2 DWL-G650M User’s Manual D-Link Systems, Inc. Table of Contents Table of Contents Table of Contents ...............................................................................................2 Package Contents ..............................................................................................3 Introduction .......................................................................................................4 Features and Benefits ......................................................................................... 5 Wireless Basics ..................................................................................................6 Installation Considerations .................................................................................8 Getting Started ...................................................................................................9 Using the Configuration Utility ......................................................................... 12 Networking Basics ...........................................................................................21 Troubleshooting ............................................................................................... 35 Technical Specifications ................................................................................... 38 Contacting Technical Support ........................................................................ 40 Warranty .......................................................................................................... 41 Registration .....................................................................................................45 3 DWL-G650M User’s Manual D-Link Systems, Inc. At least 64MB of memory and a 500MHz processor An 802.11g or 802.11b access point (for Infrastructure mode), or another 802.11g or 802.11b wireless adapter (for Ad-Hoc, Peer-to-Peer networking mode.) Package Contents Package Contents D-Link DWL-G650M 108G MIMO Wireless Notebook Adapter Manual on CD Printed Quick Installation Guide If any of the above items are missing, please contact your reseller. Minimum System Requirements A computer or laptop with an available 32-bit Cardbus slot Windows XP/2000 4 DWL-G650M User’s Manual D-Link Systems, Inc. The D-Link DWL-G650M 108G MIMO Wireless Notebook Adapter is an 802.11g high-performance, wireless adapter that brings wireless networking to your laptop or desktop PC. With a maximum wireless signal rate of up to 108Mbps, you can connect to a wireless network at home, at the office or at any wireless hotspot. Now you can stay connected wherever you are and wherever you go. The DWL-G650M is Wi-Fi compatible, meaning that it can connect and interoperate with other 802.11b and 802.11g Wi-Fi-compliant wireless routers, access points and adapters. The DWL-G650M connects to any available Cardbus slot on a laptop Windows -based computer. A laptop computer with a DWL-G650M can be positioned virtually anywhere at a workstation to achieve the best available wireless signal reception - whether that workstation is in your office, on your deck or patio, by the pool, at the local coffee shop, or in an airport terminal while waiting to board your next flight. The adapter works with Microsoft Windows XP/2000 operating systems to ensure that you’ll be up and running on a wireless network in just a matter of seconds. The DWL-G650M provides an increased level of security with WPA-PSK. WPA-Personal is directed at home users who do not have the server based equipment required for user authentication. The method of authentication is similar to WEP because you define a “Pre-Shared Key” on the wireless router/AP. Once the pre-shared key is confirmed and satisfied on both the client and access point, then access is granted. the encryption method used is referred to as the Temporal Key Integrity Protocol (TKIP), which offers per-packet dynamic hashing. It also includes an integrity checking feature which ensures that the packets were not tampered with during wireless transmission. Introduction Introduction *Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and evironmental factors lower actual data throughput rate. 5 DWL-G650M User’s Manual D-Link Systems, Inc. Features and Benefits Features and Benefits Provides maximum wireless signal rate of up to 108Mbps* * Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors lower actual data throughput rate. Fully 802.11b/802.11g compatible. Supports Infrastructure networks via an access point and Peer-to-Peer communication in Ad-Hoc mode . Better Security with WPA-PSK - In addition to 64-,128-bit WEP encryption, you can also securely connect to a wireless network using WPA-PSK. User-friendly configuration and diagnostic utilities. Utilizes Smart Antenna technology. 6 DWL-G650M User’s Manual D-Link Systems, Inc. Wireless Basics Wireless Basics Wireless users can use the same applications they use on a wired network. Wireless adapter cards used on laptop and desktop systems support the same protocols as Ethernet adapter cards. D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. D-Link wireless products will allow you access to the data you want, when and where you want it. You will be able to enjoy the freedom that wireless networking brings. A wireless local area network (WLAN) is a computer network that transmits and receives data with radio signals instead of wires. WLANs are used increasingly in both home and office environments, and public areas such as airports, coffee shops and universities. Innovative ways to utilize WLAN technology are helping people to work and communicate more efficient…
Text truncated - open the document above for the full version.
