KA2DI-764Multimode 2.4/5GHz Wireless Router

2.4 GHz / 5 GHz Multimode Manual Building Networks for People AirPro DI-764 Wireless Broadband Router D-LINK 2 Contents Package Contents................................................................................ 3 Introduction .......................................................................................... 4 Wireless Basics .................................................................................... 6 Getting Started ................................................................................... 10 Using the Configuration Menu ............................................................ 12 Networking Basics.............................................................................. 41 Troubleshooting .................................................................................. 70 Technical Specifications..................................................................... 76 Contacting Technical Support ............................................................. 79 Warranty and Registration.................................................................. 80 3 Contents of Package: D-Link AirPro DI-764 2.4GHz/5GHz Multimode Wireless Broadband Router Power Adapter ñ 5V DC, 3.0A Manual on CD Quick Installation Guide Ethernet Cable Package Contents Computer with Windows, Macintosh, or Linux-based operating system with an installed Ethernet adapter Note: Using a power supply with a different voltage rating than the one included with the DI-764 will cause damage and void the warranty for this product. If any of the above items are missing, please contact your reseller. System Requirements For Configuration: ! ! ! ! ! ! 4 Introduction D-Link, a leader in wireless technology, introduces the first integrated multimode 2.4GHz/5GHz wireless broadband router, as part of the high performance D-Link AirPro series of wireless networking products. The new D-Link AirPro DI-764 Multimode Wireless Broadband Router is a next generation multimode broadband router that simultaneously serves both 802.11a wireless networks at 54 Mbps (72 Mbps in Turbo mode * ) and 802.11b wireless networks at 11Mbps (22 Mbps with D-Link AirPlus products.) Featuring a breakthrough all-in-one dual band design that delivers future investment protection with the promise of a superior product life cycle and lower total cost of ownership, it is the ideal solution for present and future Wireless Local Area Networks (WLANs). The DI-764 will automatically obtain an IP address and forward additional IP addresses to multiple clients for a seamless Ethernet network connection and shared Internet access. At 54Mbps (up to 72Mbps in Turbo mode * ) in the 5GHz frequency range and a simultaneous 11 Mbps (up to 22 Mbps with D-Link AirPlus products) in the 2.4GHz frequency range, the D-Link AirPro DI-764 multimode broadband router delivers the fastest standards-based wireless technology in the industry. Based on WiFi technology, as well as IEEE 802.11a and 802.11b standards compliant, this next-generation multimode wireless access point provides excellent network interoperability. Armed with powerful management and security capabilities, the D-Link Air Pro DI-764 has an intuitive and secure web-based interface that is powered by an embedded web server. After completing the steps outlined in the Quick Installation Guide (included in your package) not only will you have the ability to share information and resources, but you will also be able to enjoy the freedom that wireless networking delivers, at speeds capable of handling a video stream. *When used with other D-Link AirPro products. 5 Because of its web-based interface (accessible from most Internet browser applications), the DI-764 will work with most popular operating systems, including Macintosh, Linux and Windows, and can be easily integrated into a large network. This Manual is designed to help you connect the DI-764 with the D-Link 2.4GHz AirPlus or 5GHz AirPro Wireless Adapters into an existing network. Please take a look at the Getting Started section in this manual to see an example of an Infrastructure network using the DI-764. Connections Features & Benefits Supports data transfer rates of up to 72 Mbps at 5GHz Supports data transfer rates of up to 22 Mbps at 2.4GHz Wireless range of up to 900 feet* Fully 802.11a and 802.11b compatible Supports up to 256-bit WEP Encryption at 2.4GHz, and up to 152-bit, with Enhanced Dynamic Keying at 5 GHz Less interference with a total of eleven non-overlapping channels Utilizes Direct Sequence Spread Spectrum (DSSS) and Packet Binary Convolutional Code (PBCC) at 2.4GHz Utilizes Orthogonal Frequency Division Multiplexing (OFDM) at 5GHz ! ! ! ! ! ! ! ! Easy-to-use Web-based configuration User level security 3 Year Warranty (USA only) ! ! ! Pressing the Reset Button restores the router to its original factory default settings. Receptor for the Power Adapter The WAN port is the connection for the Ethernet cable to the Cable or DSL modem LAN ports automatically sense cable type when connecting to Ethernet- enabled computers. *Environmental Factors may Adversely Affect Range. 6 LEDS LED stands for Light-Emitting Diode. The DI-764 has the following LEDs: D-Link AirPro wireless products are based on industry standards to provide easy-to- use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link AirPro wireless family of products will allow you to securely access the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking delivers. A wireless local area network (WLAN) is a cellular computer network that transmits and receives data with radio signals instead of wires. Wireless LANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people …

Text truncated - open the document above for the full version.

