KA2CS8350LHA12K QHD indoor Wi-Fi Camera

What's in the Box Quick Installation Guide 2K QHD Indoor Wi-Fi Camera DCS-8350LH MicroUSB Power Adapter 2K QHD Indoor Wi-Fi Camera (DCS-8350LH) Mounting HardwareQuick Installation Guide This is a backup of your device’s Setup Code. Please keep it as future reference for your device. Setup Code Connected to network and mydlink Booting up Ready for setup Firmware being updated - do not power off Timeout for setup - please power cycle the device Wi-Fi connection lost LED BehaviorSimple Setup Get the mydlink app on the App Store or on Google Play. Launch the app, then Sign In or Create a New Account. 1 2 Power on the device and wait for the Status LED to flash orange. Note: Make sure that your mobile device’s Bluetooth is on. 3 Place your device next to your mobile device. A prompt will appear - tap Add Device, then follow the app instructions. mydlink Note: Please set up your device before mounting it. Status LED FAQ What do I do if my device is not working properly? Reset and reinstall your device. Use a paper clip to press the recessed Reset button and the LED will turn solid red. During installation, ensure that: • Your router is connected to the Internet and Wi-Fi is enabled • Your mobile device is connected to your router’s Wi-Fi and Bluetooth is enabled • Your mydlink device is in range of your Wi-Fi network How can I use voice commands to control my device? The device will work with both Amazon Alexa and the Google Assistant. For setup instructions on these services, visit the following websites: Amazon AlexaThe Google Assistant: dlink.com/en/alexadlink.com/en/google-assistant Why is my microSD card not working/not supported? The microSD card must be formatted into the correct file system (FAT32) before it can be used with this product. This can be done in the mydlink app by selecting the Format function in the storage menu under the device settings. What is my username and password for setting up my device with an ONVIF system? To connect your device to an ONVIF system, key in “admin” a s the username and use the PIN code of your mydlink device as the password. You can find the PIN code on your device’s label. What is Color Night Vision and how does it work? Color Night Vision is enabled by default and allows you to see color images while viewing the live feed in low light scenarios. 2021/07/14 Ver 1.01(DI)_90x130 To get the most out of your camera’s view and features, please take the following placement guidelines into consideration. Height: Place the camera 1.5 - 2 meters (4 to 6.5 feet) from the ground. Person Detection: Person Detection works best when the subject is between 2 to 5 meters (6.5 - 16 feet) away from the camera. Pole Mounting Note: Cable ties are not included with this product. Align the mounting bracket so that the arrow is pointing up. Use a pencil to make marks in the two holes. Use a 6 mm drill bit to drill two 26 mm deep holes over the pencil marks. Hammer in the plastic anchors to support the screws. Align the mounting bracket’s holes over the plastic anchors. Drive the screws into the anchors to secure the mounting bracket. Adjust your camera via its tilt and rotation options until you’re satisfied with the view point. Mounting Align the arrow on the camera base with the dot on the mounting bracket and turn clockwise to secure them together. The device can be mounted on a wall or on the ceiling. 1.5 - 2 m (4 - 6.5 ft) Ideal Viewing Distance: 2 - 5 m (6.5 - 16 ft) 2 m (6.5 ft) Need Help? Having trouble installing your new product? D-Link’s website contains the latest user documentation and software updates for D-Link products. Customers can contact D-Link Technical Support through our website by choosing the relevant region. Contact Us www.dlink.com/en/contact-us Place the mounting bracket against the pole where you would like to mount the camera, and make sure the arrow is pointing upwards. Thread the cable ties through the slots on the mounting bracket. Make sure the textured side of the cable ties is facing the pole to avoid slippage. Then fasten the plastic ties around the pole to secure the mounting bracket. Align the arrow on the camera base with the dot on the mounting bracket and turn clockwise to secure them together. Wall Mounting FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IC Warning This device complie…

Text truncated - open the document above for the full version.

FCC Software Configuration Control Declaration Rev1.1.docx D-Link Corporation FCC Software Configuration Control Declaration Date: 2021-07-20 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn:D-Link Corporation Product Name: 2K QHD indoor Wi-Fi Camera Model Number(s): DCS-8350LH FCC ID: KA2CS8350LHA1 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Jiankuai Li Date: 2021-07-20 Title: Manager Signatureof applicant

D-Link Corporation Agent Authorization Company: D-Link Corporation Address: 14420 Myford Road Suite 100 Irvine California United States 92606 Product Name: 2K QHD Indoor Wi-Fi Camera Model Number(s): DCS-8350LH Product Description: 2K QHD Indoor Wi-Fi Camera We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021/7/20 Name: Jiankuai Li Title: Manager Company: Shenzhen STS Test Services Co., Ltd.

