KA2IR501A1Wireless N 150 Home Router

DIR-501A1 ENGLISH Quick Install Guide Wireless N 150 Home Router Thank you for purchasing the DIR-501A1 Wireless N 150 Home Router. Follow the easy steps in this guide to properly set up your router. Please verify that all the package contents listed below are available. Technical Support Having trouble installing your new product? D-Link’s website contains the latest user documentation and software updates for D-Link products. U.S. and Canadian customers can contact D-Link Technical Support through our website or by phone. United States Telephone: (877) 453-5465 Internet: http://support.dlink.com Canada Telephone: (800) 361-5265 Internet: http://support.dlink.ca Version 1.0 | August 03, 2010 6IR501Q...01G Power LED A solid light indicates a proper connection to the power supply. Internet LED A solid light indicates connection on the Internet port. This LED blinks during data transmission. WLAN LED A solid light indicates that the wireless segment is ready. This LED blinks during wireless data transmission. LAN LEDs (1-4) A solid light indicates a connection to an Ethernet-enabled computer on ports 1-4. This LED blinks during data transmission. LEDs Step 5 From the computer you connected to the router, open a web browser and enter http://192.168.0.1. Then, press Enter and you will be directed to the D-Link Setup Wizard page. Step 6 Follow the on-screen instructions to configure your D-Link router. Before You Begin • You can only use the Ethernet port on your modem. If you were using the USB connection before using the router, then you must turn off your modem, disconnect the USB cable and connect an Ethernet cable to the Internet port on the router, then turn the modem back on. In some cases, you may need to call your ISP to change connection types (USB to Ethernet). • If you have DSL and are connecting via PPPoE, make sure you disable or uninstall any PPPoE software such as WinPoet, Broadjump, or Enternet 300 from your computer or you will not be able to connect to the Internet. • Make sure to use the computer you were connected to the Internet with. Package Contents If any of the above items are missing, please contact your reseller. DIR-501A1 Wireless N 150 Home Router Ethernet Cable Power Adapter Router Installation Step 1 Position your router close to your modem and the computer that is already online. Place this router in an open area of your intended work area for better wireless coverage. Step 2 Unplug the Ethernet cable from your modem that is connected to your computer. Plug it into the blue port labled 1 on the back of your router. The router is now connected to your computer. Step 3 Plug one end of the included Ethernet cable that came with your router into the port labeled INTERNET on the back of the router. Plug the other end of this cable into the Ethernet port on your modem. Step 4 Connect the supplied power adapter into the power port on the back of the router and then plug into a power outlet or surge protector. Verify the power light is lit. Below is a basic network setup. DIR-501A1 R outer Broadband Modem Wireless Laptop Desktop Computer Router Placement To get the best wireless coverage, place your router in an open area away from your computer, monitor, and speakers. Try to position the router so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal. 5V --- 3A 12 LAN34INTERNET RESET INTERNET Copyright ©2010 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and other countries. Other trademarks are the property of their respective owners. Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted on the packaging. Visit www.dlink.com for more details. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. IEEE 802.11b or 802.11g operation of this product i…

Text truncated - open the document above for the full version.

Date: Aug.05 , 2010 FCC ID：KA2IR501A1 Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: No.8, Jiu Cheng Ling, Jiaokeng Village,Sinhua Township, Tainan Hsien 712,Taiwan R.O.C. Name: Daphne Liang Job Title: Section Manager Email: [email protected] I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: D-Link / DIR-501 FCC ID: KA2IR501A1 Product Name: Wireless N 150 Home Router Signature FCC grantee contact person information.

Report No.T100716302 Page 1 of 15 External Photo Report No.T100716302 Page 2 of 15 Report No.T100716302 Page 3 of 15

1:1 4 9 . 4 79.4 2

Report No.T100716302 Page 4 of 15 Internal Photo Report No.T100716302 Page 5 of 15 Report No.T100716302 Page 6 of 15 Report No.T100716302 Page 7 of 15 Report No.T100716302 Page 8 of 15 Report No.T100716302 Page 9 of 15 Report No.T100716302 Page 10 of 15 Power Adapter Photo (Model : MU05-P050100-A1) Report No.T100716302 Page 11 of 15 Report No.T100716302 Page 12 of 15 Power Adapter Photo (Model : AMS47-0501000FU) Report No.T100716302 Page 13 of 15 Report No.T100716302 Page 14 of 15 Power Adapter Photo (Model : AMS47-0501000FU) Report No.T100716302 Page 15 of 15

