KA2GL5500A1Wireless AC1300 Gaming Router

User Manual DRAFT VERSION | May 30, 2013 DGL-5500 AC1300 Gaming Router iD-Link DGL-5500 User Manual D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. Copyright © 2013 by D-Link Systems, Inc. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Systems, Inc. Preface RevisionDateDescription Draft May 30, 2013• Initial release for Revision A1 iiD-Link DGL-5500 User Manual Table of Contents Preface .................................................................................i Manual Revisions ...........................................................................i Trademarks ......................................................................................i Product Overview ..............................................................1 Package Contents .........................................................................1 System Requirements .................................................................2 Introduction ...................................................................................3 Hardware Overview .....................................................................4 Connections ...........................................................................4 LEDs ...........................................................................................5 Installation .........................................................................6 Before you Begin ...........................................................................6 Wireless Installation Considerations ......................................7 Connect to your Network ..........................................................8 Connect to an Existing Router ...............................................11 Configuration ...................................................................13 Quick Setup Wizard ....................................................................14 Web-based Configuration Utility ..........................................18 Setup .......................................................................................19 Static (assigned by ISP) ................................................20 Dynamic (Cable) .............................................................21 PPPoE (DSL) ......................................................................22 Internet Connection Setup Wizard .......................................23 Wireless Settings .................................................................27 Wireless Connection Setup Wizard..........................28 Manual Wireless Settings ............................................30 802.11n/g (2.4GHz) ..................................................30 802.11ac/n/a (5GHz) ...............................................31 Wireless Security .................................................................32 What is WPA? ...................................................................32 WPA/WPA2-Personal (PSK) .........................................33 Configure WPA/WPA2-Enterprise (RADIUS)..........34 Network Settings ................................................................35 Router Settings ...............................................................35 DHCP Server Settings ...................................................36 DHCP Reservation .........................................................38 Advanced ...............................................................................39 Media Server ....................................................................39 Virtual Server ...................................................................40 Port Forwarding .............................................................41 Network Filters ................................................................42 Access Control .................................................................43 Access Control Wizard ............................................43 Firewall Settings .............................................................46 DMZ ....................................................................................48 Maintenance .........................................................................49 Admin.................................................................................49 Time ....................................................................................50 System ...............................................................................51 Table of Contents iiiD-Link DGL-5500 User Manual Table of Contents Status ......................................................................................52 Device Info .......................................................................52 Logs.....................................................................................53 Statistics ............................................................................54 Connect a Wireless Client to your Router ......................55 WPS Button ...................................................................................55 Windows® 8 ...................................................................................56 Windows® 7 ...................................................................................58 WPA/WPA2 ............................................................................58 WPS ..........................................................................................61 Windows Vista® .............................…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6

Label location

DGL-5500 FCC ID : KA2GL5500A1 IC : 4216A-GL5500A1 Model : DGL-5500A1 CAN ICES-3 (B)/NMB-3(B) Default router settings: http://dlinkrouter.local. or http://192.168.0.1 Username : Admin Password : (leave the field blank)

Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14 2.4GHz antenna Page 15 5GHz antenna Page 16

FCC ID: KA2GL5500A1 Report No.: RF130422C26 Operational Description This device is a Wireless AC1300 Gaming Router which operates in both of 2.4GHz and 5GHz bands; the maximum data rate could be up to 866.7Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 866.7Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by the 12Vdc from AC adapter. The antenna is Printed antenna with I-PEX antenna connector. For more detailed instruction, please take a look at the user’s manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA130422C26 1 of 5 Report Format Version 5.0.0 Reference No.: 130415C13 RF EXPOSURE REPORT REPORT NO.: SA130422C26 MODEL NO.: DGL-5500 FCC ID: KA2GL5500A1 RECEIVED: Apr. 22, 2013 TESTED: Apr. 22 ~ May 29, 2013 ISSUED: May 29, 2013 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmannm, Fountain Valley, California, United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-com pliance to the specification. Report No.: SA130422C26 2 of 5 Report Format Version 5.0.0 Reference No.: 130415C13 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................................ 3 1. CERTIFICATION ............................................................................................................ 4 2. RF EXPOSURE .............................................................................................................. 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................ 5 2.2 MPE CALCULATION FORMULA ................................................................................... 5 2.3 CLASSIFICATION .......................................................................................................... 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................................. 5 Report No.: SA130422C26 3 of 5 Report Format Version 5.0.0 Reference No.: 130415C13 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130422C26 Original release May 29, 2013 Report No.: SA130422C26 4 of 5 Report Format Version 5.0.0 Reference No.: 130415C13 1. CERTIFICATION PRODUCT: Wireless AC1300 Gaming Router MODEL NO.: DGL-5500 BRAND: D-Link APPLICANT: D-Link Corporation TESTED: Apr. 22 ~ May 29, 2013 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (model: DGL-5500) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : May 29, 2013 Polly Chien / Specialist APPROVED BY : , DATE : May 29, 2013 Ken Liu / Senior Manager Report No.: SA130422C26 5 of 5 Report Format Version 5.0.0 Reference No.: 130415C13 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 2.4 Calculation result of maximum conducted power FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 29.87 4.8 20 0.583 1 5180-5240 16.81 3.01 20 0.019 1 5745-5825 25.78 3.01 20 0.151 1 NOTE: 2.4GHz: Directional gain = 0dBi + 10log(3) = 4.8dBi 5GHz: Directional gain = 0dBi + 10log(2) = 3.01dBi --END---

