D-Link AirPlus DWL-800AP+ Enhanced 2.4 GHz Wireless Range Extender Manual Building Networks for People 2 Contents 1. Package Contents ............................................. 3 2. Introduction........................................................ 4 3. Wireless Basics ................................................. 8 4. Getting Started ................................................ 11 5. Using the Configuration Menu......................... 13 6. Troubleshooting............................................... 18 7. Networking Basics........................................... 24 8. Technical Specifications .................................. 53 9. Contacting Technical Support.......................... 55 10. Warranty and Registration ............................... 56 1. Package Contents Contents of Package: • D-Link AirPlus DWL-800AP+ Enhanced 2.4GHz Wireless Range Extender • Power Supply (5V, 2.5A) • Manual and Warranty on CD • Quick Installation Guide Note: Using a power supply with a different voltage rating than the one included with the DWL-800AP+ will cause damage and void the warranty for this product. If any of the above items are missing, please contact your reseller. System Requirements For Configuration: • Computer with Windows, Macintosh, or Linux-based operating system with an installed Ethernet adapter • Internet Explorer 6.0 or later, or Netscape Navigator version 6.0 or above, with JavaScript enabled 4 2. Introduction The D-Link AirPlus DWL-800AP+ Wireless Range Extender is an enhanced 802.11b high-performance, wireless device. It is an ideal way to extend the reach and number of computers connected to your wireless network. The DWL-800AP+ can act as an access point or a wireless repeater. In repeating mode, the DWL-800AP+ repeats the wireless signal of D-Link AirPlus access points and wireless routers to extend the range of your wireless network. Unlike most 802.11b devices, the DWL-800AP+ is capable of data transfer rates up to 22 Mbps (compared to the standard 11 Mbps) when used with other D-Link AirPlus products such as the DWL-520+ Wireless PCI Adapter, DWL-650+ Wireless Cardbus Adapter, and the DI-614+ Wireless Router. After completing the steps outlined in the Quick Installation Guide (included in your package) you will have the ability to share information and resources, such as files and printers, and enjoy the freedom that wireless networking brings. The DWL-800AP+ is compatible with most popular operating systems, including Macintosh, Linux and Windows, and can be integrated into a large network. This Manual is designed to help you connect the DWL-800AP+ and the D-Link AirPlus 2.4GHz Wireless Adapters into a network in Infrastructure mode. Please take a look at the Getting Started section in this manual to see an example of an Infrastructure network using the DWL-800AP+. This manual provides a quick introduction to wireless technology and its application as it relates to networking. Please take a moment to read through this manual if you need to get acquainted with wireless technology. Connections Ethernet Port – this RJ-45 Auto MDI/MDIX port provides connection to a network device using a Cat 5 Ethernet cable. (The Auto MDI/MDIX port accommodates either a Straight-Through or a Cross- Over cable and is auto- sensing.) Reset Button – press this button to revert to the factory default settings of the DWL-800AP+ Power Receptor – connect one end of the 5V DC Power Adapter (included) to the power receptor on the DWL-800AP+ and connect the other end of the Power Adapter to a power outlet. Factory Default Settings for the DWL-800AP+* Wireless Mode Repeater SSID default Channel 6 Transmission rates Auto Encryption No Administrator password Blank (no password needed) IP Address mode Static IP Address 192.168.0.30 IP Subnet 255.255.255.0 username admin (all lower case) Ethernet Reset Button Power Receptor Category 5 is the most reliable grade of twisted-pair cable. It Is available as either Straight-Through cable or Cross-Over cable. Always check your installation instructions to make sure that you have selected the correct type of Category 5 cable for your other networking devices. The DWL-800AP+ will accept either type of cable and will automatically sense the cable that you are using. 6 *By default, the DWL-810+ is set to Repeater mode. Just input the 12- digit Ethernet MAC address (e.g., 0080CO2C5551) of the remote router or access point that you wish to repeat. If you wish to use the DWL-800AP+ as an access point, you can select this option instead. Go to the Wireless tab in the Web Configuration Utility to make these selections. Features & Benefits • Extends the range of your wireless network • Up to 2X Faster with AirPlus Products - high-speed wireless data transfer rates up to 22Mbps. With twice the data rate and capacity, the DWL-800AP+ delivers media rich content such as digital images, videos, and MP3 files much faster than standard 802.11b networks • Fully 802.11b Compatible – Fully compatible with the IEEE 802.11b standard and interoperable with all existing 802.11b compliant devices • Stronger Network Security with 256-bit WEP Encryption – Supports 64/128/256-bit WEP encryption for higher level of security for your data and wireless communication than encryption found in existing 802.11b products • Setup Wizard – for easy configuration. • Web-based interface for Managing and Configuring – Easy-to-use interface independent of the operating system • 2 Different Operation Modes – Capable of operating in Access Point or Repeater mode. In Repeater mode the DWL-800AP+ will extend your existing wireless network up to 328 feet when used with the D-Link AirPlus DI-614+ Enhanced Wireless Router; the AirPlus DI-714P+ Enhanced Wireless Router with Print Server; the AirPro DI-764 Multimode Wireless Router, the AirPro DI-754 Multimode Wireless Router with the DWL-650+, or the AirPremier DWL-1000AP+ Enterprise Wireless Access Point • Auto-MDI/MDIX Ethernet port LE…