21 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Networking Basics Using the Network Setup Wizard in Windows XP In this section you will learn how to establish a network at home or work, using Microsoft Windows XP. Note: Please refer to websites such as http://www.homenethelp.com and http://www.microsoft.com/windows2000 for information about networking computers using Windows 2000,/Me/98SE. Go to Start>Control Panel>Network Connections Select Set up a home or small office network When this screen appears, click Next. 22 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Please follow all the instructions in this window: Click Next . In the following window, select the best description of your computer. If your computer connects to the Internet through a router, select the second option as shown. Click Next. 23 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Enter a Computer description and a Computer name (optional.) Click Next. Enter a Workgroup name. All computers on your network should have the same Workgroup name. Click Next. 24 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Please wait while the Network Setup Wizard applies the changes. When the changes are complete, click Next . Please wait while the Network Setup Wizard configures the computer. This may take a few minutes. 25 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics In the window below, select the option that fits your needs. In this example, Create a Network Setup Disk has been selected. You will run this disk on each of the computers on your network. Click Next . Click Next . Insert a disk into the Floppy Disk Drive, in this case drive A. 26 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Please read the information under Here’s how in the screen below. After you complete the Network Setup Wizard you will use the Network Setup Disk to run the Network Setup Wizard once on each of the computers on your network. Click Next. 27 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Please read the information on this screen, then click Finish to complete the Network Setup Wizard . The new settings will take effect when you restart the computer. Click Yes to restart the computer. You have completed configuring this computer. Next, you will need to run the Network Setup Disk on all the other computers on your network. After running the Network Setup Disk on all your computers, your new wireless network will be ready to use. 28 DWL-G650M User’s Manual D-Link Systems, Inc. Please read the information on this screen, then click Finish to complete the Network Setup Wizard . Networking Basics The new settings will take effect when you restart the computer. Click Yes to restart the computer. You have completed configuring this computer. Next, you will need to run the Network Setup Disk on all the other computers on your network. After running the Network Setup Disk on all your computers, your new wireless network will be ready to use. 29 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Naming your Computer To name your computer using Windows XP, please follow these directions: Click Start (in the lower left corner of the screen). Right-click on My Computer. Select Properties. Select the Computer Name Tab in the System Properties window. You may enter a Computer Description if you wish; this field is To rename the computer and join a domain, click Change . 30 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Naming Your Computer Checking the IP Address in Windows XP In this window, enter the Computer name. Select Workgroup and enter the name of the Workgroup. All computers on your network must have the same Workgroup name. Click OK. All wireless adapter-equipped computers in your network must be in the same IP address range (see Getting Started in this manual for a definition of IP address range.) To check on the IP address of an adapter, please do the following: Right-click on the Local Area Connection icon in the task bar. Click on Status.
