KA2DP-311UWireless USB Print Server

D-Link Corporation
Wireless USB Print Server - FCC ID KA2DP-311U - D-Link Corporation
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
May 26, 2003
Application Purpose
Original Equipment
Date of Application
May 26, 2003
Equipment Note
Wireless USB Print Server
Frequency Range
2412.00000000 - 2462.00000000
Company
D-Link Corporation
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Block Diagram

↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗

Schematics

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Manual Building Networks for People Wireless Print Server D-Link DP-311UDP-311U DP-311UDP-311U DP-311U 2 Contents Package Contents................................................................................ 3 Introduction............................................................................................ 4 Wireless Basics .................................................................................... 8 Setting up the DP-311U ...................................................................... 10 Getting Started....................................................................................12 Using the Web Configuration...............................................................13 TCP/IP Printing for Windows XP ........................................................21 TCP/IP Printing for Windows 2000 .....................................................29 TCP/IP Printing for Windows 98SE/Me ..............................................38 Unix/Linux Printing (See PS Admin Manual on CD-ROM) .................. 49 Setting up AppleTalk or LPR Printing in MAC OSX ..............................50 Setting up AppleTalk Printing in MAC OS9..........................................55 Networking Basics.............................................................................. 58 Technical Specifications...................................................................... 70 Contacting Technical Support..............................................................71 Warranty and Registration................................................................... 72 Appendix: DP-311U Printer Compatibility List....................................75 3 Contents of Package: D-Link DP-311U Fast Ethernet Print Server Manual and Warranty on CD Printed Quick Installation Guide Package Contents If any of the above items are missing, please contact your reseller. System Requirements: „ A computer with an installed Ethernet adapter „ Windows XP/2000/ME/98SE „ Apple Mac OS with AppleTalk „ Linux „ Internet Explorer 6.0, or Netscape Navigator version 6.0 or above, with JavaScript enabled „ Printer must support required Operating System „ „ „ 4 The D-Link DP-311U Print Server is an 802.11b wireless print server that also connects to your Ethernet/Fast Ethernet network. Now you can locate USB printer services virtually anywhere in your home or office. The DP-311U manages the flow of print files from workstations or file servers to connected printers, delivering print jobs to printers much faster than a file server on a PC acting as a print server can. With one USB (v1.1) port, the DP-311U can connect to almost any printer with a USB port. The DP-311U includes easy-to-use software to install on most Windows-based networks. Protocol support for TCP/IP, NetBEUI, and AppleTalk are provided to ensure seamless connection to major networking Operating Systems. The DP-311U has a built in Web-Based management feature that allows users to easily configure and manage print queues through TCP/IP. The DP-311U also supports Telnet as an alternative method to configure the unit. The DP-311U improves network printing services in the following ways: „The DP-311U delegates print jobs to the connect USB printer. This provides workload relief to your file servers and allows the file servers’ full capacity to be used for file access or other direct services to network users. On peer-to-peer networks, workstations can print directly to the Print Server without increasing the load of another workstation or server. „The DP-311U’s USB port, version 1.1, can transmit to high-speed laser printers much faster than a PC’s parallel printer port. Introduction „Because the DP-311U is very portable and inexpensive compared to a PC-based print server, and the Print Server connects to your file servers through the network, printers can be deployed to locations of maximum convenience to users. 5 External Features Port Connectors The DP-311U’s USB port is located on its rear panel. The USB can be configured using the PS Admin program or the print server’s Telnet interface. (See the PS Admin User’s Guide, available on the CD that came with the DP-311U, for information about configuring the print server’s ports.) The Print Server also supports web configuration permitting users to configure settings through the web browser. The default IP Address is as follows: „Default IP Address – 192.168.0.10 „Subnet Mask – 255.255.255.0 The DP-311U offers extraordinary flexibility, operating with all major network operating systems and protocols: TCP/IP UNIX lpr/lpd Windows NT/2000, Windows 95/98SE/ME, Windows XP NetWare 5.x NDPS LPR Remote Printing NetBEUI Windows 2000/XP, Windows 95/98SE/ME, Microsoft LAN Manager, IBM LAN Server AppleTalk MacOS EtherTalk Windows-based setup and administration software, PS Admin, is supplied with the Print Server, making configuration and management quick and easy. The Print Server also supports configuration and management via the Telnet protocol for networks without Windows-compatible systems. Note: The PC’s IP Address must be in the same subnet as the Print Server’s IP Address for the two devices to communicate. (For example, if your Print Server’s IP Address is 192.168.0.10, with a subnet mask of 255.255.255.0, then your computer’s IP Address should be 192.168.0.x, where x is a value between 1-254, excluding 10.) „ „ „ 6 Power / USB Steady or flashing green light confirms that the Print Server is powered ON. The LED indicator lights up to show that the Print Server is transferring print data through the USB port. Ethernet/WLAN Steady or flashing green light confirms that the Print Server has a good connection to the Ethernet or Fast Ethernet network. The indicator blinks off briefly to indicate that the Print Server is receiving or transmitting from the network. These four indicators are also used by the Print Server’s Power-ON Self Test (POST) to indicate any hardware failures. Front Panel LED Indicato…