Text truncated - open the document above for the full version.

36 Networking Basics Assigning a Static IP Address with Macintosh OS X Go to the Apple Menu and select System Preferences. Click on Network Select Built-in Ethernet in the Show pull-down menu. Select Manually in the Configure pull-down menu. Input the Static IP Address, the Subnet Mask and the Router IP Address in the appropriate fields. Click Apply Now Networking Basics Selecting a Dynamic IP Address with Macintosh OS X Go to the Apple Menu and select System Preferences. Click on Network Select Built-in Ethernetin the Show pull-down menu. Select Using DHCPin the Configure pull-down menu. Click Apply Now The IP Address, Subnet mask, and the Router’s IP Address will appear in a few seconds. 38 Networking Basics Checking the Wireless Connection by Pinging For Windows XP and 2000: Go to Start > Run > type cmd. A window similar to Fig. 9.25 will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP address of the Wireless Router or Access Point. A good wireless connection will show four replies from the wireless router or access point, as shown. Checking the Wireless Connection by Pinging For Windows Me and 98: Go to Start > Run > type command. A window similar to Fig. 9.26 will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP address of the Wireless Router or Access Point. A good wireless connection will show four replies from the wireless router or access point, as shown. Adding and Sharing Printers in Windows XP After you have run the Network Setup Wizard on all the computers in your network (please see the Network Setup Wizard section at the beginning of Networking Basics,) you can use the Add Printer Wizard to add or share a printer on your network. Whether you want to add a local printer (a printer connected directly to one computer,) share an LPR printer (a printer connected to a print server) or share a network printer (a printer connected to your network through a Gateway/Router,) use the Add Printer Wizard. Please follow the directions below: First, make sure that you have run the Network Setup Wizard on all of the computers on your network. We will show you 3 ways to use the Add Printer Wizard 1. Adding a local printer 2. Sharing an network printer 3. Sharing an LPR printer 40 Networking Basics Adding a local printer (A printer connected directly to a computer) A printer that is not shared on the network and is connected directly to one computer is called a local printer. If you do not need to share your printer on a network, follow these directions to add the printer to one computer. • Go to Start> Printers and Faxes • Click on Add a printer Networking Basics Adding a local printer • Click Next • Select Local printer attached to this computer • (Deselect Automatically detect and install my Plug and Play printer if it has been selected.) • Click Next • Select Use the following port: • From the pull-down menu select the correct port for your printer (Most computers use the LPT1: port, as shown in the illustration.) • Click Next 42 Networking Basics Adding a local printer • Select and highlight the correct driver for your printer. • Click Next (If the correct driver is no t displayed, insert the CD o r floppy disk that came with your printer and click Have Disk.) • At this screen, you can change the name of the printer (optional.) • Click Next • Select Yes, to print a test page. A successful printing will confirm that you have chosen the correct driver. • Click Next Networking Basics Adding a local printer Click Finish Click OK This screen gives you information about your printer. When the test page has printed, 44 Networking Basics Adding a local printer Sharing a network printer After you have run the Network Setup Wizard on all the computers on your network, you can run the Add Printer Wizard on all the computers on your network. Please follow these directions to use the Add Printer Wizard to share a printer on your network: • Go to Start> Printers and Faxes A successful installation will display the printer icon as shown at right. You have successfully added a local printer. • Go to Start> Printers and Faxes Networking Basics Sharing a network printer • Click on Add a Printer • Click Next • Select Network Printer • Click Next 46 Networking Basics Sharing a network printer • Select Browse for a printer • Click Next • Select the printer you would like to share. • Click Next • Click Finish Networking Basics Sharing a network printer To check for proper installation: • Go to Start> Printers and Faxes The printer icon will appear at right, indicating proper installation. You have completed adding the printer. To share this printer on your network: • Remember the printer name • Run the Add Printer Wizard on all the computers on your network. • Make sure you have already run the Network Setup Wizard on all the network computers. After you run the Add Printer Wizard on all the computers in the network, you can share the printer. 48 Networking Basics Sharing an LPR printer To share an LPR printer (using a print server,) you will need a Print Server such as the DP-101P+. Please make sure that you have run the Network Setup Wizard on all the computers on your network. To share an LPR printer, please follow these directions: • Go to Start> Printers and Faxes • Click on Add a Printer The screen to the right will display. • Click Next • Select Local printer... • Click Next Networking Basics Sharing an LPR printer • Select Create a new port • From the pull-down menu, select Standard TCP/IP Port, as shown. • Click Next • Please read the instructions on this screen. • Click Next • Enter the Printer IP Address and the Port Name, as shown. • Click Next 50 Networking Basics Sharing an LPR printer • In this screen, select Custom. • Click Settings • Enter the Port Name and the Printer Name or IP Address. • Select LPR • Enter a Queue Name (if your Print-Server/ Gateway has more than one port, you will need a Queue name.) • Click OK Networking Basics Sharing an LPR printer • This screen will sho…