41 Using the Network Setup Wizard in Windows XP In this section you will learn how to establish a network at home or work, using Microsoft Windows XP. Note: Please refer to websites such as http://www.homenethelp.com and http://www.microsoft.com/windows2000 for information about networking computers using Windows 2000, ME or 98. Go to Start>Control Panel>Network Connections Select Set up a home or small office network Networking Basics When this screen appears, Click Next. 42 Please follow all the instructions in this window: Networking Basics Click Next In the following window, select the best description of your computer. If your computer connects to the internet through a gateway/router, select the second option as shown. Click Next 43 Enter a Computer description and a Computer name (optional.) Networking Basics Click Next Enter a Workgroup name. All computers on your network should have the same Workgroup name. Click Next 44 Please wait while the Network Setup Wizard applies the changes. Networking Basics When the changes are complete, click Next. Please wait while the Network Setup Wizard configures the computer. This may take a few minutes. 45 Networking Basics In the window below, select the option that fits your needs. In this example, Create a Network Setup Disk has been selected. You will run this disk on each of the computers on your network. Click Next. Insert a disk into the Floppy Disk Drive, in this case drive A. 46 Networking Basics Please read the information under Hereís how in the screen below. After you com- plete the Network Setup Wizard you will use the Network Setup Disk to run the Network Setup Wizard once on each of the computers on your network. To continue click Next. 47 Networking Basics Please read the information on this screen, then click Finish to complete the Network Setup Wizard. The new settings will take effect when you restart the computer. Click Yes to restart the computer. You have completed configuring this computer. Next, you will need to run the Network Setup Disk on all the other computers on your network. After run- ning the Network Setup Disk on all your computers, your new wireless net- work will be ready to use. 48 ! Networking Basics Naming your Computer To name your computer, please follow these directions:In Windows XP: Click Start (in the lower left corner of the screen) Right-click on My Computer Select Properties and click ! ! ! ! ! Select the Computer Name Tab in the System Properties window. You may enter a Com- puter Description if you wish; this field is optional. To rename the computer and join a domain, Click Change. 49 Networking Basics Naming your Computer ! In this window, enter the Computer name Select Workgroup and enter the name of the Workgroup All computers on your network must have the same Workgroup name. Click OK ! ! ! Checking the IP Address in Windows XP The wireless adapter-equipped computers in your network must be in the same IP Address range (see Getting Started in this manual for a definition of IP Address Range.) To check on the IP Address of the adapter, please do the following: Right-click on the Local Area Connection icon in the task bar Click on Status ! ! 50 Networking Basics Checking the IP Address in Windows XP This window will appear. Click the Support tab Click Close ! ! Assigning a Static IP Address in Windows XP/2000 Note: Residential Gateways/Broadband Routers will automatically assign IP Ad- dresses to the computers on the network, using DHCP (Dynamic Host Configura- tion Protocol) technology. If you are using a DHCP-capable Gateway/Router you will not need to assign Static IP Addresses. If you are not using a DHCP capable Gateway/Router, or you need to assign a Static IP Address, please follow these instructions: ! ! Go to Start Double-click on Control Panel 51 Networking Basics Assigning a Static IP Address in Windows XP/2000 ! Double-click on Network Connections ! ! Double-click on Properties Right-click on Local Area Connections 52 Networking Basics Assigning a Static IP Address in Windows XP/2000 Input your IP address and subnet mask. (The IP Addresses on your network must be within the same range. For example, if one computer has an IP Address of 192.168.0.2, the other computers should have IP Addresses that are sequential, like 192.168.0.3 and 192.168.0.4. The subnet mask must be the same for all the computers on the network. ! The DNS server address will be supplied by your ISP (Internet Service Provider). If the DNS Server address is not available from your ISP, you may input 192.168.0.1 in this field. Click on Internet Protocol (TCP/IP) Click Properties ! ! ! ! Click OK ! Enter the IP Address of the Default Gateway (in this case it is 192.168.0.1 for the DI-764) Input your DNS server address. 53 Networking Basics Assigning a Static IP Address with Macintosh OSX ! ! ! ! Go to the Apple Menu and se- lect System Preferences cClick on Network Select Built-in Ethernet in the Show pull-down menu Select Manually in the Configure pull-down menu ! Input the Static IP Address, the Subnet Mask and the Router IP Address in the appropriate fields Input the Domain Name Server address. Your ISP (Internet Service Provider) will provide the IP address of the DNS Server. If the DNS Server address is not avail- able from your ISP, you may input 192.168.0.1 in this field. ! ! Click Apply Now 54 Networking Basics Selecting a Dynamic IP Address with Macintosh OSX Go to the Apple Menu and select System Preferences Click on Network Select Built-in Ethernet in the Show pull-down menu Select Using DHCP in the Configure pull-down menu Click Apply Now The IP Address, Subnet mask, and the Routerís IP Address will appear in a few seconds ! ! ! ! ! ! 55 Networking Basics Checking the Wireless Connection by Pinging in Windows XP and 2000 Checking the Wireless Connection by Pinging in Windows Me and 98 Go to Start > Run > type cmd. A window similar to this one will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP …

Text truncated - open the document above for the full version.