Text truncated - open the document above for the full version.

Users Manual

49 Unix/Linux Printing Please refer to the PS Admin Manual on the CD included with your purchase for information on setting up the Print Server in Unix/Linux. 50 Setting up Apple Talk or LPR Printing in Mac OS X At the Configure pull-down menu, select Manually Open your System Preferences window and Click Network. With Mac OSX you can use AppleTalk or LPR printers using IP protocols for printing through Print Servers. Follow the instructions below for setting up the Print Server. After attaching the Print Server to your network using the directions provided in the Quick Installation Guide, change the IP Address of your Macintosh to access the Print Server’s web configuration. Note: Mac OS printing with this print server is sup- ported by Postscript printers only! 51 The default IP Address of the Print Server is 192.168.0.10. Manually change your IP Address to 102.168.0.x, where x is any number between 1 and 254 (except 10 which is the IP Address of the Print Server.) The IP Addresses and Subnet Mask shown here are examples only. Setting up Apple Talk or LPR Printing in Mac OS X (continued) Select the AppleTalk tab in this window and check Make AppleTalk Active. 52 Setting up Apple Talk or LPR Printing in Mac OS X (continued) To print, open a document and select File > Print from the menu. Select Edit Printer List from the Printer dialog box. Click Add Printer 53 Setting up Apple Talk or LPR Printing in Mac OS X (continued) Select the printing protocol preferred, AppleTalk or LPR Printers using IP. AppleTalk protocol: After selecting AppleTalk the Port Name of the Print Server will be dis- played. The Port Name shown here is an example only. Click on the Port to which the post-script printer is connected. In this example, AppleTalk has been selected. PS - 116688-U1Laserwriter Then select the printer model from the dialog box displayed here. Click Add Printer and the Printer Port configuration is complete. Select the Printer Port just configured in the Print window. Click Print to print your document. PS - 116688-U1Laserwriter 54 Setting up Apple Talk or LPR Printing in Mac OS X (continued) LPR Printers using IP protocol: When you select LPR Printers using IP Proto- col, this window will ap- pear. Type the IP Address of the Print Server into the LPR Printer’s Address field. In the Queue Name field, type in the Port Name of the post-script printer that is connected to the Print Server. The Port Name illustrated here is only an example. Select the printer model from the dialog box. In the Queue Name field, type in the Port Name of the post-script printer that is connected to the Print Server. The Port Name illustrated here is only an example. Select the printer model from the dialog box. Click Add and the process is complete. Close all Print Center windows, select the Printer Port that was just selected. Click Print to print the document.Click Add and the process is complete. PS-116688 - U1 55 Setting up Apple Talk Printing in Mac OS 9 The AppleTalk network protocol is used with computers using the MacOS operating system. It can be used for network communications over standard Ethernet or Fast Ethernet using the EtherTalk transport, or over a proprietary low-speed LocalTalk transport. Your Print Server can be used for network printing to PostScript printers. You can print from any MacOS computer connected to your Ethernet network, either directly using an EtherTalk connection, or indirectly through a LocalTalk-to-EtherTalk router. NOTE: The Chooser name of a printer connected to one of the Print Server’s ports is the same as its Port Name. If you are using AppleTalk printing, you will need to make sure that every Port Name is unique among all of the network printers in your AppleTalk zone. The Port Names shown in this manual are examples only. Setting up the Print Server for AppleTalk Printing To set up your Print Server so that it can be used for AppleTalk printing: Note: Mac OS printing with this print server sup- ports Postscript printers only! If your AppleTalk network is divided into AppleTalk zones, you will have to specify which zone the Print Server should be in. You should locate the Print Server in the same zone as most of the users who will be using it. If your network is not divided into zones, the AppleTalk Zone field should contain a single asterisk “*”. Select the Network tab and scroll to the bottom to the AppleTalk protocol section Change the IP Address on one of the computers on your network to 192.168.0.x, where x is any number between 11-254. Type 192.168.0.10 into the address field of your web browser. 192.168.0.10 is the default IP Address of the DP-311U. Make sure the AppleTalk protocol is enabled in your Macintosh. „ „ „ „ „ 56 Printing from MacOS Client Workstations The exact procedure for selecting a PostScript printer connected to your Print Server may vary slightly, depending on what printer driver version you are using. The procedure described below assumes you are using the LaserWriter 8. To choose a printer connected to your Print Server as your MacOS workstation’s default printer, Open the Chooser by selecting Chooser from the Apple menu. Select the LaserWriter 8 icon on the left. Make sure that AppleTalk is set to Active. A list of all networked PostScript printers will be displayed: Double-click the name of the Printer Port you wish to use. The Printer Ports shown are examples only. PS-116688-U1 57 Printing from MacOS Client Workstations (continued) If you have not previously set this printer as the default, your computer will prompt you for a PostScript Printer Description file. Choose Select PPD. If you wish to access this setting in the future, you can use the Setup button in the Chooser window. The selected printer will become your computer’s default printer. You may need to choose Page Setup in any applications you have open. Select the appropriate printer description file for your printer. Click Open. (If your printer is not listed, click Generic to us…

