KA2DWL-650PLUSB12.4GHz Wireless Cardbus Adapter

D-Link AirPlus DWL-650+ 2.4 GHz Wireless Cardbus Adapter Manual Rev. 062502 Building Networks for People ® 2 Contents 1. Package Contents ............................................. 3 2. Introduction........................................................ 4 3. Wireless Basics ................................................. 6 4. Getting Started .................................................. 9 5. Installing the DWL-650+ .................................. 12 6. Using the Configuration Utility ......................... 15 7. Troubleshooting............................................... 22 8. Networking Basics........................................... 26 9. Technical Specifications .................................. 58 10. Contacting Technical Support.......................... 60 11. Limited Warranty and Registration................... 61 3 1. Package Contents Contents of Package: • D-Link AirPlus DWL-650+ 2.4GHz Wireless Cardbus Adapter • Manual, QIG, and Drivers on CD • Printed Quick Installation Guide If any of the above items are missing, please contact your reseller. System Requirements: • A laptop computer with an available 32-bit Cardbus PC Card slot • Windows XP, Windows 2000, Windows Me, or Windows 98 • Cardbus Controller, properly installed and working • At least 32 MB of memory and a 300 MHz processor • An 802.11b Access Point (e.g., DWL-1000AP for Infrastructure Mode) or another 802.11b wireless adapter (e.g., DWL-520 for Ad- Hoc mode.) 4 2. Introduction The D-Link AirPlus DWL-650+ Wireless Cardbus Adapter is an enhanced 802.11b high-performance, wireless adapter that supports high-speed wireless networking at home, at work or in public places. Unlike most 802.11b network cards, the DWL-650+ provides speeds of up to 22 Mbps (compared to the standard 11 Mbps) when used with other D-Link AirPlus products such as the DWL-520+ Wireless PCI Adapter. The DWL-650+ is also compatible with existing 802.11b devices such as the D-Link Air family of products including the DWL-520 Wireless PCI Adapter, the DI-714 Wireless Router/Access Point and the DWL-120 Wireless USB Adapter. It is an ideal way to connect one laptop computer to a Wireless Local Area Network (WLAN.) After completing the steps outlined in the Quick Installation Guide (included in the package) you will have the ability to share information and resources, such as files and printers, and take full advantage of a “connected” environment for work or play! The DWL-650+ includes software drivers for the most popular Microsoft Windows operating systems (Windows XP, Windows 2000, Windows Me, Windows 98) and can be integrated into a larger network, running, in either Ad Hoc mode (without an Access Point) or Infrastructure mode (with an Access Point.) Please take a look at our Getting Started section in this manual to see examples of typical network setups using the DWL-650+ in both Infrastructure and Ad-Hoc modes. This manual provides a quick introduction to wireless technology and its application as it relates to networking. Take a moment to read through this manual and get acquainted with wireless technology. 5 Product Features • Provides high-speed wireless connection up to 22Mbps • Operates in the 2.4GHz frequency range • Maximum reliability, throughput and connectivity with automatic data rate switching • Supports Wired Equivalent Privacy (WEP) data encryption at 64/128/256-bit encryption • Supports infrastructure networks via an Access Point and peer-to- peer communication in ad-hoc mode • Built-in dual diversity antenna for reduced interference in a multi-path environment • 32-bit Cardbus Performance • User-friendly configuration and diagnostic utilities LEDs LED stands for Light-Emitting Diode. The DWL-650+ has two LEDs: 1. Power - Green LED lights on steady to indicate a proper connection to a power source. 2. Link - Green LED flashes to indicate activity on the network and lights on steady to indicate that a link to the network is established. Power Link 6 3. Wireless Basics D-Link AirPlus wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or wherever a wireless network is available. Strictly adhering to the IEEE standard, the D-Link AirPlus wireless family of products will allow you to access the data you want, when and where you want it. No longer will you be limited to one location or forced to run new wiring through your home or office. You will be able to enjoy the freedom that wireless networking delivers. A wireless local area network (WLAN) is a cellular computer network that transmits and receives data with radio signals instead of wires. Wireless LANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people to work and communicate more efficiently. Increased mobility with the absence of cabling and other fixed infrastructure have proven to be beneficial for many users. Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems, support the same protocols as Ethernet adapter cards. For most users, there is no noticeable functional difference between a wired Ethernet desktop computer and a wireless computer equipped with a wireless adapter other than the added benefit of the ability to roam within a wireless-cell. Under many circumstances, it may be desirable for mobile network devices to link to a conventional Ethernet LAN in order to use servers, printers or an Internet connection supplied through the wired LAN. A Wireless Access Point (AP) is a device used to provide this link. People use wireless LAN technology for many different purposes. Mobility - Productivity increases when people have access to data in any location within the operating range of the WLAN. Management decisions based on real-time informatio…