2021-07-31 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub- District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for CE RED Certification, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until December 31, 2021 Sincerely, Signature: Name:Brett Adair Title:General Counsel E-mail:[email protected] Company: D-Link Corporation

D-Link Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021/07/20 Subject; Request for Confidentiality FCC ID: KA2CS8350LHA1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li D-Link Corporation Title: Manager

Page 1 of 5 Report No.: STS2106200 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: DCS-8350LH Photo 1 Photo 2 Photo 3 Page 2 of 5 Report No.: STS2106200 Photo 4 Page 3 of 5 Report No.: STS2106200 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2106200 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2106200 Photo 9

Label

Page 1 of 4 Report No.: STS2106200 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model:DCS-8350LH Photo 1 Photo 2 Photo 3 BT/WIFI Antenna Page 2 of 4 Report No.: STS2106200 Photo 4 Page 3 of 4 Report No.: STS2106200 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2106200 Photo 7

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2106200H02 Issued for D-Link Corporation 14420 Myford Road Suite 100 Irvine California United States 92606 Product Name: 2K QHD Indoor Wi-Fi Camera Brand Name: D-Link Model Name: DCS-8350LH Series Model: N/A FCC ID: KA2CS8350LHA1 Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 8 Report No.: STS2106200H02 Test Report Certification Applicant’s Name ................. : D-Link Corporation Address ................................. : 14420 Myford Road Suite 100 Irvine California United States 92606 Manufacturer's Name .......... : Shenzhen Aoni Electronic Co.,Ltd Address ................................. : Building 5, Honghui Industrial Park, 2nd Road Liuxian, Baoan District, Shenzhen, P.R. China, 518101 Product Description Product Name ........................ : 2K QHD Indoor Wi-Fi Camera Brand Name ......................... : D-Link Model Name .......................... : ... : DCS-8350LH Series Model .......................... : N/A Standards ............................. : FCC 47CFR §2.1091 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 28 June 2021 Date (s) of performance of tests ............. : 28 June 2021 ~ 16 July 2021 Date of Issue ........................................... : 16 July 2021 Test Result ............................................... : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 8 Report No.: STS2106200H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Page 4 of 8 Report No.: STS2106200H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 16 July 2021 STS2106200H02 ALL Initial Issue Page 5 of 8 Report No.: STS2106200H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name 2K QHD Indoor Wi-Fi Camera Brand Name D-Link Model Name DCS-8350LH Series Model N/A Model Difference N/A Product Description The EUT is 2K QHD Indoor Wi-Fi Camera Operation Frequency: BLE: 2402~2480 MHz 2.4G WIFI: 802.11b/g/n 20: 2412~2462 MHz 802.11n(40MHz):2422~2452MHz 5G WIFI: 802.11a/n (20MHz)/ac(VHT20): 5180~5240MHz 802.11n(40MHz)/ac(VHT40):5190~5230MHz 802.11ac(VHT80): 5210MHz 802.11a/n (20MHz) /ac(VHT20): 5260~5320MHz 802.11n(40MHz)/ac(VHT40):5270~5310MHz 802.11ac(VHT80): 5290MHz 802.11a/n (20MHz)/ac(VHT20): 5500~5700MHz 802.11n(40MHz)/ac(VHT20):5510~5670MHz 802.11ac(VHT80): 5530~5610MHz 802.11a/ n(HT20)/ac(VHT20):5745~5825MHz 802.11n(HT40)/ac(VHT40): 5755~5795MHz IEEE 802.11ac(VHT80): 5775MHz Modulation Type: BLE: GFSK 2.4G WIFI: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WIFI: 802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM Antenna gain: 2 dBi, Antenna Designation: FPC Antenna Adapter Model: KA06E-0501200US Input: 100-240V 50/60Hz Output:5.0V 1.2A 6.0W Hardware Version A1 Software Version V1.0 Page 6 of 8 Report No.: STS2106200H02 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 8 Report No.: STS2106200H02 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channe…

Text truncated - open the document above for the full version.