Text truncated - open the document above for the full version.

Block Diagram

Parallel AT7601 C P U Sy stem S DRAM ( 1M* Sy stem Flash ( 256K*1 100M X'forme C om p actFla Interfac IEEE802.1 W ireless LAN Memory System LE ( LAN Reset ( factor y I/O Port Antenn R J -4 LAN S witchin ada p to 5 V /2.4 Power System AC source Re g ulat 3.3 V /5 O the r 5V USB Wireless LAN Wire LAN DP-311U Block Diagram 3.3V USB US B U B S ( series

External Photos

Report No.: 033H065FI Page : 1 of 8 Version:1.0 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo

ID Label/Location Info

D-LINK Corporation FCC ID.: KA2DP-311U FCC ID AND DoC Label The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. Wireless USB Print Server D-Link Model No.: DP-311U TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan Wireless USB Print Server Model No.: DP-311U F F C C C C I I D D : : K K A A 2 2 D D P P - - 3 3 1 1 1 1 U U This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

ID Label/Location Info

D-LINK Corporation FCC ID.: KA2DP-311U FCC ID AND DoC Label The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. Wireless USB Print Server D-Link Model No.: DP-311U TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan Wireless USB Print Server Model No.: DP-311U F F C C C C I I D D : : K K A A 2 2 D D P P - - 3 3 1 1 1 1 U U This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