61 Networking Basics Adding a local printer Go to Start> Printers and Faxes A successful installation will display the printer icon as shown at right. You have successfully added a local printer. Sharing a network printer After you have run the Network Setup Wizard on all the computers on your net- work, you can run the Add Printer Wizard on all the computers on your network. Please follow these directions to use the Add Printer Wizard to share a printer on your network: Go to Start> Printers and Faxes ! ! 62 Networking Basics Sharing a network printer Click on Add a printer Click Next Select Network Printer Click Next ! ! ! ! 63 Networking Basics Sharing a network printer Select Browse for a printer Click Next Select the printer you would like to share Click Next Click Finish ! ! ! ! 64 Networking Basics Sharing a network printer To check for proper installation: Go to Start > Printers and Faxes The printer icon will appear at right, indicating proper installation. You have completed adding the printer. To share this printer on your network: Remember the printer name Run the Add Printer Wizard on all the computers on your network Make sure you have already run the Network Setup Wizard on all the network computers After you run the Add Printer Wizard on all the computers in the network, you can share the printer. ! ! ! ! ! 65 Networking Basics Sharing an LPR printer To share an LPR printer (using a print server,) you will need a Print Server such as the DP-101P+. Please make sure that you have run the Network Setup Wizard on all the computers on your network. To share an LPR printer, please follow these directions: Go to Start > Printers and Faxes Click on Add a Printer The screen to the right will appear Click Next Select Local Printer... Click Next ! ! ! ! ! 66 Networking Basics Sharing an LPR printer Select Create a new port From the pull-down menu, select Standard TCP/IP Port, as shown. Click Next Please read the instructions on this screen Click Next Enter the Printer IP Address and the Port Name, as shown. Click Next ! ! ! ! ! ! ! 67 Networking Basics Sharing an LPR printer In this screen, select Custom Click Settings Enter the Port Name and the Printer Name or IP Address. Select LPR Enter a Queue Name (if your Print- Server/ Gateway has more than one port, you will need a Queue name.) Click OK ! ! ! ! ! ! 68 Networking Basics Sharing an LPR printer Click Next Select Keep existing driver If the printer driver is already installed, do the following: Click Have Disk Insert the printer driver disk that came with your printer. Select the printer you are adding from the list of Printers. Click Finish This screen will show you information about your printer. ! ! ! ! ! ! ! 69 Networking Basics Sharing an LPR printer Note: You must run the Network Setup Wizard on all the computers on your network before you run the Add Printer Wizard. Please run the Add Printer Wizard on all the computers on your network in order to share the printer. Click Finish to complete the addition of the printer. This screen will display informa- tion about your printer. Click Next Select Yes, to print a test page. Click Next Please remember the name of your printer. You will need this information when you use the Add Printer Wizard on the other computers on your network. You can rename your printer if you choose. It is optional. ! ! ! ! ! ! ! 70 1.The computer used to configure the DI-764 cannot access the Configuration menu. Check that the Ethernet LED on the DI-764 is ON. If the LED is not ON, check that the cable for the Ethernet connection is securely inserted. Check that the Ethernet Adapter is working properly. Please see item 3 (Check that the drivers for the network adapters are installed properly) in this Troubleshooting section to check that the drivers are loaded properly. Check that the IP Address is in the same range and subnet as the DI-764. Please see Checking the IP Address in Windows XP in the Networking Basics section of this manual. Note: The IP Address of the DI-764 is 192.168.0.1. All the computers on the network must have a unique IP Address in the same range, e.g., 192.168.0.x. Any computers that have identical IP Addresses will not be visible on the network. They must all have the same subnet mask, e.g., 255.255.255.0 Do a Ping test to make sure that the DI-764 is responding. Go to Start>Run>Type Command>Type ping 192.168.0.1. A successful ping will show four replies. Troubleshooting This Chapter provides solutions to problems that can occur during the installation and operation of the DI-764 Wireless Broadband Router. We cover various aspects of the network setup, including the network adapters. Please read the following if you are having problems. Note: If you have changed the default IP Address, make sure to ping the correct IP Ad- dress assigned to the DI-764. Note: It is recommended that you use an Ethernet connection to configure the DI-764 Wireless Broadband Router. ! ! ! ! 71 2. The wireless client cannot access the Internet in the Infrastructure mode. Make sure the wireless client is associated and joined with the correct Access Point. To check this connection: Right-click on the Local Area Connection icon in the taskbar> select View Available Wireless Networks. The Connect to Wireless Network screen will appear. Please make sure you have selected the correct available network, as shown in the illustrations below. Troubleshooting Check that the IP Address assigned to the wireless adapter is within the same IP Address range as the access point and gateway. (Since the DI-764 has an IP Address of 192.168.0.1, wireless adapters must have an IP Address in the same range, e.g., 192.168.0.x. Each device must have a unique IP Address; no two devices may have the same IP Address. The subnet mask must be the same for all the computers on the network.) To check the IP Address assigned to the wireless adapter, double-click on the Local Area Connection icon in the taskbar > select the Support t…