Page 1 of 12 Report No.: STS2106200W08 Power Spectrum Density WLAN_U-NII-1 WLAN_U-NII-1 W52_11a20_Lower_Power Spectrum Density W52_11a20_Middle_Power Spectrum Density W52_11a20_Higher_Power Spectrum Density W52_11n20_Lower_Power Spectrum Density W52_11n20_Middle_Power Spectrum Density W52_11n20_Higher_Power Spectrum Density Page 2 of 12 Report No.: STS2106200W08 WLAN_U-NII-1 WLAN_U-NII-1 W52_11n40_Lower_Power Spectrum Density W52_11n40_Higher_Power Spectrum Density W52_11ac20_Lower_Power Spectrum Density W52_11ac20_Middle_Power Spectrum Density W52_11ac20_Higher_Power Spectrum Density W52_11ac40_Lower_Power Spectrum Density Page 3 of 12 Report No.: STS2106200W08 WLAN_U-NII-1 WLAN_U-NII-1 W52_11ac40_Higher_Power Spectrum Density W52_11ac80_CH42(5210MHz)_Power Spectrum Density Page 4 of 12 Report No.: STS2106200W08 WLAN_U-NII-2A WLAN_U-NII-2A W53_11a20_Lower_Power Spectrum Density W53_11a20_Middle_Power Spectrum Density W53_11a20_Higher_Power Spectrum Density W53_11n20_Lower_Power Spectrum Density W53_11n20_Middle_Power Spectrum Density W53_11n20_Higher_Power Spectrum Density Page 5 of 12 Report No.: STS2106200W08 WLAN_U-NII-2A WLAN_U-NII-2A W53_11n40_Lower_Power Spectrum Density W53_11n40_Higher_Power Spectrum Density W53_11ac20_Lower_Power Spectrum Density W53_11ac20_Middle_Power Spectrum Density W53_11ac20_Higher_Power Spectrum Density W53_11ac40_Lower_Power Spectrum Density Page 6 of 12 Report No.: STS2106200W08 WLAN_U-NII-2A WLAN_U-NII-2A W53_11ac40_Higher_Power Spectrum Density W53_11ac80_CH58(5290MHz)_Power Spectrum Density Page 7 of 12 Report No.: STS2106200W08 WLAN_U-NII-2C WLAN_U-NII-2C W56_11a20_Lower_Power Spectrum Density W56_11a20_Middle_Power Spectrum Density W56_11a20_Higher_Power Spectrum Density W56_11n20_Lower_Power Spectrum Density W56_11n20_Middle_Power Spectrum Density W56_11n20_Higher_Power Spectrum Density Page 8 of 12 Report No.: STS2106200W08 WLAN_U-NII-2C WLAN_U-NII-2C W56_11n40_Lower_Power Spectrum Density W56_11n40_Middle_Power Spectrum Density W56_11n40_Higher_Power Spectrum Density W56_11ac20_Lower_Power Spectrum Density W56_11ac20_Middle_Power Spectrum Density W56_11ac20_Higher_Power Spectrum Density Page 9 of 12 Report No.: STS2106200W08 WLAN_U-NII-2C WLAN_U-NII-2C W56_11ac40_Lower_Power Spectrum Density W56_11ac40_Middle_Power Spectrum Density W56_11ac40_Higher_Power Spectrum Density W56_11ac80_Lower_Power Spectrum Density W56_11ac80_Higher_Power Spectrum Density Page 10 of 12 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11a20_Lower_Power Spectrum Density W58_11a20_Middle_Power Spectrum Density W58_11a20_Higher_Power Spectrum Density W58_11n20_Lower_Power Spectrum Density W58_11n20_Middle_Power Spectrum Density W58_11n20_Higher_Power Spectrum Density Page 11 of 12 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11n40_Lower_Power Spectrum Density W58_11n40_Higher_Power Spectrum Density W58_11ac20_Lower_Power Spectrum Density W58_11ac20_Middle_Power Spectrum Density W58_11ac20_Higher_Power Spectrum Density W58_11ac40_Lower_Power Spectrum Density Page 12 of 12 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11ac40_Higher_Power Spectrum Density W58_11ac80_Power Density_5775M