Internal Photos

Report No.: 033H065FI Page : 2 of 8 Version:1.0 (3) EUT Photo (4) EUT Photo Report No.: 033H065FI Page : 3 of 8 Version:1.0 (5) EUT Photo Report No.: 033H065FI Page : 4 of 8 Version:1.0 (6) EUT Photo Report No.: 033H065FI Page : 5 of 8 Version:1.0 (7) EUT Photo (8) EUT Photo Report No.: 033H065FI Page : 6 of 8 Version:1.0 (9) EUT Photo Report No.: 033H065FI Page : 7 of 8 Version:1.0 (10) EUT Photo Report No.: 033H065FI Page : 8 of 8 Version:1.0 (11) EUT Photo (12) EUT Photo

Operational Description

Report No. 033H065FI Page: 5 of 34 Version:1.0 1.2. Operational Description EUT is a Wireless USB Print Server with 11 channels. This device provided four kind of transmitting speed 1,2,5.5 and 11Mbps. The device of RF carrier is DQPSK, DB PSK and CCK. The device adapts direct sequence spread spectrum modulation. The Connector antenna was provides diversity function to improve the receiving function. This Wireless USB Print Server is an IEEE 802.11b Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direst Sequence Spread Spectrum (DSSS) radio transmission, the Wireless USB Print Server transfers data at speeds up to 64/128-bit Wired Equivalent Protection (WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any 802.11b network.