Text truncated - open the document above for the full version.

42 Networking Basics Connecting to a Wireless Network Connecting to a Wireless Network in Windows Me and 98 Go to Start > Settings > Control Panel > Double-click on the Network associated with the DWL-650+ > click Properties > select Internet Protocol (TCP/IP) > click Properties Connecting to a Wireless Network with a Wireless Router or an Access Point using a DHCP server in Windows Me and 98. Select the IP Address tab. Then, select Obtain an IP address automatically. Select Detect connection to network media. Click OK Fig. 8.32 Fig. 8.33 TCP/IP – D-Link AirPlus DWL-650+ Wireless Cardbus 43 Networking Basics Connecting to a Wireless Network Connecting to a Wireless Network with a Wireless Router or Access Point using a static IP address in Windows Me or Windows 98 . Select Use the following IP address. Input a static IP address within the same IP Address range as the wireless router or access point. IP address: 192.168.0.51 Subnet mask: 255.255.255.0 Default Gateway: Enter the LAN IP address of the Wireless Router Select Detect connection to network media. Click OK Checking the Wireless Connection by Pinging For Windows XP and 2000: Go to Start > Run > type cmd. A window similar to Fig. 8.35 will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP address of the Wireless Router or Access Point. A good wireless connection will show four replies from the wireless router or access point, as shown. Fig. 8.34 Fig. 8.35 44 Networking Basics Checking the Wireless Connection by Pinging For Windows Me and 98: Go to Start > Run > type command. A window similar to Fig. 8.36 will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP address of the Wireless Router or Access Point. A good wireless connection will show four replies from the wireless router or access point, as shown. Adding and Sharing Printers in Windows XP After you have run the Network Setup Wizard on all the computers in your network (please see the Network Setup Wizard section at the beginning of Networking Basics,) you can use the Add Printer Wizard to add or share a printer on your network. Whether you want to add a local printer (a printer connected directly to one computer,) share an LPR printer (a printer connected to a print server) or share a network printer (a printer connected to your network through a Gateway/Router,) use the Add Printer Wizard. Please follow the directions below: First, make sure that you have run the Network Setup Wizard on all of the computers on your network. We will show you 3 ways to use the Add Printer Wizard 1. Adding a local printer 2. Sharing an network printer 3. Sharing an LPR printer Fig. 8.36 45 Networking Basics Adding a local printer (A printer connected directly to a computer) A printer that is not shared on the network and is connected directly to one computer is called a local printer. If you do not need to share your printer on a network, follow these directions to add the printer to one computer. • Go to Start> Printers and Faxes • Click on Add a printer Fig. 8.37 Fig. 8.38 46 Networking Basics Adding a local printer • Click Next • Select Local printer attached to this computer • (Deselect Automatically detect and install my Plug and Play printer if it has been selected.) • Click Next • Select Use the following port: • From the pull-down menu select the correct port for your printer (Most computers use the LPT1: port, as shown in the illustration.) • Click Next Fig. 8.39 Fig. 8.40 Fig. 8.41 47 Networking Basics Adding a local printer • Select and highlight the correct driver for your printer. • Click Next (If the correct driver is no t displayed, insert the CD or floppy disk that came with your printer and click Have Disk.) • At this screen, you can change the name of the printer (optional.) • Click Next • Select Yes, to print a test page. A successful printing will confirm that you have chosen the correct driver. • Click Next Fig. 8.42 Fig. 8.43 Fig. 8.44 48 Networking Basics Adding a local printer Click Finish Click OK This screen gives you information about your printer. When the test page has printed, Fig. 8.45 Fig. 8.46 49 Networking Basics Adding a local printer Sharing a Network Printer After you have run the Network Setup Wizard on all the computers on your network, you can run the Add Printer Wizard on all the computers on your network. Please follow these directions to use the Add Printer Wizard to share the printer on your network: • Go to Start> Printers and Faxes A successful installation will display the printer icon as shown at right. You have successfully added a local printer. • Go to Start> Printers and Faxes Fig. 8.47 Fig. 8.48 50 Networking Basics Sharing a network printer • Click on Add a Printer • Click Next • Select Network Printer • Click Next Fig. 8.49 Fig. 8.50 Fig. 8.51 51 Networking Basics Sharing a network printer • Select the printer you would like to share. • Click Next • Click Finish Fig. 8.52 Fig. 8.53 Fig. 8.54 • Select Browse for a printer • Click Next 52 Networking Basics Sharing a network printer To check for proper installation: • Go to Start> Printers and Faxes The printer icon will appear at right, indicating proper installation. You have completed adding the printer. To share this printer on your network: • Remember the printer name • Run the Add Printer Wizard on all the computers on your network. • Make sure you have already run the Network Setup Wizard on all the network computers. After you run the Add Printer Wizard on all the computers in the network, you can share the printer. Fig. 8.55 Fig. 8.56 53 Networking Basics Sharing an LPR printer To share an LPR printer (using a print server,) you will need a Print Server such as the DP-101P+. Please make sure that you have run the Network Setup Wizard on all the computers on your network. To share an LPR printer, please follow these directions: • Go to Start> Printers and Faxes • Click on Add a Printer The screen to the right will display. • Click Next • Select Local Printer • Click Next F…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