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Model: DWL-800AP+ Page 2 Page 3 Page 4 Model: DWL-810+ Page 5 Page 6 Page 7

Model No: DWL-810+ FCC ID: KA2DWL-800APPLUS Tested To Comply With FCC Standards FOR HOME OR OFFICE USE 40mm 40mm Model No: DWL-800AP+ FCC ID: KA2DWL-800APPLUS Tested To Comply With FCC Standards FOR HOME OR OFFICE USE 40mm 40mm

Page 8 Page 9 Page 10 Page 11 Page 12

FCC ID: KA2DWL-800APPLUS ADT No.920107R02 Operational Description The transmitter of the EUT is powered by power adapter and connected with managing computer through RJ45 port. The antenna type is Dipole antenna with Reverse SMA antenna connector. Under normal use condition, the user has to keep at least 20cm separation distance between radiator and the body of the user. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375 Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8, respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: KA2DWL-800APPLUS ADT No.: 920107R02 FCC TEST REPORT REPORT NO.: RF920107R02 MODEL NO.: DWL-800AP+, DWL-810+ ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:D-Link Corporation ADDRESS: No. 8, Li Hsing Rd VII, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 Lab Code: 200102-0 FCC ID: KA2DWL-800APPLUS ADT No.: 920107R02 RF Exposure Measurement (Mobile Device) 1. Introduction 2.4GHz frequency band is regarded specially as a dangerous band for its heating harmfulness to the human body. That’s why microwave oven is operating in this frequency band. The manufacturer whose product is working in this frequency band is obligatory to prove the harmfulness of his product. In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). FCC ID: KA2DWL-800APPLUS ADT No.: 920107R02 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 30-30061.40.1631.06 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 30-30027.50.0730.230 300-1500......F/150030 1500-100,000......1.030 F = Frequency in MHz 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. FCC ID: KA2DWL-800APPLUS ADT No.: 920107R02 5 Climate Condition The temperature and related humidity: 20 deg. C and 63 % RH 6. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20 cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. 7. Test Results 7.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 2dBi. 7.2 Output Power Into Antenna & RF Exposure Distance : CHANNEL CHANNEL FREQUENCY (MHz) OUTPUT POWER TO ANTENNA (mW) MINIMUM ALLOWABLE DISTANCE ( r ) FROM SKIN (Centi-Meter) 1241248.3052.461 6243748.0832.462 11246250.4662.522 The minimum allowable distance is very close to the enclosure of the antenna. So, the user has no need to worry about the harmfulness of radiation. But it is recommended to always keep, at least, 20 cm separation distance with the antenna.