Item Page 1.1 2.2 3.3~4 4.5 5.6~8 69~13 7.14~22 8.23~30 9.31 10.32 ............... ... .................. ګ঴ቹ .................. .................. ՂՀࡐሿٙቹ .................. Contents Description .................................... ๵௑। .................. ᑌ঴ቹ .................. .................. ᑷᜍ୚ጥޗᔆ௽ࢤ0VM ྒྷᇢ໴ܫ Cable๵௑/UL .................. CPN!Mjtu .................. .................................... ޝ୚֗ࡐࡳஆޗᔆ௽ࢤ/UL .................. .................. .................. .................. .................. ᑌ঴ᛀ᧭ಖᙕ। .................. Specification 1. Electrical Properties : 1.1 Frequency Range............ 1.2 Impedance .................. 1.3 VSWR ..................... ... 1.4 Return Loss.................. 1.5 Radiation ..................... 1.6 Gain(Peak)...................4.0dBi (excluding cable loss) 1.7 Cable Loss.................. ...0.5dB Max. 1.8 Polarization............... ...Linear 1.9 Admitted Power............ 1.10 Cable........................ ...1.13 Coaxial Cable 2. Physical Properties : 2.1 Antenna Base............... TPE 2.2 Antenna Base............... PC 2.3 Antenna Base............... PC 2.4 Operating Temp. ......... ...-10к ~ +60к 2.5 Storage Temp. ............ ...-10к ~ +70к 2.6 Color ........................ .Black RF Antenna Assembly Omni-directional 1W 2.4GHz ~ 2.5GHz 50 Nominal 1.92 : 1 Max. -10 dB Max. 1 2 3 4 5 RF Antenna Cable Assembly P/NO : C037-511078-A SPEC : 2.4~2.5GHz 20010/5/6 6 ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳ 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C037-511078-A SSR-211352E-PLANE.nsi 2.400000 GHz2.450000 GHz2.500000 GHz 7 ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳ ʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳʳ 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of C037-511078-A SSR-211352H-PLANE.nsi 2.400000 GHz2.450000 GHz2.500000 GHz 8 6,Shang Shing Rd.,Shang Jeau Industrial District,APPROVED CHECKEDENGINEER Chang An Town,Dongguan,Guangdong,China ELIQFZQY Tel:86-769-5411045APPROVED BY CUSTOMER: Fax:86-769-5540257DOCUMENT NO.RF REVISION NO. B/0 Product Specifications DATE: 07-10-2009 Construction & Material Guests Part No. ItemUnit Product ConductorSizemm NumberC Material Constructionpcs / mm Diametermm InsulationMaterial Nom.thicknessmm Overall Diametermm Color BraidingMaterial Constructionmm JacketMaterial Nom.thicknessmm Overall Diametermm Color MarkingNone Marking Cross - Section View : FEP Conductor Braiding Jacket NOTE : Please confirmed in two days , Or we will take it as confirmed. 