Schematics

5 5 4 4 3 3 2 2 1 1 DD CC BB AA Pin 39(PIO27) ID0= 0Software Version : 0.01UF*11(VDDIO,VDDC) Pin 38(/WR) = PU : ROM 16bitPin 116(TXD1_3/PDIVD1) = PU Pin 115(TXD1_2/PDIVD0) = PU Pin 114(TXD1_1/PFEREQ1) = PD Pin 112(TXD1_0/PFEREQ0) = PU 25MHZ*4=100MHZ Pin 117(TXEN1/CLKJMP)=PU : Multiple PLL enable 45657591991232359 97 18 Pin 33(ATPGEN)=PD : Sacn chain disable Pin 28(DTR1/SBWSEL)=PU : Slow bus disable Pin 32(JTAGEN)=PU : JTAGE enable CPU0A2 DP-311U Prepared : Peter Ku Issued Date: B 15Monday, January 20, 2003 Title SizeDocument NumberRev Date:Sheet of SW_RST /RD /WR ARDY /CIS/CIS /RD/WR /PCS5/PCS5 /RD/WR /OE /IORD /WE /IOWR /PCS2 /PCS3/REG WL_A9 /PCS2 A9 AD7 AD2 AD9 AD6 AD8 AD11 AD10 AD12 AD5 AD14 AD15 AD0 AD13 AD4 AD1 AD3 /PCS2 /PCS3 /PCS5 A15 A12 A13 A7 A9 A14 A5 A8 A4 A2 A6 A10 A1 A11 A3 /UCS INT0 A0 A[0..18] AD[0..15] WL_CD2 /CS_USB SW_RST INT2 /WL_LED MDIO MDC COL RXER RXDV RXC TXC RXD0RXD1RXD2RXD3 TXD[0..3] RXD[0..3] /RST_CPU /RST_CPU /SD_WE /SD_RAS DQML /SD_CAS SD_CLK DQMH PHYCHG TXD2 TXD1 TXD3 TXD0 PD1PQ0 TXEN PD0PQ1 RST/RSTRSTWL A17 A18 A16 /CIS /PCS5 ID0 /USB_LED ID1 /WL_CE2 RST 3.3V 3.3V 3.3V 3.3VP23.3VP2 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3VP2 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V R12100 5% 1/16W R51330 5% 1/16W C39C38C46C52 R63 100 5% 1/16W U5C 74LVC32 9 10 8 14 7 U5B 74LVC32 4 5 6 14 7 C53 X2 X'TAL 25MHz U5D 74LVC32 12 13 11 14 7 C49 C33 20PF R62100 5% 1/16W R55330 5% 1/16W R48 100 5% 1/16W C50 R49 10K 5% 1/16W C47 0.1UF C34 0.1UF C42 C40 RA7100*4 5% 1/16W 1 2 3 4 8 7 6 5 R14100 5% 1/16W U5A 74LVC32 1 2 3 14 7 C60 R65 100 5% 1/16W R1510K 5% 1/16W R71 100 5% 1/16W R64 100 5% 1/16W R31 100 5% 1/16W U6A 74LVC08 1 2 3 14 7 U6B 74LVC08 4 5 6 14 7 C48 0.01UF U6D 74LVC08 12 13 11 14 7 R52100 5% 1/16W R53100 5% 1/16W C35 0.01UF U3B 74LVC14 34 RA6100*4 5% 1/16W 1 2 3 4 8 7 6 5 C24 47UF/25V C6 47UF/25V RA2100*4 5% 1/16W1 2 3 4 8 7 6 5 R5610K 5% 1/16W R23 100 5% 1/16W U3C 74LVC14 56 R61100 5% 1/16W R25100 5% 1/16W R26100 5% 1/16W R24100 5% 1/16W C13 0.01UF R6010K 5% 1/16W R5810K 5% 1/16W U4 R1610 128 127 10 12 11 13 8 6 26 25 17 20 85 84 82 86 126 125 34 35 124 95 94 93 92 90 89 88 87 61 60 58 57 56 54 53 52 79 78 77 76 71 70 69 68 80 66 51 50 49 48 47 44 43 96 100 72 67 46 9 14 120 5 16 15 37 38 122 18 1 4 64 74 32 33 39 41 42 45 65 75 91 99 123 36 55 73 81 98 113 23599712174083101636232 111117112114115116110102103109108107106118105104 19 21 22 24 27 28 29 30 31 119 X1 X2 TMRIN0 TMROUT0 TMROUT1 DRQ1/INT6 INT0 INT1/SELECT SOUT1 SIN1 RTS0/SAD9 CTS0/SAD8 WE CAS RAS DQML PCS0 PCS1 PCS2 PCS3 PCS5 AD0 AD1 AD2 AD3 AD4 AD5 AD6 AD7 AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15 A0/MA0 A1/MA1 A2//MA2 A3/MA3 A5/MA5 A6/MA6 A7/MA7 A8/MA8 A10/MA10 A11/SAD0 A12/SAD1 A13/SAD2 A14/SAD3 A15/SAD4 A16/SAD5 A18/SAD7 A19/ALE UCS CLKOUTA A4/MA4 A9/MA9 A17/SAD6 TMRIN1 DRQ0/INT5 RES INT2/INTA0/PWD SOUT0/SAD13 SIN0/SAD14 RD WR/BWSEL ARDY VDDIO VSSIO NMI DQMH SD_CLK JTAGEN ATPGEN PIO27 PIO28 PIO29 VDDIO VDDIO VDDIO VDDIO VDDIO