FCC ID: KA2DWL-800APPLUS Report No.: RF920107R02 1 Issued: Jan. 22, 2003 FCC TEST REPORT REPORT NO.: RF920107R02 MODEL NO.: DWL-800AP+, DWL-810+ RECEIVED: Jan. 7, 2003 TESTED: Jan. 7~ Jan. 21, 2003 APPLICANT:D-LINK Corporation ADDRESS: No.8, Li- Hsin VII Road, Science Based Industrial Park Hsin-Chu, Taiwan ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 67 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: KA2DWL-800APPLUS Report No.: RF920107R02 2 Issued: Jan. 22, 2003 Table of Contents 1CERTIFICATION........................................................................................... 4 2SUMMARY OF TEST RESULTS .................................................................. 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 7 3.4DESCRIPTION OF SUPPORT UNITS ......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT................................................ 9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2 TEST INSTRUMENTS.................................................................................. 9 4.1.3 TEST PROCEDURES ................................................................................ 10 4.1.4 DEVIATION FROM TEST STANDARD....................................................... 10 4.1.5 TEST SETUP.............................................................................................. 11 4.1.6 EUT OPERATING CONDITIONS ............................................................... 11 4.1.7 TEST RESULTS ......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT................................................... 18 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 18 4.2.2 TEST INSTRUMENTS................................................................................ 19 4.2.3 TEST PROCEDURES ................................................................................ 20 4.2.4 DEVIATION FROM TEST STANDARD....................................................... 20 4.2.5 TEST SETUP.............................................................................................. 21 4.2.6 EUT OPERATING CONDITIONS ............................................................... 21 4.2.7 TEST RESULTS ......................................................................................... 22 4.36DB BANDWIDTH MEASUREMENT ......................................................... 27 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT ....................................... 27 4.3.2 TEST INSTRUMENTS................................................................................ 27 4.3.3 TEST PROCEDURE................................................................................... 28 4.3.4 DEVIATION FROM TEST STANDARD....................................................... 28 4.3.5 TEST SETUP.............................................................................................. 28 4.3.6 EUT OPERATING CONDITIONS ............................................................... 28 4.3.7 TEST RESULTS ......................................................................................... 29 4.3.8 TEST RESULTS ......................................................................................... 33 4.3.9 TEST RESULTS ......................................................................................... 37 4.4MAXIMUM PEAK OUTPUT POWER.......................................................... 41 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT .......... 41 4.4.2 INSTRUMENTS .......................................................................................... 41 4.4.3 TEST PROCEDURES ................................................................................ 42 4.4.4 DEVIATION FROM TEST STANDARD....................................................... 42 4.4.5 TEST SETUP.............................................................................................. 42 4.4.6 EUT OPERATING CONDITIONS ............................................................... 42 4.4.7 TEST RESULTS ......................................................................................... 43 4.4.8 TEST RESULTS ......................................................................................... 44 4.4.9 TEST RESULTS ......................................................................................... 45 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 46 FCC ID: KA2DWL-800APPLUS Report No.: RF920107R02 3 Issued: Jan. 22, 2003 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT................... 46 4.5.2 TEST INSTRUMENTS................................................................................ 46 4.5.3 TEST PROCEDURE................................................................................... 47 4.5.4 DEVIATION FROM TEST STANDARD....................................................... 47 4.5.5 TEST SETUP.............................................................................................. 47 4.5.6 EUT OPERATING CONDIT…

Text truncated - open the document above for the full version.

FCC ID: KA2DWL-800APPLUS Report No.: RF920107R0247Issued: Jan. 12, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: KA2DWL-800APPLUS Report No.: RF920107R0248Issued: Jan. 12, 2003 RADIATED EMISSION TEST