31 DWL-G650M User’s Manual D-Link Systems, Inc. Click the Support tab. Click Close. Assigning a Static IP Address in Windows XP/2000 Note: Many broadband routers will automatically assign IP addresses to the computers on the network, using DHCP (Dynamic Host Configuration Protocol) technology. If you are using a DHCP-capable router you will not need to assign static IP addresses. If you are not using a DHCP capable router, or you need to assign a static IP address, please follow these instructions: Go to Start. Click on Control Panel . Checking the IP Address in Windows XP Networking Basics 32 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Double-click on Network Connections. Click on Properties . Right-click on Local Area Connections. Assigning a Static IP Address in Windows XP/2000 33 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Input your IP address and subnet mask. (The IP addresses on your network must be within the same range. For example, if one computer has an IP address of 192.168.0.2, the other computers should have IP addresses that are sequential, like 192.168.0.3 and 192.168.0.4. The subnet mask must be the same for all the computers on the network.) Input your DNS server addresses. (Note: If you are entering a DNS server, you must enter the IP address of the Default Gateway.) The DNS server information will be supplied by your ISP (Internet Service Provider.) Click OK. Click on Internet Protocol (TCP/IP). Click Properties. Assigning a Static IP Address in Windows XP/2000 34 DWL-G650M User’s Manual D-Link Systems, Inc. Networking Basics Checking the Wireless Connection by Pinging in Windows XP and 2000 Go to Start > Run > type cmd. A window similar to this one will appear. Type ping xxx.xxx.xxx.xxx, where xxx is the IP address of the wireless router or access point. A good wireless connection will show four replies from the wireless router or access point, as shown. 35 DWL-G650M User’s Manual D-Link Systems, Inc. 1. How do I check to see that the drivers for the DWL-G650M are installed properly? Click Device Manager. Select the Hardware Tab. Troubleshooting Go to Start > My Computer > Properties. This chapter provides solutions to problems that can occur during the installation and operation of the DWL-G650M. Read the following descriptions if you are having problems. (The examples below are illustrated in Windows XP. If you have another operating system, these solutions will still apply although the appearance on your computer screen may differ.) 36 DWL-G650M User’s Manual D-Link Systems, Inc. Double-click on Network Adapters. Right-click on D-Link DWL-G650M 108G MIMO Wireless Notebook Adapter . Select Properties to check that the drivers are installed properly. Look under Device Status to check that the device is working properly. Click OK. Troubleshooting D-Link DWL-G650M 108G MIMO Wireless Notebook Adapter D-Link DWL-G650M 108G MIMO Wireless Notebook Adapter D-Link DWL-G650M 108G MIMO Wireless Notebook Adapterr 37 DWL-G650M User’s Manual D-Link Systems, Inc. Troubleshooting 2. What variables may cause my wireless products to lose reception? D-Link products let you access your network from virtually anywhere you want. However, the positioning of the products within your environment will affect the wireless range. Please refer to Installation Considerations in the Wireless Basics section of this manual for further information about the most advantageous placement of your D-Link wireless products. 3. Why does my wireless connection keep dropping? 4. Why can’t I get a wireless connection? If you have enabled encryption on the DWL-G650M, you must also enable encryption on all wireless devices in the network in order to establish a wireless connection. If you are using 2.4GHz cordless phones, X-10 equipment or other home security systems, ceiling fans, and lights, your wireless connection will degrade dramatically or drop altogether. Try changing the channel on your router, access point and wireless adapter to a different channel to avoid interference. Keep your product away (at least 3-6 feet) from electrical devices that generate RF noise, like microwaves, monitors, electric motors, etc. The encryption settings are: 64-,128- bit. Make sure that the encryption bit level is the same on the router and the DWL-G650M. Make sure that the SSID on the wireless router (if you have one in your network) and the DWL-G650M are exactly the same. If they are not, wireless connection will not be established. The default SSID is default. 38 DWL-G650M User’s Manual D-Link Systems, Inc. Standards Technical Specifications Technical Specifications Data Rates CSMA/CA with ACK IEEE 802.11g IEEE 802.11b IEEE 802.11 Temperature Operating: 0ºC to 55ºC (32ºF to 131ºF) 95% maximum, non-condensing Humidity Internal Antenna Type Diversity 32-bit Cardbus Bus Type Security 64-, 128-bit WEP WPA-PSK 54, 48, 36,24, 18, 11, 9, 6 5.5, 2, 1Mbps (with Automatic Fallback) Media Access Control Range 1 Indoors: Up to 328 feet (100 meters) Outdoors: Up to 1,312 feet (400 meters) 1 - Environmental factors may adversely affect wireless signal range Diagnostic LEDs Power Activity 39 DWL-G650M User’s Manual D-Link Systems, Inc. Technical Specifications Receiver Sensitivity 5.5Mbps CCK 2Mbps QPSK 1Mbps BPSK 11Mbps OFDM 9Mbps OFDM 6Mbps OFDM 24Mbps OFDM 18Mbps OFDM 12Mbps OFDM 54Mbps OFDM 48Mbps OFDM 36Mbps OFDM 14dBm ± 2dB Transmitter Output Power L = 4.64 inches W = 2.13 inches H = 0.34 inches Physical Dimensions 0.12 lb. (4.4g) Weight 1 year Warranty 40 DWL-G650M User’s Manual D-Link Systems, Inc. Contacting Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our web site, or by phone. Tech Support for customers within the …
Text truncated - open the document above for the full version.
