KA2IR518LA1Wireless AC600 Dual Band Wall-Plug Cloud Router

Version 1.0 | 2/12/2013 DIR-518L User Manual Wireless AC600 Dual Band Wall-Plug Cloud Router i D-Link DIR-518L User Manual D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies.Copyright © 2013 by D-Link Systems, Inc.All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Systems, Inc.This purpose of this product is to create a constant network connection for your devices. As such, it does not have a standby mode or use a power management mode. If you wish to power down this product, please simply unplug it from the power outlet. Revision Date Description 1.0 Nov 29, 2013 • Initial release Preface ii D-Link DIR-518L User Manual Table of Contents Preface ................................................................................. i Manual Revisions ........................................................................... iTrademarks ...................................................................................... iPackage Contents......................................................................... 1System Requirements ................................................................. 2Introduction ................................................................................... 3Features............................................................................................ 4Hardware Overview ..................................................................... 5 Front/Top ................................................................................. 5Bottom...................................................................................... 6 Operation Modes.......................................................................... 7 Router Mode........................................................................... 8 Wireless Installation Considerations...................................... 9Setting Up Your DIR-518L ........................................................10Initial Setup Wizard (Router Mode) ......................................12 Firmware ................................................................................15 Status ..............................................................................................16 Device Info ............................................................................16 Connecting a Wireless Client .......................................... 17 WPS Button ...................................................................................17Windows® 7...................................................................................18 WPA/WPA2 ............................................................................18WPS ..........................................................................................21 Windows Vista®............................................................................25 WPA/WPA2 ............................................................................26 Windows® XP................................................................................28 WPA/WPA2 ............................................................................29 Troubleshooting .............................................................. 31Wireless Basics ................................................................. 35 What is Wireless?.........................................................................36Tips...................................................................................................38 Networking Basics ........................................................... 39 Statically Assign an IP address ...............................................40 GPL Code Statement........................................................ 41Safety Statements ........................................................... 56 Table of Contents 1 D-Link DIR-518L User Manual Section 1 - Product Overview Package Contents DIR-518L Wireless AC600 Dual Band Wall-Plug Cloud RouterQuick Install GuideCompanion Card If any of the above items are missing from your package, please contact your reseller. 2 D-Link DIR-518L User Manual Section 1 - Product Overview Network Requirements • Cable/DSL modem, 3G/4G USB adapter, or a hotspot• IEEE 802.11ac/n/b/a wireless clients• 10/100 Ethernet Web-based Configuration Utility Requirements Computer with the following: • Windows®, Macintosh, or Linux-based operating system • An installed Ethernet adapter Browser Requirements: • Internet Explorer 8 or higher• Firefox 8.0 or higher• Safari 4.0 or higher• Google Chrome (16.0.9.12.75)Windows ® Users: Make sure you have the latest version of Java installed. Visit www.java.com to download the latest version. System Requirements 3 D-Link DIR-518L User Manual Section 1 - Product Overview Introduction TOTAL SECURITYThe most complete set of security features including Active Firewall and WPA/WPA2 to protect your network against outside intru ders. TOTAL COVERAGEProvides greater wireless signal rates even at farther distances for best-in-class Whole Home Coverage.ULTIMATE PERFORMANCEThe D-Link Wireless AC600 Dual Band Wall-Plug Cloud Router (DIR-518L) lets you create a secure wireless network to share photos , files, music, video, printers, and network storage throughout your home. Connect the DIR-518L router to a cable or DSL modem and share your high-speed Internet access with everyone on the network. In addition, this Router includes a Quality of Service (QoS) engi ne that keeps digital phone calls (VoIP) and online ga…

Text truncated - open the document above for the full version.

Report No.: 131111E02 Page 1 CONSTRUCTION PHOTOS OF EUT

FCC ID： KA2IR518LA1 IC : 4216A-IR518LA1 LABEL LOCATION Brad name : D-Link Model name : DIR-518LA1 2013/09/262013/09/262013/09/26 Cindy Chung 970000012451G White Font : Black DIR-518L My dlink number 14.9mm 51.6mm R1.3 R1.3 R1.3 R1.3 R 0.8 R1.2 R1.2 R 0.8 15 mmΈᆨሣĂ׻া ̊˸ᔞ

Report No.: 131111E02 Page 2 Report No.: 131111E02 Page 3 Report No.: 131111E02 Page 4 Report No.: 131111E02 Page 5