4/0.05/16 FEP 0.12 Specification 7/0.084±0.005 0.22 FEP 0.26 RF 32 1 Silver-Gilt Copper 0.68±0.05 Transparent 1.13+0.1/-0.06 By Order Stranded Tinned Copper EVERNEW WIRE & CABLE CO.,LTD. FORM NO. EW-FOR-009C,C/1 9 ݼॴࢤ௽ રሽᚘ A.C ່՛࿪ᒴሽॴ -5.3 -20dB/m -15.5dB/m -3.0 -3.3 -3.9 -4.8 KV/min M-km dB/m -2.2 Ө ሽʳʳ௛ʳʳࢤʳʳ౨ 3.0 4.0 4.8Д6.0 50±2(TDR,250ps &500ps) 0.5/1 ؈୴ჾ֘(max) 2.4G~2.5G 4.8G~6.0G 1000(650V D.C) Attenuation(min) Frequency(GHZ) 1.0 2.0 2.4Д2.5 FORM NO. EW-FOR-009C,C/1 10 Appliance Wiring Material - Component Marking: Company name, voltage rating, temperature rating, conductor size, conductor material if other than copper, and use. Copyright ?2009 Underwriters Laboratories Inc. ® The appearance of a company's name or product in this database does not in itself assure that products so identified have been manufactured under UL's Follow-Up Service. Only those products bearing the UL Mark should be considered to be Listed and covered under UL's Follow-Up Service. Always look for the Mark on the product. UL permits the reproduction of the material contained in the Online Certification Directory subject to the following conditions: 1. The Guide Information, Designs and/or Listings (files) must be presented in their entirety and in a non-misleading manner, without any manipulation of the data (or drawings). 2. The statement "Reprinted from the Online Certifications Directory with permission from Underwriters Laboratories Inc." must appear adjacent to the extracted material. In addition, the reprinted material must include a copyright notice in the following format: "Copyright © 2009 Underwriters Laboratories Inc.®" AVLV2.E138922 Appliance Wiring Material - Component Page Bottom See General Information for Appliance Wiring Material - Component EVERNEW WIRE & CABLE CO LTDE138922 5TH FL 111 KEELUNG RD, SEC 2 TAIPEI, TAIWAN Table of Recognized Styles Single-conductor, thermoplastic insulation. 100711851208136515331792 10611195135415031777 Multiple-conductor, thermoplastic insulation. 246427252854296020276 2562283529192990 Last Updated on 2008-10-23 Questions?Notice of Disclaimer Page Top รʳ˄ʳ଄Δ٥ʳ˄ʳ଄˔˩˟˩˅ˁ ̆˄ˆˋˌ˅˅ʳˀʳ˔̃̃˿˼˴́˶˸ʳ˪˼̅˼́˺ʳˠ˴̇˸̅˼˴˿ʳˀʳ˖̂̀̃̂́˸́̇ ˅˃˃ˌ˂ˊ˂˄˃˻̇̇̃ˍ˂˂˷˴̇˴˵˴̆˸ˁ̈˿ˁ˶̂̀˂˶˺˼ˀ˵˼́˂˫ˬ˩˂̇˸̀̃˿˴̇˸˂˟ ̃˦ ̆˫˧˂˄ ̇˥˔ˠ ̆˂̆˻̂̊̃˴˺˸ˁ˻̇̀˿˒́˴̀˸ː˔˩˟ˁˁˁ 11 Click here to go to UL's iQ™ for Appliance Wiring Materials Database UNDERWRITERS LABORATORIES APPLIANCE WIRING MATERIAL Subj.758 Section 1 Page 1354 Issued:1964-02-19 Revised:2009-04-30 Style 1354 Coaxial Cable. Rating 60, 80 deg C, 30 Vac, Horizontal flame. Conductor 44 AWG min., material not specified. Insulation 2 mils minimum at any point, 125 mils maximum. The insulation may be: Extruded solid or cellular PE, FRPE, PP, PFA, FEP, ECTFE, PTFE, ETFE, or combination thereof with or without irradiation; or tape wrapped solid or cellular PTFE, PFA, or FEP. Applied as a spiral wrapped thread (5 mils minimum, 40 mils maximum) and enclosed in a tube of insulation. Assembly Insulated conductor with optional inner covering, optional inner shield, optional middle covering, required outer shield and required outer covering. Shield Optional. Outer Shield required. Covering Optional Inner Covering - Extruded PVC, PFA, Polyamide, Polyester, PVDF, FEP, PTFE, ECTFE, ETFE, PE, XLPE, XLFRPE or FRPE; lacquered braids; heat sealed PTFE, PFA or FEP tape; Polyester or Polyester- Polyethylene film. Thicknesses not sp…