Page 1 of 12 Report No.: STS2106200W08 26BW and 99% WLAN_U-NII-1 WLAN_U-NII-1 W52_11a20_Lower_26BW and 99% W52_11a20_Middle_26BW and 99% W52_11a20_Higher_26BW and 99% W52_11n20_Lower_26BW and 99% W52_11n20_Middle_26BW and 99% W52_11n20_Higher_26BW and 99% Page 2 of 12 Report No.: STS2106200W08 WLAN_U-NII-1 WLAN_U-NII-1 W52_11n40_Lower_26BW and 99% W52_11n40_Higher_26BW and 99% W52_11ac20_Lower_26BW and 99% W52_11ac20_Middle_26BW and 99% W52_11ac20_Higher_26BW and 99% W52_11ac40_Lower_26BW and 99% Page 3 of 12 Report No.: STS2106200W08 WLAN_U-NII-1 WLAN_U-NII-1 W52_11ac40_Higher_26BW and 99% W52_11ac80_CH42(5210MHz)_26BW and 99% Page 4 of 12 Report No.: STS2106200W08 WLAN_U-NII-2A WLAN_U-NII-2A W53_11a20_Lower_26BW and 99% W53_11a20_Middle_26BW and 99% W53_11a20_Higher_26BW and 99% W53_11n20_Lower_26BW and 99% W53_11n20_Middle_26BW and 99% W53_11n20_Higher_26BW and 99% Page 5 of 12 Report No.: STS2106200W08 WLAN_U-NII-2A WLAN_U-NII-2A W53_11n40_Lower_26BW and 99% W53_11n40_Higher_26BW and 99% W53_11ac20_Lower_26BW and 99% W53_11ac20_Middle_26BW and 99% W53_11ac20_Higher_26BW and 99% W53_11ac40_Lower_26BW and 99% Page 6 of 12 Report No.: STS2106200W08 WLAN_U-NII-2A WLAN_U-NII-2A W53_11ac40_Higher_26BW and 99% W53_11ac80_CH58(5290MHz)_26BW and 99% Page 7 of 12 Report No.: STS2106200W08 WLAN_U-NII-2C WLAN_U-NII-2C W56_11a20_Lower_26BW and 99% W56_11a20_Middle_26BW and 99% W56_11a20_Higher_26BW and 99% W56_11n20_Lower_26BW and 99% W56_11n20_Middle_26BW and 99% W56_11n20_Higher_26BW and 99% Page 8 of 12 Report No.: STS2106200W08 WLAN_U-NII-2C WLAN_U-NII-2C W56_11n40_Lower_26BW and 99% W56_11n40_Middle_26BW and 99% W56_11n40_Higher_26BW and 99% W56_11ac20_Lower_26BW and 99% W56_11ac20_Middle_26BW and 99% W56_11ac20_Higher_26BW and 99% Page 9 of 12 Report No.: STS2106200W08 WLAN_U-NII-2C WLAN_U-NII-2C W56_11ac40_Lower_26BW and 99% W56_11ac40_Middle_26BW and 99% W56_11ac40_Higher_26BW and 99% W56_11ac80_Lower_26BW and 99% W56_11ac80_Higher_26BW and 99% Page 10 of 12 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11a20_Lower_26BW and 99% W58_11a20_Middle_26BW and 99% W58_11a20_Higher_26BW and 99% W58_11n20_Lower_26BW and 99% W58_11n20_Middle_26BW and 99% W58_11n20_Higher_26BW and 99% Page 11 of 12 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11n40_Lower_26BW and 99% W58_11n40_Higher_26BW and 99% W58_11ac20_Lower_26BW and 99% W58_11ac20_Middle_26BW and 99% W58_11ac20_Higher_26BW and 99% W58_11ac40_Lower_26BW and 99% Page 12 of 12 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11ac40_Higher_26BW and 99% W58_11ac80_26BW_99%_Bandwidth_5775M

Page 1 of 3 Report No.: STS2106200W08 6BW WLAN_U-NII-3 WLAN_U-NII-3 W58_11a20_Lower_6BW W58_11a20_Middle_6BW W58_11a20_Higher_6BW W58_11n20_Lower_6BW W58_11n20_Middle_6BW W58_11n20_Higher_6BW Page 2 of 3 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11n40_Lower_6BW W58_11n40_Higher_6BW W58_11ac20_Lower_6BW W58_11ac20_Middle_6BW W58_11ac20_Higher_6BW W58_11ac40_Lower_6BW Page 3 of 3 Report No.: STS2106200W08 WLAN_U-NII-3 WLAN_U-NII-3 W58_11ac40_Higher_6BW W58_11ac80_-6_Bandwidth_5775M