Report No.: RF130422C26 1 of 102 Report Format Version 5.1.0 Reference No.: 130415C13 FCC TEST REPORT (15.247) REPORT NO.: RF130422C26 MODEL NO.: DGL-5500 FCC ID: KA2GL5500A1 RECEIVED: Apr. 22, 2013 TESTED: Apr. 22 ~ May 29, 2013 ISSUED: May 29, 2013 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Hermann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF130422C26 2 of 102 Report Format Version 5.1.0 Reference No.: 130415C13 TABLE OF CONTENTS RELEASE CONTROL RECORD .............................................................................................................. 5 1. CERTIFICATION ....................................................................................................................... 6 2. SUMMARY OF TEST RESULTS .............................................................................................. 7 2.1 MEASUREMENT UNCERTAINTY ............................................................................................ 7 3. GENERAL INFORMATION ....................................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ......................................................................................... 8 3.2 DESCRIPTION OF TEST MODES ......................................................................................... 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ......................................... 11 3.3 DESCRIPTION OF SUPPORT UNITS ................................................................................... 15 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST .................................................................... 16 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................................ 17 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ............................................................. 18 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................................. 18 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............................. 18 4.1.2 TEST INSTRUMENTS ............................................................................................................ 19 4.1.3 TEST PROCEDURES ............................................................................................................. 20 4.1.4 DEVIATION FROM TEST STANDARD ................................................................................... 20 4.1.5 TEST SETUP .......................................................................................................................... 21 4.1.6 EUT OPERATING CONDITIONS ........................................................................................... 21 4.1.7 TEST RESULTS ...................................................................................................................... 22 4.2 CONDUCTED EMISSION MEASUREMENT ......................................................................... 37 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ....................................................... 37 4.2.2 TEST INSTRUMENTS ............................................................................................................ 37 4.2.3 TEST PROCEDURES ............................................................................................................. 38 4.2.4 DEVIATION FROM TEST STANDARD ................................................................................... 38 4.2.5 TEST SETUP .......................................................................................................................... 38 4.2.6 EUT OPERATING CONDITIONS ........................................................................................... 38 4.2.7 TEST RESULTS ...................................................................................................................... 39 4.3 6dB BANDWIDTH MEASUREMENT ...................................................................................... 43 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................................... 43 4.3.2 TEST SETUP .......................................................................................................................... 43 4.3.3 TEST INSTRUMENTS .........…

Text truncated - open the document above for the full version.

Report No.: RF130422C26-1 1 of 53 Report Format Version 5.1.0 Reference No.: 130415C13 FCC TEST REPORT (15.407) REPORT NO.: RF130422C26-1 MODEL NO.: DGL-5500 FCC ID: KA2GL5500A1 RECEIVED: Apr. 22, 2013 TESTED: Apr. 24 ~ May 29, 2013 ISSUED: May 29, 2013 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Hermann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the com pliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF130422C26-1 2 of 53 Report Format Version 5.1.0 Reference No.: 130415C13 TABLE OF CONTENTS RELEASE CONTROL RECORD ......................................................................................................... 4 1. CERTIFICATION ..................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................................ 6 2.1 MEASUREMENT UNCERTAINTY ......................................................................................... 6 3. GENERAL INFORMATION ..................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ....................................................................................... 7 3.2 DESCRIPTION OF TEST MODES ......................................................................................... 9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL....................................... 10 3.3 DUTY CYCLE OF TEST SIGNAL ......................................................................................... 12 3.4 DESCRIPTION OF SUPPORT UNITS ................................................................................. 13 3.4.1 CONFIGURATION OF SYSTEM UNDER TEST .................................................................. 14 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS ...................................................... 15 4. TEST TYPES AND RESULTS .............................................................................................. 16 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .............................................. 16 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ........................... 16 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS ....................... 16 4.1.3 TEST INSTRUMENTS .......................................................................................................... 17 4.1.4 TEST PROCEDURES .......................................................................................................... 18 4.1.5 DEVIATION FROM TEST STANDARD ................................................................................ 18 4.1.6 TEST SETUP ........................................................................................................................ 19 4.1.7 EUT OPERATING CONDITION ........................................................................................... 19 4.1.8 TEST RESULTS ................................................................................................................... 20 4.2 CONDUCTED EMISSION MEASUREMENT ....................................................................... 31 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................................... 31 4.2.2 TEST INSTRUMENTS .......................................................................................................... 31 4.2.3 TEST PROCEDURES .......................................................................................................... 32 4.2.4 DEVIATION FROM TEST STANDARD ................................................................................ 32 4.2.5 TEST SETUP ........................................................................................................................ 32 4.2.6 EUT OPERATING CONDITIONS ......................................................................................... 32 4.2.7 TEST RESULTS ................................................................................................................... 33 4.3 PEAK TRANSMIT POWER MEASUREMENT ..................................................................... 37 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT .................................................. 37 4.3.2 TEST SETUP ...............…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
