FCC ID: KA2IR627A1 Report No.: RF990806E05 Operational Description This device is a Wireless N 300 Open Source Router, which operates in the 2.4GHz frequency spectrum with throughput of up to 300Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 12Vdc from a power adapter. The antenna is Dipole antenna with SMA Straight Plug Reverse connector. The other instruction, please have a look at the users manual.

Report No.: SA990806E05 Report Format Version 3.0.1 Reference: 1 RF EXPOSURE REPORT REPORT NO.: SA990806E05 MODEL NO.: DIR-627 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: D-Link Corporation ADDRESS: No. 289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB LOCATION: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan. Report No.: SA990806E05 Report Format Version 3.0.1 Reference: 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in our lab, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Report No.: SA990806E05 Report Format Version 3.0.1 Reference: 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device Report No.: SA990806E05 Report Format Version 3.0.1 Reference: 4 6. TEST RESULTS 6.1 Antenna Gain There are two antennas provided to this EUT, please refer to the following table: No. Manufacture Model No. Antenna Type Gain (dBi) Cable Loss (dB) Net Gain (dB) Cable length (mm) Antenna Connector Chain (0) Dipole 2 0.8 1.2 210 Chain (1) WANSHIH ELECTRONIC CO., LTD. C037-510982-A Dipole 2 NA NA NA SMA Straight Plug Reverse 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 218.8 0.057 1.0 6 2437 182.0 0.048 1.0 11 2462 158.5 0.042 1.0 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 343.6 0.108 1.0 6 2437 458.3 0.145 1.0 11 2462 228.2 0.072 1.0 802.11n (20MHz): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 335.8 0.106 1.0 6 2437 442.6 0.140 1.0 11 2462 212.0 0.067 1.0 802.11n (40MHz): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2422 206.6 0.065 1.0 4 2437 336.3 0.106 1.0 7 2452 191.5 0.060 1.0 --- END --

Report No.: RF990806E05 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990806E05 MODEL NO.: DIR-627 FCC ID: KA2IR627A1 RECEIVED: Aug. 06, 2010 TESTED: Aug. 27 to Sep. 02, 2010 ISSUED DATE : Oct. 29, 2010 APPLICANT: D-Link Corporation ADDRESS: No. 289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 79 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990806E05 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION....................................................................................................5 2. SUMMARY OF TEST RESULTS............................................................................6 2.1 MEASUREMENT UNCERTAINTY..........................................................................7 3. GENERAL INFORMATION.....................................................................................8 3.1 GENERAL DESCRIPTION OF EUT.......................................................................8 3.2 DESCRIPTION OF TEST MODES.......................................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL........................11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................14 3.4 DESCRIPTION OF SUPPORT UNITS.................................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................16 4. TEST TYPES AND RESULTS..............................................................................18 4.1 CONDUCTED EMISSION MEASUREMENT........................................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT.....................................18 4.1.2 TEST INSTRUMENTS.........................................................................................18 4.1.3 TEST PROCEDURES..........................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD.................................................................19 4.1.5 TEST SETUP.......................................................................................................20 4.1.6 EUT OPERATING CONDITIONS.........................................................................20 4.1.7 TEST RESULTS...................................................................................................21 4.2 RADIATED EMISSION MEASUREMENT.............................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT..........................................23 4.2.2 TEST INSTRUMENTS.........................................................................................24 4.2.3 TEST PROCEDURES..........................................................................................25 4.2.4 DEVIATION FROM TEST STANDARD.................................................................25 4.2.5 TEST SETUP.......................................................................................................26 4.2.6 EUT OPERATING CONDITIONS.........................................................................26 Report No.: RF990806E05 3 Report Format Version 3.0.1 4.2.7 TEST RESULTS...................................................................................................27 4.3 6dB BANDWIDTH MEASUREMENT....................................................................56 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.................................................56 4.3.2 TEST INSTRUMENTS.........................................................................................56 4.3.3 TEST PROCEDURE............................................................................................56 4.3.4 DEVIATION FROM TEST STANDARD.................................................................56 4.3.5 TEST SETUP.......................................................................................................56 4.3.6 EUT OPERATING CONDITIONS.........................................................................56 4.3.7 TEST RESULTS...................................................................................................57 4.4 MAXIMUM PEAK OUTPUT POWER....................................................................61 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.....................61 4.4.2 INSTRUMENTS...................................................................................................61 4.4.3 TEST PROCEDURES..........................................................................................61 4.4.4 DEVIATION FROM TEST STANDARD.................................................................61 4.4.5 TEST SETUP.......................................................................................................61 4.4.6 EUT OPERATING CONDITIONS.........................................................................61 4.4.7 TEST RESULTS...................................................................................................62 4.5 POWER SPECTRAL DENSITY MEASUREMENT...............................................64 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT.............................64 4.5.2 TEST INSTRUMENTS.........................................................................................64 4.5.3 TEST PROCEDURE.....................................................................…