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO DFS TEST REPORT Report No.: STS2106200W09 Issued for D-Link Corporation 14420 Myford Road Suite 100 Irvine California United States 92606 Product Name: 2K QHD Indoor Wi-Fi Camera Brand Name: D-Link Model Name: DCS-8350LH Series Model: N/A FCC ID: KA2CS8350LHA1 Test Standard: FCC Part 15.407 S T L A B S Page 2 of 26 Report No.: STS2106200W09 TEST REPORT CERTIFICATION Applicant’s Name ................. : D-Link Corporation Address .................................. : 14420 Myford Road Suite 100 Irvine California United States 92606 Manufacturer's Name ........... : Shenzhen Aoni Electronic Co.,Ltd Address .................................. : Building 5, Honghui Industrial Park, 2nd Road Liuxian, Baoan District, Shenzhen, P.R. China, 518101 Product Description Product Name ........................ : 2K QHD Indoor Wi-Fi Camera Brand Name ......................... : D-Link Model Name ........................... : DCS-8350LH Series Model .......................... : N/A Test Standards ..................... : FCC Part15.407 Test Procedure 905462 D02 UNII DFS Compliance Procedures New Rules v02 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 28 June 2021 Date (s) of performance of tests ............. : 28 June 2021 ~ 16 July 2021 Date of Issue .......................................... : 16 July 2021 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 26 Report No.: STS2106200W09 Table of Contents 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACTORY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF THE EUT 6 2.2 TEST CONDITIONS AND CHANNEL 8 2.3 DFS MEASUREMENT INSTRUMENTATION 10 2.4 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3. DFS PARAMETERS 12 3.1 DFS PARAMETERS 12 3.2 DFS –TEST RESULTS 16 Page 4 of 26 Report No.: STS2106200W09 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 16 July 2021 STS2106200W09 ALL Initial Issue Page 5 of 26 Report No.: STS2106200W09 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 and 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 Part 15.407 Requirement Operational Mode RESULTS Master Client Non-Occupancy Period Yes Yes Pass DFS Detection Threshold Yes Not required Not required Channel Availability Check Time Yes Not required Not required Channel Closing Transmission Time Yes Yes Pass Channel Move Time Yes Yes Pass U-NII Detection Bandwidth Yes Not required Not required 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 DFS Threshold (radiated) ±1.50dB 2 DFS Threshold (conducted) ±1.45dB 7 Temperature ±0.5°C 8 Humidity ±2% Page 6 of 26 Report No.: STS2106200W09 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name 2K QHD Indoor Wi-Fi Camera Brand Name D-Link Model Name DCS-8350LH Series Model N/A Model Difference N/A Product Description The EUT is 2K QHD Indoor Wi-Fi Camera Operation Frequency: 802.11a/n/ac(20):5260 MHz -5320 MHz 802.11a/n/ac(40):5270 MHz -5310 MHz 802.11ac(80) 5290MHz 802.11a/n/ac(20):5500 MHz -5700 MHz 802.11a/n/ac(40):5510 MHz -5670 MHz 802.11ac(80): 5530MHz -5610 MHz Modulation Type: 802.11a(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM Number Of Channel Please see Note 2. Antenna Gain(Peak) 2dBi Based on the application, features, or specification exhibited in User’s Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User’s Manual. Channel List Refer to below Sub-class H01 Adapter Model: KA06E-0501200US Input: 100-240V 50/60Hz Output:5.0V 1.2A 6.0W Hardware version number A1 Software version number V1.0 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual, the antenna information refer the manufacturer provide report, applicable only to the tested sample identified in the report. Page 7 of 26 Report No.: STS2106200W09 2 Channel List for 802.11a/n/ac (20MHz) Channel Frequency (MHz) Channel Frequency (MHz) Cha nnel Frequency (MHz) Channel Frequency (MHz) 52 5260 56 5280 60 5300 64 5320 Channel List for 802.11n/ac (40 MHz) Channel Frequency (MHz) Channel Frequency (MHz) Chan nel Frequency (MHz) Channel Frequency (MHz) 54 5270 62…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2106200W08 Issued for D-Link Corporation 14420 Myford Road Suite 100 Irvine California United States 92606 Product Name: 2K QHD Indoor Wi-Fi Camera Brand Name: D-Link Model Name: DCS-8350LH Series Model: N/A FCC ID: KA2CS8350LHA1 Test Standard: FCC Part 15.407 …