(1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: Node ID: S/N: DWL-650+ FCC ID: KA2DWL-650PLUSB1 PlusPlusPlusPlusPlus

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8

FCC ID: KA2DWL-650PLUSB1 Report No.920127R01A Operational Description The transmitter of the EUT (2.4GHz Wireless Cardbus Adapter) is powered by host equipment. The antenna is Patch antenna, and there is no antenna connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate. The bit rates are 1,2,5.5,11,22Mbps, the symbol rates are 1,1,1.375,1.375,1.375 Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8,8,and16 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: KA2DWL-650PLUSB1 Report No.: SA920127R01A 1 Issued: Mar. 7 th 2003 Reference No.: SA920127R01 SAR TEST REPORT REPORT NO.: SA920127R01A MODEL NO.: DWL-650+ RECEIVED: NA TESTED: Jan. 30, 2003 APPLICANT: D-Link Corporation ADDRESS:No.8,Li-Hsin VII Road Science Based Industrial Park Hsin-Chu,Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 16 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. FCC ID: KA2DWL-650PLUSB1 Report No.: SA920127R01A 2 Issued: Mar. 7 th 2003 Reference No.: SA920127R01 Table of Contents 1.CERTIFICATION .................................................................................................................3 2.GENERAL INFORMATION ................................................................................................. 4 2.1GENERAL DESCRIPTION OF EUT ................................................................................... 4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................... 4 2.3GENERAL INOFRMATION OF THE SAR SYSTEM .......................................................... 5 2.4GENERAL DESCRIPTION OF THE PROBE SCAN RULE................................................ 7 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ........................................... 8 4.DESCRIPTION OF SUPPORT UNITS ............................................................................... 9 5.TEST RESULTS................................................................................................................ 10 5.1TEST PROCEDURES....................................................................................................... 10 5.2MEASURED SAR RESULT .............................................................................................. 10 5.3SAR LIMITS ...................................................................................................................... 12 5.4EUT CONDUCTED POWER VARIATION ........................................................................ 12 5.5TISSUE ............................................................................................................................. 13 5.6TEST EQUIPMENT FOR TISSUE PROPERTY ............................................................... 13 6.SYSTEM VALIDATION...................................................................................................... 14 7.MEASUREMENT UNCERTAINTIES ................................................................................ 15 8.INFORMATION ON THE TESTING LABORATORIES ..................................................... 16 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: KA2DWL-650PLUSB1 Report No.: SA920127R01A 3 Issued: Mar. 7 th 2003 Reference No.: SA920127R01 1. CERTIFICATION PRODUCT : 2.4GHz Wireless Cardbus Adapter MODEL NO. : DWL-650+ BRAND NAME : D-Link APPLICANT : D-Link Corporation STANDARDS : 47 CFR Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on 30 th Jan. 2003. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate, and it was tested according to the standards listed above. This device was found to be in compliance with the Specific Absorption Rate (SAR) requirement specified in FCC part 2.1093 under General Population / Uncontrolled Exposure condition. FCC ID: KA2DWL-650PLUSB1 Report No.: SA920127R01A 4 Issued: Mar. 7 th 2003 Reference No.: SA920127R01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT2.4GHz Wireless Cardbus Adapter MODEL NO.DWL-650+ POWER SUPPLY3.3VDC powered by host equipment CLASSIFICATIONPortable device, production unit MODULATION TYPEBPSK, QPSK, CCK, PBCC RADIO TECHNOLOGYDSSS TRANSFER RATE1/2/5.5/11/22Mbps FREQUENCY RANGE2412MHz ~ 2462MHz NUMBER OF CHANNEL11 CONDUCTED OUTPUT POWER 61.52mW ANTENNA TYPEPatch antenna PEAK SAR0.205W/kg DATA CABLENA I/O PORTSPCMCIA ASSOCIATED DEVICESNA NOTE: 1. The EUT was designed with two kinds of Pre Amplifier. The details as below: ItemBrand nameModel name 1MAXIM MAX2242 2GATAXGA2P4W22 2. The test result PA1 stands for amplifier with model MAX2242 and the result PA2 stands for model GA2P4W22. Also refer to note 1 on page 8 please. 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS According to the specifications of the manufacturer, this product must comply with the requirements of the following standards: FCC 47 CFR Part 2 (2.1093) FCC OET Bulletin 65, Supplement C (01- 01) RSS-102 All tests have been performed and recorded as per the above standards. FCC ID: KA2DWL-650PLUSB1 Report No.: SA920127R01A 5 Issued: Mar. 7 th 2003 Reference No.: SA920127R01 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM DASY3 (software 3.1d) consists of high precision robtics system, probe alignment sensor, phantom, robot controller, controlled PC and near-field probe. The robot includes six axis that can move to the precision position of the DASY3 software defined. The DASY3 software can define the area which is detected by the probe. The robot is connected to controlled box. Controlled PC is connected to the controlled robot box. The DAE includes amplifier, signal multiplexing, AD converter, offset measurement, surface detection. It is connected to the Electro-optical coupler (ECO). The ECO performs the conversion form the optical into digital electric si…

Text truncated - open the document above for the full version.

2.4GHz Wireless Cardbus Adapter Mode 1(PA2) Separation distance : 0mm (Laptop PC to Phantom) Air temperature : 24 degrees centigrade ; Liquid temperature : 22.5 degrees centigrade SAM Phantom; Section; Position: ; Antenna type : Internal Printed Modulation type : DSSS Probe: ET3DV6 - SN1687; ConvF(4.40,4.40,4.40); Crest factor: 1.0 Test Frequency : 2412 MHz Liquid parameters : Body 2412 MHz σ = 1.89 mho/m ε r = 52.4 ρ = 1.00 g/cm 3 Z-Axis : Dx = 0.0, Dy = 0.0, Dz = 2.0 : , () Powerdrift: -0.30 dB 01/30/03 ADVANCE DATA TECHNOLOGY CORPORATION 0.0 0.1 0.2 0.3 0.4 0.5 012345678910111213141516171819 SAR tot [mW/g] [mm] APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM D2: 2450MHz SYSTEM VALIDATION DIPOLE D3: DOSIMETRIC E-FILED PROBE ET3DV6 SN:1687 June 5, 2002 Isotropy Error (Φ), θ = 0 ̊ ET3DV6 SN:1687 June 5, 2002 Frequency Response of E-Field (TEM – Cell:ifi110, Waveguide R22) Dynamic Range f (SAR brain ) (Waveguide R22) 1.E+7 1.E+6 1.E+5 1.E+4 1.E+3 1.E+2 1.E+1 1.E+0 mW/cm 3 not compensated compensated μ μμ μV 0.0001 0.001 0.01 0.1 1 10 100 ET3DV6 SN:1687September 28, 2002 Conversion Factor Assessment

