KA2CS2332LA1HD Wirless N Outdoor Network Camera

User Manual HD Wireless Outdoor Cloud Camera Version 1.0 | 10/23/2012 DCS-2332L 2D-Link DCS-2332L User Manual D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change. Please refer to the www.mydlink.com website for the most current information. Manual Revisions RevisionDateDescription 1.0October 23, 2012DCS-2332L Revision A1 with firmware version 1.00 Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. Copyright © 2012 D-Link Corporation. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation. Preface 3D-Link DCS-2332L User Manual Table of Contents Product Overview ......................................................................... 4 Package Contents ................................................................. 4 Introduction ............................................................................ 5 System Requirements ......................................................... 5 Features .................................................................................... 6 Hardware Overview ............................................................. 7 Front ...................................................................................... 7 Rear: External ...................................................................... 8 Rear: Internal ...................................................................... 9 Removing the Top Panel ..................................................10 Replacing the Ethernet Cable ....................................11 Reattaching the Top Panel ...........................................12 Removing the Bottom Panel ..........................................13 Using the Reset Button .................................................13 Installing an SD Memory Card ...................................14 Reattaching the Bottom Panel ...................................14 Installation ....................................................................................16 Zero Configuration Setup ................................................16 Camera Installation Wizard .............................................19 Windows Users ....................................................................19 Mac Users...............................................................................20 Manual Hardware Installation ........................................21 SD Memory Card Installation .........................................22 mydlink ...........................................................................................23 Configuration ...............................................................................24 Using the Configuration Interface ................................24 Live Video ..............................................................................25 Setup .......................................................................................27 Setup Wizard ....................................................................27 Network Setup .................................................................33 Wireless Setup ..................................................................36 Dynamic DNS ...................................................................37 Image Setup .....................................................................38 Audio and Video ..............................................................40 Preset ...................................................................................42 Motion Detection ...........................................................44 Time and Date ..................................................................45 Event Setup .......................................................................46 SD Card ...............................................................................55 Advanced ...............................................................................56 ICR and IR ...........................................................................56 HTTPS ..................................................................................57 Access List ..........................................................................58 System ................................................................................59 Maintenance .........................................................................60 Device Management .....................................................60 Firmware Upgrade ..........................................................61 Status ......................................................................................62 Device Info ............................................................................62 Logs .....................................................................................63 Help......................................................................................64 Technical Specifications ...........................................................65 4D-Link DCS-2332L User Manual Section 1: Product Overview Product Overview Package Contents If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage than the one included with your product will cause damage and void the warranty for this product. DCS-2332L HD Wireless Outdoor Cloud Camera CAT5 Ethernet cable (Pre-Attached) Power adapter (Pre-Attached) CD-ROM with User Manual and software Quick Installation Guide Antenna 5D-Link DC…

Text truncated - open the document above for the full version.

Report No: T121101J01 Page 1 / 6 Rev.00 EXTERNAL PHOTOGRAPHS OF EUT Report No: T121101J01 Page 2 Rev.00 Report No: T121101J01 Page 3 Rev.00

Report No: T121101J01 Page 4 Rev.00 INTERNAL PHOTOGRAPHS OF EUT Report No: T121101J01 Page 5 Rev.00 Report No: T121101J01 Page 6 Rev.00 RF Module

Compliance Certification Services Inc. Report No.: T121101J01-RP1 FCC ID: KA2CS2332LA1 Date of Issue: November 13, 2012 Page 93 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 8. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT HD Wirless N Outdoor Network Camera Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5.825GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power (AVG.) IEEE 802.11b mode: 13.18 dBm (0.0208 W) IEEE 802.11g mode: 12.02 dBm (0.0159 W) IEEE 802.11n HT20 mode: 12.32 dBm (0.0171 W) IEEE 802.11n HT40 mode: 11.28 dBm (0.0134 W) Antenna gain (Max) 3.39dBi (including cable loss) (Numeric gain: 2.1827) Evaluation applied MPE Evaluation SAR Evaluation N/A Remark: 1. The maximum output power is 13.18dBm (0.0208W) at 2437MHz (with 2.1827numeric antenna gain.) 2. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger. TEST RESULTS No non-compliance noted. Compliance Certification Services Inc. Report No.: T121101J01-RP1 FCC ID: KA2CS2332LA1 Date of Issue: November 13, 2012 Page 94 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Calculation Given d GP E ×× = 30 & 3770 2 E S= Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S ×× = Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 2 2 0796.0 100/3770 1000/30 d GP d GP S × ×= × ×× = Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Maximum Permissible Exposure EUT output power = 20.8mW Numeric Antenna gain = 2.1827 Substituting the MPE safe distance using d = 20 cm into Equation 1: Yields GPS××=000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Æ Power density = 0.00903 mW / cm 2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)

Compliance Certification Services Inc. Report No.: T121101J01-RP1 FCC ID: KA2CS2332LA1 Date of Issue: November 13, 2012 Page 95 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 9. APPENDIX II PHOTOGRAPHS OF TEST SETUP Radiated Emissions Setup Photos Below 1GHz Data Link Compliance Certification Services Inc. Report No.: T121101J01-RP1 FCC ID: KA2CS2332LA1 Date of Issue: November 13, 2012 Page 96 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Above 1GHz Transmitting Mode Compliance Certification Services Inc. Report No.: T121101J01-RP1 FCC ID: KA2CS2332LA1 Date of Issue: November 13, 2012 Page 97 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Conducted Emission Setup Photos Compliance Certification Services Inc. Report No.: T121101J01-RP1 FCC ID: KA2CS2332LA1 Date of Issue: November 13, 2012 Page 98 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Powerline Conducted Emissions Setup Photos Data Link
