KA2DWLG650MSuper G Smart Antenna Notebook Adapter

DSL-G604T 2 DWL-G650M User’s Manual D-Link Systems, Inc. Table of Contents Table of Contents Table of Contents ............................................................................................... 2 Package Contents .............................................................................................. 3 Introduction ....................................................................................................... 4 Features and Benefits ......................................................................................... 5 Wireless Basics ................................................................................................. 6 Installation Considerations ................................................................................ 8 Getting Started................................................................................................... 9 Using the Configuration Utility ......................................................................... 12 Networking Basics ........................................................................................... 21 Troubleshooting ............................................................................................... 35 Technical Specifications .................................................................................. 38 Contacting Technical Support ........................................................................ 40 Warranty.......................................................................................................... 41 Registration..................................................................................................... 45 3 DWL-G650M User’s Manual D-Link Systems, Inc.
At least 64MB of memory and a 500MHz processor
An 802.11g or 802.11b access point (for Infrastructure mode), or another 802.11g or 802.11b wireless adapter (for Ad-Hoc, Peer-to-Peer networking mode.) Package Contents Package Contents
D-Link DWL-G650M Super G TM Smart Antenna Wireless Notebook Adapter
Manual on CD
Printed Quick Installation Guide If any of the above items are missing, please contact your reseller. Minimum System Requirements
A computer or laptop with an available 32-bit Cardbus slot
Windows XP/2000 4 DWL-G650M User’s Manual D-Link Systems, Inc. The D-Link DWL-G650M Super G TM Smart Antenna Wireless Notebook Adapter is an 802.11g high-performance, wireless adapter that brings wireless networking to your laptop or desktop PC. With a maximum wireless signal rate of up to 108Mbps, you can connect to a wireless network at home, at the office or at any wireless hotspot. Now you can stay connected wherever you are and wherever you go. The DWL-G650M is Wi-Fi compatible, meaning that it can connect and interoperate with other 802.11b and 802.11g Wi-Fi-compliant wireless routers, access points and adapters. The DWL-G650M connects to any available Cardbus slot on a laptop Windows -based computer. A laptop computer with a DWL-G650M can be positioned virtually anywhere at a workstation to achieve the best available wireless signal reception - whether that workstation is in your office, on your deck or patio, by the pool, at the local coffee shop, or in an airport terminal while waiting to board your next flight. The adapter works with Microsoft Windows XP/2000 operating systems to ensure that you’ll be up and running on a wireless network in just a matter of seconds. The DWL-G650M provides an increased level of security with WPA-PSK. WPA-Personal is directed at home users who do not have the server based equipment required for user authentication. The method of authentication is similar to WEP because you define a “Pre-Shared Key” on the wireless router/AP. Once the pre-shared key is confirmed and satisfied on both the client and access point, then access is granted. the encryption method used is referred to as the Temporal Key Integrity Protocol (TKIP), which offers per-packet dynamic hashing. It also includes an integrity checking feature which ensures that the packets were not tampered with during wireless transmission. Introduction Introduction *Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and evironmental factors lower actual data throughput rate. 5 DWL-G650M User’s Manual D-Link Systems, Inc. Features and Benefits Features and Benefits Provides maximum wireless signal rate of up to 108Mbps*
* Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors lower actual data throughput rate. Fully 802.11b/802.11g compatible.
Supports Infrastructure networks via an access point and Peer-to-Peer communication in Ad-Hoc mode.
Better Security with WPA-PSK - In addition to 64-,128-bit WEP encryption, you can also securely connect to a wireless network using WPA-PSK.

User-friendly configuration and diagnostic utilities.
Utilizes Smart Antenna technology. 6 DWL-G650M User’s Manual D-Link Systems, Inc. Wireless Basics Wireless Basics Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards. D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. D-Link wireless products will allow you access to the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking brings. A wireless local area network (WLAN) is a computer network that transmits and receives data with radio signals instead of wires. WLANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people to w…

Text truncated - open the document above for the full version.