1 Steve Cheng 寄件者: [email protected] 寄件日期: 2005年5月3日星期二 上午 2:09 收件者: steve.cheng 副本: [email protected] 主旨: 回信: TCB Review Comments for (KA2DWLG650MB1,940311L15) Dear Steve Our reply as below: Question #1: From the block diagram, this device seems has two Receiving chains and one transiting chain with 4 antennas. Please clarify how all these antennas will be configured in the transmission and receiving function. Answer: The product is a 1x3 MIMO, i.e. has only one Tx antenna and 3 Rx antennas due to the power limitation. Tx diversity has been implemented on the Tx site and only one antenna could be selected for the data transmission. Question #2: If in case that this product has only one transmitting chain, could signal send to more than one antenna at same time or only one antenna activated at a time? Answer: As described above, the product adopted the Tx diversity scheme and only one antenna could be selected for the transmission. Thanks for your assistance! Best Regards Wendy Liao Wendy Liao (廖意紋)/ ADT Corp. TEL: 03-318-3232 EXT 1625 FAX: 03-318-5050 Email: [email protected] 地址:桃園縣龜山鄉文化村華亞二路19號
Page 1 CONSTRUCTION PHOTOS OF EUT Page 2
Page 1 Label location (FCC ID: KA2DWLG650MB1)
FCC ID: KA2DWLG650MB1
Page 3 Page 4 Page 5
FCC ID: KA2DWLG650MB1 Report No.: RF940311L15 Technical Description This device is a 108G MIMO Wireless Notebook Adapter which operates in the 2.4GHz frequency spectrum with throughput of up to 108Mbps which OFDM technique for turbo mode will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is Chip antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.
D3: 3G DOSIMETRIC E-FIELD PROBE
D4: 2450MHz SYSTEM VALIDATION DIPOLE SN: 716
D4: DAE SN: 510
APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM
A - 1 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION Bottom Position of EUT The Bottom of the EUT to the flat phantom distance 16 mm A - 2 EUT Photo A - 3 Liquid Level Photo MSL 2450MHz D=150mm A - 4 Date/Time: 03/16/05 12:03:15 Test Laboratory: Advance Data Technology DWL-G650M-Mode 1 11b Bottom DUT: DWL-G650M ; Type: PCMCIA Card ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Low Channel 1/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.214 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 9.31 V/m Peak SAR (extrapolated) = 0.467 W/kg SAR(1 g) = 0.222 mW/g; SAR(10 g) = 0.116 mW/g Maximum value of SAR (measured) = 0.237 mW/g A - 5 A - 6 Date/Time: 03/16/05 12:36:26 Test Laboratory: Advance Data Technology DWL-G650M-Mode 1 11b Bottom DUT: DWL-G650M ; Type: PCMCIA Card ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.98 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Mid Channel 4/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.220 mW/g Mid Channel 4/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.35 V/m Peak SAR (extrapolated) = 0.462 W/kg SAR(1 g) = 0.217 mW/g; SAR(10 g) = 0.112 mW/g Maximum value of SAR (measured) = 0.232 mW/g A - 7 Date/Time: 03/16/05 13:02:11 Test Laboratory: Advance Data Technology DWL-G650M-Mode 1 11b Bottom DUT: DWL-G650M ; Type: PCMCIA Card ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used (interpolated): f = 2462 MHz; σ = 2.06 mho/m; ε r = 50.8; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Mid Channel 7/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.188 mW/g Mid Channel 7/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.24 V/m Peak SAR (extrapolated) = 0.410 W/kg SAR(1 g) = 0.187 mW/g; SAR(10 g) = 0.096 mW/g Maximum value of SAR (measured) = 0.202 mW/g A - 8 Date/Time: 03/16/05 13:36:51 Test Laboratory: Advance Data Technology DWL-G650M-Mode 2 11g Bottom DUT: DWL-G650M ; Type: PCMCIA Card ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.4 Build 3 ; Postprocessing SW: SEMCAD, V1.8 Build 130 Low Channel 1/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.091 mW/g Low Channel 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.69 V/m Peak SAR (extrapolated) = 0.206 W/kg SAR(1 g) = 0.091 mW/g; SAR(10 g) = 0.048 mW/g Maximum value of SAR (measured) = 0.097 mW/g A - 9 Date/Time: 03/16/05 14:32:43 Test Laboratory: Advance Data Technology DWL-G650M-Mode 2 11g Bottom DUT: DWL-G650M ; Type: PCMCIA Card ; Test Frequency: 2437 MHz Communication System: 802.11g ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used (interpolated): f = 2437 MHz; σ = 1.98 mho/m; ε r = 50.9; ρ = 1000 kg/m 3 ; Liquid level : 150 mm Phantom section: Flat Section ; Separation distance : 16 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechan…