Text truncated - open the document above for the full version.

D-Link Corporation No.8, Li-shing Rd VII,Science-based Industrial park, Hsinchu,Taiwan,R.O.C. TEL.:+886+3-563-6666 FAX:+886+3-563-6789 FCC ID: KA2DI-764 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission¡¦ s Rul es, t he Appli cant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely ------------------------------------------- Leeming Li / Associate Project Manager D-LINK Corporation Tel: +886 3 563-6666ext.6613 Fax: +886 3 578-1861 e-mail: [email protected]

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2 Page 3 Page 4

764 FCC ID:KA2DI-764

764 FCC ID:KA2DI-764

Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12

FCC ID: KA2DI-764 ADT No.910814R03 Technical Description The transmitter of the EUT is powered by host equipment. The antenna is Dipole antenna without antenna connector. This device is a Multimode 2.4/5GHz Wireless Router operates in both the 5GHz and 2.4GHz bands, the maximum data rate could be 54Mbps. Both the 5GHz and 2.4GHz can be operated simultaneously, and the total MPE of these combination is shorter than 20cm. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states : The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

ADT No: 910814R03 1 RF EXPOSURE TEST REPORT REPORT NO.: RF910814R03 MODEL NO.: DI-764 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:D-Link Corporation ADDRESS:No.8, Li-shing Rd VII, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 ADT No: 910814R03 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT No: 910814R03 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 20 deg. C and 63 % RH 6 Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT No: 910814R03 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 5dBi for 5GHz and 2.4GHz. 7.2 Output Power Into Antenna & RF Exposure Distance : For Part 802.11b: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241259.433.87 6243755.593.74 11246259.173.42 For Part 802.11a: Normal Mode: CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1518020.232.25 4524031.262.80 5526066.534.09 8532029.042.70 The minimum allowable distance (3.87+4.09=7.96) is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20cm separation distance with the antenna.

ADT No: 910814R03 1 RF EXPOSURE TEST REPORT REPORT NO.: RF910814R03 MODEL NO.: DI-764 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: D-Link Corporation ADDRESS: No.8, Li-shing Rd VII, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 ADT No: 910814R03 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz ADT No: 910814R03 3 3. Friis Formula Friis transmission formula: Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5 Climate Condition The temperature and related humidity: 20 deg. C and 63 % RH 6 Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. ADT No: 910814R03 4 7 Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 5dBi or 3.16 (numeric) for 5GHz and 2.4GHz. 7.2 Output Power Into Antenna & RF Exposure Distance: For Part 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 12412 59.43 0.0371.0 62437 55.59 0.0351.0 112462 59.17 0.0371.0 For Part 802.11a: Normal Mode: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1518020.23 0.0131.0 4524031.26 0.0201.0 5526066.53 0.0421.0 8532029.04 0.0181.0 NOTE: 2.4GHz max. e.i.r.p = 22.74dBm (187.93mW e.i.r.p) 5.0GHz max. e.i.r.p = 23.23dBm (210.39mW e.i.r.p) Total e.i.r.p (mW) = 187.93 + 210.39 = 398.32 Power density = 398.32 * 1 / (4 * 3.14 * 400) = 0.079 < 1.

FCC ID: KA2DI-764 Report No.: RF910814R03 1 Issued: Feb. 25, 2003 FCC TEST REPORT REPORT NO.: RF910814R03 MODEL NO.: DI-764 RECEIVED: Oct. 16, 2002 TESTED: Feb. 15 ~ Feb. 21, 2003 APPLICANT:D-Link Corporation ADDRESS: No.8, Li-shing Rd VII, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 111 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: KA2DI-764 Report No.: RF910814R03 2 Issued: Feb. 25, 2003 Table of Contents 1CERTIFICATION .................................................................................................................... 5 2SUMMARY OF TEST RESULTS............................................................................................ 6 3GENERAL INFORMATION .................................................................................................... 8 3.1GENERAL DESCRIPTION OF EUT ..................................................................................…

Text truncated - open the document above for the full version.
