and then connect the other end to a switch, router, or computer. 2. Use the supplied power adapter. Connect the power adapter to the Power receptor on the DAP-2690 access point. 3. Connect the power cable to the power adapter and then connect the other end into a power outlet. 8DAP-2690 Install Guide Step 1: Insert the provided wall anchors in the wall where the mounting plate will be attached. Mounting Plate Assembly Step 2: Use the provided screws to secure the mounting plate on the wall. DAP-2690 Install Guide9 Step 3: Attach the remaining screws securely to the back of the DAP-2690. Step 4: A ttach t he D AP-2690 t o t he m ounting p late. 10DAP-2690 Install Guide Step 5: Slide the DAP-2690 down into the grooves on the mounting plate to secure it to the plate. DAP-2690 Install Guide11 When you have completed the steps in this Installation Guide and configured your for your network, your network should look similar to this: Your Setup is Complete * Maximum Wireless signal rate derived from IEEE 802.11n (draft 2.0) specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead lower actual data throughput rate. To s etup and manage the DAP-2690 from a computer, use one of the following methods: 1. Connect a s traight t hrough E thernet c able b etween t he a ccess p oint a nd y our c omputer. 2 . Connect t he a ccess p oint t o a s witch o r r outer a nd u se a c omputer f rom a c omputer t hat i s a lso c onnected t o t hat s witch o r r outer. 12DAP-2690 Install Guide Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digi- tal device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro- vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televi- sion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dif ferent from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user ’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. For operation within 5.15 ~ 5.25GHz it is restricted to indoor environment. This device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules.…

Text truncated - open the document above for the full version.

Report No.: 120530E05 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 120530E05 Page 2 Report No.: 120530E05 Page 3 Report No.: 120530E05 Page 4 Report No.: 120530E05 Page 5 Report No.: 120530E05 Page 9 POE : EBU-101G-T2 LF Report No.: 120530E05 Page 10 POE : PE03G Report No.: 120530E05 Page 11 Report No.: 120530E05 Page 12

LABEL DRAWING The label will be permanently affixed at a conspicuous location on the device.

Label Location Label here

Report No.: 120530E05 Page 6 Report No.: 120530E05 Page 7 Report No.: 120530E05 Page 8

Report No.: SA120530E05 1 of 9 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 RF EXPOSURE REPORT REPORT NO.: SA120530E05 MODEL NO.: DAP-2690 FCC ID: KA2AP2690B1 RECEIVED: May 30, 2012 TESTED: June 13, 2012 ISSUED: Sep. 11, 2012 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA120530E05 2 of 9 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 TABLE OF CONTENTS RELEASE CONTROL RECORD .................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 7 Report No.: SA120530E05 3 of 9 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA120530E05 Original release Sep. 11, 2012 Report No.: SA120530E05 4 of 9 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 1. CERTIFICATION PRODUCT: DAP-2690 AirPremier N Dual Band Concurrent PoE Access Point BRAND NAME: D-Link MODEL NO.: DAP-2690 TEST SAMPLE: MASS-PRODUCTION APPLICANT: D-Link Corporation TESTED DATE: June 13, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: DAP-2690) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 11, 2012 ( Midoli Peng, Specialist ) APPROVED BY : , DATE: Sep. 11, 2012 ( May Chen, Deputy Manager ) Report No.: SA120530E05 5 of 9 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA120530E05 6 of 9 Report Format Version 5.0.0 Cancels and replaces the report No.: SA120522E09 dated Apr. 10, 2012 5. ANTENNA GAIN 1. The antennas provided to the EUT, please refer to the following table: For 2.4GHz Transmitter Circuit Manufacture Model name Antenna Gain Antenna Type Connector Gain (dBi) Chain (0) WHA YU GROUP NP-9022 4.29 Dipole SMA Plug Reverse Chain (1) WHA YU GROUP NP-9022 4.29 Dipole SMA Plug Reverse For 5GHz Transmitter Circuit Manufacture Model name Antenna Gain Antenna Type Connector Gain (dBi) Chain (0) WHA YU GROUP SSR-12968 5G Band1: 5.646 5G Band2: 6.270 5G Band3: 5.428 5G Band4: 5.264 Dipole SMA Plug Reverse Chain (1) WHA YU GROUP SSR-12968 5G Band1: 5.646 5G Band2: 6.270 5G Band3: 5.428 5G Band4: 5.264 Dipole SMA Plug Reverse 2. The EUT incorporates a MIMO function. MODULATION MODE Tx/Rx FUNCTION 802.11b 2Tx/2Rx 802.11g 2Tx/2Rx 802.11a 2Tx/2Rx 802.11n (20MHz) 2Tx/2Rx 802.11n (40MHz) 2Tx/2Rx Report No.: SA120530E05 7 of 9 Repo…