Text truncated - open the document above for the full version.
B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION
FCC ID: KA2DWLG650B1 Report No.: SA940311L151Report Format Version 2.0.1 SAR TEST REPORT REPORT NO.: SA940311L15 MODEL NO.: DWL-G650M RECEIVED: Mar. 14, 2005 TESTED: Mar. 16, 2005 ISSUED: Mar. 18, 2005 APPLICANT: D-Link Corporation ADDRESS: No.8,Li-Hsin VII Road Science Based Industrial Park Hsin-Chu,Taiwan ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 30 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: KA2DWLG650B1 Report No.: SA940311L152Report Format Version 2.0.1 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF EUT............................................................................4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM .............................................. ....5 2.4 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................13 4.DESCRIPTION OF SUPPORT UNITS ......................................................................14 5.TEST RESULTS ........................................................................................................15 5.1 TEST PROCEDURES ...............................................................................................15 5.2 MEASURED SAR RESULT .......................................................................................16 5.3 SAR LIMITS...............................................................................................................17 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................17 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................19 6.SYSTEM VALIDATION ..............................................................................................20 6.1 TEST EQUIPMENT ...................................................................................................20 6.2 TEST PROCEDURE .................................................................................................20 6.3 VALIDATION RESULT...............................................................................................22 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................23 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................24 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................24 7.2 ISOTROPY UNCERTAINTY......................................................................................24 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................25 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................25 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................25 7.6 RESPONSE TIME UNCERTAINTY...........................................................................26 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................27 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................27 7.9 PROBE POSITIONING .............................................................................................28 7.10 PHANTOM UNCERTAINTY ......................................................................................28 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................29 8.INFORMATION ON THE TESTING LABORATORIES ..............................................30 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: KA2DWLG650B1 Report No.: SA940311L153Report Format Version 2.0.1 1. CERTIFICATION PRODUCT : 108G MIMO Wireless Notebook Adapter MODEL NO. : DWL-G650M BRAND NAME : D-Link APPLICANT : D-Link Corporation TESTED : Mar. 186, 2005 TEST SAMPLE : ENGINEERING SAMPLE STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE:Mar. 18, 2005 ( Windy Chou) TECHNICAL ACCEPTANCE :, DATE:Mar. 18, 2005 Responsible for RF ( Ansen Lei ) APPROVED BY:, DATE:Mar. 18, 2005 ( Cody Chang, Deputy Manager ) FCC ID: KA2DWLG650B1 Report No.: SA940311L154Report Format Version 2.0.1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT PRODUCT Super G Smart Antenna Notebook Adapter MODEL NO. DWL-G650M POWER SUPPLY 3.3Vdc from host equipment CLASSIFICATION Portable device, production un…