VDDIO VSSIO VSSIO VSSIO VSSIO VSSIO VSSIO VDDCVDDCVDDCVDDCVSSCVSSCVSSCVSSCVDDP1VSSP1VDDP2VSSP2 TXC1 TXEN1/CLKJMP TXD1_0/PFEREQ0TXD1_1/PFEREQ1 TXD1_2/PDIVD0TXD1_3/PDIVD1 RXC1 MDIO1 MDC1 RXD1_3RXD1_2RXD1_1RXD1_0 COL1 RXDV1RXER1 DTR0/SAD12 DSR0/SAD11 DCD0/SAD15 RI0/SAD10 RTS1/TD0 DTR1/SBWSEL CTS1/TMS DSR1/TCK DCD1/TDI PHY_CHG1 R591K 5% 1/16W RA347*4 5% 1/16W1 2 3 4 8 7 6 5 U3D 74LVC14 98 U6C 74LVC08 9 10 8 14 7 R20100 5% 1/16W R45100 5% 1/16W R9100 5% 1/16W R6 10K 5% 1/16W R10100 5% 1/16W C21 0.01UF R775 5% 1/16W R875 5% 1/16W RA8100*4 5% 1/16W1 2 3 4 8 7 6 5 R57 10K 5% 1/16W R22100 5% 1/16W R7275 5% 1/16W R50 330 5% 1/16W RA1047*4 5% 1/16W 1 2 3 4 8 7 6 5 RA5 100*4 5% 1/16W 1 2 3 4 8 7 6 5 RA947*4 5% 1/16W 1 2 3 4 8 7 6 5 Q2 XC61FC3012MR XC61B 31 2 VINVOUT VSS R46 100K 1% 1/16W C36 0.1UF C44 0.01UF SW1 PUSH BOTTON C43 10UF/10V R47 1M 5% 1/16W L8 BEAD 1206 C41 20PF RA447*4 5% 1/16W 1 2 3 4 8 7 6 5 R5410K 5% 1/16W C8 0.01UF U3A 74LVC14 12 RA1100*4 5% 1/16W 1 2 3 4 8 7 6 5 /OE(5) /IORD(5) /WE(5) /IOWR(5) /REG(5) WL_A9(5) SD_CLK(2) /UCS(2) INT0(5) WL_CD2(5) INT2(4) /WL_LED(4) AD[0..15](2,4,5) A[0..18](2,4,5) TXD[0..3](3) RXD[0..3](3) TXC(3) RXC(3) RXDV(3) RXER(3) COL(3) MDIO(3) MDC(3) ARDY(5) /RD(2,4) /WR(2,4) WL_CD1(5) /SD_RAS(2) /SD_WE(2) DQML(2) /SD_CAS(2) DQMH(2) PHYCHG(3) TXEN(3) /RST(3,4) RSTWL(5) /CS_USB(4) /USB_LED(4) /WL_CE2(5) 5 5 4 4 3 3 2 2 1 1 DD CC BB AA 0.01UF*2 0.01UF*4 125 7133844 37 0A2 DP-311U Prepared: Peter Ku Issued Date: B 25Monday, January 20, 2003 Memory Title SizeDocument NumberRev Date:Sheet of AD3 A1 /RD A3 A11 AD6 AD4 AD5 AD7 A6 AD10 A17 A15 AD1 AD14 A4 A18 A9 A12 AD0 AD9 AD11 A8 AD12 A13 A14 A16 A7 AD13 A5 AD2 A2 AD15 A10 AD8 /UCS /WR SD_CLK /SD_WE /SD_CAS DQML DQMH /SD_RAS AD8 AD9 AD10 AD11 AD12 AD13 AD14 AD15 A0 A1 A2 A3 A5 A4 A6 A7 A8 A10 A9 AD[0..15] A[0..18] AD6 AD5 AD1 AD2 AD7 AD3 AD4 AD0 3.3V 3.3V3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V 3.3V RA1347*4 5% 1/16W 1 2 3 4 8 7 6 5 RA1547*4 5% 1/16W 1 2 3 4 8 7 6 5 C61C56 C23 0.01UF U7 29LV400-TSOP 29F400-TSOP 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 A15 A14 A13 A12 A11 A10 A9 A8 NC NC /WE /RESET NC NC RY/BY NC A17 A7 A6 A5 A4 A3 A2 A1 A16 /BYTE VSS DQ15 DQ7 DQ14 DQ6 DQ13 DQ5 DQ12 DQ4 VCC DQ11 DQ3 DQ10 DQ2 DQ9 DQ1 DQ8 DQ0 /OE VSS /CE A0 C58 RA1447*4 5% 1/16W 1 2 3 4 8 7 6 5 RA1247*4 5% 1/16W 1 2 3 4 8 7 6 5 U9 KM416S1120D 2 3 5 6 8 9 11 12 39 40 42 43 45 46 48 49 1 50 7 13 38 44 4 10 41 47 34 35 21 22 23 24 27 28 29 30 31 32 20 25 26 18 19 17 16 15 14 36 33 37 DQ0 DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7 DQ8 DQ9 DQ10 DQ11 DQ12 DQ13 DQ14 DQ15 VDD VSS VDDQ VDDQ VDDQ VDDQ VSSQ VSSQ VSSQ VSSQ CKE CLK A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10/AP VDD VSS CS BA RAS CAS WE LDQM UDQM NC NC/RFU C63 10UF/10V C20 10UF/10V C18 10UF/10V C66 10UF/10V C67 C59 C62 A[0..18](1) AD[0..15](1,4,5) /WR(1) /RD(1) /UCS(1) SD_CLK(1) /SD_RAS(1) /SD_CAS(1) /SD_WE(1) DQML(1) DQMH(1) 5 5 4 4 3 3 2 2 1 1 DD CC BB AA 0603 0.01UF*4 2413 31474238 7 0.01UF*3 RX…