Text truncated - open the document above for the full version.

FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 94 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE According to FCC 1.1310 : The criteria listed in the following table shall be used to evaluate theenvironment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b)LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (A) Limits for Occupational / Control Exposures 300-1,500 -- -- F/300 6 1,500-100,000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300-1,500 -- -- F/1500 6 1,500-100,000 -- -- 1 30 CALCULATIONS Given d G×P×30 =E & 3770 E =S 2 Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 d3770 G×P×30 =S Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields () () 22 d G×P ×0796.0= 100/d×3770 G×1000/P×30 =S Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm2 FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 95 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. LIMIT Power Density Limit, S=1.0mW/cm 2 TEST RESULTS Mode Antenna Gain (dBi) Minimum separation distance (cm) Output Power (dBm) Numeric antenna gain (mW) Power Density Limit (mW/cm 2 ) Power Density at 20cm (mW/cm 2 ) IEEE 802.11b 4.00 20.0 19.30 2.51 1.00 0.042532 IEEE 802.11g 4.00 20.0 19.38 2.51 1.00 0.043323 IEEE 802.11n HT204.00 20.0 19.31 2.51 1.00 0.042630 IEEE 802.11n HT404.00 20.0 18.74 2.51 1.00 0.037387 Remark: For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.

FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 1 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2009 TEST REPORT For Wireless N 150 Home Router Model : DIR-501 Trade Name : D-Link Issued for D-Link Corporation No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. Issued by Compliance Certification Services Inc. Tainan Laboratory No. 8, Jiu Cheng Ling, Jiaokeng Village, Sinhua Township, Tainan Hsien 712, Taiwan R.O.C. TEL: +886-6-580-2201 FAX: +886-6-580-2202 http://www.ccsrf.com E-Mail : [email protected] Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 2 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 08/06/2010 Initial Issue All Page 100 Winnie Chen FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 3 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 2.1 DESCRIPTION OF EUT & POWER ....................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 6 5. FACILITIES AND ACCREDITATION ........................................................................... 6 5.1 FACILITIES ............................................................................................................ 6 5.2 ACCREDITATIONS................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 7 6. SETUP OF EQUIPMENT UNDER TEST...................................................................... 8-9 7. FCC PART 15.247 REQUIREMENTS.......................................................................... 10 7.1 6dB BANDWIDTH .................................................................................................. 10-19 7.2 MAXIMUM PEAK OUTPUT POWER..................................................................... 20-30 7.3 AVERAGE POWER ............................................................................................... 31-33 7.4 POWER SPECTRAL DENSITY............................................................................. 34-44 7.5 CONDUCTED SPURIOUS EMISSION .................................................................. 45-53 7.6 RADIATED EMISSION........................................................................................... 54-86 7.7 CONDUCTED EMISSION ...................................................................................... 87-93 APPENDIX I MAXIMUM PERMISSIBLE EXPOSURE ..................................................... 94-95 APPENDIX II SETUP PHOTOS ....................................................................................... 96-100 FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 4 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST REPORT CERTIFICATION Applicant D-Link Corporation Address No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. Equipment Under Test Wireless N 150 Home Router Model DIR-501 Trade Name D-Link Tested Date July 16 ~ August 06, 2010 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2009 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Jeter Wu Eric Yang Section Manager Senior Engineer FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 5 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION 2.1 DESCRIPTION OF EUT & POWER Product Name Wireless N 150 Home Router Model Number DIR-501 Received Date July 16, 2010 IEEE 802.11b/g, 802.11n HT20 : 2412MHz～2462MHz Frequency Range IEEE 802.11n HT40 : 2422MHz～2452MHz IEEE 802.11b : 19.30dBm (0.0851W) IEEE 802.11g : 19.38dBm (0.0867W) IEEE 802.11n HT20 : 19.31dBm (0.0853W) Transmit Power IEEE 802.11n HT40 : 18.74dBm (0.0748W) Channel Spacing IEEE 802.11b/g, 802.11n HT20/HT40 : 5MHz IEEE 802.11b/g : 11 Channels Channel Number IEEE 802.11n HT40 : 7 Channels IEEE 802.11b : 11, 5.5, 2, 1 Mbps IEEE 802.11g : 54, 48, 36, 24, 18, 12, 9, 6 Mbps IEEE 802.11n HT20 : 72.2, 65, 58.5, 57.8, 52, 43.3, 39, 28.9, 26, 21.7, 19.5, 14.4, 13, 7.2, 6.5 Mbps Transmit Data Rate IEEE 802.11n HT40 : 150, 135, 121.5, 120, 108, 90, 81, 60, 54, 45, 40.5, 30, 27, 15, 13.5 Mbps IEEE 802.11b : DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g : OFDM (64QAM, 16QAM, QPSK, BPSK) Type of Modulation IEEE 802.11n HT20/…

Text truncated - open the document above for the full version.

FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 96 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX II SETUP PHOTOS RADIATED EMISSION SETUP Below 1 GHz FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 97 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 98 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Above 1 GHz FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 99 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP FCC IDKA2IR501A1 Report No.T100716302-RP1 Page 100 of 100 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. CONDUCTED EMISSION SETUP