TCB Review Questions for (D-Link Super G Smart Antenna Notebook Adapter, KA2DWLG650M) -EMC- Question #1: It is not clear that how many antennas are available for the transition in this product. Please clarify the number of TX/RX antennas? Question #2: If more than one antenna are available for transmitting purpose, could those antennas perform space-time coding, beam-forming or Tx diversity either automatically or manually by the user? Question #3: Is there any special function regarding to the name “smart antenna”? -SAR- Question #1: N/A The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best Regards Steve Cheng / Technical Reviewer TCB/FCB/NB North American EMC Certification Services Inc. Email: [email protected] Tel: 403-241-8826

1 steve.cheng 寄件者: [email protected] 寄件日期: 2005年1月20日星期四 上午 2:04 收件者: steve.cheng 主旨: 回信: TCB Review Questions for (D-Link Super G MIMO Wireless NotebookAdapter, KA2DWLG650M) Dear Steve: Here are the answers: 1. There are two chip antenna for TX used. Two printed antenna for RX used. 2. This product is used the way of the TX auto diversity. 3. No. Only the function of diversity. Merry X'mas and Happy New Year Best Regards, Stephanie Hung (洪榭薇) Advance Data Technology Corporation (誠信科技) Website: www.adt.com.tw Tel: 886-3 318 3232 Ext. 1668 Fax: 886-3 327 0892 e-mail: [email protected] \(^o^)/ \(^o^)/ \(^o^)/ \(^o^)/ \(^o^)/ \(^o^)/ \(^o^)/ \ (^o^)/ "steve.cheng" <steve.cheng@nacs emc.com> 收件人 Wendy Liao <[email protected]>, 2005/01/20 下午 [email protected] 04:38 副本抄送 [email protected], 吳佳鑫 <[email protected]> 主旨 TCB Review Questions for (D-Link Super G MIMO Wireless NotebookAdapter, KA2DWLG650M) 2 TCB Review Questions for (D-Link Super G MIMO Wireless Notebook Adapter, KA2DWLG650M) -EMC- Question #1: It is not clear that how many antennas are available for the transmitting in this product. Please clarify the number of TX/RX antennas? Question #2: If more than one antenna are available for transmitting purpose, could those antennas perform space-time coding, beam-forming or Tx diversity either automatically or manually by the user? Question #3: Is there any special functions regarding to the name “Smart Antenna”? -SAR- Question #1: N/A The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best Regards Steve Cheng / Technical Reviewer TCB/FCB/NB North American EMC Certification Services Inc. Email: [email protected] Tel: 403-241-8826

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID Label Location

Page 3 Page 4 Page 5 Page 6

FCC ID: KA2DWLG650M Report No. RF931221L22 Operational Description This device is a Super G Smart Antenna Notebook Adapter which operates in the 2.4GHz frequency spectrum with throughput of up to 108Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 108Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is Printed antenna without connector. SAR evaluation has been performed with the typical laptop position and the product could be used in similar hosts and configuration. The other instruction, please have a look at the users manual.

FCC ID: KA2DWLG650M Report No.: RF931221L221Report Format Version 2.0.1 FCC TEST REPORT REPORT NO.: RF931221L22 MODEL NO.: DWL-G650M RECEIVED: Dec. 21, 2004 TESTED: Dec. 21 ~ Dec. 27, 2004 ISSUED: Dec. 28, 2004 APPLICANT: D-Link Corporation ADDRESS: No.8, Li-Hsin VII Road Science Based Industrial Park Hsin-Chu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 72 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: KA2DWLG650M Report No.: RF931221L222Report Format Version 2.0.1 Table of Contents 1.CERTIFICATION ......................................................................................................4 2.SUMMARY OF TEST RESULTS ..............................................................................5 2.1MEASUREMENT UNCERTAINTY ...........................................................................6 3.GENERAL INFORMATION.......................................................................................7 3.1GENERAL DESCRIPTION OF EUT.........................................................................7 3.2DESCRIPTION OF TEST MODES...........................................................................8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ..........................................8 3.4DESCRIPTION OF SUPPORT UNITS .....................................................................9 3.5CONFIGURATION OF SYSTEM UNDER TEST ....................................................10 4.TEST TYPES AND RESULTS ................................................................................ 11 4.1CONDUCTED EMISSION MEASUREMENT ......................................................... 11 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT....................................... 11 4.1.2 TEST INSTRUMENTS............................................................................................ 11 4.1.3 TEST PROCEDURES ............................................................................................ 12 4.1.4 DEVIATION FROM TEST STANDARD .................................................................. 12 4.1.5 TEST SETUP ......................................................................................................... 13 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 13 4.1.7 TEST RESULTS ..................................................................................................... 14 4.2RADIATED EMISSION MEASUREMENT ..............................................................20 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................ 20 4.2.2 TEST INSTRUMENTS............................................................................................ 21 4.2.3 TEST PROCEDURES ............................................................................................ 22 4.2.4 DEVIATION FROM TEST STANDARD .................................................................. 22 4.2.5 TEST SETUP ......................................................................................................... 23 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 23 4.2.7 TEST RESULTS ..................................................................................................... 24 4.2.8 TEST RESULTS (A) ............................................................................................... 25 4.2.9 TEST RESULTS (B) ............................................................................................... 28 4.36dB BANDWIDTH MEASUREMENT .....................................................................30 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................... 32 4.3.2 TEST INSTRUMENTS............................................................................................ 32 4.3.3 TEST PROCEDURE............................................................................................... 33 4.3.4 DEVIATION FROM TEST STANDARD .................................................................. 33 4.3.5 TEST SETUP ......................................................................................................... 33 4.3.6 EUT OPERATING CONDITIONS ........................................................................... 33 4.3.7 TEST RESULTS (A) ............................................................................................... 34 4.3.8 TEST RESULTS (B) ............................................................................................... 37 4.4MAXIMUM PEAK OUTPUT POWER .....................................................................42 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...................... 42 FCC ID: KA2DWLG650M Report No.: RF931221L223Report Format Version 2.0.1 4.4.2 INSTRUMENTS...................................................................................................... 42 4.4.1 TEST PROCEDURES ............................................................................................ 43 4.4.2 DEVIATION FROM TEST STANDARD .................................................................. 43 4.4.3 TEST SETUP ......................................................................................................... 43 4.4.4 EUT OPERATING CONDITIONS ........................................................................... 43 4.4.3 TEST RESU…