Text truncated - open the document above for the full version.

Test Report

Report No. 033H065FI Page: 1 of 34 Version:1.0 Test Report Product Name : Wireless USB Print Server Model No.: DP-311U FCC ID.: KA2DP-311U Applicant : D-LINK Corporation Address : No. 8, Li-Shing Road VII, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Date of Receipt : Mar 17, 2003 Date of Test : Apr 25, 2003 Report No. : 033H065FI The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 033H065FI Page: 2 of 34 Version:1.0 Test Report Certification Test Date : Apr 25, 2003 Report No. : 033H065FI The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Product Name : Wireless USB Print Server Applicant : D-LINK Corporation Address : No. 8, Li-Shing Road VII, Science-based Industrial Park, Hsinchu, Taiwan, R.O.C. Manufacturer : Cellvision Systems Inc. Model No. : DP-311U FCC ID. : KA2DP-311U Rated Voltage : AC 120V/60Hz Trade Name : D-Link Measurement Standard : FCC Part 15 Subpart C Paragraph 15.247 Measurement Procedure : ANSI C63.4: 1992 Test Result : Complied Documented By : ( Carol Tasi ) Tested By : ( Ken Hsu ) Approved By : ( Kevin Wang ) Accredited by NIST (NVLAP) NVLAP Lab Code: 200347-0 Report No. 033H065FI Page: 3 of 34 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................4 1.1. EUT Description............................................................................................................................4 1.2. Operational Description ................................................................................................................5 1.3. Tested System Datails....................................................................................................................6 1.4. Configuration of tested System .....................................................................................................7 1.5. EUT Exercise Software .................................................................................................................7 1.6. Test Facility ...................................................................................................................................8 2. Conducted Emission....................................................................................................................9 2.1. Test Equipment..............................................................................................................................9 2.2. Test Setup ......................................................................................................................................9 2.3. Limits ............................................................................................................................................9 2.4. Test Procedure .............................................................................................................................10 2.5. Test Result of Conducted Emission.............................................................................................11 3. Peak Power Output ...................................................................................................................13 3.1. Test Equipment............................................................................................................................13 3.2. Test Setup ....................................................................................................................................13 3.3. Limits ..........................................................................................................................................13 3.4. Test Result of Peak Power Output...............................................................................................14 4. Radiated Emission .....................................................................................................................15 4.1. Test Equipment............................................................................................................................15 4.2. Test Setup ....................................................................................................................................15 4.3. Limits ..........................................................................................................................................16 4.4. Test Procedure .............................................................................................................................17 4.5. Test Result of Radiated Emission................................................................................................18 5. Band Edge ..................................................................................................................................24 5.1. Test Equipment............................................................................................................................24 5.2. Test Setup ....................................................................................................................................24 5.3. Limits ..........................................................................................................................................25 5.4. Test Procedure .............................................................................................................................25 5.5. Test Result of Band Edge ............................................................................................................26 6. Occupied Bandwidth ......…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: 033H065FI Page : 1 of 3 Version:1.0 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 033H065FI Page : 2 of 3 Version:1.0 Front View of Radiated Test Back View of Radiated Test Report No.: 033H065FI Page : 3 of 3 Version:1.0 Front View of Radiated Test (Horn)

Contact Information

Applicant

Brett Adair(General Counsel)
[email protected]714-885-6000Fax: 866-743-4589

Test Firm

DEKRA Testing and Certification Co., Ltd.Sky Hsu
[email protected]886-2-86013788Fax: 886-2-86013789

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz28.00 mW
Grant Notes
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