FCC ID: KA2DWL-650PLUSB1 Report No.: RF920127R01A 1 Issued: March 7, 2003 Reference No.: RF920127R01 FCC TEST REPORT REPORT NO.: RF920127R01A MODEL NO.: DWL-650+ RECEIVED: NA TESTED: Jan. 27 ~ Feb. 6, 2003 APPLICANT: D-Link Corporation ADDRESS:No.8,Li-Hsin VII Road Science Based Industrial Park Hsin-Chu,Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 69 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: KA2DWL-650PLUSB1 Report No.: RF920127R01A 2 Issued: March 7, 2003 Reference No.: RF920127R01 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5TEST SETUP ...............................................................................................11 4.1.6EUT OPERATING CONDITIONS.................................................................11 4.1.7TEST RESULTS (A) .................................................................................... 12 4.1.8TEST RESULTS (B) .................................................................................... 18 4.2RADIATED EMISSION MEASUREMENT ................................................... 24 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 24 4.2.2TEST INSTRUMENTS ................................................................................ 25 4.2.3TEST PROCEDURES................................................................................. 26 4.2.4DEVIATION FROM TEST STANDARD ....................................................... 26 4.2.5TEST SETUP .............................................................................................. 27 4.2.6EUT OPERATING CONDITIONS................................................................ 27 4.2.7TEST RESULTS (A) .................................................................................... 28 4.2.8TEST RESULTS (B) .................................................................................... 32 4.36dB BANDWIDTH MEASUREMENT .......................................................... 36 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 36 4.3.2TEST INSTRUMENTS ................................................................................ 36 4.3.3TEST PROCEDURE ................................................................................... 37 4.3.4DEVIATION FROM TEST STANDARD ....................................................... 37 4.3.5TEST SETUP .............................................................................................. 37 4.3.6EUT OPERATING CONDITIONS................................................................ 37 4.3.7TEST RESULTS (A) .................................................................................... 38 4.3.8TEST RESULTS (B) .................................................................................... 42 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 46 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 46 FCC ID: KA2DWL-650PLUSB1 Report No.: RF920127R01A 3 Issued: March 7, 2003 Reference No.: RF920127R01 4.4.2TEST INSTRUMENTS ................................................................................ 46 4.4.3TEST PROCEDURES................................................................................. 47 4.4.4DEVIATION FROM TEST STANDARD ....................................................... 47 4.4.5TEST SETUP .............................................................................................. 47 4.4.6EUT OPERATING CONDITIONS................................................................ 47 4.4.7TEST RESULTS (A) .................................................................................... 48 4.4.8TEST RESULTS (B) .................................................................................... 48 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 49 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 49 4.5.2TEST INSTRUMENTS ................................................................................ 49 4.5.3TEST PROCEDURE ................................................................................... 50 4.5.4DEVIATION FROM TEST STANDARD ....................................................... 50 4.5.5TEST SETUP ............................................................................................…

Text truncated - open the document above for the full version.

FCC ID: KA2DWL-650PLUSB1 Report No.: RF920127R01A 67 Issued: March 7, 2003 Reference No.: RF920127R01 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: KA2DWL-650PLUSB1 Report No.: RF920127R01A 68 Issued: March 7, 2003 Reference No.: RF920127R01 RADIATED EMISSION TEST