Text truncated - open the document above for the full version.

FCC ID: KA2DWLG650M Report No.: SA931221L221Report Format Version 2.0.1 SAR TEST REPORT REPORT NO.: SA931221L22 MODEL NO.: DWL-G650M RECEIVED: Dec. 23, 2004 TESTED: Dec. 27, 2004 ISSUED: Dec. 29, 2004 APPLICANT: D-Link Corporation ADDRESS: No.8,Li-Hsin VII Road Science Based Industrial Park Hsin-Chu,Taiwan ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 30 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: KA2DWLG650M Report No.: SA931221L222Report Format Version 2.0.1 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM .............................................. ....5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................13 4.DESCRIPTION OF SUPPORT UNITS ......................................................................14 5.TEST RESULTS ........................................................................................................15 5.1 TEST PROCEDURES ...............................................................................................15 5.2 MEASURED SAR RESULT .......................................................................................16 5.3 SAR LIMITS...............................................................................................................17 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................17 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................19 6.SYSTEM VALIDATION ..............................................................................................20 6.1 TEST EQUIPMENT ...................................................................................................20 6.2 TEST PROCEDURE .................................................................................................20 6.3 VALIDATION RESULT...............................................................................................22 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................23 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................24 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................24 7.2 ISOTROPY UNCERTAINTY......................................................................................24 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................25 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................25 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................25 7.6 RESPONSE TIME UNCERTAINTY...........................................................................26 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................27 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................27 7.9 PROBE POSITIONING .............................................................................................28 7.10 PHANTOM UNCERTAINTY ......................................................................................28 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................29 8.INFORMATION ON THE TESTING LABORATORIES ..............................................30 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: KA2DWLG650M Report No.: SA931221L223Report Format Version 2.0.1 1. CERTIFICATION PRODUCT : Super G Smart Antenna Notebook Adapter MODEL NO. : DWL-G650M BRAND NAME : D-Link APPLICANT : D-Link Corporation TESTED : Dec. 27, 2004 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Dec. 29, 2004 ( Andrea Hsia ) TECHNICAL ACCEPTANCE :, DATE:Dec. 29, 2004 Responsible for RF ( Ansen Lei ) APPROVED BY:, DATE:Dec. 29, 2004 ( Cody Chang, Deputy Manager ) FCC ID: KA2DWLG650M Report No.: SA931221L224Report Format Version 2.0.1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Super G Smart Antenna Notebook Adapter MODEL NO. DWL-G650M POWER SUPPLY 3.3Vdc from host equipment CLASSIFICATION Portable device, production unit MODULATION TYPE CCK, DQPSK, DBPSK for DSSS, 64QAM, 16QAM, QPSK, BPSK for OFDM RADIO TECHNOLOGY DSSS, OFDM TRANSFER RATE 802.11b: 11/5.5/2/1Mbp…

Text truncated - open the document above for the full version.

FCC ID: KA2DWLG650M Report No.: RF931221L2270Report Format Version 2.0.1 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: KA2DWLG650M Report No.: RF931221L2271Report Format Version 2.0.1 RADIATED EMISSION TEST
