KA2CS8620LHA12K QHD Outdoor Wi-Fi Camera

Quick Start Guide 2K QHD Outdoor Wi-Fi Camera DCS-8620LH https://eu.dlink.com/DCS-8620LH https://eu.dlink.com/support 1 mydlink 2 3 DCS-8620LH Ver 1.00(EU)_90x130 2021/06/01 2 - 2.5m (6.5 - 8ft.) Ideal Viewing Distance: 2 - 7 m (6.5 - 23ft.) 2m (6.5ft.) 1 2 1 2 3 3 4 RESET  RESET  RESET  RESET  RESET  RESET  RESET  RESET  FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IC Warning This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioé lectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCC Software Configuration Control Declaration Rev1.1.docx D-Link Corporation FCC Software Configuration Control Declaration Date: 2021-07-20 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn:D-Link Corporation Product Name: 2K QHD Outdoor Wi-Fi Camera Model Number(s): DCS-8620LH FCC ID: KA2CS8620LHA1 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Jiankuai Li Date: 2021-07-20 Title: Manager Signatureof applicant

D-Link Corporation Agent Authorization Company: D-Link Corporation Address: 14420 Myford Road Suite 100 Irvine California United States 92606 Product Name: 2K QHD Outdoor Wi-Fi Camera Model Number(s): DCS-8620LH Product Description: 2K QHD Outdoor Wi-Fi Camera We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021/7/20 Name: Jiankuai Li Title: Manager Company: Shenzhen STS Test Services Co., Ltd.

2021-07-31 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO.,LTD./ A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub- District,Bao’an District, Shenzhen, Guang Dong, China/Jiankuai Li(Name of Agent company name and address, Name of Agent) to act on our behalf in all matters relating to application for CE RED Certification, including the signing of all documents relating to these matters. Name: Jiankuai Li Title: PM E-mail:[email protected] This appointment is valid until further until December 31, 2021 Sincerely, Signature: Name:Brett Adair Title:General Counsel E-mail:[email protected] Company: D-Link Corporation

D-Link Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021/07/20 Subject; Request for Confidentiality FCC ID: KA2CS8620LHA1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiankuai Li Title: Manager

Page 1 of 6 Report No.: STS2106125 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model:DCS-8620LH Photo 1 Photo 2 Photo 3 Page 2 of 6 Report No.: STS2106125 Photo 4 Page 3 of 6 Report No.: STS2106125 Photo 5 Photo 6 Page 4 of 6 Report No.: STS2106125 Photo 7 Photo 8 Page 5 of 6 Report No.: STS2106125 Photo 9 Photo 10 Page 6 of 6 Report No.: STS2106125 Photo 11

Label

Page 1 of 5 Report No.: STS2106125 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: DCS-8620LH Photo 1 Photo 2 Photo 3 BT/WIFI Antenna Page 2 of 5 Report No.: STS2106125 Photo 4 Page 3 of 5 Report No.: STS2106125 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2106125 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2106125 Photo 9

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2106125H02 Issued for D-Link Corporation 14420 Myford Road Suite 100 Irvine California United States 92606 Product Name: 2K QHD Outdoor Wi-Fi Camera Brand Name: D-Link Model Name: DCS-8620LH Series Model: N/A FCC ID: KA2-CS8620LHA1 Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 8 Report No.: STS2106125H02 Test Report Certification Applicant’s Name ................. : D-Link Corporation Address ................................. : 14420 Myford Road Suite 100 Irvine California United States 92606 Manufacturer's Name .......... : Shenzhen Aoni Electronic Co.,Ltd Address ................................. : Building 5, Honghui Industrial Park, 2nd Road Liuxian, Baoan District, Shenzhen, P.R. China, 518101 Product Description Product Name ........................ : 2K QHD Outdoor Wi-Fi Camera Brand Name ......................... : D-Link Model Name .......................... : ... : DCS-8620LH Series Model .......................... : N/A Standards ............................. : FCC 47CFR §2.1091 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 18 June 2021 Date (s) of performance of tests ............. : 18 June 2021 ~ 12 July 2021 Date of Issue .......................................... : 12 July 2021 Test Result.............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 8 Report No.: STS2106125H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Page 4 of 8 Report No.: STS2106125H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 12 July 2021 STS2106125H02 ALL Initial Issue Page 5 of 8 Report No.: STS2106125H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name 2K QHD Outdoor Wi-Fi Camera Brand Name D-Link Model Name DCS-8620LH Series Model N/A Model Difference N/A Product Description The EUT is Wi-Fi Camera Operation Frequency: BLE: 2402~2480 MHz 2.4G WIFI: 802.11b/g/n 20: 2412~2462 MHz 802.11n(40MHz):2422~2452MHz 5G WIFI: 802.11a/n (20MHz): 5180~5240MHz 802.11n(40MHz):5190~5230MHz 802.11ac(VHT80): 5210MHz 802.11a/n (20MHz): 5260~5320MHz 802.11n(40MHz):5270~5310MHz 802.11ac(VHT80): 5290MHz 802.11a/n (20MHz): 5500~5700MHz 802.11n(40MHz):5510~5670MHz 802.11ac(VHT80): 5530~5610MHz Modulation Type: BLE: GFSK 2.4G WIFI: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WIFI: 802.11a(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM Antenna gain: BLE: 2dBi 2.4G/5G WIFI: ANT A: 2 dBi,ANT B: 2 dBi, MIMO A+B: 5.01 dBi, Antenna Designation: FPC Antenna Adapter Input: 100-240V 50/60Hz Output:12.0V 1.0A 12.0W Hardware Version A1 Software Version V1.0 Page 6 of 8 Report No.: STS2106125H02 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 8 Report No.: STS2106125H02 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning stat…