Report No.: SA131111E02 1 of 7 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA131111E02 MODEL NO.: DIR-518L FCC ID: KA2IR518LA1 RECEIVED: Nov. 11, 2013 TESTED: Nov. 13 to 14, 2013 ISSUED: Dec. 05, 2013 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C.. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA131111E02 2 of 7 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA131111E02 3 of 7 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA131111E02 Original release Dec. 05, 2013 Report No.: SA131111E02 4 of 7 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Wireless AC600 Dual Band Wall-Plug Cloud Router BRAND NAME: D-Link MODEL NO.: DIR-518L TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: D-Link Corporation TESTED DATE: Nov. 13 to 14, 2013 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: DIR-518L) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Dec. 05, 2013 ( Midoli Peng, Specialist ) APPROVED BY : , DATE: Dec. 05, 2013 ( May Chen, Manager ) Report No.: SA131111E02 5 of 7 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION This product could be applied with one USB Cellular Modem device, and the safe distance is 34 cm for collocated radio. The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA131111E02 6 of 7 Report Format Version 5.0.0 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER 15.247(2.4GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 160.325 -0.43 34 0.01629 1 15.247(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 874.984 1.8 34 0.09117 1 15.407(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 48.978 1.8 34 0.00510 1 For USB Cellular Modem: DEVICE MAX POWER (mW) MAX POWER (dBm) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) USB Cellular Modem 7000 38.45 34 0.48187 0.55 This product can operate with a plug-in USB Cellular Modem device which has maximum of 7W output power. Report No.: SA131111E02 7 of 7 Report Format Version 5.0.0 CONCLUSION: Both of the WLAN and plug-in USB Cellular Modem device can transmit simultaneously, the formula of calculated the MPE is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.09117 / 1 + 0.48187 / 0.55 = 0.967 which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit. --- END ---

Report No.: RF131111E02 1 of 100 Report Format Version 5.2.0 FCC TEST REPORT(15.247) REPORT NO.: RF131111E02 MODEL NO.: DIR-518L FCC ID: KA2IR518LA1 RECEIVED: Nov. 11, 2013 TESTED: Nov. 12 to 27, 2013 ISSUED: Dec. 05, 2013 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF131111E02 2 of 100 Report Format Version 5.2.0 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 8 3. GENERAL INFORMATION ..................................................................................... 9 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 9 3.2 DESCRIPTION OF TEST MODES ....................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 16 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 17 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 19 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 20 4. TEST TYPES AND RESULTS (FOR 2.4GHz, 2.400 ~ 2.4835GHz Band) ............. 21 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 21 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 21 4.1.2 TEST INSTRUMENTS .......................................................................................... 21 4.1.3 TEST PROCEDURES .......................................................................................... 22 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 22 4.1.5 TEST SETUP ....................................................................................................... 22 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 23 4.1.7 TEST RESULTS ................................................................................................... 24 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 26 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 26 4.2.2 TEST INSTRUMENTS .......................................................................................... 27 4.2.3 TEST PROCEDURES .......................................................................................... 28 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 28 4.2.5 TEST SETUP ....................................................................................................... 29 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 29 4.2.7 TEST RESULTS ................................................................................................... 30 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 43 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 43 4.3.2 TEST INSTRUMENTS .......................................................................................... 43 4.3.3 TEST PROCEDURE ............................................................................................. 43 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 43 4.3.5 TEST SETUP ....................................................................................................... 43 4.3.6 EUT OPERATIN…

Text truncated - open the document above for the full version.

Report No.: RF131111E02-1 1 of 60 Report Format Version 5.2.0 Cancels and replaces the report No.: RF131111E02 dated Sep. 02, 2013 FCC TEST REPORT (15.407) REPORT NO.: RF131111E02-1 MODEL NO.: DIR-518L FCC ID: KA2IR518LA1 RECEIVED: Nov. 11, 2013 TESTED: Nov. 13 to 27, 2013 ISSUED: Dec. 05, 2013 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF131111E02-1 2 of 60 Report Format Version 5.2.0 Cancels and replaces the report No.: RF131111E02 dated Sep. 02, 2013 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 19 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 20 4. TEST TYPES AND RESULTS .............................................................................. 21 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 21 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 21 4.1.2 TEST INSTRUMENTS .......................................................................................... 21 4.1.3 TEST PROCEDURES .......................................................................................... 22 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 22 4.1.5 TEST SETUP ....................................................................................................... 22 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 23 4.1.7 TEST RESULTS ................................................................................................... 24 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 26 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 26 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 26 4.2.3 TEST INSTRUMENTS .......................................................................................... 27 4.2.4 TEST PROCEDURES .......................................................................................... 28 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 28 4.2.6 TEST SETUP ....................................................................................................... 29 4.2.7 EUT OPERATING CONDITION ............................................................................ 29 4.2.8 TEST RESULTS ................................................................................................... 30 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 40 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 40 4.3.2 TEST INSTRUMENTS .......................................................................................... 40 4.3.3 TEST PROCEDURE ............................................................................................. 41 4.3.…

Text truncated - open the document above for the full version.

Report No.: 130725E04 1 of 3 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 130725E04 2 of 3 RADIATED EMISSION TEST(Below 1GHz) Report No.: 130725E04 3 of 3 RADIATED EMISSION TEST(Above 1GHz)
